Model:SB1T14-B Product:13.3inch Digital Signage Rate power Input: 5V/3A S/N:SB1T141BO257A300030 WiFi MAC:A1:B2:C3:D4:E5:F6 BT MAC:A1:B2:C3:D4:E5:F6 【Label內容】 【Label粘貼位置】 Rate Power Input: 5V/3A Model:SB1T14-B Product: 13.3inch Digital Signage FCC ID:NOI-SB1T14 S/N:SB1T141BO257A300030 WiFi MAC:A1:B2:C3:D4:E5:F6 BT MAC:A1:B2:C3:D4:E5:F6 Made in Taiwan Model:SB1T14-X Product: 13.3inch Digital Signage FCC ID:NOI-SB1T14 S/N:SB1T141XO257A300030 WiFi MAC:A1:B2:C3:D4:E5:F6 BT MAC:A1:B2:C3:D4:E5:F6 Made in Taiwan Rate Power Input: 5V/3A Rate Power Input: 5V/3A Model:SB1T14-B Product: 13.3inch Digital Signage FCC ID:NOI-SB1T14 S/N:SB1T141BO257A300030 WiFi MAC:A1:B2:C3:D4:E5:F6 BT MAC:A1:B2:C3:D4:E5:F6 Made in Taiwan →尺寸:50X20mm →尺寸:40X10mm →尺寸:50X20mm →尺寸:40X10mm

FCC ID: NOI-SB1T14 RF EXPOSURE EVALUATION According to FCC 1.1310 and KDB 447498 D01 V06, The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d G P * * 30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 * 377 * * 30 D G P From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Measurement Result BT: Operation Frequency: 2402-2480MHz, Power density limited: 1mW/ cm 2 Power density limited: 1mW/cm Antenna Type: PCB Antenna Antenna :1.06dBi R=20cm mW=10^(dBm/10) conducted power Evaluation result Power density Limits (dBm) (mW) (dBi) Numeric 2402 6.79 7±1 8 6.310 1.06 1.28 0.0016 1 2441 6.71 7±1 8 6.310 1.06 1.28 0.0016 1 2480 7.03 7±1 8 6.310 1.06 1.28 0.0016 1 2402 6.58 6±1 7 5.012 1.06 1.28 0.0013 1 2441 6.48 6±1 7 5.012 1.06 1.28 0.0013 1 2480 6.8 6±1 7 5.012 1.06 1.28 0.0013 1 2402 6.49 6±1 7 5.012 1.06 1.28 0.0013 1 2441 6.37 6±1 7 5.012 1.06 1.28 0.0013 1 2480 6.74 6±1 7 5.012 1.06 1.28 0.0013 1 2402 3.93 4±1 5 3.162 1.06 1.28 0.0008 1 2440 3.6 4±1 5 3.162 1.06 1.28 0.0008 1 2480 4.08 4±1 5 3.162 1.06 1.28 0.0008 1 2402 4.03 4±1 5 3.162 1.06 1.28 0.0008 1 2440 3.52 4±1 5 3.162 1.06 1.28 0.0008 1 2480 4.17 4±1 5 3.162 1.06 1.28 0.0008 BT (mW/cm2 ) BLE π/4- DQPSK BLE 2M Mode tune-up power Tune-up power (dBm) (dBm) GFSK BT modulation BT (mW/cm2) Antenna Gain GFSK Channel Freq. (MHz) Max 8-DPSK GFSK 2.4G WIFI: Operation Frequency: WIFI 802.11b/g/n HT20: 2412-2462MHz, Power density limited: 1mW/ cm 2 Power density limited: 1mW/cm Antenna Type: PCB Antenna 2.4G WIFI Antenna 1:1.06dBi; R=20cm mW=10^(dBm/10) conducted power Evaluation result Power density Limits (dBm) (mW) (dBi) Numeric Ant 1 2412 13.04 13±1 14 25.119 1.06 1.28 0.0064 1 Ant 1 2437 13.22 13±1 14 25.119 1.06 1.28 0.0064 1 Ant 1 2462 12.87 13±1 14 25.119 1.06 1.28 0.0064 1 Ant 1 2412 13.48 13±1 11 12.589 1.06 1.28 0.0032 1 Ant 1 2437 13.63 13±1 11 12.589 1.06 1.28 0.0032 1 Ant 1 2462 13.58 13±1 11 12.589 1.06 1.28 0.0032 1 Ant1 2412 11.39 11±1 12 15.849 1.06 1.28 0.0040 1 Ant 1 2437 11.42 11±1 12 15.849 1.06 1.28 0.0040 1 Ant 1 2462 11.15 11±1 12 15.849 1.06 1.28 0.0040 1 Ant 1 2412 11.63 11±1 12 15.849 1.06 1.28 0.0040 1 Ant 1 2437 11.42 11±1 12 15.849 1.06 1.28 0.0040 1 Ant 1 2462 11.41 10±1 12 15.849 1.06 1.28 0.0040 1 Antenna tune-up power Tune-up power (dBm) (dBm) Channel Freq. (MHz) Max 802.11b (mW/cm2 ) modulation 802.11ax2 0 (mW/cm2) Antenna Gain 802.11g 802.11n20 5G WIFI 802.11a/n20/ac/ax20: 5180-5240MHz, 5500-5700MHz Power density limited: 1mW/cm Antenna Type: PCB antenna Antenna Gain: 5.56dBi; R=20cm mW=10^(dBm/10) antenna 1gain Numeric=10^(dBi/10) 5.2G conducted power Evaluation result Power density Limits (dBm) (mW) (dBi) Numeric Ant1 5180 12.4 12±1 13 19.953 5.56 3.60 0.0143 1 Ant1 5200 12.4 12±1 13 19.953 5.56 