NP8SCBS-419MOutdoor BTS

Samsung CDMA BSS: Indoor BTS Installation 1 CDMA Base Station System Indoor BTS Installation Introduction Physical Installation Cabling Initial Testing Completion Appendix A: Indoor BTS installation required tools Appendix B: Indoor BTS installation materials Appendix C: Indoor BTS Installation Record About this Document Samsung CDMA BSS: Indoor BTS Installation Manual 1 Introduction Scope Conventions Required installation materials and tools Required documentation Safety precautions Warning Caution Samsung CDMA BSS: Indoor BTS Installation Manual 2 CDMA BSS Version 4, Indoor BTS Installation Manual, release 2.0 Scope This document covers the installation procedures for a single rack Indoor Base Transceiver Station (Indoor BTS). Note: This installation must be performed by Samsung qualified service personnel only, using only the tools, supplies, and materials listed in this manual. Any deviation will negate the responsibility of Samsung for operation or condition of this equipment. Note: Access to the Indoor BTS is restricted to Samsung qualified service personnel or other qualified maintenance personnel for internal subassembly or component replacement or any internal adjustment. Warning: The rear or side panels of any Samsung equipment may be opened only by Samsung qualified service personnel. Samsung is not responsible for injury or harm to persons violating this policy. This equipment complies with Part 24 of the FCC rules. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Warning: This product is designed for use with antennas mounted on permanent outdoor structures. Upon installation the potential for RF exposure to persons should be evaluated. Following completion of the civil construction, the following procedures will be performed: wSite preparation and layout wBBU installation wGPS installation wPhysical installation of the BTS wCabling the equipment wInitial testing of the BTS wCompleting the installation A checklist for these procedures is given in Appendix B. Samsung CDMA BSS: Indoor BTS Installation Manual 3 BSS Version 4, Document V4D0001 release 0.5, Indoor BTS Installation Manual, release 2.0 Conventions All measurements provided in this manual are given in metric units, with US units in parentheses: wUnless otherwise specified, lengths are given in millimeters (inches). For example, a length of 600.0 (23.6) means 600.0 mm (23.6 inches). wWeights are given in kilograms (pounds). For example, weight of 450 (992) means 450 kilograms (992 pounds). wTemperatures are given in degrees Celsius (Fahrenheit). For example: temperature of 37.8 (100) means 37.8 degrees Celsius (100 degrees Fahrenheit). wOther dimensions are specified as required. Samsung CDMA BSS: Indoor BTS Installation Manual 4 BSS Version 4, Document V4D0001 release 0.5, Indoor BTS Installation Manual, release 2.0 Required documentation Before beginning the installation, verify that you have at least the following documents: wSite survey check list (customer-provided). wSite folder (customer-provided). wSamsung GPS System Installation Manual, v1.0. wTDI 24VDC Indoor Power Plant Turn Up and Test Manual. wIndoor BTS Installation Record wPacking lists (Samsung-provided) An example packing list is shown in the following figure: You should study these documents before proceeding. PROJECT0190015275 SITEDALLAS, USA REMARKSEDV-BMBR A/S(TEL82-(0546)460-2515 NOSEC CODEDESCRIPTION QTY SERIAL NO 01EP44-00011ASMPS-SRM;S001S22N203231 02EP75-00133AMEC-HEAT E001S22N203235 03EP44-00011ASMPS-SRM;S001S22N203230 04EP44-00011ASMPS-SRM;S001S22N203229 05EP44-00011ASMPS-SRM;S001S22N203232 06EP44-00010ASMPS-ASSY-001S22N203233 07EP44-00012ASMPS-SDP-A001S22N203227 08EP44-00012ASMPS-SDP-A001S22N203228 09EP96-01209AELA HOU RA001S3AN101668 10EP96-00921CELA HOU-CC001S22N203253 11EP96-00921CELA HOU-CC001S22N203252 12EP96-00921CELA HOU-CC001S22N203251 13EP96-00919CELA HOU-AF001S22N203247 14EP96-00919CELA HOU-AF001S22N203246 15EP96-00919CELA HOU-AF001S22N203245 16EP96-00919CELA HOU-AF001S22N203248 17EP96-00919CELA HOU-AF001S22N203249 18EP96-00919CELA HOU-AF001S22N203250 19EP96-00930AELA UNIT-C001S22N203243 20EP92-00741APBA MAIN-M001S21KC47554 PACKING LIST DATE 00/02/13Page 1 Of 3 Samsung CDMA BSS: Indoor BTS Installation Manual 5 BSS Version 4, Document V4D0001 release 0.5, Indoor BTS Installation Manual, release 2.0 Required installation materials and tools For a complete list of installation tools, see "Appendix A: Indoor BTS installation required tools". For a complete list of installation materials, see "Appendix B: Indoor BTS installation materials". Verify that all required tools and materials are present before proceeding to the next section. Samsung CDMA BSS: Indoor BTS Installation Manual 6 BSS Version 4, Document V4D0001 release 0.5, Indoor BTS Installation Manual, release 2.0 Safety precautions This section specifies the recommended safety precautions to follow when you work with the equipment described in this Installation Manual. This equipment meets the requirements of NFPA 70 (National Electric Code) and UL 1459 (Telephone Equipment). Note: The installation of this equipment is to be performed by Samsung qualified service personnel only, using only the tools, supplies, and materials listed in the manual. Safety guidelines include the following: WarningWarning: Warning denotes a danger that may cause loss of life, physical injury or ill health. Lethal voltage wPotentially lethal voltages are present within this system. Ensure all power supplies are completely isolated by setting all power switches to off, disconnecting all relevant connectors and removing all relevant fuses before attempting any maintenance work. Do not rely on switches alone to isolate a supply. wPotentially lethal voltages are present within this system. Ensure high voltage safety requirements are implemented before attempting to work on the system with the power connected. wPotentiall…

