NYZKPL-150NNumeric Radio Paging Receiver

KOREA POLYTEC CO., LTD. Telecom Laboratory 6’h Fl. Yulgok Munhwa hwoikwan, 93 S-20, Hokye-dong, Dongan-ku, Anyang-si, Kyunggi-do, Korea Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7485 Oakland Mills Road Columbia, MD 21046 Tel No:+82 343 53 66 16 FaxNo:+82 343 53 6667 e-mail:[email protected] May 27, 1998 FCC ID.: NYZKPL-150N Section 2.97 (a) (b) - Statement of Compliance Dear Sirs: This equipment has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that equipment complies with the appropriate standard. Each unit manufactured, imported, or marked, as defined in the Commission’s regulation, will conform to the samples tested within the variations that can be expected due to production and tested on a statistical basis. I further certify that the necessary measurements were made by: PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 Sincerely, Seok-Han Hur President Korea Polytec Co., Ltd.

June 10, 1998 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Korea Polytec Co., Ltd. FCC ID: NYZKPL-150N Gentlemen: Transmitted herewith, on behalf of Korea Polytec Co., Ltd. is an application for notification of the following Numeric Radio Paging Receiver: FCC ID:NYZKPL-150N MODEL No.:KPL-150N TRADE NAME:EXPOSE EUT TYPE:Numeric Radio Paging Receiver (CYY) Attached is the applicant’s attestation statement, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Seok-Han Hur, President Korea Polytec Co., Ltd.

Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd.

Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd. Test Report S/N: NOT.980529392.NYZFCC Notification Test Date(s): June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST Lab FCC ID: NYZKPL-150N NVLAP Lab Code: 100431-0 Korea Polytec Co., Ltd.

© 1998 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE KOREA POLYTEC CO., LTD.Dates of Tests: June 03-04, 1998 6 TH Fl. Yulgok Munhwa hwoikwan,Test Report S/N: NOT.980829392.NYZ 932-20 Hokye-dong, Dongan-ku,Test Site: PCTEST Lab, Columbia MD Anyang-si, Kyunggi-do, KOREA Attention: Seok-Han Hur, President FCC ID NYZKPL-150N APPLICANT KOREA POLYTEC CO., LTD. FCC Rule Part(s):§ 15, § 2 (Notification) Classification:Numeric Radio Paging Receiver (CYY) Freq. Range:135MHz ~ 174MHz Bit Rate(s):512/1200/2400 bps Trade Name: EXPOSE Model:KPL-150N This device has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992 (Note Codes: #37). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) Lab Code 100431-0 © 1998 PCTEST Engineering Laboratory, Inc. FCC Notification TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 TEST DATA (CONDUCTED) 6 FREQUENCY MEASUREMENTS (SPURIOUS) 7 PLOTS OF EMISSION (RADIATED) 8 ACCURACY OF MEASUREMENT 9 LIST OF TEST EQUIPMENT10 RECOMMENDATION / CONCLUSION11 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL Test Report S/N: NOT.980529392.NYZFCC Notification Dates of Tests: June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST LabFCC ID: NYZKPL-150N (135 – 174MHz)1 Korea Polytec Co., Ltd. Paging Receiver MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name:KOREA POLYTEC CO., LTD. Address:6 TH Yulgok Munhwa hwoikwan, 938-20, Hokye-dong, Dongan-ku, Anyang-si, Kyunggi-do, KOREA Attention:Seok-Han Hur, President • FCC ID:NYZKPL-150N • Model:KPL-150N • Trade Name:EXPOSE • EUT Type:Numeric Radio Paging Receiver (CYY) • FCC Procedure:Notification • Freq. Range:135MHz ~ 174MHz • Bit Rate(s):512/1200/2400 bps • FCC Rule Part(s):§ 15, §2 • Dates of Tests:June 03-04, 1998 • Place of Tests:PCTEST Lab, Columbia, MD • Test Report S/N:NOT.980529392.NYZ Lab Code 100431-0 Test Report S/N: NOT.980529392.NYZFCC Notification Dates of Tests: June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST LabFCC ID: NYZKPL-150N (135 – 174MHz)2 Korea Polytec Co., Ltd. Paging Receiver 1.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from Korea Polytec Co., Ltd. (Model: KPL-150N) Numeric Paging Receiver FCC ID: NYZKPL-150N. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 1.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: NOT.980529392.NYZFCC Notification Dates of Tests: June 03-04, 1998Paging Receiver (CYY) © 1998 PCTEST LabFCC ID: NYZKPL-150N (135 – 174MHz)3 Korea Polytec Co., Ltd. Paging Receiver 2.1 Product Information 2.2 Equipment Description The Equipment Under Test (EUT) is the KOREA POLYTEC Co., Ltd. (Model KPL-150N) Numeric Paging receiver FCC ID: NYZKPL-150N. * Freq. Range:135MHz ~ 174MHz * Bit Rate(s):512/1200/2400 bps * Crystal/Oscillator(s):171.325MHz, 20.945MHz, 21.0MHz, 171.7MHz * Main Chipset:NEC 753D23A761 * Antenna:Micro Loop * Power Supply:(1) 1.5 VDC (AAA size Alkaline) * Channel Spacing:±± 25 kHz * Receiving method:Double Superheterodyne * Signal method:POCSAG * Modulation:CFSK * Frequency Stability:±± 10 ppm * Image rejection:> 55dB * Spurious rejection:> 60dB * Selectivity:> 65dB * Deviation:±± 4.5 kHz * Dimensions:58 x 18 x 48 mm 2.4 EMI Suppression Device(s) EMI suppression device(s) added and/or modified during testing: • none Test Report S/N: N…
