O55TWS2326Wireless Earbuds

Radiation Exposure StatementThe device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction. Wireless Earbuds Logic TW9 Radiation Exposure StatementThe device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction.

SWAGTEK Covered Equipment Certification Attestation Letter 7/17/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: O55TWS2326 SWAGTEK (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. SWAGTEK (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. SWAGTEK (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Charles Cheng Title: Manager Company Name: SWAGTEK Date: 7/17/2026

SWAGTEK 12415 SW 136th Avenue STE 6, Miami FL33186, USA 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: SWAGTEK Address: 12415 SW 136th Avenue STE 6, Miami FL33186, USA Product Name: Wireless Earbuds FCC ID: O55TWS2326 2.911(d)(7) USA Designated Agent for Service of Process We, [SWAGTEK] (“the applicant”) designate [SWAGTEK] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: SWAGTEK USA Address: 12415 SW 136th Avenue STE 6, Miami FL33186, USA FRN Number: 0021846670 Contact Name: Charles Cheng Telephone No: (305) 421-9938 Email: [email protected] Applicant Company name: SWAGTEK Address: 12415 SW 136th Avenue STE 6, Miami FL33186, USA Grantee FRN Number: 0021846670 FCC Grantee Code: O55 Contact Name: Charles Cheng Telephone No: (305) 421-9938 Email: [email protected] SWAGTEK 12415 SW 136th Avenue STE 6, Miami FL33186, USA 2.911 (d)(7)USA Agent v1.5 Signature: Title: Manager Signature: Title: Manager Date: 2026/7/17 Date: 2026/7/17 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

SWAGTEK DATE: 7/17/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongzhou Testing Co.,Ltd. (1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with SWAGTEK (12415 SW 136th Avenue STE 6, Miami FL33186, USA) <Signature> Name: Charles Cheng Title: Manager Applicant Company: SWAGTEK

Date: 7/17/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Charles Cheng Title: Manager Company: SWAGTEK

Date: 7/17/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: O55TWS2326 Product Name: Wireless Earbuds Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Charles Cheng Title: Manager Company: SWAGTEK

SWAGTEK 12415 SW 136th Avenue STE 6, Miami FL33186, USA Date: 2026/7/17 Dear Sir/Madam, We, SWAGTEK, Hereby declares the following statement, PCB board, circuit, structure and internal of these model(s) are the same, Only model name is different for these model: FCC ID: O55TWS2326 Product name: Wireless Earbuds Model no.: Logic TW9, Y02 Sincerely, Name/Title： Charles Cheng / Manager Company: SWAGTEK Address: 12415 SW 136th Avenue STE 6, Miami FL33186, USA Phone: (305) 421-9938 Fax: (305) 471-9011 E-Mail: [email protected]

Report No.: TZ0053260601PH02 Page 1 of 4 External Photographs of EUT External Photo 1 External Photo 2 Report No.: TZ0053260601PH02 Page 2 of 4 External Photo 3 External Photo 4 Report No.: TZ0053260601PH02 Page 3 of 4 External Photo 5 External Photo 6 Report No.: TZ0053260601PH02 Page 4 of 4 External Photo 7

The size of the label is 15mm*10mm with White forecolor. The size of the logo is 5mm*5mm. FCC ID: O55TWS2326

Report No.: TZ0053260601PH03 Page 1 of 5 Internal Photographs of EUT Internal Photo 1 Internal Photo 2 Report No.: TZ0053260601PH03 Page 2 of 5 Internal Photo 3 Internal Photo 4 Antenna Report No.: TZ0053260601PH03 Page 3 of 5 Internal Photo 5 Internal Photo 6 Report No.: TZ0053260601PH03 Page 4 of 5 Internal Photo 7 Internal Photo 8 Report No.: TZ0053260601PH03 Page 5 of 5 Internal Photo 9 Internal Photo 10

