NWS10801Avionics Communication Management Unit

Universal Avionics Systems Corporation
Avionics Communication Management Unit - FCC ID NWS10801 - Universal Avionics Systems Corporation
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Feb 23, 2012
Application Purpose
Original Equipment
Date of Application
Feb 21, 2012
Equipment Note
Avionics Communication Management Unit
Frequency Range
118.00000000 - 136.97500000
Company
Universal Avionics Systems Corporation
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗
↗
↗
↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗
↗
↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

23-20-06.01 December 2011 UNILINK UL-800/801 OPERATOR’S MANUAL (FANS Disabled) SCN 30.X With Corporate Database The information contained herein is subject to the Export Administration Regulations (“EAR”), 15 C.F.R. Parts 730-774. Diversion contrary to U.S. law is prohibited. This document is available at www.uasc.com © 2011 UNIVERSAL AVIONICS SYSTEMS CORPORATION UniLink UL-800/801 Operator’s Manual 23-20-06.01 ROR-1 December 2011 RECORD OF REVISIONS Rev No. Issue Date Insertion Date Initials Retain this record in front of the manual. Upon receipt of revision, insert and remove pages according to the List of Effective Pages. Then enter on this page the revision number, issue date, insertion date and your initials. UniLink UL-800/801 Operator’s Manual 23-20-06.01 ROTC-1 December 2011 RECORD OF TEMPORARY CHANGES Change No. Issue Date/ Page Insertion Date & Initials Removal Date / Initials / Reason UniLink UL-800/801 Operator’s Manual 23-20-06.01 LOEP-1 December 2011 LIST OF EFFECTIVE PAGES Original........XX October 2010 Page No. Date Page No. Date Cover .............................. xx/xx/11 21 .................................... xx/xx11 22 .................................... xx/xx11 ROR-1 ............................. xx/xx11 25 .................................... xx/xx11 26 .................................... xx/xx11 ROTC-1 ........................... xx/xx11 23 .................................... xx/xx11 24 .................................... xx/xx11 LOEP-1............................ xx/xx11 25 .................................... xx/xx11 LOEP-2............................ xx/xx11 26 .................................... xx/xx11 27 .................................... xx/xx11 TOC-1 ............................. xx/xx11 28 .................................... xx/xx11 TOC-2 ............................. xx/xx11 29 .................................... xx/xx11 30 .................................... xx/xx11 1 ...................................... xx/xx11 31 .................................... xx/xx11 2 ...................................... xx/xx11 32 .................................... xx/xx11 3 ..................................... xx/xx11 33 .................................... xx/xx11 4 ...................................... xx/xx11 34 .................................... xx/xx11 5 ...................................... xx/xx11 35 .................................... xx/xx11 6 ...................................... xx/xx11 36 .................................... xx/xx11 7 ...................................... xx/xx11 37 .................................... xx/xx11 8 ...................................... xx/xx11 38 .................................... xx/xx11 9 ...................................... xx/xx11 39 .................................... xx/xx11 10 .................................... xx/xx11 40 .................................... xx/xx11 11 .................................... xx/xx11 41 .................................... xx/xx11 12 .................................... xx/xx11 42 .................................... xx/xx11 13 .................................... xx/xx11 43 .................................... xx/xx11 14 .................................... xx/xx11 44 .................................... xx/xx11 15 .................................... xx/xx11 45 .................................... xx/xx11 16 .................................... xx/xx11 46 .................................... xx/xx11 17 .................................... xx/xx11 47 .................................... xx/xx11 18 .................................... xx/xx11 48 .................................... xx/xx11 19 .................................... xx/xx11 49 .................................... xx/xx11 20 .................................... xx/xx11 50 .................................... xx/xx11 UniLink UL-800/801 Operator’s Manual LOEP-2 23-20-06.01 December 2011 Page No. Date Page No. Date 51 .................................... xx/xx11 86 .................................... xx/xx11 52 .................................... xx/xx11 53 .................................... xx/xx11 54 .................................... xx/xx11 55 .................................... xx/xx11 56 ................................... xx/xx11 57 .................................... xx/xx11 58 .................................... xx/xx11 59 .................................... xx/xx11 60 .................................... xx/xx11 61 .................................... xx/xx11 62 ................................... xx/xx11 63 .................................... xx/xx11 64 .................................... xx/xx11 65 .................................... xx/xx11 66 .................................... xx/xx11 67 .................................... xx/xx11 68 .................................... xx/xx11 69 .................................... xx/xx11 70 .................................... xx/xx11 71 .................................... xx/xx11 72 .................................... xx/xx11 73 .................................... xx/xx11 74 .................................... xx/xx11 75 .................................... xx/xx11 76 .................................... xx/xx11 77 .................................... xx/xx11 78 .................................... xx/xx11 79 .................................... xx/xx11 80 .................................... xx/xx11 81 .................................... xx/xx11 82 .................................... xx/xx11 83 .................................... xx/xx11 84 .................................... xx/xx11 85 .................................... xx/xx11 UniLink UL-800/801 Operator’s Manual 23-20-06.01 TOC-1 December 2011 TABLE OF CONTENTS INTRODUCTION.................................................................................. 1 Components ..................................................................................... 1 Capabilities ......…

