NKR-DNUA93C2WLAN 802.11 b/g/n USB Adapter

WLAN 802.11 b/g/n USB Adapter DNUA-93C2 User Manual May 2012 1 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Pentium is trademark of Intel. All copyright reserved. 2 FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. 3 This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 4 IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. USERS MANUAL OF THE END PRODUCT: In the users manual of the end product, the end user has to be informed to keep at least 20cm separation with the antenna while this end product is installed and operated. The end user has to be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available in the users manual: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX FCC ID: DNUA-93C2 ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. 5 IC Statement: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 6 IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the IC compliance requiremen…

Text truncated - open the document above for the full version.

Wistron NeWeb Corporation Modular Approval Request Letter Type of equipment: WIFI Module Model name: DNUA-93C2 FCC ID: NKR-DNUA93C2 According to DA 00-1047 the requirements for modular transmitter approval are met by the following compliance statements: 1. The modular transmitter must have its own RF Shielding. Confirmed, the shielding of radio portion can be demonstrated in exhibition “external photos”. 2. The modular transmitter must have buffered modulation/data inputs. Confirmed, buffered data inputs has been integrated in chip AR9271 （location No.: U2） 3. The modular transmitter must have its own power supply regulation. Confirmed, the transmitter have power regulation provided on-board by RT8010 ( location No.:VR1), see exhibition “Schematic diagram (Confidential)” 4. The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna. Confirmed, the antenna connections to the module will be internal to the product utilizing the module and will therefore be non-user accessible. See the exhibition “FCC test report” and “external photos”. 5. The modular transmitter must be tested in a stand-along configuration. Confirmed, see the FCC test report. 6. The modular transmitter must be labeled with its own FCC ID number. Confirmed, the FCC ID will be NKR-DNUA93C2, see exhibition “label” and “label location”. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacture must provide adequate instructions along with module to explain any such requirement. A copy of these instructions must be included in the application for equipment authorization. Confirmed, the required FCC rule has been fulfilled and all the instructions for maintaining compliance have been clearly stated in User manual. 8. The modular transmitter must comply with any application RF exposure requirements. Confirmed, see exhibition “Maximum Permissible Exposure (MPE) Estimation”. Sincerely, Name / Title Troy Chien Wistron NeWeb Corporation Tel: 886-3-666-7799 Fax: 886-3-666-7323 Email: [email protected]

Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Tel: 886-3-666-7799 ; Fax: 886-3-666-7323 Date (26/06/2012) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Tel: 886-3-666-7799 ; Fax: 886-3-666-7323 hereby authorize Shenzhen Institute of Telecommunications No.12 Building, Shangsha Innovation and Technology Park Futian District, Shenzhen 518048 P. R. China Du Zhaoxuan Phone: +86-755-33322000-8140 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to denial of U.S Federal benefits, which include FCC benefits, pursuant to section 5301 of Anti-Drug Abuse Act of 1988, U.S.C 862 because of conviction for possession or distribution of controlled substance. This authorization is application to product: Type of equipment: WIFI module Model name: DNUA-93C2 FCC ID: NKR-DNUA93C2 This authorization expires one year from the current date. Sincerely, Telephone Number: 886-3-666-7799 Fax: 886-3-666-7323

Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Tel: 886-3-666-7799 ; Fax: 886-3-666-7323 Date (25/06/2012) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: NKR-DNUA93C2 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Wistron NeWeb Corporation hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Parts List Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Troy Chien Telephone Number: 886-3-666-7799 Email: [email protected]

