Setup menuNetwork servicesCall divertCall barringCall waitingCall backCalling name presentationCall deflectionClosed user groupNetwork selectionSelection modePreferred listCountry listNetwork typesTones setup Ringing toneMessage toneBroadcast toneYour own ring toneKey toneSilent modeTremblerFactory settingsPhone setupLanguageIrDABacklightHandsfreeGreetingSignal diodeGraphicsOwner IDCall setupCaller IDSpeed diallingCaller accessAutomatic rediallingAny key answerCall timers and chargeIncoming call setupLine selection Message setupSend SMS setupBroadcast setupSorting of messagesWAP browser setupText input setupCalendar setupSet timeSet dateDisplay time and dateSet start of dayRemove entriesSecurityPIN code on/off and changeChange PIN 2 codeSIM lockChange network passwordEncryption indicationFixed dialling on/offBarred dialling on/offKeypad lockLine lock SAR Body ExposureDue to the possibility of expo-sure of SAR body-worn opera-tions of this mobile phoneshould be restricted to belt-clips, holsters or similar acces-sories that have no metalliccomponent in the assemblyand that provides at least 1 cmseparation between this de-vice and the user’s body. List menuApplicationsOutgoing callsAnswered calls Missed calls Phone booksStatusCalculatorDictaphone CalendarIrDA operationWAP BrowserMessagesAddress andphone bookentries Siemens service Complete survey of keypad functions and display symbols on pp. 80 - 83 Abu Dhabi Siemens Service Center 02713500Australia . Siemens . . . . . . . . . . . 1800622414Austria . . . . Siemens . . . . . . . . . . . 0517075004Bangladesh Siemens . . . . . . . . . . . . 017527447Belgium . . . Siemens . . . . . . . . . . . . 078152221Brunei. . . . . incomm . . . . . . . . . . . . . . . . . 02151Bulgaria . . . Omnitel . . . . . . . . . . . . . . 02739488China . . . . . Siemens . . . . . . . . . . 02150318149Croatia . . . . Siemens . . . . . . . . . . . . 016105381Czech Rep. . Siemens . . . . . . . . . . . 0233032727Denmark . . Siemens . . . . . . . . . . . . . 35258600Dubai . . . . . Siemens Service Center . 04699720Egypt . . . . . Siemens . . . . . . . . . . . . . 23313129Finland . . . . Siemens . . . . . . . . . . . . 092294370France . . . . Siemens . . . . . . . . . . . 0156384200Germany . . Siemens . . . . . . . . . . 01805333226Greece . . . . Siemens . . . . . . . . . . . . 016864389Hong Kong . Siemens . . . . . . . . . . . . . 22583636Hungary . . . Siemens . . . . . . . . . . . 0614712444Iceland . . . . Smith & Norland. . . . . . . . 5113000India . . . . . . Siemens . . . . . . . . . . . . 116923988 (ISDN) 116925589 Indonesia . . Dian Graha Elektr.. . . . 0214615081Ireland . . . . Siemens . . . . . . . . . . . 1850777277Italy . . . . . . Siemens . . . . . . . . . . . 0269893691Jordan . . . . F.A. Kettaneh. . . . . . . . . 079559663Kuwait . . . . NGEECO . . . . . . . . . . . . . . 4818749Latvia . . . . . Siemens . . . . . . . . . . . . . . . 7501114 Lebanon . . . . F.A. Kettaneh . . . . . . . . 01443043Lithuania . . . . Siemens . . . . . . . . . . . 822391555Luxembourg . Siemens . . . . . . . . . . . . 43843399Malaysia . . . . Siemens . . . . . . . . . . . 037514974Morocco . . . . SETEL S.A. . . . . . . . . . . . 2352409Mauritius . . . Ireland Blyth . . . . . . . . . . 2116213Netherlands . Siemens. . . . . . . . . . 0703333100Norway . . . . . Siemens. . . . . . . . . . . . 22708400Oman . . . . . . Siemens Service Center . 791012Pakistan . . . . Siemens . . . . . . . . . . 0215673565Philippines . . Siemens . . . . . . . . . . . . 28149888Poland . . . . . . Siemens. . . . . . . . . . 0800220990Portugal . . . . Siemens . . . . . . . . . . . 014178393Russia . . . . . . Siemens . . . . . . . . . 80957371801Saudi Arabia . Siemens . . . . . . . . . . . 026655058Singapore . . . Siemens . . . . . . . . . . . . . 8454818Slovak Rep. . . Siemens . . . . . . . . . . 0759682266Slovenia . . . . Siemens . . . . . . . . . . 0611746336South Africa . Siemens . . . . . . . . . . 0800114050Spain. . . . . . . Siemens . . . . . . . . . . . 902115061Sweden. . . . . Siemens . . . . . . . . . . . 087509911Switzerland. . Siemens . . . . . . . . . . . 012120090Taiwan . . . . . Siemens . . . . . . . . . . 0225186504Thailand . . . . Siemens . . . . . . . . . . . . 26791777Turkey . . . . . . SIMKO . . . . . . . . . . 02122528835United Kingd. Siemens . . . . . . . . . . 0990334411USA. . . . . . . . Siemens . . . . . . . 1-877 687 1671Vietnam . . . . Opticom . . . . . . . . . . . 090456789 Internet:http://www.siemens.com/cd.service Menu overview Cover S40 US 17/01/01 11:41 Side 3

