NKR-DTVDWVBWireless Video Bridge

Tabletop Installation The DIRECTV Wireless Video Bridge unit can be placed directly on a flat surface. Follow the IMPORTANT SAFETY INSTRUCTIONS to find a proper place for the safe use of this product. Wall Mount Installation Two M4 x 20mm pan head screws (Thread type: Tapping) and expansion anchors are included for wall mounting. You can call DIRECTV for detailed information. * Suitable masonry plugs may be required if attaching to a stone/brick wall.  To mount the unit on a wall, follow these instructions: 1. Ensure that the mounting location is free from hazards (electric cables/wires/pipes/etc.). 2. Drill two pilot holes 26mm (about 1.0 inch) deep using a 3.6mm (about 0.14 inch) drill bit.  The two pilot holes must be level and spaced 55mm (about 2.17 inches) apart horizontally.  When mounting on a stud partition wall, at least one of the mounting screws must be attached to a wooden stud. 3. If using the wall mount method:  Drive the screws through the mounting plate to be fastened and into the wall. (See step 1 below).  Align the two slots at the bottom of the unit with the two pins on the mounting plate. (See step 2 below).  Slide them until they lock in place. (See step 3 below). Wall Mount Installation DIRECTV Wireless Video Bridge Installation Guide IMPORTANT SAFETY INSTRUCTIONS Before you install or use the apparatus, you must read and understand these Important Safety Instructions. At all times when using the apparatus you must follow these Important Safety Instructions to reduce the risk of fire, electrical shock and injury to persons. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/ accessories specified by the manufacturer. 12. Unplug this apparatus during lightning storms or when unused for long periods of time. 13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. CONNECTING TO THE POWER SUPPLY You must not plug this Wireless Video Bridge into the power supply until you have connected this bridge to the other equipment in your system. This bridge itself is designed for use only with the supplied power supply unit or a compatible power inserter. On the power supply unit there is a label that specifies the correct AC power supply input for it. Do not connect the power supply unit to any supply other than this. Always connect the power cord from the power supply unit to this bridge before you insert the power supply unit into the wall socket-outlet. To disconnect power from this bridge, always remove the power supply unit from the wall socket-outlet (i.e. not by removing the power cord from this bridge). Therefore you must install this bridge near to the wall socket-outlet, which should be easily accessible. If you are in any doubt about the power supply lead, its plug or its connection, consult a competent electrician. INSTALLATION The installation of this Wireless Video Bridge should be carried out by a qualified installer and should conform to local codes. Note to the installer This reminder is provided to call the attention of the satellite system installer to Section 810, or the cable-TV installer to Section 820 of the National Electrical Code (USA), which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as is practical. SAFETY INFORMATION This Wireless Video Bridge has been manufactured and tested with your safety in mind. However, improper use can result in potential electric shock or fire hazards. The enclosed RF/DC adapter is for use with the DCA2SR0-01 model only. To avoid defeating the safeguards that have been built into this bridge, please observe the precautions discussed in this document. Warnings on this Wireless Video Bridge The lightning flash with arrowhead symbol, within a triangle, is intended to alert you to the presence of uninsulated “dangerous” voltages within this bridge’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within a triangle is intended to alert you to the presence of important instructions in the literature accompanying this bridge. Other warnings To reduce the risk of electric shock, do not remove the cover of this bridge. There are no user-serviceable parts inside it. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Do not perform any servicing unless you are qualified to do so. Refer all servicing to qualified service personnel. Servicing the bridge yourself will invalidate the warranty. Power sources You must operate this bridge only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your d…

Text truncated - open the document above for the full version.

Wistron NeWeb Corp. 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. January 29, 2013 We, WISTRON NEWEB CORP. declare that the device does not support any non-US channels in all the operational mode(s), like Ad-Hoc...etc, for the following product. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad- hoc peer-to-peer modes. FCC ID: NKR-DTVDWVB If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ------------------------------------------------------- Troy Chien / Associate Technical Director WISTRON NEWEB CORP. Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

Wistron NeWeb Corp. 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. Date: January 29, 2013 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: NKR-DTVDWVB Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematic Diagram Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------ Troy Chien / Associate Technical Director WISTRON NEWEB CORP. Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

Wistron NeWeb Corp. 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. Federal Communications Commission Authorization and Evaluation Division Date: January 29, 2013 Confidentiality Request FCC ID: NKR-DTVDWVB Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until 2013/06/30 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------------------- Troy Chien /Associate Technical Director WISTRON NEWEB CORP. Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

