NKRDRUAWLAN 802.11G USB ADAPTER

WLAN 802.11G USB ADAPTER User’s Guide Version: 1.0 — Sep 2004 1 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Windows™ 2000/XP are trademarks of Microsoft® Corp. Atheros is a registered trademark of Atheros Communications, Inc. All copyright reserved. 2 Regulatory Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. We declare that the product is limited in CH1~CH11 by specified firmware controlled in the USA 3 Table of Contents REGULATORY INFORMATION.............................................................................................................2 1. WELCOME...............................................................................................................................................5 1.1 KIT CONTENTS......................................................................................................................................5 1.2 MAIN FEATURES OF 802.11G USB 2.0 ADAPTER................................................................................5 1.3 WIRELESS NETWORKING SCENARIOS..................................................................................................6 2. QUICK START TO WIRELESS NETWORKING............................................................................8 2.1 INSTALLATION.......................................................................................................................................8 2.2 CONNECTING TO AN EXISTING NETWORK...........................................................................................9 3. STEP-BY-STEP INSTRUCTIONS......................................................................................................10 3.1 INSTALLATION.....................................................................................................................................10 3.2 CONNECTING TO A NETWORK.............................................................................................................15 3.3 CREATING AN AD HOC NETWORK.....................................................................................................19 3.4 REMOVING YOUR 802.11G USB 2.0 ADAPTER..................................................................................21 3.5 UNINSTALLATION................................................................................................................................22 4. USING THE UTILITY..........................................................................................................................24 4.1 CURRENT STATUS...............................................................................................................................24 4.2 DIAGNOSTICS......................................................................................................................................25 4.3 PROFILE MANAGEMENT.....................................................................................................................28 4.3.1 Creating or Modifying a Configuration Profile......................................................................28 4.3.2 Removing a Profile....................................................................................................................32 4.3.3 Profile Auto Selection................................................................................................................32 4.3.4 Switching Profiles......................................................................................................................33 4.4 SECURITY............................................................................................................................................34 4.4.1 Using EAP-TLS Security...................................................................................…

Text truncated - open the document above for the full version.

25 n Advanced: Click Advanced button to view related info of SSID, Encryption, Current Power Level or Channel etc. 4.2 Diagnostics In Diagnostics tab, you can check Transmit and Receive Data: Multicast Packets, Broadcast Packets, Unicast Packets and Total Bytes. 26 Adapter Information n Card Name: The name of the wireless network adapter. n MAC Address: The MAC address of the wireless network adapter. n Driver: The driver name and path of the wireless network adapter driver. n Driver Version: The version of the wireless network adapter driver. n Driver Date: The creation date of the wireless network adapter driver. n Client Name: The name of the client computer. Advanced Statistics: Shows receive and transmit statistical information for the following receive and transmit diagnostics for frames received by or transmitted to the wireless network adapter: 27 Transmitted Frames: n Frames transmitted OK n Frames retried n Frames dropped n No ACK frames n ACK frames n RTS Frames n Clear-to-send (CTS) Frames n No CTS frames n Retried RTS frames n Retried data frames Received Frames: n Frames received OK n Beacons n Frames with errors n CRC errors n Encryption errors n Duplicate frames n AP mismatches n Data rate mismatches n Authentication time-out n Authentication rejects: the number of AP authentication failures received by the wireless network adapter n Association time-out n Association rejects: the number of access point authentication rejects received by the wireless network adapter n Standard MIC OK n Standard MIC errors n CKIP MIC OK n CKIP MIC errors 28 4.3 Profile Management n Network Type: Indicates whether the current activated network type is Infrastructure or Ad Hoc mode. n Security Mode: Indicates current connected network’s security mode. n Network Name: Indicates current connected network’s name. n New: To create new profile. n Modify: To edit settings of chosen profile. n Remove: To remove the chosen profile from the list. n Activate: To activate the chosen profile. n Import: To import a pre-set profile (pre-saved as a Config File *.prf) n Export: To export the chosen profile, so you can save the profile as a Config File (*.prf) for future use. n Scan: To scan all available network in vicinity. n Order Profiles: To place the order of preferred profiles. 4.3.1 Creating or Modifying a Configuration Profile 1. To add a New configuration profile, click New on the Profile Management tab. To modify a configuration profile, select the configuration from the Profile list and click the Modify button. 2. The Profile Management dialog box displays the General, Security and Advanced tabs. 29 3. Edit the fields in the General tab to configure the configuration profile. n Profile Name: Identifies the configuration profile. This name should be unique. Profile names are not case sensitive. n Client Name: Identifies the client machine. n Network Names (SSIDs): The IEEE 802.11 wireless network name. This field has a maximum limit of 32 characters. Configure up to three SSIDs (SSID1, SSID2, SSID3). 4. Edit the fields in the Security tab to configure the configuration profile. n WPA/WPA2: Enables the use of Wi-Fi Protected Access (WPA). 30 n WPA Passphrase: Enables WPA Passphrase security. Click on the Configure button and fill in the WPA Passphrase. n 802.1x: Enables 802.1x security. This option requires IT administration. n Pre-Shared Key (Static WEP): Enables the use of pre-shared keys that are defined on both the access point and the station. n None: No security (not recommended). 5. Edit the fields in the Advanced tab to configure the configuration profile. n Transmit Power Level: Selects the transmit power level for 802.11b/g in mW. Actual transmit power may be limited by regulatory domain or hardware limitations. n Power Save Mode: Specify: ̧ Maximum mode: causes the access point to buffer incoming messages for the wireless adapter. The adapter up periodically polls the access point to see if any messages are waiting. ̧ Normal mode: uses maxim when retrieving a large number of packets, then switches back to power save mode after retrieving the packets. ̧ Off: turns power saving off, thus powering up the wireless adapter continuously for a short message response time. n Network Type: Specifies the network as either Infrastructure or Ad Hoc. n 802.11b Preamble: Specifies the preamble setting in 802.11b. The default setting is Short & Long (access point mode), which allows both short and long headers in the 802.11b frames. The adapter can only use short radio headers if the access point supports and uses them. Set to Long Only to 31 override allowing short frames. n Wireless Mode: Specifies 2.4GHz 54Mbps, 2.4GHz 11Mbps, or Super G operation in an access point network. The wireless adapter must match the wireless mode of the access point it associates to. n Wireless Mode when Starting Ad Hoc Network: Specifies 2.4GHz 54/11Mbps, to start an Ad Hoc network if no matching network name is found after scanning all available modes. This mode also allows selection of the channel the wireless adapter uses. The channels available depend on the regulatory domain. If the adapter finds no other ad hoc adapters, this selection specifies which channel with the adapter starts the Ad Hoc network with. The wireless adapter must match the wireless mode of the access point it associates to. n 802.11 Authentication Mode: Select what mode the wireless adapter uses to authenticate to an access point: ̧ Auto: causes the adapter to attempt authentication using shared, but switches it to open authentication if shared fails. ̧ Open: enables an adapter to attempt authentication regardless of its WEP settings. It will only associate with the access point if the WEP keys on both the adapter and the access point match. ̧ Shared: only allows the adapter to associate with access points that have the same WEP key. n Preferred APs: User can set up to five preferred APs. 32 4.3.2 Removing a Profile 1. Go to the Profile Manageme…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT MODEL NO.: DRUA Page 2 MODEL NO.: Vigor600 Page 3 Page 4