Text truncated - open the document above for the full version.

ED cdma2000 BLOCK DIAGRAM 12. 2000. COPYRIGHT This manual contains the information, which is proprietary to SAMSUNG Electronics Co.Ltd. and is protected by copyright. No information contained herein may be copied, translated, transcribed or duplicated for any commercial purposes or disclosed to third parties in any form without the prior written consent of SAMSUNG Electronics Co.Ltd. TRADEMARKS SAMSUNG, are registered trademark of SAMSUNG. Product names mentioned in this document may be trademarks and/or registered trademarks of their respective companies. Disclaimer While reasonable efforts have been made to assure the accuracy of this document, SAMSUNG assumes no liability resulting from any omissions in this document, or from misuse of the information obtained here. nor shall SAMSUNG be liable or responsible for any claim or damage, direct or consequential, arising out of use, interpretation, reliance upon or other implementation of said information. SAMSUNG reserves the right to change information contained in this manual for the system improvement, standardization and other technical reasons without prior notice. For further information on the updated manual, contact Document Center at the address below . Address : 463-050 Document Center Post Box 32, 20th Fl. SAMSUNG Plaza Bldg. 263 Seohyun-dong Bundang- ku, Seungnam-si, Kyungki-do, Korea Phone : 82-031-779-7284 Or contact Customer Care Group at the address below if you have any questions or concerns regarding the operation of your equipment. Address : 463-050 Customer Care Center Post Box 32, 20th Fl. SAMSUNG Plaza Bldg. 263 Seohyun-dong Bundang-ku, Seungnam-si, Kyungki-do, Korea Phone : 82-031-779-7551 http://www.samsungnetwork.com ©2000 SAMSUNG Electronics Co., Ltd. All rights reserved CHAPTER 1 BLOCK DIAGRAM Block Diagram / ED 00 © SAMSUNG Electronics Co., Ltd.Page 2 1BTMA Block Diagram LED +3.6V TM_EQA Red Green TM Block UART2 (Reserved) Cable(16pin) Coaxial Cable RS232 (MAX232) Buffer (74LVT16245) Power_Monitor (DS1834) Power Module Regulator1 (LT1086) Regulator2 (LT1086) BPDA BCAA Rectifoer +3.6V +3.6V +5V TM_PWR_OnOff TM_EQA UART1 Power_Fail UART2 (Reserved,115.2Kbps) TM_PWR_OnOff TM_EQA UART1 (RS-232C, 57.6Kbps) CellularK-PCSU-PCSIMT2000 Tx fl869~8941810~18701930~19902110~2170 Rx ‡824~8491720~17801850~19101920~1980 +27V unit : MHz Remote_reset Alarm (Delete, Power_Fail, Function_Fail) Block Diagram / ED 00 © SAMSUNG Electronics Co., Ltd.Page 3 1.1BTMA feature Core Component ü Power Module : +27V Input/+5.0V Output ü Regulator1 : +5.0V Input/+3.6V Output ü Regulator2 : +5.0V Input/+3.3V Output ü Buffer : 74LVT16245 ü EconoRest : DS1834A(Power Monitor) ü TM(Test Mobile) Specification & Function ü UART1: RS-232C, Async.HDLC, 57600bps, to/from BPDA Block Diagram / ED 00 © SAMSUNG Electronics Co., Ltd.Page 4 2TRXA Block Diagram 1) Transmit Block Diagram AMP AMP AMP AMP AMP AMP AMP LPF BPF BPF ATT. BPF MIXER MIXER AMP AMP AMP LPF BPF BPF ATT. BPF MIXER MIXER