WLAN 802.11a/b/g USB 2.0 Adapter User’s Guide Version: 1.0 — Sep. 2004 1 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Windows ™ 2000/XP are trademarks of Microsoft ® Corp. Atheros is a registered trademark of Atheros Communications, Inc. All copyright reserved. 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Wistron NeWeb Corp. declares that this product is limited in CH1~CH11 by specified firmware controlled in the USA. Highest SAR test value: 1.55W/kg 3 Table of Contents REGULATORY INFORMATION......................................................................! 1. WELCOME...............................................................................................................................................5 1.1 KIT CONTENTS......................................................................................................................................5 1.2 MAIN FEATURES OF 802.11A/B/G USB 2.0 ADAPTER.........................................................................5 1.3 WIRELESS NETWORKING SCENARIOS..................................................................................................6 2. QUICK START GUIDE..........................................................................................................................8 2.1 INSTALLATION.......................................................................................................................................8 2.2 CONNECTING TO AN EXISTING NETWORK...........................................................................................9 3. STEP-BY-STEP INSTRUCTIONS......................................................................................................10 3.1 INSTALLATION.....................................................................................................................................10 3.2 CONNECTING TO A NETWORK.............................................................................................................15 3.3 CREATING AN AD HOC NETWORK.....................................................................................................19 3.4 REMOVING YOUR 802.11A/B/G USB 2.0 ADAPTER...........................................................................21 3.5 UNINSTALLATION................................................................................................................................22 4. USING THE UTILITY..........................................................................................................................24 4.1 CURRENT STATUS...............................................................................................................................24 4.2 DIAGNOSTICS......................................................................................................................................25 4.3 PROFILE MANAGEMENT.....................................................................................................................27 4.3.1 Creating or Modifying a Configuration Profile.................................................28 4.3.2 Removing a Profile.........................................................................................30 4.3.3 Profile Auto Selection.....................................................................................31 4.3.4 Switching Profiles...........................................................................................32 4.4 SECURITY............................................................................................................................................33 4.4.1 Using EAP-TLS Security...................................................................…

Text truncated - open the document above for the full version.

