DIN EN ISO 9001 Created: TN, 21.02.2011 Page 1 of 32 S_01125- A1_E_Documentation_R09.doc SR-Module HG 76360 ZA Operational Description, Block Diagrams and Users Manual Revision - History Documentation Rev. Author Date Reason fo Modification 01 TN 27.05.2009 Reissued 02 TN/TG/TK 21.07.2009 Adapted to firmware V0.17 03 TN/TG 26.10.2009 Adapted to firmware V0.22 (page.5 and page.8) 04 TN/TG 03.09.2010 V0.24-V0.28 updated and commissioning 05 TN/TG 09.12.2010 V0.29 updated 06 TN/TG 24.03.2011 P. 18, Table 8, Bit 3 and 4, Rx, Tx changed 07 TN 12.05.2011 Block diagram included 08 TN 01.06.2011 Labels for type approvals added, page 27 09 TN 11.07.2011 minor changes Revision - History Software Rev. Date Reason for Modification V0.20 10.08.2009 Module doesn’t start before Host configuration V0.21 11.09.2009 Debug version for log- analysis V0.22 13.10.2009 Different bug fixes Master of last connection is stored on slaves Packets have to be received successfully on both channels if slave looks for a master The configuration memory will be regularly written with meaningful values before each interrupt calling for configuration V0.24 29.01.2010 Detection and signalisation of burst errors V0.26 28.04.2010 Reading bus- test and debug information V0.28 11.08.2010 Quicker activation of radio chips (Warning: unstable) V0.29 16.08.2010 The “Lost-Sync” interrupt (BIT 5) is now redefined to a “Lost- Reg” interrupt, as already defined before. If text debugdata are provided, a SetDebugAvailable is set now, otherwise 0 (see GRFExternInterface, i.e. after SerDebug). So far only values from 1- 10 were correctly processed for the Master ID. From now on the Master ID can be set up to a value of 255 (as usual, only more options). The automatic search function only scans the first 10 options. Thus a conflict in an environment with a lot of operational systems can be avoided. Documentation Rev. 08 DIN EN ISO 9001 Created: TN, 21.02.2011 Page 2 of 32 S_01125- A1_E_Documentation_R09.doc Table of Contents SR-Module HG 76360 ZA......................................................................................................1 Revision - History Documentation .......................................................................................1 Revision - History Software.................................................................................................1 Table of Contents ...............................................................................................................2 Documentation .....................................................................................................................4 Short-range transmission module (SR module for Transmodule) ........................................4 General points ....................................................................................................................4 Block diagrams ...................................................................................................................5 Timing.................................................................................................................................6 Signal integrity ....................................................................................................................6 Registering a new vehicle, solving slave to master allocation problems ..............................7 Allocating time slot to a sledge number and slave ID ..........................................................7 Sledge malfunction .............................................................................................................8 Commissioning new machine / new facility .........................................................................8 Commissioning, service (controlled by host) .......................................................................9 Standard operation .............................................................................................................9 Memory configuration / structure.........................................................................................9 Configuration ....................................................................................................................10 Start- Configuration register from offset 0x0400 (RXDPRAM): ..........................................11 Frequency Hopping...........................................................................................................11 Data Memory ....................................................................................................................12 Telegram Memory Configuration (received from offset 0x400) ..........................................12 Telegram memory configuration (transmitting from offset 0x0000)....................................12 Status Information.............................................................................................................13 Control- and Status register (CTRL register from offset 0x800).........................................14 CRC Checksum ................................................................................................................15 Initialising Process ............................................................................................................16 Communication Cycle .......................................................................................................17 Timing...............................................................................................................................17 Time Slots.........................................................................................................................17 LED Status Signalling .......................................................................................................18 Module is configured as slave .......................................................................................18 Module is configured as master.............…
Text truncated - open the document above for the full version.
