20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. Date: 2013-08-23 FCC ID: NKR-DTVDCCKII Declaration for DFS client devices We, WISTRON NEWEB CORP. declare that the device does not support any non-US channels in all the operational mode(s), like Ad-Hoc...etc, for the following product. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- Troy Chien Associate Technical Director Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. Declaration for DFS client devices Date: 2013-08-23 FCC ID: NKR-DTVDCCKII Dear Examiner: Per KDB# 848637, We, WISTRON NEWEB CORP. declare that following description truly represent our product in consideration. Please do not hesitate to contact us, if further info is required. Thanks. a). A channel/frequency plan for the device showing the channels that have active scanning or passive scanning. Active scanning is where the device can transmit a probe (beacon) and passive scanning is where the device can listen only without probes. Below is the channel / frequency plan for the device b). For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) or in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies), or modular devices that configure the modes of operations through software; the applicant must provide in the application software and operations description that discuss how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by an end user or an installer. Also, include an attestation that the device complies with the requirements for software configuration control as discussed in KDB #594280. On DFS channels, the WLAN driver on the device operates under the control of an AP at all times, except when in ad-hoc mode, on US non-DFS channels. As described in the answer to question a, the device passively scans DFS frequencies until a master device is detected. The control of this functionality is not accessible to anyone under any conditions. Furthermore, the firmware is locked by proprietary password and cannot be changed or modified by end user. CH 52 56 60 64 100 104 108 112 116 120 Frequency (MHz) 5260 5280 5300 5320 5500 5520 5540 5560 5580 5600 Scan Type Passive Passive Passive Passive Passive Passive Passive Passive Passive Passive CH 124 128 132 136 140 Frequency (MHz) 5620 5640 5660 5680 5700 Scan Type Passive Passive Passive Passive Passive If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- Troy Chien Associate Technical Director Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Date: 2013/8/23 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: NKR-DTVDCCKII Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematic Diagram Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ---------------------------------------------- Troy Chien Associate Technical Director Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. 2 Power of Attorney Date:2013/8/23 FCC ID: NKR-DTVDCCKII To whom it may concern: We, the undersigned WISTRON NEWEB CORP. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C+15E approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. This authorization shall expire six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, __________________________________ Troy Chien Associate Technical Director Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

Report No.: 130709E03 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 130709E03 Page 2 Report No.: 130709E03 Page 3 Report No.: 130709E03 Page 4 Report No.: 130709E03 Page 5

4L-J715C07-001 4L-J715C07-001 LABEL,DIRECTV,J715C 08/19/13 08/19/13 08/19/13 08/19/13 J715C SANDY CHEN SANDY CHEN KEVIN HUANG KEVIN HUANG NOTES: 1. MATERIAL: 消銀龍(UL APPROVED), t=0.75, 上霧PET,t=0.025,網紋背膠 2. COLOR: a. 印刷顏色如圖面標示 b.其餘未標示部份印刷黑色 3. TEMPERATURE RESISTANT= 80 0 C. 4. ADHESIVE MATERIAL: ACRYLIC 5. ADHESIVE THICKNESS= 上膠厚度0.033 +_ 0.003, 網紋深度 0.017~0.027 + _ 0.005 6.捲狀出貨 7.被貼物材質:ABS E E E Made in China DIRECTV Cinema Connection Kit DCAW1R1-01 54.5 44.5 R 2 , 3PLS C2 Pantone 367C R LISTED 24LR I.T.E FCC Statement : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: NKR-DTVDCCKII 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Tel: 886-3-6667799 Fax: 886-3-5788726 2.7 2.5 MAC:XXXXXXXXXXXX S/N: XED5AYYWWXXXXX MAC:XXXXXXXXXXXX S/N: XED5AYYWWXXXXX Arial 7.5 Pt FCC IDΚNKR-DTVDWVB LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. FCC ID: NKR-DTVDCCKII

Report No.: 130709E03 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 130709E03 Page 2 Report No.: 130709E03 Page 3 Report No.: 130709E03 Page 4 Report No.: 130709E03 Page 5 Report No.: 130709E03 Page 6 Report No.: 130709E03 Page 7 Report No.: 130709E03 Page 8 Report No.: 130709E03 Page 9 Report No.: 130709E03 Page 10 Report No.: 130709E03 Page 11

