NS645517-0027MHZTRUE HERO-R/C DUNE BUGGY

Parts List Remote Control How to Power Up RC Vehicle How to Control RC Vehicle Warning Initial Setup & Battery Replacement Care & Maintenance After Use Storage Battery Warnings 1. 1 x Remote control 2. 1 x RC Vehicle 3. 2 x Figures 1. Take the remote control out of the package (for initial setup only). 2. Loosen screw from battery compartment door with a Phillips head screwdriver (not included). 3. Remove battery compartment door. 4. Insert 1 9V Alkaline battery in the orientation shown. 5. Replace and secure the battery compartment door. Simply slide the ON/OFF switch on the RC Vehicle and remote control to the “On” position. Power indication LED lights up to show remote control is switched on. • Adult setup and supervision required at all times. • Adult should instruct children on proper use of this toy. • Only for children ages 5 or above. • Do not stand on this product. • Keep away from fire. • Do not immerse this toy in water. • Play on hard, flat surfaces only. Important: Only ADULTS should replace batteries. Replace all included batteries that came with this item with new alkaline batteries upon purchase. RC Vehicle 1. Take the vehicle out of the package (for initial setup only). 2. Loosen screws in battery compartment door with a Phillips / cross-head screwdriver (not included). 3. Remove battery compartment door. 4. Insert 4 “AA” Alkaline batteries in the orientation shown. 5. Replace and secure the battery compartment door. • Figure can be positioned standing on outside or sitting inside vehicle. • Clean the product (plastic parts) with a damp cloth. • Do not immerse this in water. • Do not expose product to direct sunlight for long periods of time. • If movements from this toy became weak or slow, replace the batteries. • Do not take this toy apart since no serviceable parts are availble. • A power protective circuit is inside the RC vehicle. I t s h u t s d o w n t h e p o w e r w h e n a n object gets trapped in the driving wheel to avoid malfunction or damage to the vehicle. After a few seconds, it will restart automatically. Remove all batteries before storage. NOTE: Always store the product in a dry place. Never leave outside when not in use! Important! Only adults should replace batteries. • Use of alkaline batteries is recommended. • Do not use rechargeable batteries. • Non-rechargeable batteries are not to be recharged. • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. • Only batteries of the same or equivalent type as recommend are to be used. • Used batteries are to be inserted with the correct polarity. • Exhausted batteries are to be removed from the toy. • The supply terminals are not to be short-circuited. • Please keep this information for future reference. • Remove batteries from the product before extended storage. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC ID: CAUTION: Do not modify this toy or any of the included components. Light & Sound function On/Off Adjust front wheel alignment Power indication LED After pressing the button on the controller, the gun will flash on. On/Off Forward Backward right & left Forward right Forward left Reverse right Reverse left Forward Backward Dune BuggyDune BuggyDune Buggy 55 Lista de piezas Control remoto Cómo encender el vehículo por control remoto Cómo controlar el vehículo por radio control Advertencia Configuración inicial y cambio de las pilas Cuidado y mantenimiento Almacenamiento después de su utilización Advertencias sobre las pilas 1. 1 control remoto 2. 1 vehículo por radio control 3. 2 figuras Importante: Sólo los ADULTOS deben cambiar las pilas. Reemplazar todas las pilas que se incluyen con este artículo por pilas alcalinas nuevas. Vehículo por radio control • El muñeco puede colocarse de pie fuera del vehículo o sentado dentro de él • Limpiar el producto (piezas de plástico) con un paño húmedo. • No sumergirlo en agua. • No se debe exponer el producto a la luz directa del sol durante un largo período de tiempo. • Cambiar las pilas si el funcionamiento del producto se vuelve lento o débil. • No desmontar este juguete, ya que sus piezas no son útiles por separado. • El vehículo por control remoto lleva incorporado un circuito protector que desconecta la energía cuando un objeto bloquea la dirección. Tras unos segundos se reiniciará automáticamente. Retirar todas las pilas antes de guardar el juguete. NOTA: Guardar siempre el producto en un lugar seco. ¡No dejarlo nunca fuera cuando …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Manley Toys Ltd 2010-11-25 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ___ Manley Toys Ltd ____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): TRUE HERO-R/C DUNE BUGGY; 45517 We affirm that between SIEMIC and __ Manley Toys Ltd ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Eric Cheng / QA Manager Contact information / address: 8/F Hong Kong Spinners Industrial Bldg 818 Cheung Sha Wan Road

