NKR-XRAINFC Module

USER MANUAL XRAI NFC MOUDULE USER MANUAL & SPECIFICATION USER MANUAL I. Introduction XRAI is one kind of NFC module that could be embedded in one IT system by simply connecting the module to his target microcontroller and start developing his application software. Note that this module is also used for the NXP PN544/PN65O standard Evaluation Kit software. It is recommended that this user guide be read in conjunction with the XRAI datasheet. II. DESIGN REFERENCE As illustrated in Figure 1 below, the XRAI reference design module consists of the following: ‧ Reference Design: This section includes the NXP PN544C3 chip but also all the external components in an optimized BOM and form factor. When the user wishes to incorporate the XRAI to PCB, it is strongly recommended that this reference design (i.e. schematics, placement, layout, BOM, etc...) is copied “as is” in the final application board to guarantee optimum performance, regulatory compliance and lowest development time and design effort. Figure 1: Overview (Top View) ‧ MCU FPC/FFC Connector: Enables the user to connect the XRAI control and interface pins to the host microcontroller (please refer to the XRAI datasheet for further information). ‧ IPEX Connector: Provided for COXIAL Cable or antenna connection. ‧ Hardware Block Diagram: Connection rule: user could refer the block diagram in Figure 2 Figure 2 NFC module Major Component and System Interface The pin-out of the MCU connector is tabulated below in Table 1. Pin number Name Direction Description 1 PVDD Power 1.8V 2 VBAT Power 3.3V 3 GPIO4 I Reserved for FW download 4 GND -- 5 IRQ -- IRQ output 6 NFC_EN I Enable signal 7 USB_5V Power USB power 8 DP -- USB D+ 9 DM USB D- 10 GND -- USER MANUAL III. FEATURE „ Contactless protocols: • ISO14443 A/B • ISO15693 • ISO18092 IV. Environmental Requirement Item Feature Description 5.1 Operating Temperature 0 to 40 deg.C 5.2 Storage Temperature -10 to 70 deg.C 5.3 Operating Humidity 10 to 90 % (Non-condensing) 5.4 MTBF TBD 5.5 ROHS TBD V. Certifications and Regulatory Item Feature Description 6.1 FCC RF: FCC part 15C EMI: FCC part 15B FCC grant: TCB Filing fee 6.2 CE RF: EN302291 EMC: EN301489-1/-3 Safety:EN 60950-1:2006/A11:2009 6.3 TBD TBD USER MANUAL Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: The product comply with the US portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device is intended only for OEM integrators under the following conditions: The transmitter module may not be co-located with any other transmitter or antenna. As long as 1 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and USER MANUAL obtaining a separate FCC authorization. End Product Labeling The final end product must be labeled in a visible area with the following: “Contains FCC ID: NKR-XRAI”. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.

September 14, 2012 Federal Communications Commission Authorization and Evaluation Division Subject: Request for Confidentiality FCC ID: NKR-XRAI To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until October.25.2012 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards __________________________________ Troy Chien / Associate Technical Director Tel: +886-3-6667799 Fax: +886-3-6667323 E-mail:[email protected]

A G E N C Y A U T H O R I Z A T I O N L E T T E R FCC ID: NKR-XRAI September 14, 2012 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, __________________________________ Troy Chien / Associate Technical Director Tel: +886-3-6667799 Fax: +886-3-6667323 E-mail:[email protected]

FCC ID: NKR-XRAI Report No.: RF 120831E03 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch September 20, 2012 Dear Application Examiner, Wistron NeWeb Corp., It’s a NFC Module, FCC ID: NKR-XRAI would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip PN5441A2ET/C30701_BGA64P. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is PN5441A2ET/C30701_BGA64P. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: NKR-XRAI Report No.: RF 120831E03 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, signature Hank Chung Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Report No. : 120831E03 Page 1 CONSTRUCTION PHOTOS OF EUT Report No. : 120831E03 Page 3 Report No. : 120831E03 Page 4 Report No. : 120831E03 Page 5 Report No. : 120831E03 Page 6 Report No. : 120831E03 Page 7

FCC ID: NKR-XRAI PROPOSED FCC ID LABEL AND LOCATION Bottom of EUT FCC / IC Label Location Wistron NeWeb Corp. FCC ID: NKR-XRAI MODEL: XRAI

Report No. : 120831E03 Page 2

Report No.: RF120831E03 1 of 33 Report Format Version 5.0.0 FCC TEST REPORT (RFID) REPORT NO.: RF120831E03 MODEL NO.: XRAI FCC ID: NKR-XRAI RECEIVED: Aug. 28, 2012 TESTED: Aug. 28 to Sep. 04, 2012 ISSUED: Sep. 19, 2012 APPLICANT: Wistron NeWeb Corp. ADDRESS: 20 Park Avenue II, Hsinchu Science Park,Hsinchu 308, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120831E03 2 of 33 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD ............................................................................................ 3 1 CERTIFICATION ....................................................................................................... 4 2 SUMMARY OF TEST RESULTS ............................................................................... 5 2.1 MEASUREMENT UNCERTAINTY ............................................................................. 6 3 GENERAL INFORMATION ........................................................................................ 7 3.1 GENERAL DESCRIPTION OF EUT .......................................................................... 7 3.2 DESCRIPTION OF TEST MODES ............................................................................ 8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................... 10 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................... 11 3.5 CONFIGURATION OF SYSTEM UNDER TEST ...................................................... 11 4 TEST PROCEDURES AND RESULTS .................................................................... 12 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................... 12 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................... 12 4.1.2 TEST INSTRUMENTS............................................................................................. 12 4.1.3 TEST PROCEDURES ............................................................................................. 13 4.1.4 DEVIATION FROM TEST STANDARD .................................................................... 13 4.1.5 TEST SETUP .......................................................................................................... 14 4.1.6 EUT OPERATING CONDITIONS ............................................................................ 15 4.1.7 TEST RESULTS ...................................................................................................... 16 4.2 RADIATED EMISSION & OCCUPIED BANDWIDTH EASUREMENT ..................... 18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.............................................. 18 4.2.2 TEST INSTRUMENTS............................................................................................. 19 4.2.3 TEST PROCEDURES ............................................................................................. 21 4.2.4 DEVIATION FROM TEST STANDARD .................................................................... 22 4.2.5 TEST SETUP .......................................................................................................... 22 4.2.6 EUT OPERATING CONDITIONS ............................................................................ 22 4.2.7 TEST RESULTS ...................................................................................................... 23 4.3 20DB BANDWIDTH ................................................................................................. 27 4.3.1 LIMITS OF 20DB BANDWIDTH MEASUREMENT .................................................. 27 4.3.2 TEST INSTRUMENTS............................................................................................. 27 4.3.3 EUT OPERATING CONDITION ............................................................................... 27 4.3.4 TEST RESULTS ...................................................................................................... 28 4.4 FREQUENCY STABILITY........................................................................................ 29…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST(Below 30MHz) 3 4 RADIATED EMISSION TEST(Above 30MHz)
