NKRBT500Bluetooth USB Dongle

Wistron NeWeb Corp. Bluetooth for Windows Bluetooth Neighborhood User Manual BT-500 User Manual Wistron NeWeb Corp.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, (example - use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. CAUTION STATEMENT RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. BT-500 User Manual Wistron NeWeb Corp.2 Table of contents 1Introduction....................................................................................................3 2Icons Used for Devices and Services.............................................................4 3Search for Devices (Device Inquiry).............................................................5 4 Find a Service (Service Discovery)...............................................................8 5 Local Services................................................................................................9 6Security........................................................................................................ 11 Appendix A－Troubleshooting............................................................................12 BT-500 User Manual Wistron NeWeb Corp.3 1Introduction Bluetooth technology provides short-range wireless communications enabled devices. Bluetooth for Windows(BTW) is the WIDCOMM, Inc.(WIDCOMM), solution for the seamless integration of Bluetooth technology into personal computers. Most Bluetooth-enabled devices have the capability to act as: z A Bluetooth server—these devices provide one or more services, such as access to the Internet, to other Bluetooth devices. and z A Bluetooth client—these devices use the service(s) provided by Bluetooth servers. Bluetooth for Windows provides: z Clients with the means: ¾ To locate other Bluetooth devices in the immediate vicinity (inquiry). ¾ Discover the services that those devices offer (discovery). ¾ Connect to, use, and disconnect from those services. z Servers with the means: ¾ To include/exclude individual services in the list of services it provides to clients. z Extensive security, including: ¾ Authorization ¾ Authentication ¾ Encryption BTW supports: z Windows 2000 z Windows 98SE(Second Edition) z Windows Me(Millennium Edition) BTW functions the same, regardless of the supported version of Windows it is running on. BT-500 User Manual Wistron NeWeb Corp.4 2Icons Used for Devices and Services Bluetooth for Window’s icons provide at-a-glance feedback about a device or service’s status by changing color and form. Device icons turn green when a connection is active. The device icons also indicate if devices are paired (“trusted”). If a device is trusted, the icon form changes to include a white check mark in a black circle. The service icons also turn green when a connection is active. To view an illustration of the device and service icon types in Bluetooth Neighborhood, open the Help menu and select Help Topics. On the Contents tab, double-click the General topic and then the Icons Used for Devices and Services topic. BT-500 User Manual Wistron NeWeb Corp.5 3Search for Devices (Device Inquiry) “Search for Devices” looks for Bluetooth devices in the vicinity and displays the devices it finds in Bluetooth Neighborhood. Bluetooth for Windows automatically searches for devices when Bluetooth Neighborhood is opened. To start the Search for Devices when Bluetooth Neighborhood is open: z In Bluetooth Neighborhood, double-click the Search for Devices icon or z Open the Bluetooth menu and select Search for Devices. BT-500 User Manual Wistron NeWeb Corp.6 BTW can be configured to automatically search for devices on regular basis (Bluetooth Configuration window > Discovery tab). One of the advantages of Bluetooth is the mobility the wireless connections allow. However, mobility means that devices may move in or out of connection range during the time between the automatic updates performed by BTW. To be certain that the displayed list of devices in the neighborhood is current, or if automatic periodic inquiry is not enabled, force an up-to-date view by clicking Search for Devices. Some devices within connection range may not…

Text truncated - open the document above for the full version.

Wistron Neweb Corp. No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, TEL: +886-3-6667799 FAX: +886-3-6667711 MAIL: [email protected] FCC ID: NKRBT500 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, 2002/4/3 -------------------------- Robin Wu/ Manager Engineer Wistron Neweb Corp. Tel: +886 3 6667799-6631 Fax: +886 3 6667711 MAIL: [email protected]

Inform Letter Dear Customer, According to FCC’s regulation, the following Declaration of Conformity has to be made by a company located in USA. They are: This device has been confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number RF910222R03 And this compliance is subject to the following two conditions: (1) This device may not cause harmful interference and, (2) This device must accept any interference received, including interference that may cause undesired operation. This declaration can be a separate sheet and be sure that the following message will be also included in this declaration: 1) Product name, model name and trade name. 2) Company name, and address of the one who is responsible for this declaration. 3) Name, title, telephone and fax number as well as the signature of the contact person. Thanks for your attention. No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, TEL: +886-3-6667799 FAX: +886-3-6667711































Wistron NeWeb Corp.






!





  !







 "


#
$
%&



















  !




!!


!










'!



"




 (





 )
*


+





,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,












! "



#
$%&% % '#%
















 !





Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

BT-500 BT-500 20mm Label for BT-500 Bluetooth USB Dongle Bluetooth USB Dongle Made in Taiwan 12mm Wistron Neweb Corp. 895234564 Input: DC 5V / 150mA XXXXXXXX BT Add257368542 S/N Tested To Comply With FCC Standards FOR HOME OR OFFICE USE FCC ID:NKRBT500

Page 3 Page 4

FCC ID: NKRBT500 ADT No.910222R03 Operational Description The transmitter of the EUT is powered by host equipment from USB port. The antenna is Meander IFA, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. This device is a Frequency Hopping device with 79 hopping frequencies. The declared output power is only -1dBm.