Report No.: SA130709E03 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA130709E03 MODEL NO.: DCAW1R1-01 FCC ID: NKR-DTVDCCKII RECEIVED: July 09, 2013 TESTED: July 30, 2013 ISSUED: Nov. 04, 2013 APPLICANT: Wistron NeWeb Corp. ADDRESS: 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA130709E03 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA130709E03 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130709E03 Original release Nov. 04, 2013 Report No.: SA130709E03 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: DIRECTV Cinema Connection Kit BRAND NAME: DIRECTV MODEL NO.: DCAW1R1-01 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Wistron NeWeb Corp. TESTED DATE: July 30, 2013 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: DCAW1R1-01) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Nov. 04, 2013 ( Phoenix Huang, Specialist ) APPROVED BY : , DATE: Nov. 04, 2013 ( May Chen, Manager ) Report No.: SA130709E03 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA130709E03 6 of 6 Report Format Version 5.0.0 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 954.694 3.1 20 0.38779 1 For 15.247(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 558.985 2.8 20 0.21190 1 For 15.407(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180-5240 5260-5320 5500-5580 & 5660-5700 177.630 2.8 20 0.06734 1 --- END --- CONCLUSION: Both of the 2.4GHz and 5GHz WLAN can transmit simultaneously, the formula of calculated the MPE is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.59359 / 1 + 0.17091 / 1 = 0.765, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Report No.: RF130709E03-2 1 of 27 Report Format Version 5.2.0 DFS TEST REPORT REPORT NO.: RF130709E03-2 MODEL NO.: DCAW1R1-01 FCC ID: NKR-DTVDCCKII RECEIVED: July 09, 2013 TESTED: July 30, 2013 ISSUED: Nov. 04, 2013 APPLICANT: Wistron NeWeb Corp. ADDRESS: 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF130709E03-2 2 of 27 Report Format Version 5.2.0 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 3 1. CERTIFICATION .................................................................................................... 4 2. EUT INFORMATION ............................................................................................... 5 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT ..................................... 5 2.2 EUT SOFTWARE AND FIRMWARE VERSION ...................................................... 5 2.3 DESCRIPTION OF AVAILABLE ANTENNAS TO THE EUT .................................... 5 2.4 EUT MAXIMUM CONDUCTED POWER ................................................................ 6 2.5 EUT MAXIMUM EIRP POWER ............................................................................... 7 2.6 TRANSMIT POWER CONTROL (TPC) .................................................................. 8 2.7 STATEMENT OF MAUNFACTURER ...................................................................... 8 3. U-NII DFS RULE REQUIREMENTS ....................................................................... 9 3.1 WORKING MODES AND REQUIRED TEST ITEMS .............................................. 9 3.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS ........................................... 10 4. TEST & SUPPORT EQUIPMENT LIST ................................................................. 13 4.1 TEST INSTRUMENTS .......................................................................................... 13 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................. 13 5. TEST PROCEDURE ............................................................................................. 14 5.1 BVADT DFS MEASUREMENT SYSTEM: ............................................................. 14 5.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL: ............................... 15 5.3 DEVIATION FROM TEST STANDARD ................................................................. 16 5.4 CONDUCTED TEST SETUP CONFIGURATION .................................................. 16 5.4.1 CLIENT WITHOUT RADAR DETECTION MODE ................................................. 16 6. TEST RESULTS ................................................................................................... 17 6.1 SUMMARY OF TEST RESULTS .......................................................................... 17 6.2 DETAILED TEST RESULTS ................................................................................. 18 6.2.1 TEST MODE: DEVICE OPERATING IN CLIENT WITHOUT RADAR DETECTION MODE................................................................................................................... 18 6.2.1.1 DFS DETECTION THRESHOLD .......................................................................... 18 6.2.1.2 CHANNEL CLOSING TRANSMISSION AND CHANNEL MOVE TIME ................. 19 6.2.1.3 NON- OCCUPANCY PERIOD .............................................................................. 20 6.2.1.4 NON-ASSOCIATED TEST .................................................................................... 23 6.2.1.5 NON- CO-CHANNEL TEST .................................................................................. 23 7. INFORMATION ON THE TESTING LABORATORIES .......................................... 24 8. APPENDIX-A ........................................................................................................ 25 9. APPENDIX B - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ................................................................................... 27 Report No.: RF130709E03-2 3 of 27 Report Format Version 5.2.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF130709E03-2 Original release Nov. 04, 2013 Report No.: RF130709E03-2 4 of 27 Report Format Version 5.2.0 1. CERTIFICATION PRODUCT: DIRECTV Cinema Connection Kit BRAND NAME : D…
