NKRM2M6270TDKM2M Development Kit

1/20 M2M6270T User Guide The document of content is consist of 3 part: Section A: Main Board user guide A-1. Function description of all key components A-2. Jumper setting Section B: Adapter Board user guide B-1. Function description of all key components B-2. Jumper setting Section C: Jumper default setting Section A: Main Board user guide A-1.Function description of all key components 2/20 M2M6270T User Guide Interface board connection directions: a. DC jack The adapter must be in the range 5V~6.5V and can supply over 1.5A. b. DC power switch Switch to right direction for supplying VBAT to the module. Otherwise, switch to left direction to turn off VBAT. 3/20 M2M6270T User Guide c. USIM socket The purpose of the socket is to insert SIM card. d. Micro USB This USB has some main functions: (a) Download firmware. (b)Send AT command. (c)Trace GPS log e. Adaptor board Conn. This is for the purpose of connecting main board and adaptor board. f. SD card socket The purpose of the socket is to insert SD card or some SDIO interface module. g. Audio in (mic) This is a differential input microphone.The audio generator can generate a tone to 6270T module through this jack for testing. h. Accessory board Conn. (HPGP) This is for the purpose of connecting main board and accessory board(HPGP). i. Power key Press this key to power on/off 6270T module. j. RS232 Conn for UART&GPIO24~GPIO27 This is a stacked DSUB-9 connector. The upper one is for QSC6270T UART and the other is reserved for GSBI UARTs in the future (like 9x15). k. RS232 Conn for GPIO21,GPIO22,GPIO34&GPIO35 These DSUB-9 connectors are reserved for GSBI UARTs in the future (like 9x15). 4/20 M2M6270T User Guide l. PCM CODEC input The analog audio pass through this jack and encoded by PCM CODEC(TLV320AIC1110). m. PCM CODEC output 6270T PCM signals are decoded by PCM CODEC(TLV320AIC1110) and Output from this audio jack. n. Audio output(Speaker) This is analog audio output path of 6270T module o. Battery Conn This is battery connector which supplies VBAT to 6270T module. A-2. JUMP setting A-2.1 VREG_IN: JP2.1 short to JP2.2  Translated to 5V/3.3V/1.8V/1.2V from adapter. JP2.2 short to JP2.3  Translated to 5V/3.3V/1.8V/1.2V from battery. 5/20 M2M6270T User Guide A-2.2 Battery charger switch JP19.1 short to JP19.2 Use internal (QSC6270T) charger function. JP19.2 short to JP19.3 Use external (charger IC on main board) charger function. A-2.3 BATT_THERM to Charge IC Short this JP4 to connect BATT_THERM to external charge IC on main board. 6/20 M2M6270T User Guide A-2.4 BATT_THERM to Fuel Gauge IC Short this jump(JP5) to connect BATT_THERM to Fuel Gauge IC thermostat. To avoid BATT_THERM read interference, if short JP5, suggest to remove JP6 jump (Disconnect BATT_THERM with QSC6270T). A-2.5 Battery thermostat switch JP21.1 short to JP21.2 Use 22kΩ resistor as battery thermostat for testing. JP21.2 short to JP21.3 Use the real external battery thermostat. 7/20 M2M6270T User Guide A-2.6 BATT_THERM path to 120 pin connector Short this jump(JP6) to connect BATT_THERM to QSC6270T. 8/20 M2M6270T User Guide A-2.7 VBAT switch JP1.1 short to JP1.2 Use 5V~6.5V DC jack power to supply VBAT to JP1.2 short to JP1.3 Use external battery power to supply VBAT to module. A-2.8 G-sensor interface switch JP15.1 short to JP15.2 JP16.1 short to JP16.2 JP17.1 short to JP17.2 JP18.1 short to JP18.2 JP15.2 short to JP15.3 JP16.2 short to JP16.3 JP17.2 short to JP17.3 JP18.2 short to JP18.3 G-sensor controlled by I 2 C interface G-sensor controlled by SPI interface 9/20 M2M6270T User Guide A-2.9 G-sensor switch Short this JP11 to connect GPIO6 with G-sensor interrupt pin, If GPIO6 has been reserved for other use, disconnect JP11 for avoiding interference. A-2.10 GPIO7 switch Short this JP12 to connect GPIO7 with Light-sensor interrupt pin, If GPIO7 has been reserved for other use, disconnect JP12 for avoiding interference 10/20 M2M6270T User Guide A-2.11 GPIO9 switch Short this JP13 to connect GPIO9 with Temperature-sensor interrupt pin, If GPIO9 has been reserved for other use, disconnect JP13 for avoiding interference. A-2.12 SPI level shifter JP14.1 short to JP14.2  Put the jumps on JP14 pin1/2 to select level shifter 3.3V voltage for SPI JP14.2 short to JP14.3  Put the jumps on JP14 pin2/3 to select level shifter 1.8V voltage for SPI 11/20 M2M6270T User Guide A-2.13 ADC Multiplexer input Header JP10 is external ADC Multiplexer input. A-2.14 ADC Multiplexer channel switch The ADC Multiplexer supports up to 8 channels. And these jumpers configure the Multiplexer channel connection to 6270T ADC. JP7.1 short to JP7.2 configure GPIO1 to high JP7.2 short to JP7.3 configure GPIO1 to low JP8.1 short to JP8.2 configure GPIO2 to high JP8.2 short to JP8.3 configure GPIO2 to low JP9.1 short to JP9.2 configure GPIO3 to high JP9.2 short to JP9.3 configure GPIO3 to low 12/20 M2M6270T User Guide GPIO3 GPIO2 GPIO1 Multiplexer channel L L L 1 L L H 2 L H L 3 L H H 4 H L L 5 H L H 6 H H L 7 H H H 8 13/20 M2M6270T User Guide A-2.15 GPIO14/GPIO15/GPIO16/GPIO17/GPIO18 indicator P2 GPIO14. Short P2 to connect GPIO14 to LED indicator. P3 GPIO15. Short P3 to connect GPIO15 to LED indicator. P4 GPIO16. Short P4 to connect GPIO16 to LED indicator. P5 GPIO17. Short P5 to connect GPIO17 to LED indicator. P6 GPIO18. Short P6 to connect GPIO18 to LED indicator. 14/20 M2M6270T User Guide Section B: Adapter Board user guide B-1. Function description of all key components 15/20 M2M6270T User Guide a. RF Antenna in This is for the connection with GSM/UMTS antenna. b. Wifi Antenna in This is for the connection with WiFi antenna. c. GPS Antenna in This is for the connection with GPS antenna. 16/20 M2M6270T User Guide d. JTAG connector JTAG ICE connector. e. Adaptor board connector This is for the purpose of connecting main board and adaptor board. B-2 JUMP setting B-2.1 Header JP6 is a test header of MPP1~MPP3. Section 3: Jumper default setting 17/20 M2M6270T User Guide : 1.Use battery …
