NLKTMI330984949MHz R/C Transmitter

APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 REPORT #: T\TOYMAX\795U1\795U1RPT.doc PAGE #: TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 TEST REPORT CONTAINING: PAGE 1......TEST EQUIPMENT LIST AND TEST PROCEDURE PAGE 2......TEST PROCEDURE CONTD. PAGE 3......RADIATION INTERFERENCE TEST DATA PAGE 4......OCCUPIED BANDWIDTH TEST DATA PAGE 5......OCCUPIED BANDWIDTH PLOT EXHIBITS CONTAINING: EXHIBIT 1............BLOCK DIAGRAM EXHIBIT 2............SCHEMATIC EXHIBIT 3A-C.........INSTRUCTION MANUAL EXHIBIT 4............LABEL SAMPLE AND LOCATION EXHIBIT 5............EXTERNAL PHOTO - FRONT SIDE EXHIBIT 6............EXTERNAL PHOTO - BACK SIDE EXHIBIT 7............INTERNAL PHOTO - COMPONENT SIDE EXHIBIT 8............INTERNAL PHOTO - COPPER SIDE EXHIBIT 9............CIRCUIT DESCRIPTION EXHIBIT 10...........TEST SET UP PHOTO APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 REPORT #: T\TOYMAX\795U1\795U1RPT.doc PAGE #: Page 1 of 5 APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 TEST EQUIPMENT LIST 1._X_Spectrum Analyzer: HP 8566B-Opt 462, S/N 3138A07786, w/ preselector HP 85685A, S/N 3221A01400, Quasi-Peak Adapter HP 8565OA, S/N 3303A01690 & Preamplifier HP 8449B-OPT H02, S/N 3008A00372 2._X_Biconnical Antenna: Eaton Model 94455-1, S/N 1057 3.___Biconnical Antenna: Electro-Metrics Model BIA-25, S/N 1171 4._X_Log-Periodic Antenna: Electro-Metrics Model EM-6950, S/N 632 5.___Log-Periodic Antenna: Electro-Metrics Model LPA-30, S/N 409 6.___Double-Ridged Horn Antenna: Electro-Metrics Model RGA-180, 1-18 GHz, S/N 2319 7.___18-26.3GHz Systron Donner Standard Gain Horn #DBE-520-20 8.___Horn 40-60GHz: ATM Part #19-443-6R 9.___Line Impedance Stabilization Network: Electro-Metrics Model ANS-25/2, S/N 2604 10.___Temperature Chamber: Tenney Engineering Model TTRC, S/N 11717-7 11.___Frequency Counter: HP Model 5385A, S/N 3242A07460 12.___Peak Power Meter: HP Model 8900C, S/N 2131A00545 13._X_Open Area Test Site #1-3meters 14.___Signal Generator: HP 8640B, S/N 2308A21464 15.___Signal Generator: HP 8614A, S/N 2015A07428 16.___Passive Loop Antenna: EMCO Model 6512, 9KHz to 30MHz, S/N 9706-1211 17.___Dipole Antenna Kit: Electro-Metrics Model TDA-30/1-4, S/N 153 18.___AC Voltmeter: HP Model 400FL, S/N 2213A14499 19.___Digital Multimeter: Fluke Model 8012A, S/N 4810047 20.___Digital Multimeter: Fluke Model 77, S/N 43850817 21.___Oscilloscope: Tektronix Model 2230, S/N 300572 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a prese- lector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz. The ambient temperature of the UUT was 93°C with a humidity of 45%. APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 REPORT #: T\TOYMAX\795U1\795U1RPT.doc PAGE #: Page 2 of 5 APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 TEST PROCEDURES CONTINUED FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was estab- lished by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor sup- plied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 REPORT #: T\TOYMAX\795U1\795U1RPT.doc PAGE #: Page 3 of 5 APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.235 REQUIREMENTS: CARRIER FREQUENCY WILL NOT EXCEED 80 dBuV/m AT 3M. OUT-OF-BAND EMISSIONS SHALL NOT EXCEED: 30 - 88 MHz 40.0 dBuV/M MEASURED AT 3 METERS 88 - 216 MHz 43.5 dBuV/M 216 - 960 MHz 46.0 dBuV/M ABOVE 960 MHz 54.0 dBuV/M TEST DATA: Emission Frequency MHz Meter Reading dBuv Ant. Polarity Coax Loss dB Correction Factor dB Field Strength dBuv/m Margin dB 49.86 64.9 V 0.80 11.00 76.70 3.30 99.80 16.2 V 1.20 8.25 25.65 17.85 149.70 15.7 V 1.40 16.90 34.00 9.50 199.60 9.9 V 1.80 12.60 24.30 19.20 249.50 11.7 V 2.00 13.77 27.47 18.53 299.40 13.1 V 2.20 15.50 30.80 15.20 349.30 24.3 V 2.50 14.35 41.15 4.85 399.20 16.5 V 2.80 16.91 36.21 9.79 448.90 18.5 V 3.10 17.01 38.61 7.39 498.60 16.9 V 3.10 17.43 37.43 8.57 SAMPLE CALCULATION: FSdBuV/m = MR(dBuV) + ACFdB. TEST PROCEDURE: The procedure used was ANSI STANDARD C63.4-1992. The spectrum was scanned from 30 MHz to 1000 MHz. When an emission was found, the table was rotated to produce the maximum signal strength. The antenna was placed in both the horizontal and vertical planes and the worse case emissions were reported. The UUT was tested in 3 orthogonal planes. TEST RESULTS: THE UNIT DOES MEET THE FCC REQUIREMENTS. PERFORMED BY: JOSEPH SCOGLIO DATE: JULY 25, 2001 APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 REPORT #: T\TOYMAX\795U1\795U1RPT.doc PAGE #: Page 4 of 5 APPLICANT: TOYMAX INC. FCC ID: NLKTMI3309849 NAME OF TEST: Occupied Bandwidth RULES PART NO.: 15.235 REQUIREMENTS: The field strength of any emissions appearing between the band edges and up to 10 kHz above and below the band edges shall be attenuated at least 26 dB below the level of the unmodu- lated carrier or to the general limits of 15.209, whichever permits the higher …
