NKR-SY75WiFi module

Wireless LAN Module (11abgn 2x2 USB Module) DNUA-SY75 User Manual Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Pentium is trademark of Intel. All copyright reserved. 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/ Projector technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Country Code selection feature to be disabled for products marketed to the US/CANADA Operation of this device is restricted to indoor use only This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna, 3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. 2 As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: NKR-SY75”. Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. 3 Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: - IEC 60950-1:2005 (2nd Edition); Am 1:2009 - EN 60950-1:2006+A11:2009+A1:2010+A12:2011 Safety of Information Technology Equipment - EN 62311: 2008 / Article 3(1)(a) and Article 2 2006/95/EC) Assessment of electronic and electrical equipment related to human exposure restrictions for electromagnetic fields (0 Hz-300 GHz) - EN 300 328 V1.8.1: 2012-06 - Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data transmission equipment operating using wide band modulation techniques; Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive - EN 301 893 V1.7.1: 2012-06 - Broadband Radio Access Networks (BRAN); 5 GHz high performance RLAN; Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive - EN 301 489-1 V1.9.2: 2011 - Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements - EN 301 489-17 V2.2.1 2012 - Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment; Part 17: Specific conditions for Broadband Data Transmission Systems - In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunicat…

Text truncated - open the document above for the full version.

Date: 2015/9/7 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: NKR-SY75 Product name: WiFi module To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model DNUA-SY75 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Hsiang, Tao Yuan Hsein 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Wistron NeWeb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan,R.O.C. Signature : _________________________________ Name and Job Title. : Edward Yeh / Engineer E-mail : [email protected] Tel. : 886-3-667799

Confidentiality Request Letter Date: 2015/9/7 Federal Communications Commission Authorization and Evaluation Division FCC ID：NKR-SY75 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Wistron NeWeb Corporation Applicant’s company address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan,R.O.C. Signature : Job Title and Dept. : Edward Yeh / Engineer E-mail : [email protected] Tel. : 886-3-6667799

Date: September 7, 2015 Subject: Ad Hoc Mode Function Declaration FCC ID: NKR-SY75 To Whom it may concern, We, Wistron NeWeb Corporation declare that the device does not support any non-US channels, country code selection in all the operational mode(s), like Ad-Hoc...etc. for the following product. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master and the device without support DFS detection capability. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. Regards, Applicant : Wistron NeWeb Corp. Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Signature : Name and Job Title. : Edward Yeh / Engineer E-mail [email protected] Tel. 886-3-666-7799

RF_734_00, Issue 1 Modular Approval Request FCC (per DA 00-1407) FCC ID: NKR-SY75 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. The modular has a shielding Case. Please refer to EUT Photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The component number is QCA9375 3. The modular transmitter must have its own power supply regulation. The component number is QCA9375 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. In-line switch connector is used. And no external amplifier will be used with this modular. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. This modular is tested under stand-alone configuration. Please refer to Test setup photo. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The modular transmitter is labeled with its own FCC ID number. Please refer to label sample and label location. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. The modular complies with this requirement. Please refer to user manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The device complies with this requirement. Please refer to RF exposure report. Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or authorized representative): __________________ Date: ___17 September 2015____ Signature: ___________________________

Project No.: 580301 Page No. : 1 of 2 Photographs of EUT

COLOR 1 COLOR 1 WHITE HSINYUN LIN07/28/15 DNUA-SY75 A 1.3 3.2 5.2 1.3 1.0 ± 0.2 mm 0.8 1.0 29.4 14.2 Label Location

