NKR-DHUB8111abgn WLAN/Bluetooth Combo adapter

11abgn WLAN/Bluetooth Combo adapter DHUB-81 User Manual Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Pentium is trademark of Intel. All copyright reserved. 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2 Country Code selection feature to be disabled for products marketed to the US/CANADA Operations in the 5.15-5.25GHz band are restricted to indoor usage only. 3 Table of Contents 1. INTRODUCTION 4 2. DRIVER/UTILITY INSTALLATION / UNINSTALLATION 4 3. CONNECTING TO AN EXISTING NETWORK 4 4. MODIFYING A WIRELESS NETWORK 6 4.1 MODIFYING GENERAL SETTINGS .............................................................................................. 6 4.2 MODIFYING SECURITY SETTINGS .............................................................................................. 7 5. SPECIFICATIONS 9 4 1. Introduction Thank you for purchasing the 802.11 a/b/g/n / Bluetooth Combo adapter that provides the easiest way to wireless networking. This User Manual contains detailed instructions in the operation of this product. Please keep this manual for future reference. System Requirements - 128 MB of RAM or later (recommended) - 300 MHz processor or higher 2. Driver/Utility Installation The driver should have been installed before the STB is shipped from the manufacturer. You can start using its network function without installing driver or utility. This module is associated product for STB host. The following description provides a basic installation for wireless module. For more information about the Wireless Module, please refer to your STB manual. Installing Wi-Fi module : 1. Link cable with USB connector on wireless module 2. Link wireless module with USB connector to PC and install software in wireless module 3. Open the back lid of STB, lock wireless module on internal main board of STB 4. Power supply on internal main-board and allow STB to load fully. 3. Connecting to an Existing Network 1. Use the remote control that came with your STB to access the network configuration settings page. 2. Select the scanning wireless network function. The system starts to scan for available network. On this list, click Refresh to refresh the list at any time 3. Select the network you want to connect to. 4. If the chosen network has security enabled, you will have to setup corresponding security 5 parameter. Contact the network manager for the correct settings. Select the security type and fill in required parameters. The options include the following:  WPA/WPA2/CCKM  WPA/WPA2 Passphrase  802.1x  Pre-Shared Key (Static WEP)  None 6 4. Modifying a Wireless Network 4.1 Modifying General Settings 1. Use the remote control that came with your STB to access the network configuration settings page. 2. From the profile list, select one profile and choose the modify function. 3. Modify the settings below for your network. Profile Name Identifies the configuration wireless network profile. This name must be unique. Profile names are not case sensitive. Client Name Identifies the client machine. Use this profile for Access Point mode Configures station to operate in Access Point mode. Network Names (SSIDs) The IEEE 802.11 wireless network name. This field has a maximum limit of 32 characters. Configure up to three SSIDs (SSID1, SSID2, and SSID3). 7 4.2 Modifying Security Settings 1. Use the remote control that came with your STB to access the network configuration settings page. 2. Select a security option of this wireless network. This product provides security options below. Contact your wireless network administrator for choosing a correct option.  WPA/WPA2/CCKM  WPA/WPA2 Passphrase  802.1x  Pre-Shared Key (Static WEP)  None WPA/WPA2 Enables the use of Wi-Fi Protected Access (WPA). Choosing WPA/WPA2 opens the WPA/WPA2 EAP drop-down menu. The options include:  EAP-FAST  EAP-TLS  EAP-TTLS  EAP-SIM  PEAP (EAP-GTC)  PEAP (EAP-MSCHAP V2)  LEAP WPA/WPA2 Passp…

Text truncated - open the document above for the full version.

Date: 2014/2/24 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: NKR-DHUB81 Product name: 11abgn WLAN/Bluetooth Combo adapter To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model DHUB-81 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Hsiang, Tao Yuan Hsein 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Wistron NeWeb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Signature : _________________________________ Name and Job Title. : Alan Wang / Senior Engineer E-mail : [email protected] Tel. : +886-3-666-7799 ext:6907

Confidentiality Request Letter Date: 2014/2/24 Federal Communications Commission Authorization and Evaluation Division FCC ID：NKR-DHUB81 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Wistron NeWeb Corporation Applicant’s company address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Signature : Job Title and Dept. : Alan Wang / Senior Engineer E-mail : [email protected] Tel. : +886-3-666-7799 ext:6907

General Declaration Date: Februar 24, 2014 We, Wistron NeWeb Corp., declare that the device can work only with set top box, TV,...etc. and the product won't supply any driver for the PC or laptop and it is not recognizable by any PC or Notebook. Model name: DHUB-81 FCC ID: NKR-DHUB81 If you have any questions regarding the declaration, please don’t hesitate to contact us. Thank you! Sincerely yours, Applicant : Wistron NeWeb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Signature : Name and Job Title. : Alan Wang / Senior Engineer E-mail [email protected] Tel. +886-3-666-7799 ext:6907

Project No.: EP421807 Page No. : 1 of 6 Photographs of EUT Project No.: EP421807 Page No. : 2 of 6

Label Location

Project No.: EP421807 Page No. : 3 of 6 Project No.: EP421807 Page No. : 4 of 6 Project No.: EP421807 Page No. : 5 of 6 Project No.: EP421807 Page No. : 6 of 6