31 2. Select the profile to remove from the list of configuration profiles. 3. Click Remove. 4.3.3 Profile Auto Selection n Including a profile in the auto selection feature allows the wireless adapter to automatically select that profile from the list of profiles and use it to connect to the network. n Including a profile in auto profile selection: 1. On the Profile Management tab, click Order Profiles. 2. The Auto Profile Selection Management window pops up, with a list of all created profiles in the Available Profile box. 3. Highlight the profiles to add to Auto Profile selection, and then click Add. The profiles appear in the Auto Selected Profiles box. 32 n Ordering the auto selected profiles: 1. On the Profile Management tab, click Order Profiles. 2. Highlight a profile in the Auto Selected Profiles box. 3. Click Move up or Move down as appropriate. 4. Click OK. 5. Check the Auto Selected Profiles box. 6. Save the modified configuration file. 7. With Auto Profile Selection enabled, the wireless adapter scans for available networks. The highest priority profile with the same SSID as a found network is used to connect to the network. On a failed connection, the client adapter tries with the next highest priority profile. NOTE! When Auto Profile Selection is enabled by checking Auto Select Profiles on the Profile Management tab, the client adapter scans for an available network. The profile with the highest priority and the same SSID as one of the found networks is the one that is used to connect to the network. If the connection fails, the client adapter tries the next highest priority profile that matches the SSID, and so on. 4.3.4 Switching Profiles 1. To switch to a different profile, go to the Profile Management tab. 2. Click on the Profile Name in the Profile List. 3. Click Activate. 4. The Profile List provides icons that specify the Operational State for that profile. 33 The list also provides icons that specify the Signal Strength for that profile. 4.4 Security You may select WPA, WPA Passphrase, 802.1x, Pre-Shared Key or None. 4.4.1 Using EAP-TLS Security To use EAP-TLS security in the Utility, access the Security tab in the Profile Management window. 1. On the Security tab, click WPA/WPA2 or 802.1x. 2. Select EAP-TLS from the drop-down menu. 34 4.4.2 Enabling EAP-TLS Security To use EAP-TLS security, the machine must already have the EAP-TLS certificates downloaded onto it. Check with the IT manager. 1. Click Configure. 2. Select the appropriate certificate authority. Select Server Properties. The Server/Domain Name and the Login Name are filled in automatically from the certificate information. 3. Click OK again. 4. Activate the profile. 35 4.4.3 Using EAP-TTLS Security To use EAP-TTLS security in the WLAN 802.11a/b/g Utility, access the Security tab in the Profile Management window. 1. On the Security tab, click WPA/WPA2 or 802.1x. 2. Select EAP-TTLS from the drop-down menu. 36 4.4.4 Enabling EAP-TTLS Security To use EAP-TTLS security, the machine must already have the EAP-TTLS certificates downloaded onto it. Check with the IT manager. 1. Click Configure. 2. Select the appropriate certificate from the drop-down list and click OK. 3. Specify a user name for EAP authentication: ̧ Enter an EAP user name in the User Name field to use a separate user name and password and start the EAP authentication process. 4. Click Advanced and: ̧ Enter the Specific Server or Domain name of the server from which the client will accept a certificate. ̧ Change the login name if needed. 5. Click OK. 37 6. Enable the profile. 4.4.5 Using PEAP(EAP-GTC) Security To use PEAP-GTC security in the WLAN 802.11a/b/g Utility, access the Security tab in the Profile Management window. 1. On the Security tab, click WPA/WPA2 or 802.1x. 2. Select PEAP(EAP-GTC) from the drop-down menu. 38 4.4.6 Enabling PEAP(EAP-GTC) Security To use PEAP-GTC security, the server must have the PEAP-GTC certificates, and the server properties must already be set. Check with the IT manager. 1. Click Configure. 2. Select the appropriate network certificate authority from the drop-down list. 3. Specify a user name for inner PEAP tunnel authentication: ̧ Enter a PEAP user name in the User Name field to use a separate user name and start the PEAP authentication process. 4. Select Token or Static Password, depending on the user database. NOTE! Token uses a hardware token device or the Secure Computing SofToken program (version 1.3 or later) to obtain and enter a one-time password during authentication. 5. Click Advanced and: ̧ Enter the Specific Server or Domain name of the server from which the client will accept a certificate. 39 ̧ The login name used for PEAP tunnel authentication, fills in automatically as PEAP-XXXXXXXXXX, where XXXXXXXXXX is the computer’s MAC address. Change the login name if needed. 6. Click OK. 7. Enable the profile. 4.4.7 Using PEAP-MSCHAP V2 Security To use PEAP-MSCHAP V2 security in the WLAN 802.11a/b/g Utility, access the Security tab in the Profile Management window. 1. On the Security tab, click WPA/WPA2 or 802.1x. 2. Select PEAP- MSCHAP V2 from the drop-down menu. 40 4.4.8 Enabling PEAP- MSCHAP V2 Security To use PEAP-MSCHAP V2 security, the server must have the PEAP-MSCHAP V2 certificates, and the server properties must already be set. Check with the IT manager. 1. Click Configure. 2. Select the appropriate network certificate authority from the drop-down list. 3. Specify a user name for inner PEAP tunnel authentication: ̧ Enter a PEAP user name in the User Name field to use a separate user name and start the PEAP authentication process. 4. Click Advanced and: ̧ Enter the Specific Server or Domain name of the server from which the client will accept a certificate. ̧ Change the login name if needed. 5. Click OK. 6. Enable the profile. 41 4.4.9 Using LEAP Security To use LEAP security in the WLAN 802.11a/b/g Utility, access the Security tab in the Profile Management window. 1. On the Security tab, clic…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT (For Model: DCUA-81) Page 2 (For Model: DCUA-82) Page 3

FCC ID : NKRDCUA Label Location FCC ID : NKRDCUA Label Location Model No.: DCUA-81

Page 4 (For Model: DCUA-81) Page 5 Page 6 (For Model: DCUA-82) Page 7

FCC ID: NKRDCUA Report No.RF940526L11 Technical Description The transmitter of the EUT (WLAN 802.11 a/b/g USB2.0 Adapter) is powered by 5Vdc from host equipment. The antenna is printed antenna without any connector. This device is a WLAN 802.11 a/b/g USB2.0 Adapter, which operates in both of the 5GHz and 2.4GHz bands and can not transmitting simultaneously, the maximum data rate could be 108Mbps. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

