NKR-CB1GI210CIntegrate with certified module-End product

Subject: UMC-I210C User Manual REV: 2.3 PAGE 1 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document UMC-I210C User Manual The document contains proprietary information which is the property of Wistron NeWeb Corporation and is strictly confidential and shall not be disclosed to others in whole or in part, reproduced, copied, or used as basic for design, manufacturing or sale of apparatus without the written permission of Wistron NeWeb Corporation. Subject: UMC-I210C User Manual REV: 2.3 PAGE 2 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document Revision History Issue Date Version Description 2015/04/16 0.0 Initial Issued 2015/04/30 0.1 Add freq. mapping table and tx output power setting 2015/05/06 0.2 Modify Zigbee Test Center Frequency Setting (i.e. CH. No.) 2015/05/06 1.0 Change document file name to match FCC application form 2015/05/12 2.0 Add LTE antenna gain table 2015/05/26 2.1 Add FCC Warning Message and Note for LTE antenna gain 2015/05/27 2.2 Correct typo 2015/06/08 2.3 Add required description by FCC Part 15.21 Subject: UMC-I210C User Manual REV: 2.3 PAGE 3 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document Contents 1. Introduction ..................................................................................................... 4 2. Test Setup Configuration ............................................................................. 5 2.1 Power Supply and Debug Console Connection ........................ 5 2.2 Antenna Connection ............................................................................ 6 2.3 Hardware Component Introduction ............................................. 7 3. Zigbee Test ........................................................................................................ 8 3.1 Setup socat Server in CB Device ..................................................... 8 3.2 Setup socat Client in PC host ........................................................... 9 3.3 Zigbee Test Command (Refer to Ember Node Test) ............ 10 4. LTE B4/B13 Test .......................................................................................... 12 Subject: UMC-I210C User Manual REV: 2.3 PAGE 4 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 1. Introduction This User Manual of Victor CB (Communication Board) module is to describe how to use the following sections for lab test by specific qualified engineers or technicians. Furthermore, this module is NOT intended for commercial use but designed as part of Smart Meter product which mainly provides 4G LTE WAN access and/or Zigbee HAN access capabilities. For the procedure of CB installation into electric meter and the operation of CB in assembly factory, that information is described in assembly instruction document. FCC Interference Statement This module complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This module may not cause harmful interference and (2) this module must accept any interference received, including interference that may cause undesired operation. Radiation Exposure Statement This module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This module should be installed and operated with minimum distance of 20cm between radiator and human body. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the device. Subject: UMC-I210C User Manual REV: 2.3 PAGE 5 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 2. Test Setup Configuration 2.1 Power Supply and Debug Console Connection Power on Sequence: I. Connect 12-pin-to-Jig-baord cable II. Attach AC-DC Adaptor & USB Debug Port Cable III. Wait for 20 seconds when system ready (See Note 1) IV. Plug-in Console Port cable [Caution] Improper power on sequence might lead to system boot-up failure! AC-DC 5V Adaptor Interface Board DUT (CB) USB Debug Port Console Subject: UMC-I210C User Manual REV: 2.3 PAGE 6 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 2.2 Antenna Connection Connect to LTE primary antenna Connect to LTE diversity antenna Connect to Zigbee antenna Subject: UMC-I210C User Manual REV: 2.3 PAGE 7 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 2.3 Hardware Component Introduction AC-DC 5V Adaptor Interface Board Victor CB Subject: UMC-I210C User Manual REV: 2.3 PAGE 8 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 3. Zigbee Test 3.1 Setup socat Server in CB Device Telnet 192.168.0.1 into CB and run the commands below. [root@Grid –NetOS ~] # socat TCP-LISTEN:6666,fork /dev/ttyS2,raw,b115200,echo=0 Login: root Password: gridnet Subject: UMC-I210C User Manual REV: 2.3 PAGE 9 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 3.2 Setup socat Client in PC host Unpack socat.7z and install into PC and change directory to that. Execute the commands below. D:\Test Tool\socat> socat - tcp4:192.168.0.1:6666 Press “ Enter “ twice. Note, the socat binaries compiled for windows can be found in http://blog.gentilkiwi.com/downloads/socat-1.7.2.1.zip Subject: UMC-I210C User Manual REV: 2.3 PAGE 10 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 3.3 Zigbee Test Command (Refer to Ember Node Test) Freq. channel setting: setchannel 0x0B Channel Low : 0x0B -> CH11 Channel Middle : 0x12 -> CH18 Channel High : 0x19 -> CH25 Antenna selection: gpioout a 0 Power mode setting: settxpowmode 1 1 Power level setting: setTxPower -3 Single tone output: txTone Modulation signal output: txStream Subject: UMC-I210C User Manual REV: 2.3 PAGE 11 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document Subject: UMC-I210C User Manual REV: 2.3 PAGE 12 OF 12 Wistron Neweb Corporation Proprietary & Confidential Design Document 4. LTE B4/B13 Test …

Text truncated - open the document above for the full version.

