CWT-5500 &MWM-1562 SERIES TINSE053C--001 Table of Contents 1. Location of controls on Camera 2. Location of controls on Monitor 3. Connections/Setting up 4. Specfications 1 2 3~7 8~9 Camera Transmitter: 1. Transmit Frequency: 2400~2483MHz 2. Microwave Output Power: 94 dBu FCC/10mW(BZT) 3. Modulation: FM4. Maximum Frequency Deviation: 20 MHz 5. Audio Sub, Carrier Frequency: 5.5 MHz, 5.74 6. Infrared Detection Range: 1~2 meter 7. Operation Current: 300 MA MAX. 8. Dimension: Monitor Receiver: 1. Receiver Frequency: 2400~2483MHz 2. Receiver Sensitivity: -80 ~ -85 dBm 3. Monitor Type: Black&White4. Video Output: 1 Vpp 75 ohm5. Audio Output: -8dBs 47K ohm6. Monitor Center horizontal Resolution: 330 lines 7. Operation Current: <1A 8. Power Supply: Adaptor: DC 12V 1ABattery: 10 pcs size"C" Alkaline Battery(optional) 9. Dimension: 9 114W 55 122D H m/m 160W 160H 196Dm/m Notice: The changes or modifications not expressly approvedby the party responsible for compliance could void the user'sauthority to operate the equipment. Location of controls on camera 2 3 4 6 8 7 9 1. Patch Antenna2. Infra-red Lighting3. Wide-angle Camera Lens5. Off/On/Night Switch4. Microphone 6. Wall Mount Lug 7. Channel Selector Switch 8. DC Input Jack 9. Audio/Video Input 1 5 Specifications General: 1. Operation Frequency: 2400MHz - 2480MHz 3. Video: a) Input Impedance: 1 Vpp 75 ohm b) Frequency Response: 0~5 Mhz 4. Audio: a) Input Impedance: 10K ohm b) Interface Level: 1 Vpp c) Frequency Response: 300 - 3400 Hz 8 1 2. Usable range: 30 ~ 50 Meter 5. Operation Temperature: -10~50 C 2. 5 inches/12.5cm CRT1. Patch Antenna3. Power Indicator4. Off/Audio/Video Switch) 5. Contrast Control6. Brightness Control7. Volume Control8. Speaker Location of controls on monitor 9. Channel & timer selector 10. DC Input Jack 11. Audio/Video Output 12. V-Hold Control 7 Audio Function: Connections/setting up When the Monitor is switched to"Audio" position and the Camerais at power on, there will be nopicture on the Monitor screen.The unit is using a small amountof power and is audio operational.You can hear the sound signalthat captured from the monitoringarea. The Monitor Audio/Video Link Option: An additional security featureof this 2.4Ghz AV Monitor is that. will resume Video picture whenyou switch to the "Video" position. 3 The Video and Audio outputjacks are located at the backof the Monitor. These need tobe connected to the VideoInput and Audio Input jackson your VCR or televisionwith "RCA type" cableavailable at your localelectronics retailer. you can link the Monitor to aVCR for recording what everthe camera sees. Also, youcan link to a conventionaltelevision that has a "Picture-In-Picture" feature that allowyou to take a glance to themonitoring area all the timewhile watching your favoriteTV program. 2 Connections/setting up 3 6 Connections/setting up Installing /Removing Batteries: Monitor- 1. Remove the battery cover as shown below. 2. Insert (or remove) the 10 size "C" batteries as below.Note: Install batteries as shownby the battery compartmentmarking only.. AC Adaptor Use: Make sure that proper AC adaptorshave been installed correctly. Useonly the AC adaptors supplied withthe Monitor. 1. Install the plug of the AC Adaptor to the DC jack ofthe unit. 2. Plug the adaptor into a standard wall outlet. 3. Switch on the power switch of the unit. 4. The power indicator will be illuminated. Channel & Timer Setting Sw5Sw6 ONON OFFON OFFOFF ONOFF Switcher time 3sec 5sec 7sec 10sec 1.The channel & Timer selector on the REAR cabinet used for channel & timing setting .put the switch to on position, than you can select single channel 1-4 or any other channel combination. 2.Timer setting defaut as below. CH TIMER Connections/setting up To prevent speaker and Microphonefeedback noise, the Monitor shouldbe placed far enough away from theCamera.If the picture rolls up or down, theV-Hold control located on the back of the Monitor needs to beadjusted. Once you have a clear and crisppicture displayed on the screen, you can adjust the brightnessand contrast by using the controlson the front of the Monitor untilyou achieve the desired result. Battery Use: The monitor requires 10 size "C"batteries when powered by battery.Alkaline batteries are recommend-ed for longer viewing time. 1. If you are using batteries in the M- onitor and the video image startsto shrink, it's time to change thebatteries. 2. Do not mix old and new batteries.3. Do not mix alkaline, standard or rechargeable batteries. 4. Remove the batteries during long period of non-use. 4 5 The infrared lighting of the camera isdesigned to allow the camera to pickup pictures clearly during darkness orperiods of very low levels of light.Slide switch to night position onwhenever needed. Please rememberthat if you intend to use the camerain the dark, it will only monitor objectsplaced within 6ft/2m of its infraredsensor. Place the Camera in the mostappropriate location for monitoring(tabletop, dresser or wall mount) Point the camera lens toward thearea you want to pick up picture. Make sure that both units are on thesame channel. Check the video reception on theMonitor screen. Adjust the quality of the picture byusing the Contrast, Brightness and VHold adjustment knobs on the back and front of the Monitor. In case of poor display quality,rotatethe antennas or reposition of bothunits to obtain optimal picturetransmission. Connections/Setting up
MODEL NO.:CWT-5500AM DATE : AUG.01.2000 PART NO.: CHECKED:DRAWN BY:z.x.p. EMPEROR CORP.(H.K.) LTD THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.SERIAL NO.: 1026000001 2.4GHz WIRELESS MODEL:CWT-5500AM BRAND:EMPEROR POWER INPUT: DC 12V 0.2/0.3A MFD. DATE: JUL. 2000 MADE IN CHINA CAMERA FCC ID: O3SCWT-5500 18.00 53.00 LOCATION OF FCC LABEL BOTTOM VIEW OF UNIT
! " # $ % & # '('( '))'*+',- $ # $ . $ !! #