IF_LO (137.1MHz) Main Path From IFDA (12.9MHz) To TXCA (1930~1990MHz) RF_LO (1780~1840MHz) 150MHz 150MHz OTD Path From IFDA (12.9MHz) To TXCA (1930~1990MHz) Block Diagram / ED 00 © SAMSUNG Electronics Co., Ltd.Page 5 2) Receive Block Diagram AMP Int. AMP BPF AMP Divider AMP ATT. BPF BPF AMP MIXER RF_LO (1780~1840MHz) To IFDA (70MHz) 70MHz LAN 70MHz RSSI-A RSSI-A Detector Detector Detector AMP SAW AMP AGC SAW Divider To IFDA (70MHz) Main_Path From FEU Diversity_Path From FEB Int. BPF AMP Divider AMP ATT. BPF BPF AMP MIXER LAN Detector AMP SAW AMP AGC SAW Divider (1850~1910MHz) (1850~1910MHz) Block Diagram / ED 00 3TXCA Block Diagram TXCA (Transmitter Combiner Board Assembly) This Block Diagrm describes the Transmitter Combiner Board Assembly (TXCA) used for PCS (1900MHz) A_α_1 A_β_1 A_α_2 A_α_3 A_α_4 A_β_2 A_β_3 A_β_4 A_γ_1 A_γ_2 A_γ_3 A_γ_4 4-way combiner 4-way combiner 4-way combiner 4-way combiner A_α A_β A_γ GND VCC TXCA0_EQA Block Diagram / ED 00 © SAMSUNG Electronics Co., Ltd.Page 7 4TXCU Block Diagram TXCU (Transmitter Combiner Unit) This Block Diagrm describes the Transmitter Combiner Unit(TXCU) used for PCS (1900MHz) IN4 IN3IN2 IN1 OUTIN4 IN3IN2 IN1 OUT IN4 IN3IN2 IN1 OUT IN4 IN3IN2 IN1 OUT IN4 IN3IN2 IN1 OUT IN4 IN3IN2 IN1 OUT Block Diagram / ED 00 © SAMSUNG Electronics Co., Ltd.Page 8 5RXDU Block Diagram RXDU (Receiver Distribution Unit) This Block Diagrm describes the Receiver Distribution Unit(RXDU) circuit used for PCS (1900MHz) OUT4 OUT3OUT2 OUT1 IN OUT4 OUT3OUT2 OUT1 IN OUT4 OUT3OUT2 OUT1 IN OUT4 OUT3OUT2 OUT1 IN OUT4 OUT3OUT2 OUT1 IN OUT4 OUT3OUT2 OUT1 IN Block Diagram / ED 00 6FRDP Block Diagram FRDP-12 (Frequency Reference Distribution Panel) This Block Diagrm describes the Frequency Reference Distribution Panel (FRDP-12) used for PCS (1900MHz) From GCRU 12 Way Divider To TRXA0 To TRXA1 To TRXA2 To TRXA3 To TRXA4 To TRXA5 To TRXA6 To TRXA7 To TRXA8 To TRXA9 To TRXA10 To TRXA11 Block Diagram / ED 00 7PAU Block Diagram PRE DISTORTION INPUT Pilot RXVR & Synthesizer CTRL & Data DELAY DELAY Loop 1 Detector I/O & DC Alarm Board Pre Error AmpError Amp Output Section Main Amp Driver Amp Pre Main Amp Pre Amp RF IN RF OUT Block Diagram / ED 00 8FEU Block Diagram Tx BPF Rx BPF ANT. CPL EQP.CPL J1 J2 J3 J4 TRB0 RXDU TRB1 RXDU TRB2 RXDU TRB3 RXDU From TFCA +12V Function FAIL To BCAA 4-Way Power Divider Tx RF To ANT Rx RF From ANT From BPDA To BPDA Test Port From SDP-T +8.5V Tx IN Tx RF From PAU R LED Duplexer Filter TEST CPL Directional Coupler Bias Tee ANNTENA LNA Block Diagram / ED 00 Specification Function ü Duplexer − It separate Tx, Rx Signal and suppress spurious signal − Bandwidth = 11MHz, IL(Tx)=0.6dB (Max), IG(Rx)=25 ±1.5 dB (Insertion Gain) ü Directional Coupler − It connect forward & reverse coupling signal to BPDA − Coupling Value = 33 ±0.3 dB ü LNA(Low Noise Amplifier) − Delivering to TRXA receiving part through RXDU by amplifying so that the received RF signal can have minimum additional noise components − Gain = 38dB, NF = 1.2dB max ü BPF(Band Pass Filter…