Götting KG, Celler Str, 5, D - 31275 Lehrte/Röddensen GOTTTlNE Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 lhr Zeichen, Ihre Nachricht vomUnser Zeichen, unsere Nachricht vom TN/HHG Götting KG Celler Str. 5 D -31 27 5 Leh rte/Röddensen Germany Tel.: +49 (0) 51 36 80 96 -0 Fax.: +49 (0) 51 36 80 96 -80 E-Mail: [email protected] I nternet: www. goetting.de Lehrte, den 3'1 . Mai 2011 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC lD: NUDHG76360 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Hans - H. Götting Managing Director Götting KG KG, Celler Slraße 5,31275 Lehrte/Röddensen E!{ -::EJ L orN EN rso 9oo1 Geschäftsführer H.-H. Götting HRA31127 Amtsgericht Hildesheim Gerichtsstand Lehrte USl.-ld. Nr. DE 11s055039 USt.-Nr. 16-226-13403 Telefon: 0 51 36 - 80 96 -0 Fax: 0 51 36 - 80 96 -80 E-Mail: [email protected] lnternet: www.goetting.de Bankverbindungen: Stadtsparkasse Burgdorf BLZ251 513 71, Konto 281 6 IBAN DE48 2515 1371 0000 002816 Volksbank Lehrte BIZ 251 933 31 , Konto 76 02 1 5 80 00 IBAN DE58 2519 3331 7602 1 580 00
Göfting KG, Celler Str. 5, D - 31275 Lehrte/Röddensen GOTTIINE Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 lhr Zeichen, lhre Nachricht vomUnser Zeichen, unsere Nachricht vom TN/HHG Götting KG Celler Str. 5 D-31 27 5 Lehrte/Röddensen Germany Tel.: +49 (0) 51 36 80 96 -0 Fax.: +49 (0) 51 36 80 96 -80 E-Mail: [email protected] lnternet: www.goeiting.de Lehrte, den 31. Mai 2011 Request for Confidentialitv Company name: Götting KG FCC lD: NUDHG76360 FCC Part 15 Certification Gentlemen, ln accordance with 0.459 of CFR 47, Götting KG hereby requests confidentiality of following attachments: Block Diagrams, Circuit Description, Schematics, Parts List, Operational Description for the subject application. These documents contain detailed system and equipment description and related information about the product which Götting KG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Götting KG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Götting KG Celler Straße 5 31275 Lehrte Hans - H. Götting Managing Director GÖTTING KG, celler Straße 5,31275 Lehrte/Röddensen Telefon: 0 51 36 - 80 96 -0 Fax: 0 51 36 - 80 96 -80 E-Mail: [email protected] lnternet: www.goetting.de Bankverbindungen: Stadtsparkasse Burgdorf BLZ251 513 71 , Konto 281 6 |BAN DE48 2515 1371 0000 002816 vorksbank Lehrte l't]-*$ 'll BLZ251 933 31, Konto 76 02 1 5 80 00 DrN EN rso e001 |BAN DE58 25'19 333'1 7602 1580 00 'i:.. Geschäftsführer H.-H. Götting HR A 31127 Amtsgericht Hildesheim Gerichtsstand Lehrte USt.-ld. Nr. DE 115055039 USt.-Nr. 16-226-13403
g9ling XC, Celter Srr. S, D - 31275 LehrreiRöddensen Modular Approval Request Letter Date: 2011-07-12 FCC lD: NUDHG76360 Type of Equipment: Modelname: HG 76360 -H. Götting General Manager Götting KG Celler Straße 5 31275 Lehrte Germany EgITLrc Götting KG Celler Str. 5 D-3 1 27 5 Leh rte/Röd den se n Germany Tel.: +49 (0) 51 36 80 96 _0 Fax.: +49 (0) 51 36 80 96 -80 E-Mail: [email protected] lnternet: www. goetting.de lil IV We, Eurofins Product Service GmbH, are authorized by Gpettinq KG to approve the above described unlicensed radio device under modular approval rne appiEffi of this module is specified to mobile host equipment. The requirements have been furfiiled ,ni "*pr",ned berow: RF shielding The radio portion does not need any shierding (see externar photos). Buffered modulation/data inputs, has been integrated in the chifset Power supply regulation, is integrated Antenna requirements section 15.203,15.204 b and 15.204 c The module comes with two permanently attached antennas. The spurious emission requirements are fulfilled (see attached test report). Stand alone test configuration Please referring to test set up configuration photo Labelling The module has its own label. The instruction for labelling rules for the host device has been stated in the users manual Gompliance on specific rule or operating requirements The required FCC rules has been tütntteo "]-ro ait instructions for maintaining compliance has been clearly stated in the users manual RF Exposure, F exposure requirements are fulfilled for mobile configuration. The installation of the module is rstricted to mobile host devices what is clearly stated i-n the instaitation instruction of the user anual vt vil vilr KG, Celler StEße 5, 3127S Lehrte/Röddensen Geschäftsführer H.