Text truncated - open the document above for the full version.

Users Manual

23-20-06.02 December 2011 UNILINK UL-800/801 FUTURE AIR NAVIGATION SYSTEM (FANS) 1/A+ OPERATOR’S MANUAL SCN 30.X With Corporate Database The information contained herein is subject to the Export Administration Regulations (“EAR”), 15 C.F.R. Parts 730-774. Diversion contrary to U.S. law is prohibited. © 2011 UNIVERSAL AVIONICS SYSTEMS CORPORATION UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 ROR-1 December 2011 RECORD OF REVISIONS Rev No. Issue Date Insertion Date Initials Retain this record in front of the manual. Upon receipt of revision, insert and remove pages according to the List of Effective Pages. Then enter on this page the revision number, issue date, insertion date and your initials. UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 ROTC-1 December 2011 RECORD OF TEMPORARY CHANGES Change No. Issue Date/ Page Insertion Date & Initials Removal Date / Initials / Reason Retain this record in front of the manual. Upon receipt of Temporary Change, insert pages into manual and enter, on this page, the Temporary Change number, issue dated, insertion date and your initials. Also, record the removal of each Temporary Change you remove. UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 LOEP-1 December 2011 LIST OF EFFECTIVE PAGES Original........XX XXXX 201X Page No. Date Page No. Date Cover ............................. X/XX/XX 20 .................................. X/XX/XX 21 .................................. X/XX/XX ROR-1 ........................... X/XX/XX 22 .................................. X/XX/XX 23 .................................. X/XX/XX ROTC-1 ......................... X/XX/XX 24 .................................. X/XX/XX 25 .................................. X/XX/XX LOEP-1 ......................... X/XX/XX 26 .................................. X/XX/XX LOEP-2 ......................... X/XX/XX 27 .................................. X/XX/XX LOEP-3 ......................... X/XX/XX 28 .................................. X/XX/XX 29 .................................. X/XX/XX TOC-1 ........................... X/XX/XX 30 .................................. X/XX/XX TOC-2 ........................... X/XX/XX 31 .................................. X/XX/XX 32 .................................. X/XX/XX 1 .................................... X/XX/XX 33 .................................. X/XX/XX 2 .................................... X/XX/XX 34 .................................. X/XX/XX 3 .................................... X/XX/XX 35 .................................. X/XX/XX 4 .................................... X/XX/XX 36 .................................. X/XX/XX 5 .................................... X/XX/XX 37 .................................. X/XX/XX 6 .................................... X/XX/XX 38 .................................. X/XX/XX 7 .................................... X/XX/XX 39 .................................. X/XX/XX 8 .................................... X/XX/XX 40 .................................. X/XX/XX 9 .................................... X/XX/XX 41 .................................. X/XX/XX 10 .................................. X/XX/XX 42 .................................. X/XX/XX 11 .................................. X/XX/XX 43 .................................. X/XX/XX 12 .................................. X/XX/XX 44 .................................. X/XX/XX 13 .................................. X/XX/XX 45 .................................. X/XX/XX 14 .................................. X/XX/XX 46 .................................. X/XX/XX 15 .................................. X/XX/XX 47 .................................. X/XX/XX 16 .................................. X/XX/XX 48 .................................. X/XX/XX 17 .................................. X/XX/XX 49 .................................. X/XX/XX 18 .................................. X/XX/XX 50 .................................. X/XX/XX 19 .................................. X/XX/XX 51 .................................. X/XX/XX UniLink UL-800/801 FANS SCN 30.X Operator’s Manual LOEP-2 23-20-06.02 December 2011 Page No. Date Page No. Date 51 .................................. X/XX/XX 85 ...................................X/XX/XX 52 .................................. X/XX/XX 86 ...................................X/XX/XX 53 .................................. X/XX/XX 87 ...................................X/XX/XX 54 .................................. X/XX/XX 88 ...................................X/XX/XX 55 .................................. X/XX/XX 89 ...................................X/XX/XX 56 .................................. X/XX/XX 90 ...................................X/XX/XX 57 .................................. X/XX/XX 91 ...................................X/XX/XX 58 .................................. X/XX/XX 92 ...................................X/XX/XX 59 .................................. X/XX/XX 93 ...................................X/XX/XX 60 .................................. X/XX/XX 94 ...................................X/XX/XX 61 .................................. X/XX/XX 95 ...................................X/XX/XX 62 .................................. X/XX/XX 96 ...................................X/XX/XX 63 .................................. X/XX/XX 97 ...................................X/XX/XX 64 .................................. X/XX/XX 98 ...................................X/XX/XX 65 .................................. X/XX/XX 99 ...................................X/XX/XX 66 .................................. X/XX/XX 100 .................................X/XX/XX 67 .................................. X/XX/XX 101 .................................X/XX/XX 68 .................................. X/XX/XX 102 .................................X/XX/XX 69 .................................. X/XX/XX 103 .................................X/XX/XX 70 .................................. X/XX/XX 104 .................................X/XX/XX 71 ............…