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Manley Toys Ltd 2010-11-25 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: NS645517-0027MHZ We hereby request confidential treatment of information accompanying this application as outlined below: - Schematics - Block Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Eric Cheng / QA Manager Contact information / address: 8/F Hong Kong Spinners Industrial Bldg 818 Cheung Sha Wan Road

1 Size: 52mm(L)*35mm(W) FCC ID: NS645517-0027MHZ This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location

1 Cove over Page FCC REPORT Applicant: Manley Toys Ltd Address of Applicant: 8/F Hong Kong Spinners Industrial Bldg 818 Cheung Sha Wan Road Equipment Under Test (EUT) Product Name: TRUE HERO-R/C DUNE BUGGY Model No.: 45517 FCC ID: NS645517-0027MHZ Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.227:2009 Date of Receipt: 17 Nov., 2010 Date of Test: 18-23 Nov., 2010 Date of Issue: 24 Nov., 2010 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager Report No: GTSE10110032001 Project No.: GTSE101100320TX Page 2 of 12 2 Contents Page 1 COVE OVER PAGE................................................................................................................................................ 1 2 CONTENTS.............................................................................................................................................................. 2 3 TEST SUMMARY.................................................................................................................................................... 3 4 GENERAL INFORMATION................................................................................................................................... 4 4.1 CLIENT INFORMATION....................................................................................................................................... 4 4.2 GENERAL DESCRIPTION OF E.U.T................................................................................................................... 4 4.3 E.U.T OPERATION MODE.................................................................................................................................. 4 4.4 TEST FACILITY................................................................................................................................................... 5 4.5 TEST LOCATION................................................................................................................................................ 5 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER.................................................................................. 5 4.7 TEST INSTRUMENTS LIST.................................................................................................................................. 6 5 TEST RESULTS AND MEASUREMENT DATA................................................................................................ 7 5.1 ANTENNA REQUIREMENT:................................................................................................................................. 7 5.2 RADIATED EMISSION......................................................................................................................................... 8 5.2.1 Field Strength Of The Fundamental Signal......................................................................................... 10 5.2.2 Spurious Emissions................................................................................................................................. 10 5.3 20DB BANDWIDTH........................................................................................................................................... 11 Report No: GTSE10110032001 Project No.: GTSE101100320TX Page 3 of 12 3 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 PASS Field strength of the fundamental signal 15.227 (a) PASS Spurious emissions 15.227/15.209 PASS 20dB Bandwidth ANSI C63.4/15.227 PASS Remark: ● Passed: The EUT complies with the essential requirements in the standard. ● Failed: The EUT does not comply with the essential requirements in the standard. ● Tx: In this whole report Tx (or tx) means Transmitter. ● Rx: In this whole report Rx (or rx) means Receiver. Report No: GTSE10110032001 Project No.: GTSE101100320TX Page 4 of 12 4 General Information 4.1 Client Information Applicant: Manley Toys Ltd Address of Applicant: 8/F Hong Kong Spinners Industrial Bldg 818 Cheung Sha Wan Road Manufacturer/Factory: Zhongshan Fuhai Industrial Co. Ltd. Address of Manufacturer/Factory: Dache Industrial Area, Nanlang Town, Zhongshan City, Guangdong, China 4.2 General Description of E.U.T. Product Name: TRUE HERO-R/C DUNE BUGGY Model No.: 45517 Operation Frequency: 27.020MHz Modulation type: ASK Antenna Type: Integral Power supply: DC 9.0V(“6F22” size) 4.3 E.U.T Operation mode Operating Environment: Temperature: 24.0 °C Humidity: 52 % RH Atmospheric Pressure: 1008 mbar Test mode: Transmitting mode: Keep the EUT in transmitting with interior modulation. Report No: GTSE10110032001 Project No.: GTSE101100320TX Page 5 of 12 4.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: ● FCC —Registration No.: 600491 Global United Technology Service Co., Ltd., Shenzhen EMC Laboratory has been registered and fuly described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in out files. Registration 600491, July 20, 2010. ● Industry Canada (IC) The 3m Semi-anechoic chamber of Global United Technology Service Co., Ltd. Has been Registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 9079A-1. ● CNAS (No. CNAS L3783) CNAS has accredited Reliance Technical Service Limited. Shenzhen EMC Laboratory to ISO/IEC 17025:2005 General Requirements for the Competence of Testing and Calibration Laboratories for the competence in the field of testing. 4.5 Test Location All tests were performed at: Global United Technology Service Co., Ltd. Address: 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China Tel: 0755-27798480 Fax: 0755-27798960 4.6 Other Information Requested by the Customer None. Report No: GTSE10110032001 Project No.: GTSE101100320TX Page 6 of 12 4.7 Test Instruments list …