3.60 0.0143 1 Ant1 5240 12.63 12±1 13 19.953 5.56 3.60 0.0143 1 Ant1 5180 11.37 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5200 11.59 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5240 11.68 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5180 11.43 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5200 11.67 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5240 11.52 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5180 11.48 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5200 11.77 11±1 12 15.849 5.56 3.60 0.0113 1 Ant1 5240 11.72 11±1 12 15.849 5.56 3.60 0.0113 1 802.11ac20 802.11n H20 Channel Freq. (MHz) 802.11ax20 (mW/cm2) Antenna Gain 802.11a Max tune-up power Tune-up power (dBm) (dBm) (mW/cm2 ) modulation Antenna 5.6G conducted power Evaluation result Power density Limits (dBm)(mW)(dBi)Numeric Ant1 550012.31 12±113 19.9535.563.600.01431 Ant1 560011.6 12±113 19.9535.563.600.01431 Ant1 570012.98 12±113 19.9535.563.600.01431 Ant1 550011.11 11±112 15.8495.563.600.01131 Ant1 560010.56 11±112 15.8495.563.600.01131 Ant1 570011.75 11±112 15.8495.563.600.01131 Ant1 550011 11±112 15.8495.563.600.01131 Ant1 560010.42 11±112 15.8495.563.600.01131 Ant1 570012.03 12±113 19.9535.563.600.01431 Ant1 550011.19 11.5±112.5 17.7835.563.600.01271 Ant1 560010.53 11.5±112.5 17.7835.563.600.01271 Ant1 570012.14 11.5±112.5 17.7835.563.600.01271 802.11ac20 802.11n H20 Channel Freq. (MHz) 802.11ax20 (mW/cm2) Antenna Gain 802.11a Max tune-up power Tune-up power (dBm) (dBm)(mW/cm2 ) modulationAntenna SIMULTANEOUS TRANSMISSIONS When a number of sources at different frequencies, and/or broadband sources, contribute to the total exposure, it becomes necessary to weigh each contribution relative to the MPE. To comply with the MPE, the fraction of the MPE in terms of E 2 , H 2 (or power density) incurred within each frequency interval should be determined and the sum of all such fractions should not exceed unity. In order to ensure compliance with the MPE for a controlled environment, the sum of the ratios of the power density to the corresponding MPE should not exceed unity. That is Worst case is Simultaneous Transmissions for 5.8G Wi-Fi +BT Standalone Standalone Evaluation result Power density Limits Evaluation result BT 0.0016 1 5.2G WIFI 0.0143 1 Simultaneous 0.0159 Limit 1 Verdict PASS Band Mode (mW/cm2) (mW/cm2 ) raio 5.2G Wi-Fi+BT Conclusion: For the max result : 0.0159≤ 1.0, SAR is not required. Signature: Date: 2026-06-15 NAME AND TITLE (Please print or type): Alex Li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ No. 24 Xinfa East Road, Xiangshan Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong, People's Republic of China

Report No.: N26033000304E Version.1.3 Page 1 of 78 RADIO TEST REPORT FCC ID: NOI-SB1T14 Product: 13.3inch Digital Signage Trade Mark: NETRONIX, Pioneer Model No.: SB1T14-B Family Model: EM133-B, SB1T14-X, EM133-X Report No.: N26033000304E Issue Date: May. 30, 2026 Prepared for NETRONIX, INC. No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. No. 24 Xinfa East Road, Xiangshan Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong, People's Republic of China Tel. 0755-23200050 Website: http://www.ntek.org.cn Report No.: N26033000304E Version.1.3 Page 2 of 78 Table of Contents Page 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES ..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 10 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................................... 