FCC RF Exposure Report FCC ID : NKR-DHUB81 Equipment : 11abgn WLAN/Bluetooth Combo adapter Model No. : DHUB-81, 700-0022-001 Brand Name : WNC Applicant : Wistron Neweb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan,R.O.C. Standard : 47 CFR FCC Part 2.1091 Received Date : Feb. 18, 2014 Tested Date : Feb. 20 ~ Mar. 03, 2014 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FA421807 Page : 1 of 6 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 4 1.1 Information .............................................................................................................................................. 4 2 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 5 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 5 2.2 MPE EVALUATION FORMULA ............................................................................................................. 5 2.3 MPE EVALUATION RESULTS .............................................................................................................. 5 3 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA421807 Page : 2 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA421807 Rev. 01 Initial issue Apr. 21, 2014 Report No.: FA421807 Page : 3 of 6 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Product Details The following models are provided to this EUT. Brand Name Model Name Product Name Description WNC DHUB-81 11abgn WLAN/Bluetooth Combo adapter marketing purpose 700-0022-001  All models are electrically identical, different model names are for marketing purpose.  The above models, model DHUB-81 was selected as a representative one for the final test and only its data was recorded in this report. Report No.: FA421807 Page : 4 of 6 Report Version: Rev. 01 2 MPE EVALUATION OF MOBILE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. 2.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 2.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 2.3 MPE EVALUATION RESULTS Mode Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) WiFi 2412~2462 20.87 -2.75 20 0.013 1 5180~5240 16.59 -2.93 20 0.005 1 5260~5320 20.50 -2.65 20 0.012 1 5500~5700 21.62 -2.71 20 0.015 1 5745~5825 22.74 -3.12 20 0.018 1 BT 2402~2480 3.65 -2.48 20 0.0003 1 Report No.: FA421807 Page : 5 of 6 Report Version: Rev. 01 3 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp, it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan Hsiang. Location map can be found on our website http://www.icertifi.com.tw . Linkou Kwei Shan Te l : 886-2-2601-1640 Te l : 886-3-271-8666 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══ Report No.: FA421807 Page : 6 of 6 Report Version: Rev. 01

FCC Test Report FCC ID : NKR-DHUB81 Equipment : 11abgn WLAN/Bluetooth Combo adapter Model No. : DHUB-81, 700-0022-001 Brand Name : WNC Applicant : Wistron Neweb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan,R.O.C. Standard : 47 CFR FCC Part 15.247 Received Date : Feb. 18, 2014 Tested Date : Feb. 20 ~ Feb. 28, 2014 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR421807AD Page : 1 of 46 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 7 1.3 Test Setup Chart .................................................................................................................................... 7 1.4 The Equipment List ................................................................................................................................ 8 1.5 Test Standards ....................................................................................................................................... 9 1.6 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION ..................................................................................................................... 10 2.1 Testing Condition ................................................................................................................................. 10 2.2 The Worst Test Modes and Channel Details ....................................................................................... 10 3 TRANSMITTER TEST RESULTS ........................................................................................................ 11 3.1 Conducted Emissions ........................................................................................................................... 11 3.2 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 14 3.3 Unwanted Emissions into Non-Restricted Frequency Bands .............................................................. 30 3.4 Conducted Output Power ..................................................................................................................... 35 3.5 Number of Hopping Frequency ............................................................................................................ 37 3.6 20dB and Occupied Bandwidth ............................................................................................................ 39 3.7 Channel Separation .............................................................................................................................. 41 3.8 Number of Dwell Time .......................................................................................................................... 43 4 TEST LABORATORY INFORMATION ............................................................................................... 46 Report No.: FR421807AD Page : 2 of 46 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR421807AD Rev. 01 Initial issue Apr. 21, 2014 Report No.: FR421807AD Page : 3 of 46 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.156MHz 47.77 (Margin -7.92dB) - AV Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 898.22MHz 39.85 (Margin - 6.15dB) - PK Pass 15.247(d) Band Edge Meet the requirement of limit Pass 15.247(b)(1) Conducted Output Power Power [dBm]: BR: 3.95 EDR: 5.61 Pass 15.247(a)(1)(iii) Number of Hopping Channels Meet the requirement of limit Pass 15.247(a)(1) Hopping Channel Separation Meet the requirement of limit Pass 15.247(a)(1)(iii) Dwell Time Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR421807AD Page : 4 of 46 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Product Details The following models are provided to this EUT. Brand Name Model Name Product Name Description WNC DHUB-81 11abgn WLAN/Bluetooth Combo adapter marketing purpose 700-0022-001  All models are electrically identical, different model names are for marketing purpose.  The above models, model DHUB-81 was selected as a representative one for the final test and only its data was recorded in this report. 1.1.2 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) Bluetooth Mode Ch. Frequency (MHz) Channel Number Data Rate 2400-2483.5 BR V4.0 2402-2480 0-78 [79] 1 Mbps 2400-2483.5 EDR V4.0 2402-2480 0-78 [79] 2 Mbps 2400-2483.5 EDR V4.0 2402-2480 0-78 [79] 3 Mbps Note 1: RF output power specifies that Maximum Peak Conducted Output Power. Note 2: Bluetooth BR uses a GFSK. Note 3: Bluetooth EDR uses a combination of π/4-DQPSK and 8DPSK. 1.1.3 Antenna Details Ant. No. Type Gain (dBi) Connector Remark 1 Printed -2.48 --- --- 1.1.4 Power Supply Type of Equipment under Test (EUT) Power Supply Type 5Vdc from host 1.1.5 Accessories N/A Report No.: FR421807AD Page : 5 of 46 Report Version: Rev. 01 1.1.6 Channel List Frequency band (MHz) 2400~2483.5 Channel Fre…

Text truncated - open the document above for the full version.

Photographs of the Test Configuration Conducted Emission Test Report No.: FR421807 Page: : 1 of 4 Report Version: Rev. 01 Report No.: FR421807 Page: : 2 of 4 Report Version: Rev. 01 Radiated Emission Test Report No.: FR421807 Page: : 3 of 4 Report Version: Rev. 01 Report No.: FR421807 Page: : 4 of 4 Report Version: Rev. 01
