NVE363Glove Radar

Sports Sensors Inc.

Click to zoom

Application Details

Equipment Class: FDS - Part 15 Field Disturbance Sensor
Date of Grant: Apr 29, 2003
Application Purpose: Original Equipment
Date of Application: Mar 20, 2003
Equipment Note: Glove Radar
Frequency Range: 10500.00000000 - 10550.00000000
Company: Sports Sensors Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

16 OWNER’S MANUAL GLOVE RADAR TM MODELS NO. 363 (illustration) CONTENTS Subject Congratulations Features Glove Attachment Reference Using the Glove Radar TM Throwing Preparations Proper Throwing Techniques Specifications Emission & Safe@ Standards Care of Your Glove Radar TM Problems/rroubleshooting Battery Replacement Page 2 2 3 3 4 5 6 7 7 8 8

Attestation Statements

March 19, 2003 Federal Communications Commission Authorization & Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SPORTS SENSORS INC. FCC ID: NVE363 Gentlemen: Submitted herewith, on behalf of SPORTS SENSORS, INC., is an application for Part 15 certification of the following field disturbance sensor. Attached are the authorization letter, measurement report (measurement data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagrams, schematic diagrams, operational description and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Telemachos J. Manolatos - Vice President January 28, 2003 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 2 1046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C. 853(a). Vice President ,/ TJM/akp Sports Sensors, lnc. Tel: (800) 589-3709 PO Box 461 98 Cincinnati, Ohio 45246-01 98 Fa: (513) 825-8532

Attestation Statements

January 28, 2003 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: COMPANY: Sport Sensors, Inc. FCC ID: NVE363 EUT TYPE: Glove Radar Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, Sport Sensors, Inc. requests confidentiality of the Block Diagram, Schematics, and Operational Description for the attached test report. These documents contain detailed system and equipment description and related information about the product which Sport Sensors, Inc. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public, Since this design is a basis from which future technological products will evolve, Sport Sensors, Inc. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. TJM/akp Sports Sensors, Inc. Tel: (800) 589-3709 PO Box 46198 Cincinnati, Ohio 45246-0198 Fax: (513) 825-8532

Cover Letter(s)

External Photos

ID Label/Location Info

© 2003 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

ID Label/Location Info

Internal Photos

© 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363) © 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363) © 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363) © 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363) © 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363) © 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363) © 2003 PCTEST Lab SPORTS SENSOR FCC ID: NVE363 NVLAP Lab Code: 100431-0 Glove Radar (Model: 363)

Test Report

PCTEST PT. 15.245 REPORT Measurement Report Reviewed By: Quality Manager Test Report S/N: TX.230110008.NVE Test Dates: JANUARY 9-10, 2003 EUT Type: SPORTS SENSORS GLOVE RADAR TM FCC ID: NVE363 Page 1of 15 . PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 15.245 Certification SPORTS SENSORS, INC. Dates of Tests: January 9-10, 2003 P.O. Box 46198 Test Report S/N: TX.230110008.NVE Cincinati, OH 45246-0198 Test Site: PCTEST Lab, Columbia MD Attn: Telemachos J. Manolatos, Vice President FCC ID NVE363 APPLICANT SPORTS SENSORS INC. FCC Rule Part(s): § 15.245 Classification: Part 15 Field Disturbance Sensor (FDS) EUT Type: GLOVE RADAR TM Frequency Range: 10.5 – 10.55 GHz Trade Name: SPORTS SENSORS Model: 363 This device has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992 with the following remarks (Note Codes): 37. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 15.245 REPORT Measurement Report Reviewed By: Quality Manager Test Report S/N: TX.230110008.NVE Test Dates: JANUARY 9-10, 2003 EUT Type: SPORTS SENSORS GLOVE RADAR TM FCC ID: NVE363 Page 2of 15 . TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION (SITE DESCRIPTION) 4 3.1 PRODUCTION INFORMATION 5 4.1 DESCRIPTION OF TESTS (CONDUCTED & RADIATED) 6-7 5.1 ANTENNA REQUIREMENT/APPLIED MODULATION 8 6.1 FREQUENCY MEASUREMENTS (Fundamental & Harmonics) 9 7.1 FREQUENCY MEASUREMENTS (Receiver Radiated Spurious) 10 8.1 LINE-CONDUCTED EMISSIONS 11 9.1 SAMPLE CALCULATIONS 12 10.1 ACCURACY OF MEASUREMENT 13 11.1 LIST OF TEST EQUIPMENT 14 12.1 CONCLUSION 15 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL DESCRIPTION ATTACHMENT L: USER’S MANUAL PCTEST PT. 15.245 REPORT Measurement Report Reviewed By: Quality Manager Test Report S/N: TX.230110008.NVE Test Dates: JANUARY 9-10, 2003 EUT Type: SPORTS SENSORS GLOVE RADAR TM FCC ID: NVE363 Page 3of 15 . MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name: SPORTS SENSORS INC. Address: P.O. Box 46198 Cincinati, OH 45246-0198 Attention: Mr. Telemachos J. Manolatos, Vice President • FCC ID: NVE363 • Model: 363 • Trade Name: SPORTS SENSORS • EUT Type: GLOVE RADAR TM • Equipment Class: Part 15 Field Disturbance Sensor (FDS) • Application Type: Certification • Frequency Range: 10.5 – 10.55 GHz • FCC Rule Part(s): § 15.245 • Dates of Tests: January 9-10, 2003 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: TX.230110008.NVE PCTEST PT. 15.245 REPORT Measurement Report Reviewed By: Quality Manager Test Report S/N: TX.230110008.NVE Test Dates: JANUARY 9-10, 2003 EUT Type: SPORTS SENSORS GLOVE RADAR TM FCC ID: NVE363 Page 4of 15 . 2.1 INTRODUCTION The measurement procedure described in Section 15.249 of FCC Rules, and American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from SPORTS SENSORS Inc. GLOVE RADAR TM FCC ID: NVE363. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure 1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. PCTEST PT. 15.245 REPORT Measurement Report Reviewed By: Quality Manager Test Report S/N: TX.230110008.NVE Test Dates: JANUARY 9-10, 2003 EUT Type: SPORTS SENSORS GLOVE RADAR TM FCC ID: NVE363 Page 5of 15 . 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the SPORTS SENSORS Inc. GLOVE RADAR TM FCC ID: NVE363. * Tx Freq. Range(Base): 10.5 – 10.55 GHz * Antenna: Permanently Attached, Omni-Directional * Power Supply: 3AA Batteries PCTEST PT. 15.245 REPORT Measurement Report Reviewed By: Quality Manager Test Report S/N: TX.230110008.NVE Test Dates: JANUARY 9-10, 2003 EUT Type: SPORTS SENSORS G…

Text truncated - open the document above for the full version.

Test Setup Photos