UMCUMC--I210C Module Installation Guide I210C Module Installation Guide □ Normal □ Internal Use □ Confidential □ Restricted Confidential Rev. 0.1 2015/06/12 Parts’ Overview Cover From Meter Transparent Mask From Meter When the UMC-I210C is installed in GE I-210+c meter (i.e. host device), the FCC labelis placed on the outside of the GE I-210+cmeter transparent mask which must coverthe info, something like “contains the FCCID: NKR- CB1GI210C” 2 □ Normal □ Internal Use □ Confidential □ Restricted Confidential From Meter UMC-I210C Base Antenna unit From WNC From WNC >>>>> LTE AntennaunitandUMC-I210Care from WNC.>>>>> Transparent mask, cover and base are from GE I-210+c meter. Overview of Installation Steps Put antenna and PCB upside down.Connect cable to PCB Top side 3 □ Normal □ Internal Use □ Confidential □ Restricted Confidential Screw in with screw driver Connect cables to main board.Connect cover and base. Finish with transparent mask Installation LTE Antenna Unit into UMC-I210C 4 □ Normal □ Internal Use □ Confidential □ Restricted Confidential x y z Hooks are designedin holder that would help assembl y of antenna and PCB. Connecting LTE Antenna Cables into IMG03 clip 5 □ Normal □ Internal Use □ Confidential □ Restricted Confidential Connect antennacable to PCB.Cablesare fixed with IPEX onthe module. Installation UMC-I210C with Antenna Unit into Meter 6 □ Normal □ Internal Use □ Confidential □ Restricted Confidential Wistron Neweb Corporation Proprietary & Confidential

Wistron NeWeb Corporation 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308 Taiwan Modular Approval Request Letter FCC ID: NKR-CB1GI210C Data: May 21, 2015 Gentlemen: There’s that would like to have your authorization as a modular approval. The specific product as below, Integrate with certified module-End product, with its designed features and specified description, meets special requirements for full modular approval on FCC Public Notice DA 00-1407 Released: June 26, 2000 by cross-reference list below. Company :Wistron Neweb Corporation Model Name : Integrate with certified module-End product Model Number : UMC-I210C FCC ID : NKR-CB1GI210C Requirement of Public Notice DA00-1407 / part 15.212 Reference to UMC-I210C 1. The modular transmitter must have its own RF shielding. The module has its own RF shielding. Please see external photo.pdf 2. The modular transmitter must have buffered modulation/data inputs. The module has buffered data inputs; it is integrated in chip. Please see schematic.pdf 3. The modular transmitter must have its own power supply regulation. The module has its own power supply regulation internal. Please see schematic.pdf 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The module meets the FCC antenna requirements. It has a unique connector. Please see external photo.pdf 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. The module was tested on evaluation board, and it’s not inside of another device during testing. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The label position of module is clearly indicated. Please see the label.pdf 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The module is compliant with all applicable FCC rules. Detail instructions are given in the Users Manual. Please see Installation guide.pdf 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). The module complies with applicable RF exposure requirements. Please see RF safety evaluation. pdf Thank you. Sincerely, Wistron Neweb Corporation Edward Yeh / Compliance Engineer_ Tel: +886-3-6667799 ext.6683 Email: [email protected]

Wistron NeWeb Corporation 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308 Taiwan Authority to Act as Agent Date: _2015/ May /19 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Intertek Testing Services Taiwan Ltd is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____3 months_____ By: __________________________ _____Edward Yeh________ (Signature 1 ) (Print name) Title: ____Compliance Engineer__________ On behalf of: ___Wistron Neweb Corporation____ (Company Name) Telephone: ___+886-3-6667799___ext.6683_________ ____________________________________ Edward Yeh / Compliance Engineer Wistron NeWeb Corporation Fax: 886-3-666-7323 Tel: 886-3-666-7799 E-mail: [email protected]

Wistron NeWeb Corporation 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308 Taiwan Request for Confidentiality Date: __June/ 12/2015 _ Subject: Confidentiality Request for: ______NKR-CB1GI210C ______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* 3 User’s Manual ______Wistron Neweb Corporation ______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: ________________ Compliance Engineer ________Edward Yeh _______ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section V regarding EXCEPTIONAL CIRCUMSTANCES. As of the October 2014 version of this document, TCB’s can not authorize these requests. The applicant should petition the FCC by submitting an inquiry as directed. A copy of this inquiry and the FCC’s response must be provided with the application. 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

External photo of EUT

◎Label of NKR-CB1GI210C ◎Label Location (Left shielding of EUT)

