NKRDMUZ802.11g WLAN USB Adapter with Flash Disk

0 802.11g WLAN USB Adapter with Flash Disk User’s Manual Model DMUZ Wistron Neweb Corporation Version 1.5__May, 2005 1 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Windows TM 98SE/Me/2000/XP are trademarks of Microsoft ® Corp. Pentium is a trademark of Intel. All copyright reserved. 2 Regulatory Information Federal Communication commission interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the use is encouraged to try to correct the interference by one of the following measures: ??Reorient or relocate the receiving antenna. ??Increase the separation between the equipment and receiver. ??Connect the equipment into an outlet on a circuit different form that to which the receiver is connected. ??Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example-use only shielded interface cables when connecting to computer or peripheral devices) any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device many not cause harmful interference, and (2) This device may accept any interference received, including interference that may cause undesired operation. 3 Important Notice: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The maximum reported SAR values are: Body: 0.284W/Kg (802.11b), 0251W/Kg (802.11g) 3 Table of Contents 1. Introduction............................................................................................................................4 1.1 Package Contents.......................................................................................................4 1.2 Main Features..............................................................................................................4 1.3 Wireless Network Scenarios.......................................................................................5 1.3.1 Ad Hoc Mode...................................................................................................5 1.3.2 Cooperate LAN (Local Area Networking)........................................................6 1.4 Advantages for Using Wireless Network.....................................................................6 2. Quick Start Guidance.............................................................................................................8 2.1 Installation...................................................................................................................8 2.2 Connecting to an Existing Network...........................................................................10 2.3 Connecting to an Access Point (AP).........................................................................16 3. Installation by Steps.............................................................................................................18 3.1 Installing WLAN 802.11g USB2.0 Adapter................................................................18 3.1.1 Additional Setup Processes...........................................................................21 3.2 Setting Your 802.11g USB2.0 Adapter......................................................................22 3.3 Removing Your 802.11g USB2.0 Adapter.................................................................22 3.4 Uninstalling Your 802.11g USB2.0 Adapter...............................................................23 4. Creating an Ad Hoc Network................................................................................................24 5. Acting as an Access Point....................................................................................................26 6. Using the Utility (Client)........................................................................................................29 6.1 Link Status Tab..........................................................................................................29 6.2 Configure Profile Tab.................................................................................................30 6.3 Site Survey Tab.........................................................................................................31 6.4 Advance Tab..............................................................................................................32 7. Using the Utility (AP)............................................................................................................33 7.1 AP Information Tab....................................................................................................33 7.2 Access Point Setting Tab...........................................................................................34 8. Network Application................................................................................................…

Text truncated - open the document above for the full version.