D3: DAE SN: 579

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION

A - 1 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION EUT place：Horizontal NB：Compaq EVO N800C The bottom of the EUT to the flat phantom distance 2 mm A - 2 EUT place：Vertical NB：Dell C600 The right of the EUT to the flat phantom distance 0 mm A - 3 EUT place：Horizontal NB：Compaq EVO N800C The bottom of the EUT to the flat phantom distance 0 mm A - 4 EUT place：Vertical NB：Compaq EVO N800C The left of the EUT to the flat phantom distance 0 mm A - 5 EUT place：Vertical NB：Compaq EVO N800C The right of the EUT to the flat phantom distance 0 mm A - 6 EUT place：Horizontal NB：Dell C600 The front of the EUT to the flat phantom distance 0 mm A - 7 EUT Photo A - 8 A - 9 A - 10 A - 11 Liquid Level Photo MSL 2450MHz D=152mm MSL 5000MHz D=150mm A - 12 Date/Time: 2005/6/23 09:30:27 Test Laboratory: Advance Data Technology DCUA-81 Horizontal 11b N800C Mode 1 DUT: WLAN 802.11a/b/g USB2.0 Adapter ; Type: DCUA-81 ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.95 mho/m; ε r = 54; ρ = 1000 kg/m 3 ; Liquid level : 152mm Phantom section: Flat Section ; Separation distance : 2 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.5 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 Low Channel 1/Area Scan (5x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.271 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.38 V/m Peak SAR (extrapolated) = 0.926 W/kg SAR(1 g) = 0.309 mW/g; SAR(10 g) = 0.129 mW/g Maximum value of SAR (measured) = 0.343 mW/g A - 13 Date/Time: 2005/6/23 09:47:57 Test Laboratory: Advance Data Technology DCUA-81 Horizontal 11b N800C Mode 1 DUT: WLAN 802.11a/b/g USB2.0 Adapter ; Type: DCUA-81 ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 1.99 mho/m; ε r = 53.9; ρ = 1000 kg/m 3 ; Liquid level : 152mm Phantom section: Flat Section ; Separation distance : 2 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.5 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 Mid Channel 6/Area Scan (5x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.311 mW/g Mid Channel 6/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.73 V/m Peak SAR (extrapolated) = 1.10 W/kg SAR(1 g) = 0.359 mW/g; SAR(10 g) = 0.144 mW/g Maximum value of SAR (measured) = 0.404 mW/g A - 14 A - 15 Date/Time: 2005/6/23 10:05:39 Test Laboratory: Advance Data Technology DCUA-81 Horizontal 11b N800C Mode 1 DUT: WLAN 802.11a/b/g USB2.0 Adapter ; Type: DCUA-81 ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2462 MHz; σ = 2.03 mho/m; ε r = 53.8; ρ = 1000 kg/m 3 ; Liquid level : 152mm Phantom section: Flat Section ; Separation distance : 2 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.5 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 High Channel 11/Area Scan (5x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.211 mW/g High Channel 11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.70 V/m Peak SAR (extrapolated) = 0.875 W/kg SAR(1 g) = 0.271 mW/g; SAR(10 g) = 0.102 mW/g Maximum value of SAR (measured) = 0.305 mW/g A - 16 Date/Time: 2005/6/23 10:24:17 Test Laboratory: Advance Data Technology DCUA-81 Horizontal 11g N800C Mode 2 DUT: WLAN 802.11a/b/g USB2.0 Adapter ; Type: DCUA-81 ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.95 mho/m; ε r = 54; ρ = 1000 kg/m 3 ; Liquid level : 152mm Phantom section: Flat Section ; Separation distance : 2 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.5 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.5 Build 19 ; Postprocessing SW: SEMCAD, V1.8 Build 146 Low Channel 1/Area Scan (5x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.163 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.16 V/m Peak SAR (extrapolated) = 0.508 W/kg SAR(1 g) = 0.168 mW/g; SAR(10 g) = 0.070 mW/g Maximum value of SAR (measured) = 0.184 mW/g A - 17 Date/Time: 2005/6/23 10:42:04 Test Laboratory: Advance Data Technology DCUA-81 …

Text truncated - open the document above for the full version.