FCC ID: NKRBT500 ADT No.: 910222R03 FCC TEST REPORT REPORT NO.: RF910222R03 MODEL NO.: BT-500 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Wistron NeWeb Corporation ADDRESS: No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. ILAC MRA 0528 Lab Code: 200102-0 FCC ID: NKRBT500 ADT No.: 910222R03 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: NKRBT500 ADT No.: 910222R03 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: NKRBT500 ADT No.: 910222R03 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -1 dBi or 0.79 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 124120.770.22 624370.800.22 1124620.770.22 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: NKRBT500 Report No.: RF910222R03 1 Issued: March 8, 2002 FCC TEST REPORT REPORT NO.: RF910222R03 MODEL NO.: BT-500 RECEIVED: Feb. 22, 2002 TESTED: Feb. 22 ~ March 4, 2002 APPLICANT:Wistron NeWeb Corp. ADDRESS: No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 59 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: NKRBT500 Report No.: RF910222R03 2 Issued: March 8, 2002 TABLE OF CONTENTS 1CERTIFICATION.........................................................................................................4 2SUMMARY OF TEST RESULTS ................................................................................5 3GENERAL INFORMATION .........................................................................................6 3.1GENERAL DESCRIPTION OF EUT ...........................................................................6 3.2DESCRIPTION OF TEST MODES .............................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................7 3.4DESCRIPTION OF SUPPORT UNITS........................................................................8 4TEST PROCEDURES AND RESULTS .......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ..............................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................9 4.1.2TEST INSTRUMENTS ................................................................................9 4.1.3TEST PROCEDURES ...............................................................................10 4.1.4TEST SETUP ............................................................................................10 4.1.5TEST RESULTS ........................................................................................ 11 4.2NUMBER OF HOPPING FREQUENCY USED .........................................................17 4.2.1LIMIT OF HOPPING FREQUENCY USED ...............................................17 4.2.2TEST INSTRUMENTS ..............................................................................17 4.2.3TEST PROCEDURES ...............................................................................18 4.2.4TEST SETUP ............................................................................................18 4.2.5TEST RESULTS ........................................................................................18 4.3DWELL TIME ON EACH CHANNEL.........................................................................21 4.3.1LIMIT OF DWELL TIME USED .................................................................21 4.3.2TEST INSTRUMENTS ..............................................................................21 4.3.3TEST PROCEDURES ...............................................................................22 4.3.4TEST SETUP ............................................................................................22 4.3.5TEST RESULTS ........................................................................................23 4.4CHANNEL BANDWIDTH ..........................................................................................27 4.4.1LIMITS OF CHANNEL BANDWIDTH ........................................................27 4.4.2TEST INSTRUMENTS ..............................................................................27 4.4.3TEST PROCEDURE .................................................................................28 4.4.4TEST SETUP ............................................................................................28 4.4.5EUT OPERATING CONDITION ................................................................28 4.4.6TEST RESULTS ........................................................................................29 4.5HOPPING CHANNEL SEPARATION ........................................................................33 FCC ID: NKRBT500 Report No.: RF910222R03 3 Issued: March 8, 2002 4.5.1LIMIT OF HOPPING CHANNEL SEPARATION ........................................33 4.5.2TEST INSTRUMENTS ..............................................................................33 4.5.3TEST PROCEDURES ...............................................................................34 4.5.4TEST SETUP ............................................................................................34 4.5.5TEST RESULTS ........................................................................................34 4.6MAXIMUM PEAK OUTPUT POWER ........................................................................38 4.6.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT .........38 4.6.2INSTRUMENTS.........................................................................................38 4.6.3TEST PROCEDURES ...............................................................................39 4.6.4TEST SETUP ............................................................................................39 4.6.5EUT OPERATING CONDITION ................................................................39 4.6.6TEST RESULTS ........................................................................................40 4.7RADIATED EMISSION MEASUREMENT .................................................................44 4.7.1LIMITS OF RADIATED EMISSION MEASUREMENT ...............................44 4.7.2TEST INSTRUMENTS ..............................................................................…

Text truncated - open the document above for the full version.