Rev 2 C:\tmp\05LR017 DMUZ\FCC\AP FORM.doc 02/08/02 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue McLean, VA 22101 Ph: (703) 847-4700 FAX: (703) 847-6888 Certification Application Package AmericanTCB CERTIFICATION APPLICATION Rev 2 C:\tmp\05LR017 DMUZ\FCC\AP FORM.doc 02/08/02 Wistron NeWeb Corporation No. 10-1, Li-hsin Road I, Science-based Industrial Park Hsinchu 300, Taiwan, R. O. C. This TESTING AND CERTIFICATION AGREEMENT ("Agreement") is made effective as of the latter date of execution below, by and between American Telecommunication Certification Body (ATCB) and Wistron NeWeb Corporation (Applicant), collectively referred to as "the Parties". Equipment Description Equipment Description: 802.11g WLAN USB Adapter with Flash Disk Model Number: DMUZ FCC Rule Part(s): 15C In consideration of the mutual covenants in this Agreement, ATCB or its subcontractors will perform certification inspection services to determine if Applicant's device(s) identified above under Equipment Description (hereinafter "Devices") are in compliance with the laws, regulations and technical standards (hereinafter "Certification Regulations") of the national authorities specified by Applicant in Schedule A. 1. General 1.1 This Agreement is for the purpose of testing and certification and applies to all tests, audits, and certifications for the Devices, and will be performed in accordance with the Certification Regulations of the national authorities specified in Schedule A. 1.2 ATCB retains full discretion to determine if the Devices are compliant with the Certification Regulations of the Countries. In the event that certification is not issued for the aforementioned Devices, ATCB agrees to advise Applicant in writing of the reasons thereof. 1.3 This Agreement may not be assigned to or acquired by any other person, firm, or corporation without ATCB's written authorization. 2. Scope of Performance 2.1 The scope of performance between the Parties shall be agreed to by contract, purchase order or other mutually agreed-upon schedule or order. 2.2 Except as provided in Section 2.3 hereof, testing of all Devices shall take place at ATCB facilities. 2.3 In lieu of section 2.2 above, ATCB may agree to accept test data from any ISO/IEC Guide 25 accredited laboratory or FCC-Listed Laboratory and evaluate the Devices on the basis of this data. ATCB may also choose to accept test data from ISO Guide 25 accredited laboratories owned by Applicant, provided the requirements of 2.3.1. are met. 2.3.1 Employees of Applicant shall not participate in any tests, evaluations, or assessments described in sections 2.2 or 2.3 above without the presence and supervision of an ATCB engineer or technician. 2.4 If requested for sample purposes (as required by the FCC), client shall supply ATCB, at no charge, with at least one test sample of each Device, including the necessary peripherals, connecting cables, accessories or other hardware or software (hereinafter collectively referred to as "support equipment") required for testing, evaluation, and assessment. 2.5 Applicant shall supply ATCB, at no charge, with all technical documentation and materials required for the testing, evaluation, and assessment of such Devices and support equipment. 2.5.1 Technical documentation and materials include, but are not limited to, any relevant operating instructions, schematics, block diagrams, photographs, prior tests and certificates concerning the safety of the Devices, its components or support equipment. 2.6 Applicant recognizes that Device samples, including support equipment, may be damaged or completely destroyed when subjected to ATCB's testing and evaluation process. Applicant shall hold ATCB harmless for any such damage or destruction to its equipment. 2.7 If necessary ATCB shall test, evaluate, or assess Applicant's equipment within 30 business days of ATCB's receipt of such Devices, support equipment and technical documentation, and to work diligently until certification is granted or denied, or Applicant decides to abandon testing, evaluation, and assessment on such Devices. AmericanTCB CERTIFICATION APPLICATION Rev 2 C:\tmp\05LR017 DMUZ\FCC\AP FORM.doc 02/08/02 2.8 Upon completion of testing, evaluation, or assessment, ATCB shall advise Applicant via an abbreviated report whether the results are favorable, and what, if any, conditions, limitations or qualifications to the requested Certification exist. 2.9 Applicant agrees that a full report is available to Applicant only by special request, and for the separate charge specified. 2.10 Where testing, evaluation, and assessment results in certification, ATCB shall certify Applicant's equipment as compliant with the laws, regulations and/or standards of the Countries within 30 business days from the date testing, evaluation, and assessment is completed. 2.10.1 Section 2.11 may be dependent upon a timely response by the United States Federal Communications Commission (FCC) or its foreign equivalent. 2.10.2 In the event of product certification, Applicant may request that ATCB return or destroy Applicant's Device sample(s), equipment support, and technical documentation. Applicant shall bear all costs associated with the return or destruction of such equipment test sample(s) and support equipment. 2.11 Where testing, evaluation, and assessment does not result in certification, ATCB shall provide cost-free storage for each Device sample, support equipment, and technical documentation for a period not to exceed 30 days, provided Applicant agrees to re-testing within this period when notified of the Device's failure. 2.12 If Applicant does not collect or accept receipt of the Device sample(s), support equipment and technical documentation, despite ATCB having sent notice pursuant to subsection 2.12.1, ATCB reserves the right to dispose of them at Applicant's expense. 2.13 Applicant shall retain all documents forwarded to it by ATCB as required by the Certification Regula…

Text truncated - open the document above for the full version.

International Standards Laboratory Report Number: ISL-05LR017P HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 -1- EUT-1. International Standards Laboratory Report Number: ISL-05LR017P HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 -2- EUT-2. International Standards Laboratory Report Number: ISL-05LR017P HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 -3- EUT-3 International Standards Laboratory Report Number: ISL-05LR017P HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 -4- EUT-4 .