10 6.2 SUPPORT EQUIPMENT ............................................................................................................................... 11 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 12 7 TEST REQUIREMENTS .................................................................................................................................... 14 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 14 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 17 7.3 6DB BANDWIDTH ....................................................................................................................................... 26 7.4 DUTY CYCLE ............................................................................................................................................... 27 7.5 PEAK OUTPUT POWER .............................................................................................................................. 29 7.6 POWER SPECTRAL DENSITY ................................................................................................................... 30 7.7 CONDUCTED BAND EDGE MEASUREMENT ......................................................................................... 32 7.8 SPURIOUS RF CONDUCTED EMISSIONS ................................................................................................ 33 7.9 ANTENNA APPLICATION .......................................................................................................................... 34 8 TEST RESULTS ................................................................................................................................................... 35 8.1 1M .................................................................................................................................................................. 35 8.2 2M .................................................................................................................................................................. 57 Report No.: N26033000304E Version.1.3 Page 3 of 78 1 TEST RESULT CERTIFICATION Applicant’s name ......................... : NETRONIX, INC. Address ....................................... : No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Manufacturer's Name .................. : NETRONIX, INC. Address ....................................... : No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Factory(1) .................................... : NETRONIX, INC. Address ....................................... : No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Factory(2) .................................... : NTX Electronics YANGZHOU CO.,LTD. Address ....................................... : No.8, Wuzhou West Road, Economic and technological Development Zone, Yangzhou, Jiangsu Province, PRC, 225009. Product description Product name .............................. : 13.3inch Digital Signage Trade Mark .................................. : NETRONIX, Pioneer Model and/or type reference ...... : SB1T14-B Family Model ............................... : EM133-B, SB1T14-X, EM133-X Test Sample number ................... : S2604010106-1# Date of Test ................................. : Mar. 30, 2026 ~ May. 30, 2026 Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C ANSI C63.10-2020+Cor 1-2023 KDB 558074 D01 15.247 Meas Guidance v05r02 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under tes…

Text truncated - open the document above for the full version.