EXTERNAL PHOTOS FCC ID:NKR-DNUA93C2

REVAPPROVEDDATE REV SIZE DWG TITLE DWG NO. SCALESHEET REV A4A4 1 1/1 1 OF 1 SANDY CHEN 07/09/12SANDY CHEN 1 1 RELEASE TO FILE DESCRIPTION REVISIONS PART NUMBER BLOCK PART NUMBER LABEL, WHITE, 13X10, DNUR-93C2LABEL, WHITE, 13X10, DNUR-93C2 DNUR-93C2 NOTES: 1. MATERIAL: WHITE MATTE PET, t=0.05, ACRYLIC ADHESIVE 2. COLOR: a. BACKGROUND= PAPER COLOR 3. TEMPERATURE RESISTANT= 80 0 C. 4. ADHESIVE THICKNESS=0.024±0.003mm. 5. RELLED WNC PROPRIETARY 07/09/12 07/09/12 07/09/12 WING CHEN WING CHEN 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Tel: 886-3-6667799 Fax: 886-3-5788726 4L-DNUA9C3-001 4L-DNUA9C3-001 13.0 9.0±0.5 R 0.5, 4PLS 10.0 3.0±0.5 ON LINE PRINTING DNUA-93C2 FCC ID: NKR-DNUA93C2 MAC: XXXXXXXXXXXXX 2D CODE 2.7x2.7 150Mbps RoHS DNUA-93C2 FCC ID: NKR-DNUA93C2 MAC: XXXXXXXXXXXXX 2D CODE 2.7x2.7 150Mbps RoHS

Label location

Internal photos FCC ID: NKR-DNUA93C2

No.2012EEB00215-EMC Page 1 of 13 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2012EEB00215-EMC for Wistron Neweb Corporation. WIFI module Model Name: DNUA-93C2 Marketing Name: DNUA-93C2 FCC ID: NKR-DNUA93C2 with Hardware Version: V1.0 Software Version: / Issued Date: 2012-07-01 Test Laboratory: FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633-2678 , Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.2012EEB00215-EMC Page 2 of 13 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. EUT SET-UPS ................................................................................................................................... 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 10 No.2012EEB00215-EMC Page 4 of 13 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: Wistron Neweb Corporation Address /Post: 20 Park Avenue II Road, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. City: Hsinchu Postal Code: / Country: Taiwan Telephone: 886-3-666-7799 Fax: 886-3-666-7323 2.2. Manufacturer Information Company Name: Wistron Neweb Corporation Address /Post: 20 Park Avenue II Road, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. City: Hsinchu Postal Code: / Country: Taiwan Telephone: 886-3-666-7799 Fax: 886-3-666-7323 No.2012EEB00215-EMC Page 5 of 13 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WIFI module Model Name DNUA-93C2 Marketing Name DNUA-93C2 FCC ID NKR-DNUA93C2 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 DNUA-93C2 V1.0 / *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test WLAN Antenna AE ID* Name Supplier GAIN（dBi） AE1 AG-011333-0296-A0-0000 SHENZHEN B&T TECHNOLOGY Co,.Ltd 2.00 AE2 AG-041333-0428-A0-0000 SHENZHEN B&T TECHNOLOGY Co,.Ltd 1.60 AE3 EZY-W8-2 Wistron NeWeb Corporation 0.78 AE4 EZY-W11-2 Wistron NeWeb Corporation 1.85 AE5 EZY-W11-1 Wistron NeWeb Corporation 5.15 AE6 EZY-W8-1 Wistron NeWeb Corporation 4.53 AE7 EHD-S6 Wistron NeWeb Corporation <3 AE8 81EAAB15.G02 Wistron NeWeb Corporation 4.35 AE9 81EAAB15.G02 Wistron NeWeb Corporation 3.91 *AE ID: is used to identify the test sample in the lab internally. 3.4. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1+ AE5 + PC Charging mode No.2012EEB00215-EMC Page 6 of 13 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices 10-1-2011 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 ICES-003 Spectrum Management and Telecommunications Policy Interference-Causing Equipment Standard Digital Apparatus Issue 4 No.2012EEB00215-EMC Page 7 of 13 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anechoic chamber (11.20 meters×6.10meters×5.60meters) did not exceed following limits along the EMC testing: Temperature Min. = 15 °C, Max. = 30 °C Relative humidity …

Text truncated - open the document above for the full version.

Test setup photos FCC ID:NKR-DNUA93C2 1、Part 15B Radiated emission below 1 GHz 2、Part 15B Radiated emission above 1 GHz 3、Part 15B conducted emission