Text truncated - open the document above for the full version.

Users Manual

UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 89 December 2011 MAINTENANCE Menu Navigation: UNILINK MENU > MAINTENANCE Maintenance pages are used to access UniLink maintenance related functions. No operation-related functions are performed on this page or subpages. Operational tests can be conducted via the TESTS option. From the UniLink Menu, press MAINTENANCE, LSK [4L]. The MAINTENANCE 1/3 page will display. NOTE: See the associated UniLink Installation Manual for installation and maintenance procedures. Tests Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS There are several tests available to exercise the functionality of UniLink. They include PRINTER Test, IMAGE Test, UniLink SELF- TEST, PTT (UL-801 only), FANS ALERTS, and UPLINK Test. Press TESTS, LSK [2R] on the MAINTENANCE page to display the TESTS page. UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 90 23-20-06.02 December 2011 Printer Test Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS > PRINTER If a printer is connected and configured, selection of PRINTER, LSK [1L] will send test message text to the printer. If there is no printer configured, the PRINTER option will not be displayed. When PRINTER is selected, a pop-up window PRINTER TEST IN PROGRESS is displayed. When complete, the pop-up window will no longer display. The following will be printed: THIS IS NOT AN UPLINK. THIS IS AN INTERNALLY GENERATED PRINTER TEST MESSAGE. !"#$%&'()*+,- ./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_` {|}~; Image Test Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS > IMAGE Selection of IMAGE, LSK [2L] is used to display a test image. While the test image is being displayed, any key push will cause the display to return to the MAINTENANCE page. Image Test is not available when the aircraft is in the air. When IMAGE is selected, a pop-up window IMAGE TEST IN PROGRESS will display. Upon test completion, an ADVISORY will display on the CDU and NEW WX MAP is displayed adjacent LSK [5L] (LSK for MCDU may be different). UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 91 December 2011 Press NEW WX MAP, LSK [5L] to display the generated test weather image. A test weather map is displayed with the title IMAGE BUS TEST. NOTE: This image will display on an EFI-890R or MFD if installed and configured. To exit the image, press RTN, LSK [5R]. The display returns to the TESTS page (NEW WX MAP and ADVISORY are no longer displayed). UniLink Self-Test Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS > SELF-TEST Selection of SELF-TEST, LSK [3L] places the system in a power up test mode. When the test is selected a pop-up window requesting to CONFIRM or CANCEL the test is displayed. Selecting CANCEL closes the pop- up window and returns to the current display. Selecting CONFIRM reboots UniLink. The message UNILINK/FMS COMM ERROR RESELECT UNILINK is displayed. During the period of reboot, the UNILINK option displayed on the CDU/MCDU (LSK [5L]) is not UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 92 23-20-06.02 December 2011 selectable (smaller font, no arrow). When the test is complete, UNILINK will be selectable. Selecting UNILINK will display the UNILINK MENU page. PTT (Push-To-Talk) (UL-801 only) Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS > PTT If available, this test commands the radio to transmit for 3 seconds. A pop-up window PTT TEST IN PROGRESS will display for 3 seconds. FANS ALERTS Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS > FANS ALERTS A FANS-equipped aircraft is required to have audio and visual alerts. Based on installation, one or two ATC annunciators (or visual annunciations) will be visible to the crew. Check with the installer for details. 1. Press FANS ALERTS, LSK [1R]. A pop-up window FANS DISCRETE TEST IN PROGRESS will display, then close. NOTE: The ATC annunciator(s) will illuminate for approximately 3 seconds during the test. Aural alerts are installation- dependent. MSG will annunciate in the upper right-hand of the screen. 2. Press the [MSG] key to view test results (UNILINK ATC ALERT). UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 93 December 2011 Uplink Test Menu Navigation: UNILINK MENU > MAINTENANCE > TESTS > UPLINK Selection of UPLINK, LSK [4R] causes a test uplink to be placed in the OPS message log, generating a NEW MSG advisory at the bottom of the display. 1. Press NEW MSG, LSK [5L] to display message. 2. If desired, press PRINT, LSK [4R] to print the screen (printer must be configured). 3. Press DELETE, LSK [4L] to delete the test message. The display returns to the TESTS page. UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 94 23-20-06.02 December 2011 OPS Menu Navigation: UNILINK MENU > OPS On the UNILINK MENU page, press OPS, LSK [1R], to access the OPS 1/2 page. This page provides access to the FREE TEXT, OOOI, TEXT WX, WX MAPS, WX MAP LOG, and MSG LOGS options Pressing the [NEXT] key displays the OPS 2/2 page. This page provides access to the DELAY, DIVERSION, ETA UPDATE, SELCAL (when made available), SITUATION, and POS REPORT options. . UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 23-20-06.02 95 December 2011 FREE-TEXT Menu Navigation: UNILINK MENU > OPS(1/2) > FREE-TEXT The FREE-TEXT option is available at LSK [2L] on the OPS 1/2 page. The FREE TEXT page allows the user to create and edit text messages. Create and Send a Message NOTE: Messages sent using this procedure will go to a service provider website. 1. Press FREE-TEXT, LSK [2L] on the OPS 1/2 page. 2. With the TO: field active, enter the destination identifier/recipient and press [ENTER]. 3. Enter the destination/recipient telephone number (if known) in the NO: field and press [ENTER]. Pressing [ENTER] moves the cursor to the first text line of the TEXT EDIT page. NOTE: Pressing LSK [2L] will also bring up the TEXT EDIT page. UniLink UL-800/801 FANS SCN 30.X Operator’s Manual 96 23-20-06.02 December 2011 4. Create a message using the alphanumeric text option key…