Page 1 Label location FCC ID: NKRDRUA

Page 5 Page 6 Page 7

FCC ID: NKRDRUA Report No.RF941110L05 Operational Description This device is a WLAN 802.11G USB ADAPTER which operates in the 2.4GHz frequency spectrum with throughput of up to 108Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 108Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is Print antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

D3: DAE SN: 579

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

A - 1 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION The bottom of the EUT to the flat phantom distance 6 mm A - 2 The edge of the EUT to the flat phantom distance 5 mm A - 3 EUT Photo Reference Point A - 4 A - 5 Liquid Level Photo MSL 2450MHz D=151mm A - 6 Date/Time: 2005/11/29 11:19:54 Test Laboratory: Advance Data Technology N800C-11b-Ch1-Mode 1 DUT: WLAN 802.11G USB ADAPTER ; Type: DRUA ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.97 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 151 mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.1 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 Low Channel 1/Area Scan (5x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.866 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.30 V/m Peak SAR (extrapolated) = 1.95 W/kg SAR(1 g) = 0.792 mW/g; SAR(10 g) = 0.330 mW/g Maximum value of SAR (measured) = 0.915 mW/g A - 7 Date/Time: 2005/11/29 11:37:29 Test Laboratory: Advance Data Technology N800C-11b-Ch6-Mode 1 DUT: WLAN 802.11G USB ADAPTER ; Type: DRUA ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 2.01 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 ; Liquid level : 151 mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.1 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 Mid Channel 6/Area Scan (5x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.872 mW/g Mid Channel 6/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.26 V/m Peak SAR (extrapolated) = 2.03 W/kg SAR(1 g) = 0.812 mW/g; SAR(10 g) = 0.337 mW/g Maximum value of SAR (measured) = 0.913 mW/g A - 8 A - 9 Date/Time: 2005/11/29 11:53:51 Test Laboratory: Advance Data Technology N800C-11b-Ch11-Mode 1 DUT: WLAN 802.11G USB ADAPTER ; Type: DRUA ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2462 MHz; σ = 2.05 mho/m; ε r = 50.7; ρ = 1000 kg/m 3 ; Liquid level : 151 mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.1 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 High Channel 11/Area Scan (5x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.913 mW/g High Channel 11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.17 V/m Peak SAR (extrapolated) = 1.97 W/kg SAR(1 g) = 0.785 mW/g; SAR(10 g) = 0.327 mW/g Maximum value of SAR (measured) = 0.895 mW/g A - 10 Date/Time: 2005/11/29 12:18:28 Test Laboratory: Advance Data Technology N800C-11g-Ch1-Mode 2 DUT: WLAN 802.11G USB ADAPTER ; Type: DRUA ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.97 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 151 mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.1 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2005/3/23 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 Low Channel 1/Area Scan (5x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.536 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.19 V/m Peak SAR (extrapolated) = 1.16 W/kg SAR(1 g) = 0.479 mW/g; SAR(10 g) = 0.202 mW/g Maximum value of SAR (measured) = 0.544 mW/g A - 11 Date/Time: 2005/11/29 12:34:43 Test Laboratory: Advance Data Technology N800C-11g-Ch6-Mode 2 DUT: WLAN 802.11G USB ADAPTER ; Type: DRUA ; Test Frequency: 2437 MHz Communication System: 802.11g ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 2.01 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 ; Liquid level : 151 mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.1 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - S…