Internal photo of EUT Internal photo of EUT Internal photo of EUT LTE Module Internal photo of EUT LTE Module LTE Module Internal photo of EUT M2 Slot for LTE LTE antenna Internal photo of EUT LTE antenna LTE antenna Internal photo of EUT LTE antenna LTE antenna connecter Internal photo of EUT LTE antenna connecter LTE Primary Antenna Internal photo of EUT LTE Diversity Antenna Zigbee module Internal photo of EUT Zigbee Antenna Zigbee Antenna Internal photo of EUT Zigbee Antenna Zigbee antenna connecter Internal photo of EUT Interface board Interface board Internal photo of EUT Interface board Interface board Internal photo of EUT Interface board Interface board Internal photo of EUT Interface board Interface board

FCC ID: NKR-CB1GI210C Report No.: 150400346TWN-001 Page 1 of 15 0597 Maximum Permissible Exposure (MPE) Evaluation Report Report No. : 150400346TWN-001 Model No. : UMC-I210C Issued Date : May 18, 2015 Applicant: Wistron Neweb Corporation 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan Test Method/ Standard: FCC 1.1310 Test By: Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). The test report was prepared by: Evelyn Lee/ Officer These measurements were taken by: Wayne Chen/ Engineer The test report was reviewed by: Name Jimmy Yang Title Senior Engineer FCC ID: NKR-CB1GI210C Report No.: 150400346TWN-001 Page 2 of 15 Table of Contents Summary of Tests ..............................................................................................................3 1. General information ......................................................................................................4 1.1 Identification of the EUT ........................................................................................4 1.2 Additional information about the EUT....................................................................5 1.3 Antenna description.................................................................................................5 2. Test specifications .........................................................................................................6 2.1 Introduction .............................................................................................................6 2.2 RF Exposure calculations........................................................................................7 2.3 Operation mode .......................................................................................................7 2.4 Test equipment ........................................................................................................8 2.5 Test Set-up ...............................................................................................................8 3. Test results .....................................................................................................................9 FCC ID: NKR-CB1GI210C Report No.: 150400346TWN-001 Page 3 of 15 Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997, IEEE C95.1-2005 Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1Complies FCC ID: NKR-CB1GI210C Report No.: 150400346TWN-001 Page 4 of 15 1. General information 1.1 Identification of the EUT Product: Integrate with certified module-End product Model No: UMC-I210C FCC ID: NKR-CB1GI210C Manufacturer: Wistron Neweb Corporation Address: 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan Operating Frequency: 2405 MHz ~ 2475 MHz for Zigbee mode LTE Band 4: 1710.7 MHz ~ 1754.3 MHz (TX) LTE Band 13: 779.5 MHz ~ 784.5 MHz (TX) LTE Band 4: 2110.7 MHz ~ 2154.3 MHz (RX) LTE Band 13: 748.5MHz ~ 753.5 MHz (RX) Channel Number: 15 channels, 2350 MHz +5k, k=11~25 for Zigbee mode Modulation: O-QPSK, 16QAM Rated Power: DC 5 V from adapter Power Cord: N/A Sample Received: Apr. 30, 2015 Sample condition: Workable Test Date(s): Apr. 27, 2015 ~ May 20, 2015 Note 1: This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Note 2: When determining the test conclusion, the Measurement Uncertainty of test has been considered. FCC ID: NKR-CB1GI210C Report No.: 150400346TWN-001 Page 5 of 15 1.2 Additional information about the EUT For Zigbee mode: Transmit path Modulation mode Chain 0 / Main Zigbee V Product SW/HW version : 2.11.0-Beta2/ DGB Radio SW/HW version : N/A Test SW Version : socat 1.7.2.1 (Zigbee) RF power setting in TEST SW: Frequency 2405MHz 2440MHz 2475MHz IEEE 802.15.4 Zigbee -3 -3 -3 For LTE mode: Product SW/HW version : 2.11.0-Beta2/ DGB Radio SW/HW version : N/A Test SW Version : N/A 1.3 Antenna description For Zigbee mode: The EUT uses a permanently connected antenna. Antenna Gain : 4.0 dBi max Antenna Type : PIFA antenna Connector Type : Fixed For LTE mode: The EUT uses a permanently connected antenna. Antenna Gain : 5.0 dBi max (Band 4), 2.5 dBi max (Band 13) Antenna Type : PCB antenna Connector Type : I-PEX FCC ID: NKR-CB1GI210C Report No.: 150400346TWN-001 Page 6 of 15 2. Test specifications 2.1 Introduction The EUT operates in the 2.4 GHz ISM band. Due to the EUT (include antenna) at its normal operation distance is at least 20 cm from the human body, the EUT was defined as a Mobile Device. The reason to do the MPE Evaluation is to avoid the RF hazard to human body. The maximum output power and gain of the antenna were used to calculate the limited Power density (S) at 20 cm distance away from the product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 and Safety Code 6 are followed. According to 1.1307 (b)(1), systems operating under th…

Text truncated - open the document above for the full version.

FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 1 of 40 EMC TEST REPORT Report No. : 150500010TWN-001 Model No. : UMC-I210C Issued Date : May 14, 2015 Applicant: Wistron Neweb Corporation 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan Test Method/ Standard: 47 CFR FCC Part 15.247 KDB 558074 D01 v03r02, ANSI C63.4: 2009 Registration No.: 93910 Test By: Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). The test report was prepared by: Evelyn Lee/ Officer These measurements were taken by: Wayne Chen/ Engineer The test report was reviewed by: Name Jimmy Yang Title Senior Engineer FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 2 of 40 Table of Contents 1. Summary of Test Data................................................................................................... 3 2. General Information...................................................................................................... 4 3. Minimum 6 dB Bandwidth ........................................................................................... 9 4. Maximum Peak Conducted Output Power ................................................................. 13 5. Power Spectral Density............................................................................................... 15 6. Emissions In Non-Restricted Frequency Bands ......................................................... 19 7. Emissions In Restricted Frequency Bands (Radiated emission measurements)......... 24 8. Emission On Band Edge ............................................................................................. 33 9. AC Power Line Conducted Emission ......................................................................... 35 Appendix A: Test equipment list..................................................................................... 39 Appendix B: Measurement Uncertainty ......................................................................... 40 FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 3 of 40 1. Summary of Test Data Test Requirement Applicable Rule (Section 15.247) Result Minimum 6 dB Bandwidth 15.247(a)(2) KDB 558074 D01 v03r02 Pass Maximum Peak Conducted Output Power 15.247(b)(3) KDB 558074 D01 v03r02 Pass Power Spectral Density 15.247(e) Pass Emissions In Non-Restricted Frequency Bands 15.247(d) Pass Emissions In Restricted Frequency Bands (Radiated emission measurements) 15.247(d), 15.205, 15.209 Pass Emission On The Band Edge 15.247(d), 15.205 Pass AC Power Line Conducted Emission 15.207 Pass Antenna Requirement 15.203 Pass FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 4 of 40 2. General Information 2.1 Identification of the EUT Product: Integrate with certified module-End product Model No: UMC-I210C FCC ID: NKR-CB1GI210C Manufacturer: Wistron Neweb Corporation Address: 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan Operating Frequency: 2405 MHz ~ 2475 MHz Channel Number: 15 channels 2350 MHz +5k, k=11~25 Modulation: O-QPSK Rated Power: DC 5 V from adapter Power Cord: N/A Sample Received: Apr. 30, 2015 Sample condition: Workable Test Date(s): Apr. 30, 2015 ~ May 11, 2015 Note 1: This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Note 2: When determining the test conclusion, the Measurement Uncertainty of test has been considered. FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 5 of 40 2.2 Description of EUT Transmit path Modulation mode Chain 0 / Main Zigbee V Product SW/HW version : 2.11.0-Beta2/ DGB Radio SW/HW version : N/A Test SW Version : socat 1.7.2.1 RF power setting in TEST SW: Frequency 2405MHz 2440MHz 2475MHz IEEE 802.15.4 Zigbee-3 -3 -3 2.3 Antenna description The EUT uses a permanently connected antenna. Antenna Gain : 4.0 dBi max Antenna Type : PIFA antenna Connector Type : Fixed 2.4 Operation mode EUT can transmit continuously with specific software “socat command”. Mode Channel Frequency (MHz) Signal on time(s) Total signal transmit time(s) Duty cycle Duty Cycle factor Low 2405 1.001 1.001 1.000 0.000 Middle 2440 1.001 1.001 1.000 0.000 Zigbee High 2475 1.001 1.001 1.000 0.000 FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 6 of 40 Duty Cycle @ Zigbee mode Ch Low Duty Cycle @ Zigbee mode Ch Middle FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 7 of 40 Duty Cycle @ Zigbee mode Ch High FCC ID: NKR-CB1GI210C Report No.: 150500010TWN-001 Page 8 of 40 2.5 Adapter information The EUT will be supplied with a power supply from below list: No. Brand Model no. Specification Adapter Ktec KSAS0120500200HU I/P: 100-240V~, 50-60Hz, 0.4A, O/P: 5.0Vdc, 2.0A The above EUT information is declared by Wistron Neweb Corporation and for more detailed features description, please refers to the manufacturer’s specifications or user’s manual 2.6 Applied test modes and channels Test item…

Text truncated - open the document above for the full version.

Conducted Emission Test set-up photo

Radiated Emission Test set-up photo Below 1G Radiated Emission Test set-up photo Above 1G
