FCC ID: NKRVM43B ADT No.910819R02 Modular Approval Request Letter Advance Data Technology Sep. 19, 2002 Dear Application Examiner, Wistron NeWeb Corp.’s WLAN a+b combo mini-PCI, FCC ID: NKRVM43B, would like to have your authorization as a limited modular approval specific to the notebook with antenna mounted around the LCD panel. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR5211. 3. “The modular transmitter must have its own power supply regulation.” The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 2.5V DC powered. The mini-pci interface provides 3.3VDC, so there are regulators in front of these chips, the part number of this regulator is SC6204B252MR. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a PCI to mini-PCI extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: NKRVM43B ADT No.910819R02 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards,

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 6 Page 7 Page 8 Page 9

FCC ID Label Location

Page 3 Page 4 Page 5

FCC ID: NKRVM43B ADT No.910819R02 Technical Description The transmitter of the EUT is powered by host equipment. The antenna is PIFA antenna. The antenna connector is UFL connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. This device is a dual band WLAN a+b combo mini-PCI card operates in both the 5GHz and 2.4GHz bands, the maximum data rate could be 108Mbps in turbo mode. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states : The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

ADT No: 910819R02 1 FCC TEST REPORT REPORT NO.: RF910819R02 MODEL NO.: VM4-3B ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Wistron NeWeb Corp. ADDRESS:No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 ADT No: 910819R02 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT No: 910819R02 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 20 deg. C and 63 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT No: 910819R02 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 2.7dBi or 1.86(numeric) for 5GHz and 2.5dBi or 1.78(numeric) for 2.4GHz. 7.2 Output Power Into Antenna & RF Exposure Distance : For Part 802.11b: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241239.082.35 6243737.842.31 11246238.902.35 For Part 802.11a: Normal Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1518020.991.76 4524023.551.87 5526023.991.89 8532024.831.92 9574514.421.46 12580521.281.78 Turbo Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1521016.941.58 2525015.851.53 3529015.241.50 4576012.251.35 5580016.371.56 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

FCC ID: NKRVM43B Report No.: RF910819R02 1 Issued: Sep. 17, 2002 FCC TEST REPORT REPORT NO.: RF910819R02 MODEL NO.: VM4-3B RECEIVED: Aug. 19, 2002 TESTED: Sep. 3 ~ Sep. 10, 2002 APPLICANT:Wistron NeWeb Corp. ADDRESS: No. 10-1, Li-hsin Road I, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 183 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: NKRVM43B Report No.: RF910819R02 2 Issued: Sep. 17, 2002 Table of Contents 1CERTIFICATION........................................................................................... 5 2SUMMARY OF TEST RESULTS .................................................................. 6 3GENERAL INFORMATION ........................................................................... 8 3.1GENERAL DESCRIPTION OF EUT ...................................................................................... 8 3.2DESCRIPTION OF TEST MODES ........................................................................................ 9 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ..................................................... 10 3.4DESCRIPTION OF SUPPORT UNITS................................................................................. 10 4TEST TYPES AND RESULTS (FOR PART 802.11b) ................................. 11 4.1CONDUCTED EMISSION MEASUREMENT....................................................................... 11 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 11 4.1.2TEST INSTRUMENTS ......................................................................................................... 11 4.1.3TEST PROCEDURES .......................................................................................................... 12 4.1.4DEVIATION FROM TEST STANDARD ................................................................................ 12 4.1.5TEST SETUP ....................................................................................................................... 13 4.1.6EUT OPERATING CONDITIONS......................................................................................... 13 4.1.7TEST RESULTS (A) ............................................................................................................. 14 4.1.8TEST RESULTS (B) ............................................................................................................. 20 4.2RADIATED EMISSION MEASUREMENT ............................................................................ 26 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 26 4.2.2TEST INSTRUMENTS ......................................................................................................... 27 4.2.3TEST PROCEDURES .......................................................................................................... 28 4.2.4DEVIATION FROM TEST STANDARD ................................................................................ 28 4.2.5TEST SETUP ....................................................................................................................... 29 4.2.6EUT OPERATING CONDITIONS......................................................................................... 29 4.2.7TEST RESULTS (A) ............................................................................................................. 30 4.2.8TEST RESULTS (B) ............................................................................................................. 34 4.36dB BANDWIDTH MEASUREMENT ................................................................................... 38 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 38 4.3.2TEST INSTRUMENTS ......................................................................................................... 38 4.3.3TEST PROCEDURE ............................................................................................................39 4.3.4DEVIATION FROM TEST STANDARD ................................................................................ 39 4.3.5TEST SETUP ....................................................................................................................... 39 4.3.6EUT OPERATING CONDITIONS......................................................................................... 39 4.3.7TEST RESULTS ................................................................................................................... 40 4.4MAXIMUM PEAK OUTPUT POWER ................................................................................... 44 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 44 4.4.2INSTRUMENTS.................................................................................................................... 44 4.4.3TEST PROCEDURES .......................................................................................................... 45 4.4.4DEVIATION FROM TEST STANDARD ................................................................................ 45 4.4.5TEST SETUP ....................................................................................................................... 45 4.4.6EUT OPERATING CONDITIONS......................................................................................... 45 FCC ID: NKRVM43B Report No.: RF910819R02 3 Issued: Sep. 17, 2002 4.4.7TEST RESULTS .................................................…

