NW6KAS-2030Wireless Remote Control

Transmitter Operating Instructions Wildlife Technologies 2006 Keypad functions 1- To turn the transmitter on, press the shift key (power on key). The green power led will turn on and the transmitter will stay powered for 1 minute and then turn off to increase battery life. 2-To play a sound, just enter the exact number of the sound you wish to play on the keypad and then press the play key. To pause a sound press the play/pause key. Each time you press a key on the transmitter the red tx led will turn on for 1 second to indicate the transmitter is in the transmit mode. You must wait for the red l ed to turn off before pressing another key. 3- To increase volume press the volume + key. To decrease volume press the volume - key. If you press and hold the shift key and then press the volume + key the volume will go to the highest level. If you press and hold the shift key and then press the volume - key the volume will go to the lowest level. Favorite sounds You can assign any sound you have to keys 0 to 9. To assign a sound to a numbered key, play the sound you want to be a favorite. While the sound is playing press and hold the shift key and then press the FAV-SET key. Next press one key (0 thru 9) to store that sound. To play one of your favorite sounds first press the FAV key and then the numbered key of the favorite sound you want to play. You can have a total of 10 favorite sounds. You can also change any or all of your favorite sounds at any time using the method described above. The volume control has 6 levels of volume. One key press for each volume level of change. NOTE: The transmitter uses 2 AA alkaline or 2 AA lithium batteries. Battery life: 3 years or longer. 1 2 3 4 5 6 7 8 9 0 VOL VOL - + = SHIFT SET FAV - PWR TX Wildlife Technologies Wireless Remote Control This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment.

Wildlife Technologies 115 Wolcott Street Manchester, N.H. 03103 April 10, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to formally notify you that the following modification that was completed by Compatible Electronics, Inc. to our transmitter model KAS-2030 during FCC certification will be implemented in production. Modification: Resistor change: Resistor R4 on the TX schematic.pdf was changed to a 2.2K ohm resistor to meet with FCC compliance. Sincerely, William Martz Owner

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference and (2) this device must accept any interference received, including inter ference that may cause undesired operation. FCC ID: NW6KAS-2030 FCC ID Label size is 1.5” wide X 1” high FCC ID label located on backside of transmitter

Report Number: B60307A1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wireless Remote Control M/N: RC2 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 15 FCC PART 15, SUBPART B and C TEST REPORT for WIRELESS REMOTE CONTROL M/N: RC2 Prepared for WILDLIFE TECHNOLOGIES 115 WOLCOTT STREET MANCHESTER, NEW HAMPSHIRE 03103 Prepared by:_____________________ BENIGNO CHAVEZ Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 11, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 15 2 2 2 13 15 49 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60307A1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wireless Remote Control M/N: RC2 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 15 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 EMI Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.2 Bandwidth of the Fundamental 14 8. CONCLUSIONS 15 Report Number: B60307A1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wireless Remote Control M/N: RC2 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 15 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site Report Number: B60307A1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wireless Remote Control M/N: RC2 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 15 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Wireless Remote Control M/N: RC2 S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was modified in order to meet the specifications. Please see list located in Appendix B. Manufacturer: Wildlife Technologies 115 Wolcott Street Manchester, New Hampshire 03103 Test Date: March 7, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209, and 15.231 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT operates on battery power only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions, 10 kHz - 4180 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. 3 -20 dB Bandwidth of the Fundamental Complies with the limits of Subpart C, sections 15.231 [c]. Report Number: B60307A1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wireless Remote Control M/N: RC2 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 15 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Wireless Remote Control M/N: RC2. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B60307A1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report Wireless Remote Control M/N: RC2 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 15 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3 Cognizant Personnel Wildlife Technologies William Martz Owner Compatible Electronics, Inc. Benigno Chavez Test Engineer James Ross Test Engineer Kyle Fujimoto Test Engineer 2.4 Date Test Sample was Received The test sample was received prior t…

Text truncated - open the document above for the full version.

DUTY CYCLE EXPLANATION This device transmits at a 2400 baud rate and can have a maximum 4 data bits high. Based on this calculation, the maximum calculated duty cycle using the formula on page 2 would be 44.79%. Plots of the duty cycle are given showing that the actual measured duty cycle is less than or equal to 44.79% (See the duty cycle plot exhibits, which are separate from this exhibit). However, per the FCC response, the maximum calculated duty is to be used for the purposes of testing. MS Series Encoder Data Structure The MS Series encoder is designed to securely register button presses or switch closures over a wireless link for remote contro l applications. It will turn eight parallel input lines into a secure, encoded serial bit stream output. The MS Series algorithm is designed to create a data stream with a 50% duty cycle by using the same number of high bits and low bits. Two wait times reduce this duty cycle to just below 50%. Power Up Is the SEND Line High? Send Data Logic State Description: 1 = HIGH 0 = LOW Total bits, including start and stop bits = 80 Total 1’s = 40 Total 0’s = 40 Value for each bit per baud rate: 2400bps = 417uS or 1.18% of duty cycle 9600bps = 104uS or 1.01% of duty cycle 19200bps = 52uS or 0.85% of duty cycle 28800bps = 35uS or 0.74% of duty cycle 680uS 465uS 800uS 0 01101000 1 0 10101010 1 0 01010 101 1 0 000 00000 1 0 1 0 1 0 1 0 11 1 0 11101010 1 00000000 1010 Wait Time Processing Time Wait Time Wake Noise Filter Error Check ADDR-H ADDR-M ADDR-L Data Byte Error Check 11111111 Duty Cycle = Time High Total Time 40 bits + 800uS 80 bits + 680uS + 465uS + 800uS ( 3 6 * 417 uS) + 800uS (80*104uS) + 1,945uS 15,812 uS 35,305 uS = 4 4.79% ==

Length of pulse (uS) How many Total time (uS) 3350 1 3350 416 8 3328 808 1 808 850 1 850 470 4 1880 426 5 2130 888 1 888 458 1 458 Total on-time 13692 Duty Cycle: 13.692 mS / 36.00 mS = 38.03%