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 86 of 88 Exhibit 13 Exhibit 13: Cover Letters September 13, 2000 FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: Enclosed is a FCC Part 24, Certification application for the Siemens Mobile Phones A/S Model S42, FCC ID: NRR-S4X. Please let me know if I can be of further assistance. Sincerely yours, COMMUNICATION CERTIFICATION LABORATORY Joseph W. Jackson V.P. Marketing COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 87 of 88 Exhibit 13 Request for Confidentiality COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 88 of 88 Exhibit 13 Change in Control of Grantee Code Letter

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 4 of 88 Exhibit 3 Exhibit 3: Photographs of Overall Appearance Front View of the S42 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 5 of 88 Exhibit 3 Back View of the S42 (with battery) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 6 of 88 Exhibit 3 Back View of the S42 (without battery) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 7 of 88 Exhibit 3 Front View of the S40 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 8 of 88 Exhibit 3 Battery Charger Accessory COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 9 of 88 Exhibit 3 Headset Accessory COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 10 of 88 Exhibit 3 Car Charger Accessory COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 11 of 88 Exhibit 3 Car Comfort Kit Accessory

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 1 of 88 Exhibit 1 Exhibit 1: FCC ID Label Equipment Identification Label In accordance with the requirements of Sections 2.925 and 2.926 of the FCC Rules, the following information will be permanently affixed to the Siemens Mobile Phones A/S Model S42 as shown in the photograph below and the photograph on Page 2. COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 2 of 88 Exhibit 1 Photograph of the back exterior view showing the label placement.

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 55 of 88 Exhibit 9 Exhibit 9: Internal Photographs Inside view of the S42 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 56 of 88 Exhibit 9 Battery COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 57 of 88 Exhibit 9 Antenna COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 58 of 88 Exhibit 9 Front view of the MMI module, main PCB and RF gasket that is placed between the two boards COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 59 of 88 Exhibit 9 Back view of the MMI module, main PCB and RF gasket that is placed between the two boards COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 60 of 88 Exhibit 9 Front view of the MMI module COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 61 of 88 Exhibit 9 Back view of the MMI module COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 62 of 88 Exhibit 9 Front view of the main PC board (with RF can) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 63 of 88 Exhibit 9 Front view of the main PC board (without RF can) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 64 of 88 Exhibit 9 Back view of the main PC board

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7306 FCC ID: NRR-S4X Page 84 of 88 Exhibit 11 Exhibit 11: RF Exposure/Environmental Evaluation Section 24.51 and 24.52 Requirement 24.51: The device must comply with IEEE C.95.1-1991, (ANSI/IEEE C.95.1-1992), “Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz”. Measurement methods are specified in IEEE C95.3-1991, “Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields-RF and Microwave”. Requirement 24.52: Licensees and manufacturers are subject to the radiofrequency radiation exposure requirements specified in § 1.1307(b), 2.1091 and 2.1093 of this chapter, as appropriate. All equipment shall be considered to operate in a “general population/uncontrolled” environment. Applications for equipment authorization of devices operating under this section must contain a statement confirming compliance with these requirements for both fundamental emissions and unwanted emissions. Technical information showing the basis for this statement must be submitted to the Commission upon request. Demonstration of Compliance: The S40 and S42 are classified as portable devices. Therefore, the S40 and S42 are subject to routine environmental evaluation for RF exposure as per § 2.1093(c). Testing to demonstrate compliance to this section was tested in accordance with the requirements of ANSI C95.1, the results of the tests for both the S40 and S42 were sent as a separate pdf files.