Text truncated - open the document above for the full version.

FCC ID: NKRVM43B Report No.: RF910819R02 121 Issued: Sep. 17, 2002 5.3 PEAK TRANSMIT POWER MEASUREMENT 5.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT Frequency BandLimit 5.15 – 5.25 GHzThe lesser of 50mW (17dBm) or 4dBm + 10logB 5.25 – 5.35 GHzThe lesser of 250mW (24dBm) or 11dBm + 10logB 5.725 – 5.825 GHzThe lesser of 1W (30dBm) or 17dBm + 10logB Note: Where B is the 26 dB emission bandwidth in MHz. 5.3.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE&SCHWARZ SINGLE CHANNEL POWER METER NRVS100026Mar. 21, 2003 ROHDE&SCHWARZ PEAK POWER METER CHANNEL POWER METER NRV-Z32100013Mar. 21, 2003 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: NKRVM43B Report No.: RF910819R02 122 Issued: Sep. 17, 2002 5.3.3 TEST PROCEDURE The transmitter output was connected to the peak power senser. 5.3.4 DEVIATION FROM TEST STANDARD No deviation 5.3.5 TEST SETUP 5.3.6 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at specific channel frequencies individually. EUT Peak power meter FCC ID: NKRVM43B Report No.: RF910819R02 123 Issued: Sep. 17, 2002 5.3.7 TEST RESULTS EUT WLAN a+b combo mini- PCI MODEL VM4-3B MODE Normal INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 30 deg. C, 55%RH, 1005 hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) 26dBc Occupied Bandwidth (MHz) PASS/FAIL 1518013.2217.0028.63PASS 4524013.7217.0028.56PASS 5526013.8024.0028.07PASS 8532013.9524.0029.26PASS 9574511.5930.0027.58PASS 12580513.2830.0028.56PASS NOTE: The 26dBc Occupied Bandwidth plot, please refer to next 6 pages. FCC ID: NKRVM43B Report No.: RF910819R02 124 Issued: Sep. 17, 2002 CHANNEL 1 FCC ID: NKRVM43B Report No.: RF910819R02 125 Issued: Sep. 17, 2002 CHANNEL 4 FCC ID: NKRVM43B Report No.: RF910819R02 126 Issued: Sep. 17, 2002 CHANNEL 5 FCC ID: NKRVM43B Report No.: RF910819R02 127 Issued: Sep. 17, 2002 CHANNEL 8 FCC ID: NKRVM43B Report No.: RF910819R02 128 Issued: Sep. 17, 2002 CHANNEL 9 FCC ID: NKRVM43B Report No.: RF910819R02 129 Issued: Sep. 17, 2002 CHANNEL 12 FCC ID: NKRVM43B Report No.: RF910819R02 130 Issued: Sep. 17, 2002 EUT WLAN a+b combo mini-PCI MODEL VM4-3B MODE Turbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 30 deg. C, 55%RH, 1005 hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) 26dBc Occupied Bandwidth (MHz) PASS/FAIL 1521012.2917.0047.64PASS 2525012.0017.0047.28PASS 3529011.8324.0047.28PASS 4576010.8830.0047.64PASS 5580012.1430.0047.28PASS NOTE: The 26dBc Occupied Bandwidth plot, please refer to next 6 pages. FCC ID: NKRVM43B Report No.: RF910819R02 131 Issued: Sep. 17, 2002 CHANNEL 1 FCC ID: NKRVM43B Report No.: RF910819R02 132 Issued: Sep. 17, 2002 CHANNEL 2 FCC ID: NKRVM43B Report No.: RF910819R02 133 Issued: Sep. 17, 2002 CHANNEL 3 FCC ID: NKRVM43B Report No.: RF910819R02 134 Issued: Sep. 17, 2002 CHANNEL 4 FCC ID: NKRVM43B Report No.: RF910819R02 135 Issued: Sep. 17, 2002 CHANNEL 5 FCC ID: NKRVM43B Report No.: RF910819R02 136 Issued: Sep. 17, 2002 5.4 PEAK POWER EXCURSION MEASUREMENT 5.