Text truncated - open the document above for the full version.

Users Manual

EXHIBIT – G 1 SUPPLEMENTARY NOTES REGARDING UL-801 MANUALS 1.1 Operator's Manual The UL-801 Operator's Manual describes user interaction with the DLM module portion of the product. There is no direct user control over the VDR module. Only the DLM module controls the VDR module in a UL-801. 1.2 Installation Manual Only limited portions of the Installation Manual are applicable to the UL-801's VDR module. These are identified below. Description and Operation – Section 1 M – VHF Management Equipment Specifications - Section 1 E – VHF Antenna Specifications Installation and Wiring - Section 2L – UL-801 to UNS-1E : Sheet 2 of 2 Installation and Wiring - Section 2M – UL-801 to UNS-1Esp : Sheet 2 of 2 Installation and Wiring - Section 2N – UL-801 to UNS-1Lw Installation and Wiring - Section 2O – UL-801 to UNS-1Fw: Sheet 1 of 2 UL-801 Connector Pin Identification - Section 3C – Bottom Plug Configuration Worksheets - Section 2 – VHF Config Configuration Procedures - Section 3J – VHF Configuration Maintenance, Checkout,and Troubleshooting -Section 1G– VHF Communications

Users Manual

3260 East Universal Way Tucson, AZ 85756-5097 (520) 295-2300 • (800) 321-5253 23-20-06 15 December 2011 UL-801 Installation Manual The information contained herein is subject to the Export Administration Regulation (“EAR”), 15 C.F.R. Parts 730-774. Diversion contrary to U.S. law is prohibited. This publication is available at www.uasc.com. © 2011 UNIVERSAL AVIONICS SYSTEMS CORPORATION ALL RIGHTS RESERVED  UL-801 Installation Manual Page 1 23-20-06 15 December 2011 Record of Revisions Rev No. Issue Date Insertion Date Initials UASC Retain this record in front of the manual. Upon receipt of revision, insert and remove pages according to the List of Effective Pages. Then enter on this page the revision number, issue date, insertion date and your initials. UL-801 Installation Manual Page 1 23-20-06 15 December 2011 Record of Temporary Changes Change No. Page No. Issue Date Insertion Date & Initials Removal Date/Initials/Reason Retain this record in the front of this manual. Upon receipt of a Temporary Change, insert pages into manual and enter the Temporary Change number, page number, issue date, insertion date and your initials. Also, record the removal of each temporary change. UL-801 Installation Manual Page 2 23-20-06 15 December 2011 Record of Temporary Changes (Continued) Change No. Page No. Issue Date Insertion Date & Initials Removal Date/Initials/Reason Retain this record in the front of this manual. Upon receipt of a Temporary Change, insert pages into manual and enter the Temporary Change number, page number, issue date, insertion date and your initials. Also, record the removal of each temporary change. UL-801 Installation Manual Page 1 23-20-06 15 December 2011 List of Effective Pages Subject Page Date Title Page 15 Dec 2011 Record of Revisions 1 15 Dec 2011 Record of Temporary Changes 1 15 Dec 2011 2 15 Dec 2011 List of Effective Pages 1 15 Dec 2011 2 15 Dec 2011 3 15 Dec 2011 Table of Contents 1 15 Dec 2011 2 15 Dec 2011 3 15 Dec 2011 4 15 Dec 2011 Introduction 1 15 Dec 2011 Description and Operation 1 15 Dec 2011 2 15 Dec 2011 3 15 Dec 2011 4 15 Dec 2011 5 15 Dec 2011 6 15 Dec 2011 7 15 Dec 2011 8 15 Dec 2011 9 15 Dec 2011 10 15 Dec 2011 11 15 Dec 2011 12 15 Dec 2011 13 15 Dec 2011 14 15 Dec 2011 15 15 Dec 2011 16 15 Dec 2011 17 15 Dec 2011 18 15 Dec 2011 19 15 Dec 2011 20 15 Dec 2011 21 15 Dec 2011 22 15 Dec 2011 23 15 Dec 2011 24 15 Dec 2011 Subject Page Date 