Text truncated - open the document above for the full version.

1130 East Arapaho Rd Richsrdson, Texas 75081 REQUEST FOR CONFIDENTIALITY Samsung Telecommunications Americas requests confidentiality with regard to the following documents in the filing for equipment approval identified by FCC ID. No. NP8SCBS-419M. (1) Schematic diagrams contained in electronic file identified as: schem1.pdf - schem10.pdf (2) Detailed circuit description contained in electronic file identified as: Circuit Description.pdf It is the opinion of Samsung Telecommunications Americas disclosure of this information would result in significant loss of revenue. This information should be kept confidential for 10 (ten) years. Authorized Signature: Deepak ParikhDate: 12/21/00 Samsung Telecommunications Americas 1130 East Arapaho Road Richardson, TX 75081 (972) 761-7000

Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 22 of 35 Photographs of Test Setup FRONT VIEW REAR VIEW

Company NameSamsung Telecommunication America FCC ID:NP8SCBS-419M Work Order Number1L0041R OUTDOOR BTS LABEL INFORMATION Position of UL/FCC Label for BTS Outdoor MFG Label UL/FCC Label Caution Label UL/FCC Label for BTS Outdoor NP8SCBS-419M M

Photo 1 - Transceiver Card with shield Photo 2 - Transceiver Card, without shield Photo 3 - Transceiver Card, trace side Photo 4 - BCPA Card, component side Photo 5 - BCPA Card, trace side Photo 6 - IFDA Card, component side Photo 7 - IFDA Card, trace side

NP8SCBS-419L Transmitter Tuning The SCBS-419L does not require manual tuning. Adjustment of the transmit rf output power is performed via software control by setting pre-defined levels.

NP8SCBS-419L RF Exposure Statement Statements relating to rf exposure are included in the user/installation manual on page 7 (page 9 of the electronic document). The product is intended for use with antennas mounted on permanent outdoor structures. Co- siting issues as they relate to rf exposure are to be addressed as part of the licensing requirement.