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT Frequency BandLimit 5.15 – 5.25 GHz13dB 5.25 – 5.35 GHz13dB 5.725 – 5.825 GHz13dB 5.4.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE&SCHWARZ SPECTRUM ANALYZER FSEK30100049July 24, 2003 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: NKRVM43B Report No.: RF910819R02 137 Issued: Sep. 17, 2002 5.4.3 TEST PROCEDURE 1. The transmitter output was connected to the spectrum analyzer. 2. Set the spectrum bandwidth span to view the entire spectrum. 3. Using peak detector and Max-hold function for Trace 1 (RB=1MHz, VB=1MHz) and 2 (RB=1MHz, VB=30KHz). 4. The largest difference between Trace 1 and Trace 2 in any 1MHz band on any frequency was recorded. 5.4.4 DEVIATION FROM TEST STANDARD No deviation 5.4.5 TEST SETUP 5.4.6 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at specific channel frequencies individually. EUT Peak power meter FCC ID: NKRVM43B Report No.: RF910819R02 138 Issued: Sep. 17, 2002 5.4.7 TEST RESULTS EUT WLAN a+b combo mini-PCI MODEL VM4-3B MODE Normal INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 30 deg. C, 55%RH, 1005 hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER EXCURSION (dB) PEAK to AV E R AG E EXCURSION LIMIT (dB) PASS/FAIL 151807.9413PASS 452408.4113PASS 552608.3413PASS 853207.2313PASS 957458.5613PASS 1258058.8613PASS FCC ID: NKRVM43B Report No.: RF910819R02 139 Issued: Sep. 17, 2002 CHANNEL 1 FCC ID: NKRVM43B Report No.: RF910819R02 140 Issued: Sep. 17, 2002 CHANNEL 4 FCC ID: NKRVM43B Report No.: RF910819R02 141 Issued: Sep. 17, 2002 CHANNEL 5 FCC ID: NKRVM43B Report No.: RF910819R02 142 Issued: Sep. 17, 2002 CHANNEL 8 FCC ID: NKRVM43B Report No.: RF910819R02 143 Issued: Sep. 17, 2002 CHANNEL 9 FCC ID: NKRVM43B Report No.: RF910819R02 144 Issued: Sep. 17, 2002 CHANNEL 12 FCC ID: NKRVM43B Report No.: RF910819R02 145 Issued: Sep. 17, 2002 EUT WLAN a+b combo mini-PCI MODEL VM4-3B MODE Turbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 30 deg. C, 55%RH, 1005 hPa TESTED BY Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER EXCURSION (dB) PEAK to AV E R AG E EXCURSION LIMIT (dB) PASS/FAIL 152108.8413PASS 252508.6413PASS 352908.6513PASS 457608.6013PASS 558008.4413PASS FCC ID: NKRVM43B Report No.: RF910819R02 146 Issued: Sep. 17, 2002 CHANNEL 1 FCC ID: NKRVM43B Report No.: RF91…

Text truncated - open the document above for the full version.