25 15 Dec 2011 26 15 Dec 2011 27 15 Dec 2011 28 15 Dec 2011 29 15 Dec 2011 30 15 Dec 2011 31 15 Dec 2011 32 15 Dec 2011 FAA Approval 101 15 Dec 2011 102 15 Dec 2011 103 15 Dec 2011 104 15 Dec 2011 105 15 Dec 2011 106 15 Dec 2011 107 15 Dec 2011 108 15 Dec 2011 109 15 Dec 2011 110 15 Dec 2011 111 15 Dec 2011 112 15 Dec 2011 113 15 Dec 2011 114 15 Dec 2011 115 15 Dec 2011 116 15 Dec 2011 Equipment Specifications 201 15 Dec 2011 202 15 Dec 2011 203 15 Dec 2011 204 15 Dec 2011 205 15 Dec 2011 206 15 Dec 2011 207 15 Dec 2011 208 15 Dec 2011 209 15 Dec 2011 210 15 Dec 2011 211 15 Dec 2011 212 15 Dec 2011 Installation and Wiring 301 15 Dec 2011 302 15 Dec 2011 303 15 Dec 2011 304 15 Dec 2011 305 15 Dec 2011 306 15 Dec 2011 307 15 Dec 2011 UL-801 Installation Manual Page 2 23-20-06 15 December 2011 Subject Page Date 308 15 Dec 2011 309 15 Dec 2011 310 15 Dec 2011 311 15 Dec 2011 312 15 Dec 2011 313 15 Dec 2011 314 15 Dec 2011 315 15 Dec 2011 316 15 Dec 2011 317 15 Dec 2011 318 15 Dec 2011 319 15 Dec 2011 320 15 Dec 2011 321 15 Dec 2011 322 15 Dec 2011 323 15 Dec 2011 324 15 Dec 2011 325 15 Dec 2011 326 15 Dec 2011 327 15 Dec 2011 328 15 Dec 2011 329 15 Dec 2011 330 15 Dec 2011 331 15 Dec 2011 332 15 Dec 2011 333 15 Dec 2011 334 15 Dec 2011 335 15 Dec 2011 336 15 Dec 2011 337 15 Dec 2011 338 15 Dec 2011 339 15 Dec 2011 340 15 Dec 2011 341 15 Dec 2011 342 15 Dec 2011 343 15 Dec 2011 344 15 Dec 2011 345 15 Dec 2011 346 15 Dec 2011 347 15 Dec 2011 348 15 Dec 2011 System Data Installation 401 15 Dec 2011 402 15 Dec 2011 403 15 Dec 2011 404 15 Dec 2011 405 15 Dec 2011 406 15 Dec 2011 407 15 Dec 2011 408 15 Dec 2011 409 15 Dec 2011 Subject Page Date 410 15 Dec 2011 411 15 Dec 2011 412 15 Dec 2011 413 15 Dec 2011 414 15 Dec 2011 415 15 Dec 2011 416 15 Dec 2011 417 15 Dec 2011 418 15 Dec 2011 419 15 Dec 2011 420 15 Dec 2011 421 15 Dec 2011 422 15 Dec 2011 423 15 Dec 2011 424 15 Dec 2011 425 15 Dec 2011 426 15 Dec 2011 427 15 Dec 2011 428 15 Dec 2011 429 15 Dec 2011 430 15 Dec 2011 431 15 Dec 2011 432 15 Dec 2011 433 15 Dec 2011 434 15 Dec 2011 435 15 Dec 2011 436 15 Dec 2011 437 15 Dec 2011 438 15 Dec 2011 439 15 Dec 2011 440 15 Dec 2011 441 15 Dec 2011 442 15 Dec 2011 443 15 Dec 2011 444 15 Dec 2011 445 15 Dec 2011 446 15 Dec 2011 447 15 Dec 2011 448 15 Dec 2011 449 15 Dec 2011 450 15 Dec 2011 451 15 Dec 2011 452 15 Dec 2011 453 15 Dec 2011 Maintenance, Checkout, and Troubleshooting 501 15 Dec 2011 502 15 Dec 2011 503 15 Dec 2011 504 15 Dec 2011 505 15 Dec 2011 506 15 Dec 2011 507 15 Dec 2011 UL-801 Installation Manual Page 3 23-20-06 15 December 2011 Subject Page Date 508 15 Dec 2011 509 15 Dec 2011 510 15 Dec 2011 511 15 Dec 2011 512 15 Dec 2011 513 15 Dec 2011 514 15 Dec 2011 515 15 Dec 2011 516 15 Dec 2011 517 15 Dec 2011 518 15 Dec 2011 519 15 Dec 2011 Appendix 1 A1-1 15 Dec 2011 A1-2 15 Dec 2011 A1-3 15 Dec 2011 A1-4 15 Dec 2011 A1-5 15 Dec 2011 Appendix 2 A2-1 15 Dec 2011 A2-2 15 Dec 2011 A2-3 15 Dec 2011 A2-4 15 Dec 2011 A2-5 15 Dec 2011 A2-6 15 Dec 2011 A2-7 15 Dec 2011 A2-8 15 Dec 2011 A2-9 15 Dec 2011 A2-10 15 Dec 2011 A2-11 15 Dec 2011 A2-12 15 Dec 2011 A2-13 15 Dec 2011 Appendix 3 A3-1 15 Dec 2011 UL-801 Installation Manual Page 1 CONTENTS 15 December 2011 Table of Contents Record of Revisions ............................................................................................................. 1 Record of Temporary Revisions ........................................................................................... 1 List of Effective Pages .........................................................................…