Project No.: 580301 Page No. : 2 of 2

Report No.: FA580301 Page : 1 of 5 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : NKR-SY75 Equipment : WiFi module Model No. : DNUA-SY75 Brand Name : WNC Applicant : Wistron NeWeb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan, R.O.C. Standard : 47 CFR FCC Part 2.1091 Received Date : Aug. 03, 2015 Tested Date : Aug. 25 ~ Sep. 03, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FA580301 Page : 2 of 5 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 MPE EVALUATION RESULTS .............................................................................................................. 4 2 TEST LABORATORY INFORMATION ................................................................................................. 5 Report No.: FA580301 Page : 3 of 5 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA580301 Rev. 01 Initial issue Sep. 17, 2015 Report No.: FA580301 Page : 4 of 5 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412~2462 23.57 0.39 20 0.050 1 5180~5240 20.03 2.57 20 0.036 1 5260~5320 19.67 3.11 20 0.038 1 5500~5700 19.88 4.13 20 0.050 1 5745~5825 18.70 4.13 20 0.038 1 Report No.: FA580301 Page : 5 of 5 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp, it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan Hsiang. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. No. 14-1, Lane 19, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR580301AN Page : 1 of 115 Report Version: Rev. 01 FCC Test Report FCC ID : NKR-SY75 Equipment : WiFi module Model No. : DNUA-SY75 Brand Name : WNC Applicant : Wistron NeWeb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan, R.O.C. Standard : 47 CFR FCC Part 15.407 Received Date : Aug. 03, 2015 Tested Date : Aug. 25 ~ Sep. 03, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR580301AN Page : 2 of 115 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 9 1.3 Test Setup Chart .................................................................................................................................... 9 1.4 The Equipment List .............................................................................................................................. 10 1.5 Testing Applied Standards ................................................................................................................... 11 1.6 Measurement Uncertainty .................................................................................................................... 11 2 TEST CONFIGURATION ..................................................................................................................... 12 2.1 Testing Condition ................................................................................................................................. 12 2.2 The Worst Test Modes and Channel Details ....................................................................................... 12 3 TRANSMITTER TEST RESULTS ........................................................................................................ 14 3.1 Conducted Emissions ........................................................................................................................... 14 3.2 Emission Bandwidth ............................................................................................................................. 19 3.3 RF Output Power .................................................................................................................................. 24 3.4 Peak Power Spectral Density ............................................................................................................... 29 3.5 Transmitter Radiated and Band Edge Emissions ................................................................................ 34 3.6 Frequency Stability ............................................................................................................................. 113 4 TEST LABORATORY INFORMATION ............................................................................................. 115 Report No.: FR580301AN Page : 3 of 115 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR580301AN Rev. 01 Initial issue Sep. 17, 2015 Report No.: FR580301AN Page : 4 of 115 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.151MHz 44.55 (Margin -11.39dB) - AV Pass 15.407(b) 15.209 Radiated Emissions [dBuV/m at 3m]: 11570.00MHz 53.67 (Margin -0.33dB) - AV Pass 15.407(a) Emission Bandwidth Meet the requirement of limit Pass 15.407(e) 6dB bandwidth Meet the requirement of limit Pass 15.407(a) RF Output Power Max Power [dBm]: 5150~5250MHz: 20.03 5250~5350MHz: 19.67 5470~5725MHz: 19.88 5725~5850MHz: 18.70 Pass 15.407(a) Peak Power Spectral Density Meet the requirement of limit Pass 15.407(g) Frequency Stability Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR580301AN Page : 5 of 115 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 5150-5250 5250-5350 5470-5725 5725-5850 a 5180-5240 5260-5320 5500-5720 5745-5825 36-48 [4] 52-64 [4] 100-144 [9] 149-165 [5] 2 6-54 Mbps 5150-5250 5250-5350 5470-5725 5725-5850 n (HT20) 5180-5240 5260-5320 5500-5720 5745-5825 36-48 [4] 52-64 [4] 100-144 [9] 149-165 [5] 2 MCS 0-15 5150-5250 5250-5350 5470-5725 5725-5850 n (HT40) 5190-5230 5270-5310 5510-5710 5755-5795 38-46 [2] 54-62 [2] 102-142 [4] 151-159 [2] 2 MCS 0-15 Note 1: RF output power specifies that Maximum Conducted Output Power. Note 2: 802.11a/n uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM modulation. Note 3: The device has disabled the 5600-5650MHz band by S/W to avoid 5600-5650MHz band. 1.1.2 Antenna Details Ant. No. Model Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5250~5350 5470~5725 5725~5850 1 DNUA-SY75 ANT0 Printed in-line switch 0.39 2.57 3.11 4.13 4.13 2 DNUA-SY75 ANT1 Printed in-line switch -0.2 1.1 1.64 2.32 2.19 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type 3.3Vdc from host 1.1.4 Accessories N/A Report No.: FR580301AN Page : 6 of 115 Report Version: Rev. 01 1.1.5 Channel List Frequency band (MHz) 5150~5725 802.11 a / n HT20 802.11n HT40 Channel Frequency(MH…

Text truncated - open the document above for the full version.