FCC ID: NKRVM43B Report No.: RF910819R02 150 Issued: Sep. 17, 2002 CHANNEL 5 FCC ID: NKRVM43B Report No.: RF910819R02 151 Issued: Sep. 17, 2002 5.5 PEAK POWER SPECTRAL DENSITY MEASUREMENT 5.5.1 LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT Frequency BandLimit 5.15 – 5.25 GHz4dBm 5.25 – 5.35 GHz11dBm 5.725 – 5.825 GHz17dBm 5.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE&SCHWARZ SPECTRUM ANALYZER FSEK30100049July 24, 2003 NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: NKRVM43B Report No.: RF910819R02 152 Issued: Sep. 17, 2002 5.5.3 TEST PROCEDURES 1. The transmitter output was connected to the spectrum analyzer. 2. Set RBW=1MHz, VBW=3MHz. The PPSD can be found. 5.5.4 DEVIATION FROM TEST STANDARD No deviation 5.5.5 TEST SETUP 5.5.6 EUT OPERATING CONDITIONS Same as 5.3.6 EUT SPECTRUM ANALYZER FCC ID: NKRVM43B Report No.: RF910819R02 153 Issued: Sep. 17, 2002 5.5.7 TEST RESULTS EUT WLAN a+b combo mini-PCI MODEL VM4-3B MODE Normal INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 30 deg. C, 55%RH, 1005 hPa TESTED BY Steven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 1 MHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 15180-2.624PASS 45240-2.554PASS 55260-2.7811PASS 85320-2.1611PASS 95745-3.8717PASS 125805-2.1617PASS FCC ID: NKRVM43B Report No.: RF910819R02 154 Issued: Sep. 17, 2002 CHANNEL 1 FCC ID: NKRVM43B Report No.: RF910819R02 155 Issued: Sep. 17, 2002 CHANNEL 4 FCC ID: NKRVM43B Report No.: RF910819R02 156 Issued: Sep. 17, 2002 CHANNEL 5 FCC ID: NKRVM43B Report No.: RF910819R02 157 Issued: Sep. 17, 2002 CHANNEL 8 FCC ID: NKRVM43B Report No.: RF910819R02 158 Issued: Sep. 17, 2002 CHANNEL 9 FCC ID: NKRVM43B Report No.: RF910819R02 159 Issued: Sep. 17, 2002 CHANNEL 12 FCC ID: NKRVM43B Report No.: RF910819R02 160 Issued: Sep. 17, 2002 EUT WLAN a+b combo mini-PCI MODEL VM4-3B MODE Turbo INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 30 deg. C, 55%RH, 1005 hPa TESTED BY Steven Lu CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 1 MHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 15210-5.204PASS 25250-5.554PASS 35290-5.8511PASS 45760-6.2017PASS 55800-4.9817PASS FCC ID: NKRVM43B Report No.: RF910819R02 161 Issued: Sep. 17, 2002 CHANNEL 1 FCC ID: NKRVM43B Report No.: RF910819R02 162 Issued: Sep. 17, 2002 CHANNEL 2 FCC ID: NKRVM43B Report No.: RF910819R02 163 Issued: Sep. 17, 2002 CHANNEL 3 FCC ID: NKRVM43B Report No.: RF910819R02 164 Issued: Sep. 17, 2002 CHANNEL 4 FCC ID: NKRVM43B Report No.: RF910819R02 165 Issued: Sep. 17, 2002 CHANNEL 5 FCC ID: NKRVM43B Report No.: RF910819R02 166 Issued: Sep. 17, 2002 5.6 FREQUENCY STABILITY 5.6.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT The frequency tolerance of the carrier signal shall be maintained within +/- 0.02% of the operating frequency over a temperature variation of –30 degrees to 50 degrees C at normal supply voltage, and for a variation in the primary supply voltage from 85% to 115% of the rated supply voltage at a temperature of 20 degrees C. 5.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ANRITSU SPECTRUM ANALYZERMS2667CM10281Mar. 15, 2003 WIT STANDARD TEMPERATURE AND HUMIDITY CHAMBER TH-4S-CW901030Jun. 24, 2003 NOTE: The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 5.6.3 TEST PROCEDURE 1. The EUT w…