FCC ID: O55TWS2326 Page 1 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). FCC ID: O55TWS2326 Page 2 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR- based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] DH5 Ant1 2402 0.78 0.5 1 0 1.5 1.41 2.79 DH5 Ant1 2441 -0.65 -1 1 0 0 1.00 2.75 DH5 Ant1 2480 -1.39 -2 1 0 -1 0.79 2.72 2DH5 Ant1 2402 1.47 1 1 0 2 1.58 2.79 2DH5 Ant1 2441 0.02 -0.5 1 0 0.5 1.12 2.75 2DH5 Ant1 2480 -0.78 -1.5 1 0 -0.5 0.89 2.72 3DH5 Ant1 2402 1.99 1.5 1 0 2.5 1.78 2.79 3DH5 Ant1 2441 0.36 0 1 0 1 1.26 2.75 3DH5 Ant1 2480 -0.56 -1 1 0 0 1.00 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 1 of 56 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Wireless Earbuds Trade Mark: Test Model: Logic TW9 FCC ID: O55TWS2326 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency [MHz] 20db EBW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.954 2401.523 2402.477 --- --- DH5 Ant1 2441 0.927 2440.526 2441.453 --- --- DH5 Ant1 2480 0.945 2479.520 2480.465 --- --- 2DH5 Ant1 2402 1.275 2401.364 2402.639 --- --- 2DH5 Ant1 2441 1.272 2440.358 2441.630 --- --- 2DH5 Ant1 2480 1.269 2479.361 2480.630 --- --- 3DH5 Ant1 2402 1.272 2401.361 2402.633 --- --- 3DH5 Ant1 2441 1.257 2440.361 2441.618 --- --- 3DH5 Ant1 2480 1.287 2479.346 2480.633 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 2 of 56 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 3 of 56 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 4 of 56 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 5 of 56 3DH5-Ant1-2402 3DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 6 of 56 3DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 7 of 56 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.85925 2401.5554 2402.4146 --- --- DH5 Ant1 2441 0.85739 2440.5562 2441.4136 --- --- DH5 Ant1 2480 0.86283 2479.5555 2480.4183 --- --- 2DH5 Ant1 2402 1.1756 2401.3998 2402.5754 --- --- 2DH5 Ant1 2441 1.1772 2440.3988 2441.5760 --- --- 2DH5 Ant1 2480 1.1624 2479.4039 2480.5663 --- --- 3DH5 Ant1 2402 1.1690 2401.4010 2402.5700 --- --- 3DH5 Ant1 2441 1.1643 2440.4052 2441.5695 --- --- 3DH5 Ant1 2480 1.1852 2479.3995 2480.5847 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 8 of 56 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 9 of 56 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 10 of 56 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 11 of 56 3DH5-Ant1-2402 3DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 12 of 56 3DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 13 of 56 Appendix C: Maximum peak conducted output power Test Result Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict DH5 Ant1 2402 0.78 ≤30 PASS DH5 Ant1 2441 -0.65 ≤30 PASS DH5 Ant1 2480 -1.39 ≤30 PASS 2DH5 Ant1 2402 1.47 ≤20.97 PASS 2DH5 Ant1 2441 0.02 ≤20.97 PASS 2DH5 Ant1 2480 -0.78 ≤20.97 PASS 3DH5 Ant1 2402 1.99 ≤20.97 PASS 3DH5 Ant1 2441 0.36 ≤20.97 PASS 3DH5 Ant1 2480 -0.56 ≤20.97 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 14 of 56 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 15 of 56 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 16 of 56 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 17 of 56 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 18 of 56 3DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 19 of 56 Appendix D: Carrier frequency separation Test Result Test Mode Antenna Frequency [MHz] Result [MHz] Limit [MHz] Verdict DH5 Ant1 Hop 1.012 ≥0.954 PASS 2DH5 Ant1 Hop 1.154 ≥0.850 PASS 3DH5 Ant1 Hop 1.002 ≥0.858 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 20 of 56 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 21 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 22 of 56 Appendix E: Time of occupancy Test Result Test Mode Antenna Frequency [MHz] Burst Width [ms] TotalHops [Num] Result [s] Limit [s] Verdict DH5 Ant1 Hop 2.911 60 0.175 ≤0.4 PASS 2DH5 Ant1 Hop 2.916 120 0.35 ≤0.4 PASS 3DH5 Ant1 Hop 2.920 100 0.292 ≤0.4 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 23 of 56 Test Graphs DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 24 of 56 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 25 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 26 of 56 Appendix F: Number of hopping channels Test Result Test Mode Antenna Frequency [MHz] Result [Num] Limit [Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 27 of 56 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 28 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0053260601FRF01 Page 29 of 56 Appendix G: Band edge measurements Test Result Test Mode Antenna Ch.Name Frequency [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 0.02 -45 ≤-19.99 PASS DH5 Ant1 High 2480 -2.33 -48.17 ≤-22.33 PASS DH5 Ant1 Low Hop_2402 -0.09 -43.76 ≤-20.09 PASS DH5 Ant1 High Hop_2480 -2.67 -48.34 ≤-22.67 PASS 2DH5 Ant1 Low 2402 -0.39 -45.81 ≤-20.39 PASS 2DH5 Ant1 High 2480 -2.40 -48.08 ≤-22.4 PASS 2DH5 Ant1 Low…

Text truncated - open the document above for the full version.