Nemko Test Report No.: 1L0042RUS1 Applicant: Samsung Telecommunications America 1130 Arapaho Road Richardson, Texas 75081 Equipment Under Test: V4 Outdoor BTS FCC ID: NP8SCBS-419M In Accordance With:FCC Part 24, Subpart E Broadband PCS Base Station Transmitter Tested By: Nemko Dallas Inc. 802 N. Kealy Lewisville, Texas 75057-3136 Authorized By:Tom Tidwell, Wireless Group Manager Date: February, 2001 Total Number of Pages: 35 Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 2 of 35 Table of Contents Section 1. Summary of Test Results........................................................................................3 Section 2. General Equipment Specification.............................................................................5 Section 3. RF Power Output....................................................................................................8 Test Data - RF Power Output.....................................................................................................9 Test Data - Occupied Bandwidth (CDMA)................................................................................11 Section 5. Spurious Emissions at Antenna Terminals.............................................................14 Test Data - Spurious Emissions at Antenna Terminals...............................................................15 Test Data - Spurious Emissions at Antenna Terminals...............................................................16 Test Data - Spurious Emissions at Antenna Terminals...............................................................17 Test Data - Spurious Emissions at Antenna Terminals...............................................................18 Test Data - Spurious Emissions at Antenna Terminals...............................................................19 Section 6. Field Strength of Spurious.....................................................................................20 Section 7. Frequency Stability...............................................................................................23 Test data - Frequency Stability..................................................................................................24 Section 8. Test Equipment List..............................................................................................25 ANNEX A - TEST DETAILS..................................................................................................26 ANNEX B - TEST DIAGRAMS..............................................................................................32 Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 3 of 35 Section 1.Summary of Test Results Manufacturer:Samsung Telecommunications Model No.:SCBS-319M Serial No.:None General:All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 24, Subpart E. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100426-0 Nemko Dallas Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Dallas Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 4 of 35 Summary Of Test Data NAME OF TESTPARA. NO.SPEC.MEAS.RESULT RF Power Output24.232100W18.2WComplies Occupied Bandwidth (CDMA)24.238GraphGraphComplies Occupied Bandwidth (GSM)24.238N/AN/AN/A Occupied Bandwidth (NADC)24.238N/AN/AN/A Spurious Emissions at Antenna Terminals 24.238(a)-13 dBm> -13 dBmComplies Field Strength of Spurious Emissions 24.238(a) -13 dBm E.R.P. < -39 dBmComplies Frequency Stability24.235 Must remain within the authorized band Maximum freq. error -117 Hz Complies Footnotes: 1. The E.U.T. is CDMA only. Measurement uncertainty is expressed to a confidence level of 95%. Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 5 of 35 Section 2.General Equipment Specification Supply Voltage Input: +27 Vdc Frequency Bands:TX Block A : 1930 – 1945 MHz Block D : 1945 – 1950 MHz Block B : 1950 – 1965 MHz Block E : 1965 – 1970 MHz Block F : 1970 – 1975 MHz Block C : 1975 – 1990 MHz Frequency Bands:RX Block A : 1850 – 1865 MHz Block B : 1865 – 1870 MHz Block C : 1870 – 1885 MHz Block D : 1885 – 1890 MHz Block E : 1890 – 1895 MHz Block F : 1895 – 1910 MHz CDMAGSMNADC (1M25G7W)(200KGXW)(40K0DXW) Type of Modulation and Designator: Maximum No. of Carriers: 3 Output Impedance: 50 ohms Per channel:20W RF Output (Rated): Total:60W SoftwareDuplexerFullband Band Selection: Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 6 of 35 Description of Modifications For Class II Permissive Change Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 7 of 35 System Description The V4 family of Base Station Transmitters consists of the following models: SCBS-319L - V4 Indoor Base Station Transmitter which holds FCC…

Text truncated - open the document above for the full version.

Dallas Headquarters: 802 N. Kealy Lewisville, TX 75057 Tel: (972) 436-9600 Fax: (972) 436-2667 Nemko Dallas, Inc. Data Plot Page 1 of1 CompleteX Job No.:0L0471RDate:3/8/01Preliminary Specification:PART 24Temperature(°C):22 Tested By:David LightRelative Humidity(%)50 E.U.T.: Configuration: Serial Number:None Location:AC 1RBW:30 kHz Detector Type:PeakVBW:30 kHz Test Equipment Used Antenna: Directional Coupler: Pre-Amp: Cable #1:1483 Filter: Cable #2:#N/A Receiver:1036Cable #3: Attenuator #11469Cable #4: Attenuator #2: Mixer: Additional equipment used:Bird 30 dB Attenuator Model #1000-WA-FFN-30 , Serial #0035 (Samsung) Cal'd prior to use. Measurement Uncertainty:+/-3.6 dB Notes: PCS BASE STATION TRANSMIT CHANNELS 25 & 50 (A BLOCK) - FULL POWER INTERMODULATION CHARACTERISTICS intermod lower band edge intermod lower band edge

Nemko Dallas FCC PART 24, SUBPART E BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT:V4 Outdoor BTS FCC ID:NP8SCBS-419MREPORT NO.:1L0042RUS1 Page 22 of 35 Photographs of Test Setup FRONT VIEW REAR VIEW