Report No.: N26033000306E Version.1.3 Page 1 of 87 FCC RADIO TEST REPORT FCC ID: NOI-SB1T14 Product: 13.3inch Digital Signage Trade Mark: NETRONIX, Pioneer Model No.: SB1T14-B Family Model: EM133-B, SB1T14-X, EM133-X Report No.: N26033000306E Issue Date: May. 30, 2026 Prepared for NETRONIX, INC. No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. No. 24 Xinfa East Road, Xiangshan Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong, People's Republic of China Tel. 0755-23200050 Website: http://www.ntek.org.cn Report No.: N26033000306E Version.1.3 Page 2 of 87 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 10 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................................... 10 6.2 SUPPORT EQUIPMENT............................................................................................................................... 11 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 12 7 TEST REQUIREMENTS .................................................................................................................................... 14 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 14 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 17 7.3 6DB BANDWIDTH ....................................................................................................................................... 26 7.4 DUTY CYCLE ............................................................................................................................................... 28 7.5 MAXIMUM OUTPUT POWER .................................................................................................................... 29 7.6 POWER SPECTRAL DENSITY ................................................................................................................... 31 7.7 CONDUCTED BAND EDGE MEASUREMENT......................................................................................... 33 7.8 SPURIOUS RF CONDUCTED EMISSIONS................................................................................................ 35 7.9 ANTENNA APPLICATION .......................................................................................................................... 36 8 TEST RESULTS ................................................................................................................................................... 37 8.1 DUTY CYCLE .................................................................................................................................................. 37 8.2 MAXIMUM CONDUCTED OUTPUT POWER ....................................................................................................... 44 8.3 -6DB BANDWIDTH .......................................................................................................................................... 45 8.4 OCCUPIED CHANNEL BANDWIDTH .................................................................................................................. 52 8.5 MAXIMUM POWER SPECTRAL DENSITY LEVEL ............................................................................................... 59 8.6 BAND EDGE .................................................................................................................................................... 66 8.7 CONDUCTED RF SPURIOUS EMISSION ............................................................................................................. 75 Report No.: N26033000306E Version.1.3 Page 3 of 87 1 TEST RESULT CERTIFICATION Applicant’s name ......................... : NETRONIX, INC. Address ....................................... : No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Manufacturer's Name .................. : NETRONIX, INC. Address ....................................... : No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Factory(1) .................................... : NETRONIX, INC. Address ....................................... : No. 945, Boai St., Jubei City, Hsinchu, Taiwan, 30265 R.O.C. Factory(2) .................................... : NTX Electronics YANGZHOU CO.,LTD. Address ....................................... : No.8, Wuzhou West Road, Economic and technological Development Zone, Yangzhou, Jiangsu Province, PRC, 225009. Product description Product name .............................. : 13.3inch Digit…

Text truncated - open the document above for the full version.

