O5JUSE000001IR / UHF Remote Control

version 1.0 09192001 U SER’S G UIDE for NG-ATH33, NG-ATH18, and NG-IR Make sure to set your TV to channel 2, 3, or 4as directed by your satellite receiver manual.This manual makes reference to “modekeys.” These are the TV , SAT , DVD , and VCR keys at the top of the remote control.After you have programmed the remote, you’lluse the mode keys to select which deviceyou want the remote control to operate. BEFORE YOU BEGIN 1 34 SELECT TV SAT POWER DVD CANCEL INFO GUIDE THEME BROWSE MENU CHAN VOL RECALL TV/VIDEO ENTER SYS INFO RECORD 1 2 3 4 5 6 7 8 0 9 MUTE VCR PAGE VIEW s t Before you can set up or operate the remote control, you mustinstall two Alkaline AA batteries. Remove the battery compartment cover on the back of yourremote control.Check battery polarity carefully, and install the batteries asshown in the illustration to the right.Replace the battery compartment cover. Option 1Place the receiver base station in theroom where your equipment is located.Choose a location near an electricaloutlet on an opposing wall to where theequipment is installed. Point the front ofthe base station towards the equipment.Try to use your remote from your chosenlocation to confirm that it is within theoperating view of your equipment.Plug the AC power adapter into the walloutlet. Attach the small plug from thetransformer into the jack on the base station.The power light should flash and go out. Thelight will only go on when it is receiving acommand from the Around the HouseRemote. The base station is ready to use.Option 2Using Your Control CablesWith the proper connection, you can hidethe receiver base station behind yourentertainment system and still control allyour equipment. First, plug the control cableinto the back of the base station receiver.The emitter end of the control cable mustthen be placed in front of each piece ofequipment you want to communicate withthe remote control sensor. The remotecontrol sensor is commonly identifiable by asmall plastic window. You may have to try different locations foroptimum performance. You can permanentlyattach the emitters using the peel-and-stickbacking. This attachment should notinterfere with normal operation. INSTALL BATTERIES 2 RECEIVER BASE INSTALLATION KNOW YOUR REMOTE bcd VIEW exits out of on-screen menus NUMBER KEYS allow direct access to specific channels and menu options CHAN changes the channel up and down MODE KEYS allow you to select which device your remote will operate. They are also used to setup the remote control RECORD does not operate VCR record. Use the VCR Recordbutton (see illustration below)INFO displays channel and program information CANCEL cancels the current procedure SELECT chooses the highlighted item in the menu PAGE moves the menu forward and backward one page RECALL tunes to the last channel that was viewedPOWER used in conjunction with the device Keys, the Power keylets you turn devices on and offSIGNAL LED lights up when the remote is transmitting signal, andduring certain setup proceduresVOL turns the volume up and down GUIDE displays the program guide FOUR-WAY CURSOR KEYS allow you to navigate through the on-screen menus MENU brings up the main on-screen menuSYS INFO displays information about the satellite receiver TV/VIDEO switches inputs on the Satellite Receiver and TV when in SAT or TV mode; and acts as the TV/VCR button when in VCR mode VCR KEYS perform standard VCR functions (see illustration below) SELECT CHAN VOL 1 2 3 4 6 7 8 0 9 5 TV/VIDEO SYS INFO ENTER s t RECALL RECORD PAG E VIEW INFO GUIDE MENU TV SAT POWER DVD VCR CANCEL BROWSE THEME PAUSE PLAY REWIND FAST FORWARD STOP RECORD VCR/DVD KEYS To initiate recording on the VCR, press RECORD twice. The diagram below shows the functions of special keys for your satellite receiver. Refer to yoursatellite receiver manual for descriptions of specific functions. NOTE : keys are marked for Dish Network ® functions. For other satellite receivers, keys may have different functions. This device complies with Part 15 of the FCC Rules. Operation issubject to the following two conditions: (1) this device may notcause harmful interference, and (2) this device must accept anyinterference received, including interference that may causeundesired operation.This equipment has been tested and found to comply with thelimits for a Class B digital device, pursuant to Part 15 of the FCCRules. These limits are designed to provide reasonable protectionagainst harmful interference in a residential installation. Thisequipment generates, uses and can radiate radio frequencyenergy and, if not installed and used in accordance with theinstructions, may cause harmful interference to radiocommunications. However, there is no guarantee that interferencewill not occur in a particular installation. If this equipment doescause harmful interference to radio or television reception, whichcan be determined by turning the equipment off and on, the user isencouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. On the remote control, press and hold the mode key ( TV , SAT , or VCR ) until the LED begins flashing.Select a code from the appropriate code list for the brand of device you wish the remoteto operate, then enter the code using the numeric keys on the remote.After you press the first digit, the LED should light and stay on. After you press the lastdigit, the LED should flash rapidly and turn off. If the LED does not flash rapidly beforeturning off, repeat the procedure, starting at step 1 above, using a valid code from theappropriate code list.Point the remote at the device and press POWER . If the device turns on/off, then the remote has been set up with a code that can control the devic…

Text truncated - open the document above for the full version.