TTI-P-G 158 DASY Test-Report, Siemens_ 6575_113a Page 1 of 14 Report Dosimetric Assessment of the Mobile Telephone Siemens S40 According to the American FCC Requirements July 21, 2000 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort customer Siemens Mobile Phones A/S Industrivej 30 DK-9490-Pandrup The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_us_2.1.doc/26.01.2000/AB DASY Test-Report, Siemens_ 6575_113a Page 2 of 14 dasy_report_us_2.1.doc/26.01.2000/AB Executive Summary The device S40 (IMEI: 004513-67-000469-4) is a new mobile phone from Siemens operating in the 1900 MHz frequency range. The device has an integrated antenna. The system concept used is the PCS 1900 standard. The objective of the measurements done by IMST was the dosimetric assessment of one device. The examinations have been carried out with the dosimetric assessment system „DASY“. The measurements were made according to the Federal Communications Commission (FCC) Guidelines [FCC 1997] for evaluating compliance of mobile phones with the American Standard ANSI C95.1 [ANSI 1992]. In [ANSI 1992] limits are defined to prevent harmful effects in human beings exposed to electromagnetic fields. The Siemens S40 mobile phone is in compliance with the American Standard ANSI C95.1 [ANSI 1992]. prepared by: ........................................... reviewed by: .............................................. Dipl.-Ing. Christoph Hennes Dr.-Ing. Frank Gustrau test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 372 Fax +49- 2842-981 398 email: [email protected] DASY Test-Report, Siemens_ 6575_113a Page 3 of 14 dasy_report_us_2.1.doc/26.01.2000/AB Table of Contents 1 SUBJECT OF INVESTIGATION.............................................................................................................. 4 2 THE AMERICAN STANDARD ANSI C95.1............................................................................................ 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES..................... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS.............................................. 5 2.3 SAR LIMIT............................................................................................................................................ 5 3 THE AMERICAN MEASUREMENT PROCEDURE............................................................................... 5 3.1 TEST CONDITIONS.................................................................................................................................. 6 3.2 TEST POSITION...................................................................................................................................... 6 4 THE MEASUREMENT SYSTEM............................................................................................................. 6 4.1 TECHNICAL PARAMETERS OF THE MEASUREMENT SYSTEM......................................................................... 8 5 SAR RESULTS........................................................................................................................................... 9 6 EVALUATION ......................................................................................................................................... 10 7 APPENDIX............................................................................................................................................... 12 7.1 ADMINISTRATIVE DATA......................................................................................................................... 12 7.2 DEVICE UNDER TEST AND TEST CONDITIONS.......................................................................................... 12 7.3 DASY OPTIONS................................................................................................................................... 12 7.4 TEST POSITION.................................................................................................................................... 12 7.5 MATERIAL MEASUREMENT SYSTEM........................................................................................................ 13 7.6 ENVIRONMENT.................................................................................................................................... 14 8 REFERENCES ......................................................................................................................................... 14 DASY Test-Report, Siemens_ 6575_113a Page 4 of 14 dasy_report_us_2.1.doc/26.01.2000/AB 1 Subject of Investigation The device S40 shown in Fig. 1 is a new mobile phone from Siemens operating in the 1900 MHz frequency range. The device has an integrated antenna. The system concept used is the PCS 1900 standard. Fig. 1: Picture of the device under test. The objective of the measurements done by IMST was the dosimetric assessment of one device. The examinations have been carried out with the dosimetric assessment system „DASY“ described below. 2 The American Standard ANSI C95.1 In the USA the recent Standard ANSI C95.1 was published in April 1992 [ANSI 1992]. It sets limits for human exposure to radiofrequency fields in the frequency range 3 kHz to 300 GHz. 2.1 Distinction Between Exposed Population, Duration of Exposure and Frequencies The American standard distinguishes between controlled and uncontrolled environment. Controlled environments are locations where there is exposure that may be incurred by persons who are aware of the potential for exposure as a concomitant of employment or by other cognizant persons. Uncontrolled environments are locations where there is the exposure of individuals who have no knowledge or control of their exposure. The exposures may occur in living quarters or workplaces. For e…

Text truncated - open the document above for the full version.