-H. Gottrno HR A 31i27 Amtsgericht Hitdäsherm Gerichtsstand Lehrie EAR-Reg.Nr. DE 2 12B9ZB8 ust.-td. Nr. DE 1 1 5055039 USt.-Nr. 16-226-134A3 Telefon: 0 51 36 - B0 96 -O Fax: 0 51 36 - 80 96 -BO E-Mail: [email protected] lnternet: www.goetting.de Ban kverbindungen: Stadisparkasse Burgdorf BLZ251 513 71, Konto 281 6 BIC: NOLA DE 21 BUF IBAN DE48 2515 1371 oOOO 002816 Hännoversche Volksbank BLZ 251 900 0.1, Konto S45 83S 800 BIC: VOHA DE 2 H rBAN DE68 2519 oool 054s 8358 o0 l,-Tlnl=^--ll il'teEtitr-'l iu:9
Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Pictures EUT Top EUT Bottom Page 13 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT with antenna 1 EUT with antenna 2 Page 14 of 52
Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Pictures EUT Top EUT Bottom Page 13 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT with antenna 1 EUT with antenna 2 Page 14 of 52
Götting KG, Celter Str. S, D ,3127b Lehrte/Röddensen qaurc It is hereby declared that the product Model No.: HG76350 SR Radio Module FCC lD: NUDHG7636O fulfills the requirement in FCC test rerating to the antenna type. The device specified above confirms to the FCC recommendations for external antenna type described below: Götting KG Celler Str. 5 D -31 27 5 LehrtelRöddensen Germany Tel.: +49 (0) 5i 36 B0 96 -O Fax.: +49 (0) 51 36 80 96 -80 E-Mail: [email protected] lnternet: www.goetting.de Model No. of antenna: Type of antenna: Gain of the antenna: Frequency range: less than 0 dB 2400 lo 2500 MHz Modet No. of antenna: HW CAB000S8 Type of antenna: Radiatino cable Gain of the antenna: less than O dB Frequency range: 2400 to 2S0O MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Göttinq KG Address: City: Celler Straße 5 Lehrle - ZIP / Postal code:31225 Country: Germanv Place: Signature: KG, Celler Straße 5, 3i275 Lehrte/Röddensen Telefon: 0 51 36 - g0 96 -O Fax: 0 51 36 - 80 9O -80 E-Mail: [email protected] lnternet: www.goetting.de Date: 12.Q7.2011 Bankverbi ndungen: Stadtsparkasse Burgdorf BLZ 251 513 7'1, Konto 2e1 6 BIC: NOLA DE 21 BUF |BAN DE48 2515 1371 0000 002816 Hannoversche Volksbank BLZ 251 900 01, Konto 545 835 800 BIC: VOHA DE 2 H IBAN DE68 2519 0001 0545 8358 o0 Geschäftsführer H.-H. Göttino HR A 31127 Amtsgericht Hildäsherm Gerichtsstand Lehrte EAR-Reg.Nr. DE 21289798 USt.-ld. Nr. DE 1 1 5055039 USt.-Nr 16-2?6-13403 l[--=Tljl/=-. ]l It=e=ffi:- 11 u:1:::::,
Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 EUROFINS PRODUCT SERVICE GMBH TEST - REPORT FCC RULES PART 15 / SUBPART C §15.249 RSS 210 Issue 7 FCC ID: NUDHG76360 SR-radio module HG 76360 Test report no.: G0M21009-3638-C-1 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1 General Information 3 1.1 NOTES 3 1.2 T ESTING LABORATORY 4 1.2.1 Location 4 1.2.2 Details of accreditation status 4 1.2.3 Details of approval holder 4 1.4 A PPLICATION DETAILS 5 1.5 T EST ITEM 5 1.6 T EST STANDARDS 6 2 Technical test 6 2.1 SUMMARY OF TEST RESULTS 6 2.2 T EST ENVIRONMENT 6 2.3 T EST EQUIPMENT UTILIZED 7 2.4 G ENERAL TEST PROCEDURE 8 3 Test results 9 3.1 OUTPUT POWER (FIELD STRENGTH) FCC § 15.249 (A), RSS 210 A2.9 10 3.1.2 De facto equivalent isotropic radiated power 10 3.1.3 Transmitter 10 3.2 RF EXPOSURE COMPLIANCE REQUIREMENTS 11 3.3 R ADIATED EMISSIONS; FCC § 15.249 (D); RSS 210 A2.9 11 Annex A Pictures 13 Annex B Fundamental Field Strength 16 Annex C Spurious Emissions radiated - Transmitter operating 23 Page 2 of 52 Page 3 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory 1.2.1 Location EUROFINS PRODUCT SERVICE GMBH Storkower Strasse 38c D- 15526 Reichenwalde Germany Telephone : + 49 33631 888 00 Telefax : + 49 33631 888 660 1.2.2 Details of accreditation status DA KKS ACCREDITED TESTING LABORATORY DA KKS-REGISTRATION NUMBER: D-PL-12092-01-01 RECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 1.2.3 Details of approval holder Name : Gerhard Schubert GmbH Verpackungsmaschinen Street : Hofäckerstr. 