Report No.: TZ0053260601FRF01 Page 1 of 35 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. TEST REPORT Report Number : TZ0053260601FRF01 Product Name : Wireless Earbuds Model/Type reference : Logic TW9, Y02 FCC ID : O55TWS2326 Prepared for : SWAGTEK 12415 SW 136th Avenue STE 6, Miami FL33186, USA Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15C, ANSI C63.10-2020 + Cor.1-2023 Date of Test : 2026-06-11 ~ 2026-06-23 Date of Issue : 2026-06-24 Prepared by : Lena Wen Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0053260601FRF01 Page 2 of 35 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-06-24 Valid Initial release Report No.: TZ0053260601FRF01 Page 3 of 35 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ....................................................... 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. EUT configuration ................................................................................................................... 5 1.5. Description of Test Facility .................................................................................................... 5 1.6. Statement of the Measurement Uncertainty ......................................................................... 5 1.7. Measurement Uncertainty ...................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 6 1.9. Frequency of Channels .......................................................................................................... 7 2. T E S T M E T H O D O L O G Y ............................................................ 8 2.1. EUT Configuration .................................................................................................................. 8 2.2. EUT Exercise ........................................................................................................................... 8 2.3. Test Sample ............................................................................................................................. 8 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 9 3.1. Justification ............................................................................................................................. 9 3.2. EUT Exercise Software ........................................................................................................... 9 3.3. Special Accessories ............................................................................................................... 9 3.4. Block Diagram/Schematics .................................................................................................... 9 3.5. Equipment Modifications ....................................................................................................... 9 3.6. Test Setup ................................................................................................................................ 9 4. S U M M A R Y O F T E S T R E S U L T S ............................................... 10 5. M E A S U R E M E N T R E S U L T S .................................................... 11 5.1. Maximum Peak Conducted Output Power ......................................................................... 11 5.2. Frequency Separation and 20 dB Bandwidth .................................................................... 12 5.3. Number of Hopping Frequency ........................................................................................... 13 5.4. Time of Occupancy (Dwell Time) ......................................................................................... 14 5.5. Conducted Spurious Emissions and Band Edges Test .................................................... 16 5.6. Restricted Band Emission Limit .......................................................................................... 17 5.7. AC Power line conducted emissions .................................................................................. 26 5.8. Band-edge measurements for radiated emissions ........................................................... 29 5.9. Pseudorandom frequency hopping sequence ................................................................... 32 5.10. Antenna requirement ............................................................................................................ 33 6. S U M M A R Y O F T E S T E Q U I P M E N T ........................................... 34 7. T E S T S E T U P P H O T O G R A P H S ................................................ 35 8. E X T E R N A L P H O T O S O F T H E E U T .......................................... 35 9. I N T E R I O R P H O T O S O F T H E E U T ......................…

Text truncated - open the document above for the full version.

ITEMModel NameMaximum GainPolarizationImpedanceManufactureAddress Antenna S p ecification ANT SPEC 2.4G ANT Antenna Photo 0 dBi Azimuth BeamPattern Omni-directional Horizontal and Vertical ZHUHAI JIELI TECHNOLOGY CO.,LTD 50 Ohm 333 Kexing Rd,Nanping Town,Xiangzhou Dist,Zhuhai City,Guangdong Province,China Frequency /MHz Gain/ dBi 2400 -0 .23 2410 -0 .28 2420 -0 .32 2430 -0 .39 2440 0.0 2450 -0 .41 2460 -0 .42 2470 -0 .34 2480 -0 .27 2490 -0 .18 2500 -0 .09 3D Radiation Pattern for 2440MHz

Report No.: TZ0053260601PH01 Page 1 of 2 Test Setup Photos of the EUT Conducted Emission Radiated Emission Below 1GHz Report No.: TZ0053260601PH01 Page 2 of 2 Radiated Emission Above 1GHz RF Conducted Test