Wistron NeWeb Corp. 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. Power of Attorney Date: January 29, 2013 FCC ID: NKR-DTVDWVB To whom it may concern: We, the undersigned WISTRON NEWEB CORP. hereby authorize Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C+15E approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Products Services (H.K) Ltd., Taoyuan Branch. on our behalf shall have the same effects as acts of our own. This authorization shall expire six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------ Troy Chien / Associate Technical Director WISTRON NEWEB CORP. Tel: +886-3-6667799 Ext 6361 Fax: + 886-3-6667323 E-mail: [email protected]

Report No.: 121227E01B Page 1 Reference No.:130122E06 CONSTRUCTION PHOTOS OF EUT Report No.: 121227E01B Page 2 Reference No.:130122E06 Report No.: 121227E01B Page 11 Reference No.:130122E06 Report No.: 121227E01B Page 12 Reference No.:130122E06

Report No.: 121227E01B Page 3 Reference No.:130122E06 Report No.: 121227E01B Page 4 Reference No.:130122E06 Report No.: 121227E01B Page 5 Reference No.:130122E06 Report No.: 121227E01B Page 6 Reference No.:130122E06 Report No.: 121227E01B Page 7 Reference No.:130122E06 Report No.: 121227E01B Page 8 Reference No.:130122E06 Report No.: 121227E01B Page 9 Reference No.:130122E06 Report No.: 121227E01B Page 10 Reference No.:130122E06

Report No.: RF121227E01B 1 of 58 Report Format Version 5.1.0 Reference No.: 130122E06 FCC TEST REPORT (15.247) REPORT NO.: RF121227E01B MODEL NO.: WVBR0-01, WVBR0-25 FCC ID: NKR-DTVDWVB RECEIVED: Dec. 27, 2012 TESTED: Jan. 04 to 09, 2013 ISSUED: Feb. 05, 2013 APPLICANT: Wistron NeWeb Corp. ADDRESS: 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF121227E01B 2 of 58 Report Format Version 5.1.0 Reference No.: 130122E06 Table of Contents RELEASE CONTROL RECORD..............................................................................4 1. CERTIFICATION ...........................................................................................5 2. SUMMARY OF TEST RESULTS ...................................................................6 2.1 MEASUREMENT UNCERTAINTY ................................................................7 3. GENERAL INFORMATION ...........................................................................8 3.1 GENERAL DESCRIPTION OF EUT ..............................................................8 3.2 DESCRIPTION OF TEST MODES ..............................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............. 11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................14 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST .........................................16 4. TEST TYPES AND RESULTS (For 5Ghz, 5725~5850MHz Band) ..............17 4.1 CONDUCTED EMISSION MEASUREMENT ..............................................17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................17 4.1.2 TEST INSTRUMENTS ................................................................................17 4.1.3 TEST PROCEDURES .................................................................................18 4.1.4 DEVIATION FROM TEST STANDARD .......................................................18 4.1.5 TEST SETUP ..............................................................................................18 4.1.6 EUT OPERATING CONDITIONS ................................................................19 4.1.7 TEST RESULTS ..........................................................................................20 4.2 RADIATED AND BANDEDGE EMISSION MEASUREMENT ......................22 4.2.1 LIMITS OF RADIATED AND BANDEDGE EMISSION MEASUREMENT ...22 4.2.2 TEST INSTRUMENTS ................................................................................23 4.2.3 TEST PROCEDURES .................................................................................24 4.2.4 DEVIATION FROM TEST STANDARD .......................................................24 4.2.5 TEST SETUP ..............................................................................................25 4.2.6 EUT OPERATING CONDITIONS ................................................................25 4.2.7 TEST RESULTS ..........................................................................................26 4.3 6dB BANDWIDTH MEASUREMENT ..........................................................35 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................35 4.3.2 TEST INSTRUMENTS ................................................................................35 4.3.3 TEST PROCEDURE ...................................................................................35 4.3.4 DEVIATION FROM TEST STANDARD .......................................................35 4.3.5 TEST SETUP ..............................................................................................35 4.3.6 EUT OPERATING CONDITIONS ................................................................35 4.3.7 TEST RESULTS ..........................................................................................36 4.4 CONDUCTED OUTPUT POWER MEASUREMENT ..................................37 Report No.: RF121227E01B 3 of 58 Report Format Version 5.1.0 Reference No.: 130122E06 4.4.1 LIMITS OF CONDUCTED OUTPUT POWER MEASUREMENT …