Label Label Location Warning statement Label

International Standards Laboratory Report Number: ISL-05LR017P HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 EUT-1 . International Standards Laboratory Report Number: ISL-05LR017P HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 EUT-2 .

Report No： 056H102SF SAR Test Report Product Name ： 802.11g WLAN USB Adapter with Flash Disk Model No. ： DMUZ Applicant ：Wistron Neweb Corporation Address ：NO.10-1,Li-hsin Road 1, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. Date of Receipt：2005/06/23 Issued Date ：2005/06/24 Report No. ：056H102SF The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Page: 1 of 116 Version:1.0 Report No： 056H102SF Page: 2 of 116 Version:1.0 Test Report Certification Issued Date: 2005/06/24 Report No.:056H102SF Product Name ： 802.11g WLAN USB Adapter with Flash Disk Applicant ： Wistron Neweb Corporation Address ： NO.10-1,Li-hsin Road 1, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. Manufacturer ： Wistron Neweb Corporation Model No. ： DMUZ Applicable Standard ： FCC Oet65 Supplement C June 2001 Test Result ： Max. SAR Measurement (1g) 802.11b: 0.284 W/kg 802.11g: 0.251 W/kg Application Type Certification The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Documented By ： (Rita Haung ) Tested By ： (Hsiu Ho) Approved By ： (Gene Chang) Report No： 056H102SF TABLE OF CONTENTS Description Page 1. General Information.............................................................................. 5 1.1 EUT Description............................................................................................................ 5 1.2 Test Environment...........................................................................................................5 2. SAR Measurement System.................................................................. 6 2.1 ALSAS-10U System Description.................................................................................. 6 2.1.1 Applications................................................................................................................ 6 2.1.2 Area Scans................................................................................................................... 6 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 7 2.1.4 ALSAS-10U Interpolation and Extrapolation Uncertainty......................................... 7 2.2 Isotropic E-Field Probe.................................................................................................. 7 2.2.1 Isotropic E-Field Probe Specification......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device................................................. 9 2.4 Daq-Paq (Analog to Digital Electronics)..................................................................... 10 2.5 Axis Articulated Robot................................................................................................ 10 2.6 ALSAS Universal Workstation.................................................................................... 11 2.7 Universal Device Positioner......................................................................................... 11 2.8 Phantom Types............................................................................................................. 11 2.8.1 APREL SAM Phantoms........................................................................................... 12 2.8.2 APREL Laboratories Universal Phantom................................................................. 12 3. Tissue Simulating Liquid................................................................... 13 3.1 The composition of the tissue simulating liquid.......................................................... 13 3.2 Tissue Calibration Result............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms....................................... 14 4. SAR Measurement Procedure........................................................... 15 4.1 SAR System Validation................................................................................................ 15 4.1.1 Validation Dipoles..................................................................................................... 15 4.1.2 Validation Result....................................................................................................... 15 4.2 SAR Measurement Procedure...................................................................................... 16 5. SAR Exposure Limits......................................................................... 17 6. Test Equipment List............................................................................ 18 7. Measurement Uncertainty.................................................................. 19 8. Test Results......................................................................................... 20 8.1 SAR Test Results Summary......................................................................................... 20 8.2 SAR System Validation Data....................................................................................... 22 8.3 SAR Measurement Data............................................................................................... 26 Page: 3 of 116 Version:1.0 Report No： 056H102SF Test Setup Photographs...................................................................................................... 80 EUT Photographs............................................................................................................... 83 Probe Calibration............................................................................................................... 86 Dipole Calibration............................................................................................................ 106 Page: 4 of 116 Version:1.0 Report No： 056H102SF …

Text truncated - open the document above for the full version.