Report No.: N26033000306E Version.1.3 Page 69 of 87 Band Edge NVNT g 2412MHz Ant1 Ref Band Edge NVNT g 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 70 of 87 Band Edge NVNT g 2462MHz Ant1 Ref Band Edge NVNT g 2462MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 71 of 87 Band Edge NVNT n20 2412MHz Ant1 Ref Band Edge NVNT n20 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 72 of 87 Band Edge NVNT n20 2462MHz Ant1 Ref Band Edge NVNT n20 2462MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 73 of 87 Band Edge NVNT ax20 2412MHz Ant1 Ref Band Edge NVNT ax20 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 74 of 87 Band Edge NVNT ax20 2462MHz Ant1 Ref Band Edge NVNT ax20 2462MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 75 of 87 8.7 CONDUCTED RF SPURIOUS EMISSION Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT b 2412 Ant1 -46.57 -30 Pass NVNT b 2437 Ant1 -46.91 -30 Pass NVNT b 2462 Ant1 -45.85 -30 Pass NVNT g 2412 Ant1 -47.1 -30 Pass NVNT g 2437 Ant1 -47.36 -30 Pass NVNT g 2462 Ant1 -47.39 -30 Pass NVNT n20 2412 Ant1 -44.13 -30 Pass NVNT n20 2437 Ant1 -43.38 -30 Pass NVNT n20 2462 Ant1 -43.53 -30 Pass NVNT ax20 2412 Ant1 -42.23 -30 Pass NVNT ax20 2437 Ant1 -43.49 -30 Pass NVNT ax20 2462 Ant1 -43.1 -30 Pass Report No.: N26033000306E Version.1.3 Page 76 of 87 Test Graphs Tx. Spurious NVNT b 2412MHz Ant1 Ref Tx. Spurious NVNT b 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 77 of 87 Tx. Spurious NVNT b 2437MHz Ant1 Ref Tx. Spurious NVNT b 2437MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 78 of 87 Tx. Spurious NVNT b 2462MHz Ant1 Ref Tx. Spurious NVNT b 2462MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 79 of 87 Tx. Spurious NVNT g 2412MHz Ant1 Ref Tx. Spurious NVNT g 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 80 of 87 Tx. Spurious NVNT g 2437MHz Ant1 Ref Tx. Spurious NVNT g 2437MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 81 of 87 Tx. Spurious NVNT g 2462MHz Ant1 Ref Tx. Spurious NVNT g 2462MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 82 of 87 Tx. Spurious NVNT n20 2412MHz Ant1 Ref Tx. Spurious NVNT n20 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 83 of 87 Tx. Spurious NVNT n20 2437MHz Ant1 Ref Tx. Spurious NVNT n20 2437MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 84 of 87 Tx. Spurious NVNT n20 2462MHz Ant1 Ref Tx. Spurious NVNT n20 2462MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 85 of 87 Tx. Spurious NVNT ax20 2412MHz Ant1 Ref Tx. Spurious NVNT ax20 2412MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 86 of 87 Tx. Spurious NVNT ax20 2437MHz Ant1 Ref Tx. Spurious NVNT ax20 2437MHz Ant1 Emission Report No.: N26033000306E Version.1.3 Page 87 of 87 Tx. Spurious NVNT ax20 2462MHz Ant1 Ref Tx. Spurious NVNT ax20 2462MHz Ant1 Emission END OF REPORT

Item Page 1.1 2.2 3.3~15 Contents Description .................. 規格表 .................. .................. 成品圖 .................. .................. 測試報告 .................. Specification Without housing (with Cable Loss) 1. Electrical Properties : 1.1 Frequency Range....................................... 1.2 Impedance .................................................. 1.3VSWR ....................................................... 1.4Return Loss..................................................... 1.5Radiation ................................................... 1.6Peak Gain.................................2.4 ~ 2.5GHz < 1.06dBi 5.15 ~ 5.85 GHz < 5.56dBi 1.71.2 1.8Polarization.................................................Linear 1.9 Cable................................................1.37mm Normal Coaxial Cable 1.10Connector....................................MHF 1.11Core...................................................N/A 2. Physical Properties : 2.1 Operating Temp. .............................................-10°C ~ +60°C 2.2Storage Temp. ...............................................-10°C ~ +70°C 2.4 ~ 2.5 , 5.15~5.85 GHz 50Ω Nominal 4.7 :1Max. 3.76 dB Min. Cable Loss....................................................... RF Antenna Cable Assembly Omni-directional C020-510083-A Antenna Test Report Version:V 1.01 Released Date:2025/02/26 Prepared By: Leo Reviewed By:Stone 1 2 Contents Revised History Specification Antenna Placement & Solution Test Setup for S-parameter Measurement Return Loss Results Test Setup for Radiation Pattern Measurement 2D Radiation Pattern Results Results Summary (return loss, peak gain, efficiency ) 3 Revision History Released DateVersion Record 2025/02/261.01Antenna Testing Report 4 Specification RF FunctionNumber of ANTFrequency BandRemark DBANT2400~2500/5150~5850 MHz Requirements of Antenna Design Requirements of Measurement Test ItemSpecificationRemark Return LossN/A Peak GainN/A EfficiencyN/A Radiation patternScale: +10 ~ -40dBi, Angle step size: 5 degree 5 Antenna Placement & Solution Return Loss Results 6 Antenna (Criterion:>10 dB) 7 Test Setup for Radiation Pattern Measurement Chamber Information AU…