          )
!*

 +,

2567   $

 -./01##&


/
    !"#$!%$ &'($")'(*$+ $, "$- .$$" / 8
 3 2 9
 3 !
 ,
 $:


















!    "  #


  $%       &   '     (
! %


  )
!*

 +,

 $

 -./01##&


/
    !"#$!%$ &'($")'(*$+ $, "$- .$$" /

            !" #"$$!"%$!& # $$!!'%"!"" $$$&()!'$'"!!" $* '+,%$!& # $$!!'%"!"" $$$&*'-  #.!'+,%$!&!##"!/!!'- .!'%"!""*,!" $%$!&$'"!*             0 1 02 3 1        2 3 4
5% 4 6)  4





  '7 '7
0   0   8) 8 )        3 9   : :  :  :  :  :  :  2  4
  4
 :  :  :  6)  :  :  :  :  :  :  : :  :  :  : 7  :  :  :   3 1    357 02    )
!*

  +,

 $

 -./01##&-


/
 !"#$!%$ &'($")'(*$+ $, "$- .$$" /  ;7
<5%= <;!=8<;!= ) 8  ::!  >    2 ;7 ;7    8 >
>   ;7 ;7   8  ;7  ;7  ;7 >     > (5 <?  @=  5 < 8
))A= ;7
) ))
: 0 )
5% 7 3
)
!*

 +,

23
)*2%+4  $

 -./01##&


/
    !"#$!%$ &'($")'(*$+ $, "$- .$$" / ) 8  ::!  >    2 ;7 ;7    8 >
>   ;7 ;7   8  ;7  ;7  ;7 >     > (5 <?  @=  5 < ? = ;7
) ))
: 0 )
 5% 7 3

< 5%=8 <;!= )
!*

 +,

23
)*2%+& 4  $

 -./01##&


/
    !"#$!%$ &'($")'(*$+ $, "$- .$$" /

          )
!*

 +,

2567   $

 -./01##&


/
    !"#$!%$ &'($")'(*$+ $, "$- .$$" / 8
 3 2 9
 3 !
 ,
 $:


American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 26, 2001 RE: U.S. Electronics FCC ID: O5JUSE000001 Please review my comments on this Application. 1.) The Internal Photographs and External Photographs could not be opened. Please take these respective Exhibits and insert into MS Word format, label, and convert to *.pdf 2.) The Test Setup photos must be separated into a it’s own exhibit. 3.) The Block Diagram contains a mixture of both Schematics and Block Diagrams. Please resubmit only the Block Diagram portion. William H. Graff Examining Engineer President and Director of Engineering mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

1076 Deer Clover Way •• Castle Rock, Colorado 80104 USA •• Phone 303 663 3396 • Fax 303 663 5545 e-mail: [email protected] The information in this document is private and company confidential Compliance & More, Inc. ™ "your compliance solution" March 4, 2002 Mr. William H. Graff AmericanTCB, Inc. 6731 Whittier Ave McLean, VA 22101 Re: FCC ID O5JUSE000001 Dear Bill: In reply to your March 1, 2002, e-mail message, I can explain the confusion in the U.S. Electronics, Inc Grant of Equipment Authorization. In all locations in the application except for the draft of the FCC Label drawing, the FCC ID # is O5JUSE000001. In the draft the FCC Label the number is O5JUSE00001. Attached is a “jpg” of the actual label being applied on the remote control. As you can see the FCC ID is O5JUSE000001. The draft simply had a typographical error. In the TUV Product Service report number B944301 dated January 23, 2001, TUV omitted the duty cycle reduction from their test data on pages A2, A3, and A4. However, if you refer to pages A11 and A12 it notes that the duty cycle was measured and calculated to be –24.7 dbuV/m. TUV Product Service just failed to add the duty cycle reduction to their calculations. The information was included in their test report but not included in their reported test data. Per the attached spread sheet, I have included the duty cycle reduction to their test results and as you can see the remotes meet the FCC limits. This was just an oversight on the part of TUV Product Service. Please submit this information to the FCC. Sincerely, J. Douglas Barnes President, Compliance & More, Inc.

External Front view

External Rear View

FCC ID Label: FCC ID O5JUSE00001 Made In Korea This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal back view

Internal front view

Internal back view

Internal front view

Theory of Operation for: RMD-001, RMD-002 IR/UHF Remotes The RMD-001 and RMD-002 remote control units generate through contact closure and the microprocessor controller, pulse position modulation (PPM) code that is applied to the Infrared emitters and UHF driver circuit simultaneously. The PPM code is applied to the UHF transmitter through Q5 and Q4 and mixed with the respective UHF frequency generated by the SAW resonator in Q3. The output of Q3 is matched to the loop antenna through filter C4, C5 and L2.