Report No： 056H102SF Page: 101 of 116 Version:1.0 Report No： 056H102SF Page: 102 of 116 Version:1.0 Report No： 056H102SF Page: 103 of 116 Version:1.0 Report No： 056H102SF Page: 104 of 116 Version:1.0 Report No： 056H102SF Page: 105 of 116 Version:1.0 Report No： 056H102SF Dipole Calibration Page: 106 of 116 Version:1.0 Report No： 056H102SF Page: 107 of 116 Version:1.0 Report No： 056H102SF Page: 108 of 116 Version:1.0 Report No： 056H102SF Page: 109 of 116 Version:1.0 Report No： 056H102SF Page: 110 of 116 Version:1.0 Report No： 056H102SF Page: 111 of 116 Version:1.0 Report No： 056H102SF Page: 112 of 116 Version:1.0 Report No： 056H102SF Page: 113 of 116 Version:1.0 Report No： 056H102SF Page: 114 of 116 Version:1.0 Report No： 056H102SF Page: 115 of 116 Version:1.0

Report Number: ISL-05LR017FC Issue Date: 2005/06/23 HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 ISL-T10-R29-1 Test Report for FCC Part 15 Subpart B & C of Product Name 802.11g WLAN USB Adapter with Flash Disk Model DMUZ (Brand: Wistron Neweb) Applied by: Wistron Neweb Corporation No. 10-1, Li-hsin Road 1, Science-based Industrial Park,Hsinchu 300, Taiwan, R. O. C. Test Performed by: International Standards Laboratory No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325 Taiwan, R.O.C. Tel:(03)407-1718 Fax:(03)407-1738 FCC ID:NKRDMUZ International Standards Laboratory Report Number: 05LR017FC HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 -i- Contents of Report 1. General........................................................................................................1 1.1 Certification of Accuracy of Test Data.........................................................................1 2. Test Results Summary.............................................................................2 3. Description of Equipment Under Test (EUT)....................................3 4. TEST RESULTS (802.11b).............................................................4 4.1 Powerline Conducted Emissions [Section 15.207]......................................................4 4.1.1 EUT Configuration..................................................................................................................4 4.1.2 Test Procedure..........................................................................................................................4 4.1.3 EMI Receiver/Spectrum Analyzer Configuration (for the frequencies tested).4 4.1.4 Test Data:....................................................................................................................................5 4.2 Bandwidth for DSSS [Section 15.247 (a)(2)]...............................................................7 4.2.1 Test Procedure..........................................................................................................................7 4.2.2 Test Setup...................................................................................................................................7 4.2.3 Test Data:....................................................................................................................................7 4.3 DSSS Maximum Peak Output Power [Section 15.247 (b)(1)]...................................10 4.3.1 Test Procedure........................................................................................................................10 4.3.2 Test Setup.................................................................................................................................10 4.3.3 Test Data...................................................................................................................................10 4.4 Radiated Emission Measurement [Section [15.247(c)(4)].........................................11 4.4.1 EUT Configuration................................................................................................................11 4.4.2 Test Procedure........................................................................................................................11 4.4.3 EMI Receiver/Spectrum Analyzer Configuration (for the frequencies tested)11 4.4.4 Test Data (30MHz – 1GHz):.............................................................................................12 4.4.5 Test Data ( 1GHz – 25 GHz) ............................................................................................13 4.5 Band Edge Measurement............................................................................................16 4.5.1 Test Procedure (Conducted)..............................................................................................16 4.5.2 Test Setup (Conducted).......................................................................................................16 4.5.3 Test Data:..................................................................................................................................16 4.5.4 Test Procedure (Radiated)..................................................................................................18 4.5.5 Test Setup (Radiated)...........................................................................................................18 4.5.6 Test Data...................................................................................................................................19 4.6 RF Exposure Measurement [Section 15.247(b)(4) & 1.1307(b)]...............................22 4.7 DSSS Peak Power Spectral Density [Section 15.247(d) ]..........................................23 4.7.1 Test Procedure........................................................................................................................23 4.7.2 Test Setup.................................................................................................................................23 4.7.3 Test Data...................................................................................................................................23 5. TEST RESULTS (802.11g)...........................................................26 5.1 Powerline Conducted Emissions [Section 15.207]....................................................26 5.1.1 EUT Configuration................................................................................................................26 5.1.2 Test Procedure........................................................................................................................26 5.1.3 EMI …

Text truncated - open the document above for the full version.