FCC ID: NKRDCUA Report No.: SA940526L111Report Format Version 2.0.1 SAR TEST REPORT REPORT NO.: SA940526L11 MODEL NO.: DCUA-81, DCUA-82 RECEIVED: May 26, 2005 TESTED: Jun. 23 ~ Jun. 27, 2005 ISSUED: Jul. 14, 2005 APPLICANT: Wistron NeWeb Corp. ADDRESS: No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 56 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: NKRDCUA Report No.: SA940526L112Report Format Version 2.0.1 TABLE OF CONTENTS 1.CERTIFICATION........................................................................................................................ 3 2.GENERAL INFORMATION........................................................................................................ 4 2.1GENERAL DESCRIPTION OF EUT................................................................................ 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS................................................. 6 2.3GENERAL INOFRMATION OF THE SAR SYSTEM ....................................................... 6 2.4GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION .................... 10 3.DESCRIPTION OF SUPPORT UNITS .................................................................................... 13 4.DESCRIPTION OF TEST MODES AND CONFIGURATIONS................................................ 14 4.1.DESCRIPTION OF ANTENNA LOCATION................................................................... 14 4.2.DESCRIPTION OF ASSESSMENT POSITION ............................................................ 16 4.3.DESCRIPTION OF TEST MODE .................................................................................. 17 4.4.SUMMARY OF TEST RESULT ..................................................................................... 18 5.TEST RESULTS ...................................................................................................................... 22 5.1TEST PROCEDURES ................................................................................................... 22 5.2MEASURED SAR RESULTS ........................................................................................ 24 5.3SAR LIMITS...................................................................................................................35 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS .......................................................... 36 5.5TEST EQUIPMENT FOR TISSUE PROPERTY............................................................ 41 6.SYSTEM VALIDATION ............................................................................................................42 6.1TEST EQUIPMENT ....................................................................................................... 42 6.2TEST PROCEDURE...................................................................................................... 43 6.3VALIDATION RESULTS ................................................................................................ 45 6.4SYSTEM VALIDATION UNCERTAINTIES (For 2.4GHz) .............................................. 46 6.5SYSTEM VALIDATION UNCERTAINTIES (For 5.0GHz) .............................................. 47 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES ...................................................... 48 7.1PROBE CALIBRATION UNCERTAINTY ....................................................................... 48 7.2ISOTROPY UNCERTAINTY ......................................................................................... 49 7.3BOUNDARY EFFECT UNCERTAINTY ......................................................................... 49 7.4PROBE LINEARITY UNCERTAINTY ............................................................................ 50 7.5READOUT ELECTRONICS UNCERTAINTY ................................................................ 50 7.6RESPONSE TIME UNCERTAINTY............................................................................... 50 7.7INTEGRATION TIME UNCERTAINTY .......................................................................... 51 7.8PROBE POSITIONER MECHANICAL TOLERANCE ................................................... 52 7.9PROBE POSITIONING ................................................................................................. 52 7.10PHANTOM UNCERTAINTY .......................................................................................... 53 7.11DASY4 UNCERTAINTY BUDGET (For 2.4GHz) .......................................................... 54 7.12DASY4 UNCERTAINTY BUDGET (For 5.0 ~ 6.0GHz) ................................................. 55 8.INFORMATION ON THE TESTING LABORATORIES............................................................ 56 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: NKRDCUA Report No.: SA940526L113Report Format Version 2.0.1 1. CERTIFICATION PRODUCT : WLAN 802.11 a/b/g USB2.0 Adapter MODEL NO. : DCUA-81, DCUA-82 BRAND NAME : Wistron NeWeb APPLICANT : Wistron NeWeb Corp. TESTED : Jun. 23 ~ Jun. 27, 2005 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of th…

Text truncated - open the document above for the full version.

FCC ID: NKRDCUA Report No.: RF9405026L111Report Format Version 2.0.2 FCC TEST REPORT (15.247) REPORT NO.: RF940526L11 MODEL NO.: DCUA-81 (refer to page 7 for other Models) RECEIVED: May 26, 2005 TESTED: May 30 ~ Jun. 13, 2005 ISSUED: Jun. 15, 2005 APPLICANT: Wistron NeWeb Corp. ADDRESS: No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 126 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: NKRDCUA Report No.: RF9405026L112Report Format Version 2.0.2 Table of Contents 1.CERTIFICATION ......................................................................................................5 2.SUMMARY OF TEST RESULTS ..............................................................................6 2.1 MEASUREMENT UNCERTAINTY ...........................................................................6 3.GENERAL INFORMATION.......................................................................................7 3.1GENERAL DESCRIPTION OF EUT.........................................................................7 3.2DESCRIPTION OF TEST MODES...........................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ...................................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL: ........................ 10 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................12 3.4DESCRIPTION OF SUPPORT UNITS ...................................................................12 4.TEST TYPES AND RESULTS (802.11b & g 2412~2462MHz BAND)....................13 4.1CONDUCTED EMISSION MEASUREMENT .........................................................13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 13 4.1.2 TEST INSTRUMENTS............................................................................................ 13 4.1.3 TEST PROCEDURES ............................................................................................ 14 4.1.4 DEVIATION FROM TEST STANDARD .................................................................. 14 4.1.5 TEST SETUP ......................................................................................................... 15 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 15 4.1.7 TEST RESULTS ..................................................................................................... 16 4.2RADIATED EMISSION MEASUREMENT ..............................................................28 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................ 28 4.2.2 TEST INSTRUMENTS............................................................................................ 29 4.2.3 TEST PROCEDURES ............................................................................................ 30 4.2.4 DEVIATION FROM TEST STANDARD .................................................................. 30 4.2.5 TEST SETUP ......................................................................................................... 31 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 31 4.2.7 TEST RESULTS ..................................................................................................... 32 4.36dB BANDWIDTH MEASUREMENT .....................................................................41 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .........................…