TTI-P-G 158 DASY Test-Report, Siemens_ 6575_113b Page 1 of 14 Report Dosimetric Assessment of the Mobile Telephone Siemens S42 According to the American FCC Requirements July 21, 2000 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort customer Siemens Mobile Phones A/S Industrivej 30 DK-9490-Pandrup The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_us_2.1.doc/26.01.2000/AB DASY Test-Report, Siemens_ 6575_113b Page 2 of 14 dasy_report_us_2.1.doc/26.01.2000/AB Executive Summary The device S42 (IMEI: 004513-67-000081-7 ) is a new mobile phone from Siemens operating in the 1900 MHz frequency range. The device has an integrated antenna. The system concept used is the PCS 1900 standard. The objective of the measurements done by IMST was the dosimetric assessment of one device. The examinations have been carried out with the dosimetric assessment system „DASY“. The measurements were made according to the Federal Communications Commission (FCC) Guidelines [FCC 1997] for evaluating compliance of mobile phones with the American Standard ANSI C95.1 [ANSI 1992]. In [ANSI 1992] limits are defined to prevent harmful effects in human beings exposed to electromagnetic fields. The Siemens S42 mobile phone is in compliance with the American Standard ANSI C95.1 [ANSI 1992]. prepared by: ........................................... reviewed by: .............................................. Dipl.-Ing. Christoph Hennes Dr.-Ing. Frank Gustrau test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 372 Fax +49- 2842-981 398 email: [email protected] DASY Test-Report, Siemens_ 6575_113b Page 3 of 14 dasy_report_us_2.1.doc/26.01.2000/AB Table of Contents 1 SUBJECT OF INVESTIGATION.............................................................................................................. 4 2 THE AMERICAN STANDARD ANSI C95.1............................................................................................ 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES..................... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS.............................................. 5 2.3 SAR LIMIT............................................................................................................................................ 5 3 THE AMERICAN MEASUREMENT PROCEDURE............................................................................... 5 3.1 TEST CONDITIONS.................................................................................................................................. 6 3.2 TEST POSITION...................................................................................................................................... 6 4 THE MEASUREMENT SYSTEM............................................................................................................. 6 4.1 TECHNICAL PARAMETERS OF THE MEASUREMENT SYSTEM......................................................................... 8 5 SAR RESULTS........................................................................................................................................... 9 6 EVALUATION ......................................................................................................................................... 10 7 APPENDIX............................................................................................................................................... 12 7.1 ADMINISTRATIVE DATA......................................................................................................................... 12 7.2 DEVICE UNDER TEST AND TEST CONDITIONS.......................................................................................... 12 7.3 DASY OPTIONS................................................................................................................................... 12 7.4 TEST POSITION.................................................................................................................................... 12 7.5 MATERIAL MEASUREMENT SYSTEM........................................................................................................ 13 7.6 ENVIRONMENT.................................................................................................................................... 14 8 REFERENCES ......................................................................................................................................... 14 DASY Test-Report, Siemens_ 6575_113b Page 4 of 14 dasy_report_us_2.1.doc/26.01.2000/AB 1 Subject of Investigation The device S42 shown in Fig. 1 is a new mobile phone from Siemens operating in the 1900 MHz frequency range. The device has an integrated antenna. The system concept used is the PCS 1900 standard. Fig. 1: Pictures of the device under test. The objective of the measurements done by IMST was the dosimetric assessment of one device. The examinations have been carried out with the dosimetric assessment system „DASY“ described below. 2 The American Standard ANSI C95.1 In the USA the recent Standard ANSI C95.1 was published in April 1992 [ANSI 1992]. It sets limits for human exposure to radiofrequency fields in the frequency range 3 kHz to 300 GHz. 2.1 Distinction Between Exposed Population, Duration of Exposure and Frequencies The American standard distinguishes between controlled and uncontrolled environment. Controlled environments are locations where there is exposure that may be incurred by persons who are aware of the potential for exposure as a concomitant of employment or by other cognizant persons. Uncontrolled environments are locations where there is the exposure of individuals who have no knowledge or control of their exposure. The exposures may occur in living quarters or workplaces. For…

Text truncated - open the document above for the full version.

The response to your questions are listed below: Re: FCC ID NRR-S4X Applicant: Bosch Telecom Danmark AS Correspondence Reference Number: 16227 731 Confirmation Number: EA98749 Date of Original E-Mail: 09/21/2000 Please place your reply in the RF exposure info folder. A technical review is pending. Make sure the EIRP measurements are submitted. Bosch Telecom, EA 98749 - 1. The highest conducted output indicated in the EMC report is 28.8 dBm. SAR report has indicated 30 dBm. Please verify discrepancies and confirm the maximum output of production units. What are the conducted outputs measured before and after the SAR tests? Response: The output power (dBm) measured before and after SAR measurements (conducted) is as follows: Type:ch512ch661ch810 S4030.630.530.4 S4230.630.530.4 The values are measured at the RF connector. At production units the output power is max. 30 dBm at the RF connector 2. Users manual describes a headset PTT accessory. Please clarify if this particular accessory would allow users to operate this device in body-worn operating configurations with belt-clips, holsters or other similar accessories, either supplied with this device or available through third party suppliers. A device with a headset output is considered to have provisions for body-worn use. If it is supplied with belt-clips, holsters or similar accessories or available as options, such accessories should be tested with the device to demonstrate body-worn SAR compliance. If the device does not come with belt-clips or similar accessories and users may acquire third party accessories for body-worn use, the device should be tested with a separation distance of 1-2 cm between the back of the device and a muscle-equivalent phantom to demonstrate body-worn SAR compliance. Applicable operating instructions should be included in the users manual, at a conspicuous location towards the front, to indicate to users the applicable body-worn operating requirements for satisfy FCC RF exposure compliance - limited to the specific belt-clips tested or limited to belt-clips…