-28- FCC ID: NKRDMUZ International Standards Laboratory Report Number: 05LR017FC HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 Power Line Conducted Emissions (Neutral) Channel 1, 6, 11 Operator:MailesHsieh Temperature(C):29 03:47:40PM,Thursday,June16,2005 Humidity(%):54 Frequency LISNLoss CableLoss QPCorrct. QPLimit QPMargin AVECorrct. AVELimit AVEMargin MHz (dB) (dB) Amp.(dBuV) (dBuV) (dB) Amp.(dBuV) (dBuV) (dB) 0.47578 0.11 0.07 37.73 56.69 -18.97 35.65 46.69 -11.04 0.55576 0.13 0.07 36.31 56.00 -19.69 34.63 46.00 -11.37 0.63493 0.14 0.07 36.24 56.00 -19.76 35.54 46.00 -10.46 0.88580 0.18 0.07 27.30 56.00 -28.70 17.15 46.00 -28.85 0.95048 0.19 0.07 32.94 56.00 -23.06 30.14 46.00 -15.86 1.74593 0.20 0.08 36.05 56.00 -19.95 33.99 46.00 -12.01 1.98459 0.20 0.09 36.54 56.00 -19.46 33.55 46.00 -12.45 2.30169 0.20 0.10 37.37 56.00 -18.63 36.47 46.00 -9.53 2.38217 0.20 0.10 36.87 56.00 -19.13 34.55 46.00 -11.45 2.62151 0.20 0.11 36.67 56.00 -19.33 34.45 46.00 -11.55 * NOTE: During the test, the EMI receiver was set to Max. Hold then switch the EUT Channel between 1 , 6, 11 to get the maximum reading of all these channels. Margin = Amplitude + Insertion Loss- Limit A margin of -8dB means that the emission is 8dB below the limit CISPR22 Class B International Standards Laboratory Conduction 02 Neutral Class B Test Graph 100.0K1.0M10.0M100.0M Frequency ( Hz ) 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 Amplitude ( dBuV ) Operator: Mailes Hsieh Limit_QP Limit_AV NBand1_1 NBand2_1 PK Read QP Read AVG Read -29- FCC ID: NKRDMUZ International Standards Laboratory Report Number: 05LR017FC HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 5.2 Bandwidth for DSSS [Section 15.247 (a)(2)] 5.2.1 Test Procedure The Transmitter output of EUT was connected to the spectrum analyzer. The 6 dB bandwidth of the fundamental frequency was measured. The setting of spectrum analyzer is as follows Equipment mode Spectrum analyzer Detector function Peak mode RBW 100KHz VBW 100KHz 5.2.2 Test Setup 5.2.3 Test Data: 6dB Bandwidth Test Engineer:Mailes Hsieh Temperature ():27 Humidity (%):55 Frequency 6dB Bandwidth Limit Channel (MHz) (MHz) (MHz) Pass/Fail 1 2412 16.56 0.5 Pass 6 2437 16.60 0.5 Pass 11 2462 16.56 0.5 Pass EUT Spectrum Analyzer -30- FCC ID: NKRDMUZ International Standards Laboratory Report Number: 05LR017FC HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 Channel 1: Channel 6: -31- FCC ID: NKRDMUZ International Standards Laboratory Report Number: 05LR017FC HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 Channel 11: -32- FCC ID: NKRDMUZ International Standards Laboratory Report Number: 05LR017FC HC LAB:NVLAP:200234-0;VCCI: R-341,C-354;NEMKO:ELA 113a,113c;BSMI:SL2-IN-E-0037;SL2-R1-E-0037;CNLA:1178 LT LAB:NVLAP:200234-0;VCCI: R-1435,C-1440;NEMKO:ELA 113b,113d;BSMI:SL2-IN-E-0013;CNLA:0997 5.3 DSSS Maximum Peak Output Power [Section 15.247 (b)(1)] 5.3.1 Test Procedure The Transmitter output of EUT was connected to the peak power analyzer. 5.3.2 Test Setup 5.3.3 Test Data Maximum P…

Text truncated - open the document above for the full version.