7 Town : 74564 Crailsheim Country : GERMANY Telephone : +49 7951 400803 Contact : Herr Jens Stoll Telephone : +49 7951 400803 E-mail : [email protected] Page 4 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Application details Date of receipt of application : 15.12.2010 Date of receipt of test item : 15.12.2010 Date of test : 21.12.2010 1.5 Test item Description of test item : SR-radio module Type identification : HG 76360 Serial number : 210462 (module 1) 210463 (module 2) Photos : See Annex A Technical data Assigned Frequency band : 2400 -2483.5MHz Frequency range : 2402 -2478MHz Tested frequencies : F 1 2401MHz F2 2438MHz F3 2475MHz Antenna 1 : external antenna HG G-97601ZA (2.45GHz) Antenna gain 1 : 0dBi Antenna 2 : external antenna HW CAB00058 Antenna gain 2 : 0dBi Number of Channels : 76 Hardware Version : V3 Software version : V1 Power supply : 5VDC Manufacturer: Name : Götting KG Street : Celler Str. 5 Town : 31275 Lehrte/Röddersen Country : GERMANY Page 5 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.6 Test standards Technical standard : FCC RULES PART 15 / SUBPART C § 15.249 IC Standards: RSS 210 Issue 7 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 25°C Relative humidity content : 45% Air pressure : 936 hPa Extrem conditions parameters: : test voltage - extreme nom.: 5.0VDC min.: 4.5VDC max: 5.5VDC Additional information : The device works with two different antennas. Page 6 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.3 Test equipment utilized ID No. Test equipment Type Manufacturer ETS 0012 Biconical Antenna HK 116 R & S ETS 0013 LPD Antenna HL 223 R & S ETS 0014 Log Periodical Antenna HL 025 R & S ETS 0271 Spectrum Analyzer FSEK30 R & S ETS 0288 Artificial mains ESH2-Z5 R & S ETS 00086 Anechoic chamber AC 1 Frankonia Page 7 of 52 Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.4 General Test Procedure POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STANDARD C63.4- 2003 5.2 using a 50 μH LISN (if necessary). Both lines were observed. The bandwidth of the spectrum analyzer was 10 kHz with an appropriate sweep speed. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 6.4 using a spectrum analyzer. The resolution bandwidth of the spectrum analyzer was 100 kHz for measurements below 1 GHz and RBW 1 MHz was used above 1 GHz. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The ambient temperature of the UUT was 23 ° C with a humidity of 43 %. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBμV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. Example: Freq (MHz) METER READING + ACF + CABLE LOSS (to the receiver) = FS 33 20 dBμV + 10.36 dB + 6 dB = 36.36 dBμV/m @ 3 m ANSI STANDARD C63.4-2003 6.2.1 MEASUREMENT PROCEDURES: The UUT was placed on a table 80 cm high and with dimensions of 1m by 1.5 m (non metallic table). The UUT was placed in the center of the table. The table used for radiated measurements is capable of continuous rotation. The spectrum was scanned from 30 MHz to 10 th harmonic of the fundamental. Peak readings were taken in three (3) orthogonal planes and the highest readings. Measurements were…
Text truncated - open the document above for the full version.
Test Report No.: G0M21009-3638-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Test Setup radiated measurments Test Setup conducted measurments Page 15 of 52
Celler Str. 5 · Lehrte/R�ddersen · Germany
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |
DSR - Part 15 Remote Control/Security Device Transceiver
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