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION

FCC ID: NKRDRUA Report no.: SA941110L051Report Format Version 2.0.2 SAR TEST REPORT REPORT NO.: SA941110L05 MODEL NO.: DRUA (refer to page 4 for other model) RECEIVED: Nov. 10, 2005 TESTED: Nov. 29, 2005 ISSUED: Nov. 30, 2005 APPLICANT: Wistron NeWeb Corp. ADDRESS: No. 10-1, Li-hsin Road I, Hsinchu Science Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 36 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: NKRDRUA Report no.: SA941110L052Report Format Version 2.0.2 TABLE OF CONTENTS 1.CERTIFICATION.......................................................................................................3 2.GENERAL INFORMATION........................................................................................4 2.1GENERAL DESCRIPTION OF EUT.......................................................................4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS.........................................5 2.3GENERAL INOFRMATION OF THE SAR SYSTEM................................................5 2.4GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION...............8 3.DESCRIPTION OF SUPPORT UNITS....................................................................12 4.DESCRIPTION OF TEST MODES AND CONFIGURATIONS.................................13 4.1.DESCRIPTION OF ANTENNA LOCATION...........................................................13 4.2.DESCRIPTION OF ASSESSMENT POSITION.....................................................14 4.3.DESCRIPTION OF TEST MODE..........................................................................15 4.4.SUMMARY OF TEST RESULTS...........................................................................15 5.TEST RESULTS......................................................................................................16 5.1TEST PROCEDURES..........................................................................................16 5.2MEASURED SAR RESULTS................................................................................18 5.3SAR LIMITS..........................................................................................................20 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS..................................................21 5.5TEST EQUIPMENT FOR TISSUE PROPERTY....................................................23 6.SYSTEM VALIDATION............................................................................................24 6.1TEST EQUIPMENT..............................................................................................24 6.2TEST PROCEDURE.............................................................................................25 6.3VALIDATION RESULTS........................................................................................27 6.4SYSTEM VALIDATION UNCERTAINTIES............................................................28 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES........................................29 7.1.PROBE CALIBRATION UNCERTAINTY...............................................................29 7.2.ISOTROPY UNCERTAINTY.................................................................................30 7.3.BOUNDARY EFFECT UNCERTAINTY.................................................................30 7.4.PROBE LINEARITY UNCERTAINTY....................................................................31 7.5.READOUT ELECTRONICS UNCERTAINTY........................................................31 7.6.RESPONSE TIME UNCERTAINTY......................................................................31 7.7.INTEGRATION TIME UNCERTAINTY..................................................................32 7.8.PROBE POSITIONER MECHANICAL TOLERANCE...........................................33 7.9.PROBE POSITIONING.........................................................................................33 7.10.PHANTOM UNCERTAINTY..................................................................................34 7.11.DASY4 UNCERTAINTY BUDGET........................................................................35 8.INFORMATION ON THE TESTING LABORATORIES.............................................36 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: NKRDRUA Report no.: SA941110L053Report Format Version 2.0.2 1. CERTIFICATION PRODUCT: WLAN 802.11G USB ADAPTER MODEL: DRUA (refer to page 4 for other model) BRAND: Wistron NeWeb (refer to page 4 for other brand) APPLICANT: Wistron NeWeb Corp. TESTED: Nov. 29, 2005 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY :, DATE:Nov. 30, 2005 Andrea Hsia TECHNICAL ACCEPTANCE:, DATE:Nov. 30, 2005 Responsible for RF Stanely Hsu APPROVED BY:, DATE:Nov. 30, 2005 Cody Chang / Deputy Manager FCC ID: NKRDRUA Report no.: SA941110L054Report Format Version 2.0.2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT WLA…