Report No.: FZ580301 Page : 1 of 18 Report Version: Rev. 01 FCC DFS Test Report FCC ID : NKR-SY75 Equipment : WiFi module Model No. : DNUA-SY75 Brand Name : WNC Applicant : Wistron NeWeb Corporation Address : 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308,Taiwan, R.O.C. Standard : 47 CFR FCC Part 15.407 Received Date : Aug. 03, 2015 Tested Date : Aug. 13, 2015 Operating Mode : Client Without Radar Detection We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FZ580301 Page : 2 of 18 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Support Equipment List .......................................................................................................................... 6 1.3 The Equipment List ................................................................................................................................ 6 1.4 Testing Condition ................................................................................................................................... 6 1.5 Test Standards ....................................................................................................................................... 6 2 TECHNICAL REQUIREMENTS FOR DFS ............................................................................................ 7 2.1 Applicability of DFS Requirements ......................................................................................................... 7 2.2 DFS Detection Thresholds and Response Requirement ....................................................................... 8 2.3 Radar Test Waveforms .......................................................................................................................... 9 3 DFS TEST RESULT ............................................................................................................................. 13 3.1 DFS Detection Threshold levels ........................................................................................................... 13 3.2 In-Service Monitoring ........................................................................................................................... 14 3.3 Non-Associated .................................................................................................................................... 17 4 TEST LABORATORY INFORMATION ............................................................................................... 18 Report No.: FZ580301 Page : 3 of 18 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FZ580301 Rev. 01 Initial issue Sep. 17, 2015 Report No.: FZ580301 Page : 4 of 18 Report Version: Rev. 01 Summary of Test Results FCC Rules Description of Test Result FCC 15.407 KDB 905462 D02 Non-Occupancy Period Pass FCC 15.407 KDB 905462 D02 Channel Closing Transmission Time Pass FCC 15.407 KDB 905462 D02 Channel Move Time Pass Report No.: FZ580301 Page : 5 of 18 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) Frequency Range (GHz) 5.15~5.25, 5.25~5.35, 5.47~5.725 Wireless Function 11a / HT20 / HT40 Operating Mode at DFS Band Client without radar detection and ad hoc function Firmware / Software Version 5.0.0.51 1.1.2 Antenna Details Ant. No. Model Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5250~5350 5470~5725 1 DNUA-SY75 ANT0 Printed in-line switch 0.39 2.57 3.11 4.13 2 DNUA-SY75 ANT1 Printed in-line switch -0.2 1.1 1.64 2.32 Report No.: FZ580301 Page : 6 of 18 Report Version: Rev. 01 1.2 Support Equipment List Support Equipment List No. Equipment Brand Name Model Name FCC ID 1 AP (Master) Netgear R6100 PY312400225 2 Notebook DELL LATITUDE-E5420 B6FV9T1 1.3 The Equipment List Test Item RF Conducted Test Site (DF01-WS) Instrument Manufacturer Model No. Serial No. Calibration Date Calibration Until Spectrum R&S FSV-7 101607 Dec. 09, 2014 Dec. 08, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 MY15686/4 Dec. 19, 2014 Dec. 18, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 296081/4 Dec. 19, 2014 Dec. 18, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 500199/4 Dec. 19, 2014 Dec. 18, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 500202/4 Dec. 19, 2014 Dec. 18, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 296088/4 Dec. 19, 2014 Dec. 18, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 329023/4 Dec. 19, 2014 Dec. 18, 2015 RF cable HUBER+SUHNER SUCOFLEX_104 329021/4 Dec. 19, 2014 Dec. 18, 2015 Vector signal generator R&S SMJ100A 100498 Dec. 24, 2014 Dec. 23, 2015 Measurement Software Sporton Sporton_2 1.3.30 NA NA Note: Calibration Interval of instruments listed above is one year. 1.4 Testing Condition Test Item Test Site Ambient Condition Tested By DFS DF01-WS 25°C / 64% Jack Li 1.5 Test Standards According to the specification of EUT, the EUT must comply with following standards and KDB documents. 47 CFR FCC Part 15.407 FCC KDB 905462 D02 UNII DFS Compliance Procedures New Rules v01r01 FCC KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r01 FCC KDB 905462 D06 802 11 Channel Plans v01 Report No.: FZ580301 Page : 7 of 18 Report Version: Rev. 01 2 Technical Requirements for DFS 2.1 Applicability of DFS Requirements 2.1.1 Applicability of DFS Requirements Prior to use of a Channel Requiremen…

Text truncated - open the document above for the full version.

Report No.: FZ580301 Page: : 1 of 1 Report Version: Rev. 01 Photographs of the Test Configuration DFS Test

Report No.: FR580301 Page: : 1 of 10 Report Version: Rev. 01 Photographs of the Test Configuration C…