The information contained in this letter is intended for the named recipients only. It may contain privileged and confidential information and, if you are not an intended recipient, you must not copy, distribute, or take any action in reliance on it. If you have received this letter in error, please notify the sender immediately by reverse charge telephone call to 01223 692000 and return the original by post. We will reimburse you the postage. Registered Number: 3665875 England VAT Registration Number: 731 9856 07 Cambridge Silicon Radio Limited Cambridge Science Park, Milton Road Cambridge CB4 0WH England Telephone: +44 (0)1223 692000 Fax: +44 (0)1223 692001 http://www.csr.com PROCESS GAIN MEASUREMENTS EXHIBIT. For product FCC ID:- PIWBCES301199-1, this is exhibit K. For product FCC ID:- 02Z-BT2, this is exhibit BB. Page 1 of 11 PG Results 23 March 2001 Filename: BlueCore01_BC01b_PG_Results_v2.1 MEMORANDUM Distribution:Peter Flittner, Robert Young, James Collier cc: Prepared By:Alex Busteed Subject:Results of Processing Gain Tests for FCC Qualification 1 INTRODUCTION This memo presents the results of the Processing Gain (PG) tests carried out for FCC qualification of the Cambridge Silicon Radio BC01B Bluetooth chip. The FCC states that the PG from a hybrid Bluetooth receiver must be greater than 17 dB when measured in accordance with the Continuous Wave (CW) jamming margin method. Testing of the BC01b has found the PG due to the DS section to be approximately 5 dB and the PG due to the FH part to be approximately 15 dB. It is therefore concluded that the BC01B complies with the FCC PG requirements for radio communication systems. The rest of this paper outlines the PG measurement technique and discusses the test results. Appendix A contains a list of test equipment and Appendix B contains a printout of the measurement results. 2 METHOD 2.1 PG Definition The Processing Gain from a frequency hopping communication system is derived from two parts, the FH section and the DS section. The PG due to FH is given by a simple equation and is constant. However measurement of the PG due to DS is a little more complex. One technique is to use the CW jamming margin method. This method measures PG due to DS using the following algorithm: A CW signal generator is stepped in 50kHz increments across the passband of the system, recording at each point the generator level required to produce the 0.1% Packet Error Rate (PER). This is the jammer level. This level is then referenced to the output power of the intended Bluetooth signal and the Jammer to Signal Ratio JSR is thus calculated. The worst 4 Page 2 of 11 PG Results 23 March 2001 JSR measurements are discarded and the worst remaining JSR is used to calculate the PG due to DS as follows: sysp LJSRSNRG++= min where G p = the processing gain of the system, SNR = the signal to noise ratio required for 0.1% BER, JSR min = minimum J/S ratio and L sys = system losses. 2.2 PG Measurement Technique Figure 1 provides an overview of the PG measurement technique. The measurement is performed in two parts, measurement of the system SNR and measurement of JSR min . Figure 1: PG Measurement Technique The system SNR is calculated using the following algorithm. Generate Bluetooth PRBS-9 packets using a BC01B emulator (1) and a Vector Signal Generator (2). Combine this signal with white noise of a constant level, which is generated using a noise source (4) and a CW Signal Generator (3). Then vary the level of the Bluetooth signal until the BER measured by the BC01B (7) is 0.1%. The resulting SNR is the signal level divided by the Noise level. Page 3 of 11 PG Results 23 March 2001 The JSR for a given jamming frequency is calculated using the following algorithm. Generate Bluetooth PRBS-9 packets using the BC01B emulator (1) and the Vector Signal Generator (2). Combine this signal with a constant CW tone at the jamming frequency using a CW Signal Generator (5) and a combiner (6). Then vary the level of the Bluetooth signal until the PER measured by the Casira Bluetooth Module (7) is 0.1%. The resulting JSR is the signal level divided by the jamming level. 3 RESULTS 3.1 Overview The measurements found that the PG due to DS caused by the access code in page and inquiry mode is found to be approximately 5dB when the access code is a relatively random mixture of 1's and 0's. A random access code causes the most Inter Symbol Interference (ISI) and hence the worst PG for a hybrid system. Therefore only the results for this access code are used in the PG calculation. The PG due to FH is given as PG FH = 10 log 10 (number of frequency hops) The number of hops in a Bluetooth system is 32, therefore the PG due to FH is approximately 15 dB. When this is added to the PG due to DS, the total PG for the BC01B is approximately 20 dB, above the minimum PG requirement for FCC qualification. 3.2 Detailed Results Test Date:17/11/00 Sample Time: 30 seconds Access Code: c6967e Signal Frequency:2.432GHz Receiver Sensitivity: -88.7 dBm Jammer Signal Level:-85.7 dBm Measured SNR: 18.8dB System Losses: 2dB To calculate processing gain, ignore the worst 20% of data points and then apply the following formula: Page 4 of 11 PG Results 23 March 2001 sysp LJSRSNRG++= min Where G p = Processing Gain of the module SNR = signal to noise ratio of the module JS min = minimum J/S ratio after the worst 20% of J/S samples have been discarded L sys = System losses A total of 20 samples were taken by stepping the jamming signal frequency offsets in 50kHz increments over the bandwidth of the receiver. The worst 4 samples were found at –500kHz, -450kHz, -400kHz and 500kHz and were discarded. The remaining minimum J/S ratio was found to be -15.4dB at an offset of +350kHz Thus, the processing gain due to direct sequence spreading in page and inquiry mode is dBG p 4.524.158.18=+−= -500-400-300-200-1000100200300400500 -30 -25 -20 -15 -10 -5 0 5 Jamming Frequency Offset (kHz) J/S (dBs) J/S ratio performance for Proce…

Text truncated - open the document above for the full version.

FCC ID: NKRBT500 Report No.: RF910222R03 57 Issued: March 8, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: NKRBT500 Report No.: RF910222R03 58 Issued: March 8, 2002 RADIATED EMISSION TEST