Text truncated - open the document above for the full version.

Attestation Statements

Universal Avionics Systems Corporation CAL-2011-1052 3260 E. Universal Way 08-Nov-2011 Tucson, AZ 85756 Page 1 of 1 Certification Contacts: 3260 E. Universal Way • Tucson, AZ 85756 U.S.A. • (520) 573‐7627 • (800) 595‐5906 • Fax 520‐295‐2384 [email protected] • [email protected] • [email protected] • [email protected] Federal Aviation Administration Mr. Michael Biggs, Acting Division Manager ATC Spectrum Engineering Services 800 Independence Avenue, SW Room 715 Washington, DC 20591 Attention: FAA: Mr. Michael Biggs Electronic Copies: FAA: Mr. Jerry Ramos, Ms. Stacey Jackson UASC: Robert C. Uhde, Paul Damschen, Kenneth Lenger, Laura Niles, Joe LoCascio, Lynn Root, Bill Kelly, Rene Spani, Scott Hornbrook CKC Labs: Randy Clark Subject: FAA Notification of Application for Certification under FCC Part 87 for UL-801 Communications Management Unit FAA Project: ST14460LA-A Delivery: Progress tracking number 1158998 Reference: DOCUMENT DOCUMENT TITLE (a) 47 CFR Part 87.147 01-Oct-2009 Authorization of equipment Enclosures: DOCUMENT DOCUMENT TITLE (1) FCC Form 731 19-Oct-2011 Application for Equipment Authorization Mr. Biggs, In accordance with the requirements of the Federal Communications Commission Rules and Regulations, 47 CFR Part 87.147(d), Universal Avionics Systems Corporation hereby notifies the Federal Aviation Administration of its simultaneous filing with CKC Certification Services (an FCC TCB) of an Application for Equipment Authorization on FCC Form 731 of equipment intended for transmission in frequency ranges set forth in FCC rules Part 87.147(d)(3) which require FAA notification. The Application for Equipment Authorization covers Universal Avionics UL-801 Communications Management Unit, part number 10801-XX. A copy of Form 731 is enclosed. Please direct any questions regarding this filing to Universal Avionics Certification organization at the contact information in the footer of this letter. FAA Action Requested: 9 Please acknowledge receipt and acceptance of this application in accordance with standard procedures for your office. Best regards: Kenneth Lenger – Senior Certification Engineer

External Photos

EXHIBIT B : External Photographs Photo 1 : UL-801 External View of Top and Side Photo 2 : UL-801 External View of Rear and Side Photo 3 : UL-801 Rear Connector

ID Label/Location Info

EXHIBIT D : Identification Label and Location Figure 1 : UL-801 ID Label Location Figure 2 : UL-801 ID Label

Internal Photos

Page 1 of 9 EXHIBIT C : Internal Photographs Photo 1 : UL-801 with Side Panel Removed Photo 2 : UL-801 with VDR Module Disconnected from Power Supply 15" 8" Page 2 of 9 Photo 3 : VDR Module. Connections (left to right) are Antenna, 28VDC Power, and Serial Communication/Digital Power. (Approx. size is 5.5"x5.5"x0.75") Photo 4 : VDR Module with Bottom Lid Removed Showing Mod-Demod Board (top) and Transmitter Board (bottom). Page 3 of 9 Photo 5 : VDR Module with Top Lid Removed Showing DSP Board Page 4 of 9 Photo 6 : DSP Board – Top Left Photo 7 : DSP Board – Top Right 3" Page 5 of 9 Photo 8 : DSP Board – Bottom Left Photo 9 : DSP Board – Bottom Right Page 6 of 9 Photo 10 : MDM Board – Top Left Photo 11 : MDM Board – Top Right 2.25"

Internal Photos

Page 7 of 9 Photo 12 : MDM Board – Bottom Left Photo 13 : MDM Board – Bottom Right Page 8 of 9 Photo 14 : TX Board – Top Left Photo 15 : TX Board – Top Right 2.5" Page 9 of 9 Photo 16 : TX Board – Bottom Left Photo 17 : TX Board – Bottom Right

Test Report

This report contains a total of 41 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Universal Avionics Systems Corporation ADDENDUM TEST REPORT TO 91992-8B Unilink, UL-801 Tested To The Following Standards: FCC Part 87 Report No.: 91992-8C Date of issue: January 30, 2012 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 41 Report No.: 91992-8C TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ........................................................................................................................................................ 3 Report Authorization ...............................................................................................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Scott Hornbrook
[email protected]425-602-5000Fax: 425-556-7808

Technical Contact

Universal Avionics Systems CorporationRoger Dieterich
[email protected]425-602-1379

11351 Willows Road NE · Redmond, Washington · United States

Non-Technical Contact

Universal Avionics Systems CorporationBill Kelly
[email protected]425-602-1363

Test Firm

CKC Laboratories, Inc.Steve Behm
[email protected]209-966-5240Fax: 866 779 9776

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
287118 MHz - 136.975 MHz23.88 W14K0G1D5 ppm
Confidentiality
Long Term
Grant Notes
Power listed is conducted.