File No. BC1G944301, Page 1 of 4 T ÜV PRODUCT SERVICE INC 40 Meadow Road Pinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004 Rev.No 1.0 EMC EMISSIONS - TEST REPORT Test Report No. B944301 Issue Date January 23, 2001 Model / Serial No. Thomas / EMC1 Product Type UHF Hand Held TV Remote Control Client ICX International Inc. Manufacturer ICX International Inc. License holder ICX International Inc. Address 8250 Park Meadow Drive, Suite 150 Littleton, CO 80124 Test Criteria Applied FCC Part 15 Class B Limits and methods of measurement of radio disturbance characteristics of information technology equipment. Test Result PASS Test Report Project No. BC1G944301 Total Pages including Appendices 28 Reviewed By : Carlos Marrero Reviewed By : Robert Cresswell TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others fr Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval of TÜV Product Service. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI PRODUCT SERVICE File No. BC1G944301, Page 2 of 4 T ÜV PRODUCT SERVICE INC 40 Meadow Road Pinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004 Rev.No 1.0 DIRECTORY - EMISSIONS Page(s) Documentation Test report 1 - 4 Directory 2 Test Regulations 3 General Remarks 3 Test-setup Photographs 4 Appendix A Test Data Sheets and Test Equipment Used A1 - A12 Appendix B Test Plan/Constructional Data Form B1 - B12 STATEMENT OF MEASUREMENT UNCERTAINTY The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device. EUT Received Date: November 8, 1999 Testing Start Date: November 8, 1999 Testing End Date: November 9, 1999 PRODUCT SERVICE File No. BC1G944301, Page 3 of 4 T ÜV PRODUCT SERVICE INC 40 Meadow Road Pinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004 Rev.No 1.0 EMISSIONS TEST REGULATIONS : The tests were performed according to following regulations : n - Federal Communication Commission Part 15 o - Class A n - Class B -------------------------------------------------------------------------------- All tests performed according to ANSI C63.4 Emission Test Results: Conducted emissions 150 kHz - 30 MHz Test Result oo - PASS oo - FAIL nn - Not Applicable Passing Margin dB at MHz Failing Margin dB at MHz Remarks: Radiated emissions (electric field) 30 MHz - 1000 MHz Test Result oo - PASS oo - FAIL oo - Not Applicable Passing Margin 27.9dB at 31.99MHz Failing Margin dB at MHz Remarks: GENERAL REMARKS: Modifications required to pass: None Test Specification Deviations: Additions to or Exclusions from: None PRODUCT SERVICE File No. BC1G944301, Page 4 of 4 T ÜV PRODUCT SERVICE INC 40 Meadow Road Pinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004 Rev.No 1.0 Test-setup photo(s) Radiated Emissions PRODUCT SERVICE File No. BC1G944301, Page A1 of A12 T ÜV PRODUCT SERVICE INC 40 Meadow Road Pinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004 Rev.No 1.0 Appendix A Test Data Sheets and Test Equipment Used PRODUCT SERVICE Radiated Electromagnetic Emissions Test Report #: B9443 Run 01 Test Area: Pinewood Site 1 (3m) Test Method: Test Date: 08-Nov-1999 EUT Model #: Thomas EUT Power: EUT Serial #: EMC1 Temperature: 24 °C Manufacturer: Compliance and More Relative Humidity: <18 % EUT Description: UHF Remote Air Pressure: 80 kPa Notes: Page: 1 of 3 FREQ LEVEL CABLE / ANT / PREAMP FINAL POL/HGT/AZ DELTA 1 DELTA2 (MHz) (dBuV) (dB) (dBuV/m) (m)/(deg) None None Tested by: Steve Brauns Signature On File Printed Signature Reviewed by: Felix J. Chavez Printed Signature EUT in worst case position, standing straight up. 433.88 63.8Pk 1.2 / 16.2 / 0.0 81.1 V / 1.2 / 258.0 N/A N/A 433.88 59.2Pk 1.2 / 16.2 / 0.0 76.6 H / 3.0 / 344.0 N/A N/A 867.78 66.2Pk 1.8 / 22.5 / 30.0 60.4 H / 1.0 / 315.0 N/A N/A 867.78 72.5Pk 1.8 / 22.4 / 30.0 66.7 V / 1.0 / 227.0 N/A N/A 1301.68 52.4Pk 2.4 / 25.6 / 30.0 50.4 V / 1.0 / 248.0 N/A N/A 1735.58 49.6Pk 2.7 / 27.7 / 30.0 50.0 V / 2.4 / 171.0 N/A N/A 2169.48 53.4Pk 3.1 / 29.1 / 30.0 55.6 V / 1.4 / 132.0 N/A N/A 2603.38 58.9Pk 3.4 / 31.1 / 30.0 63.4 V / 1.0 / 179.0 N/A N/A 3037.27 50.5Pk 3.8 / 32.6 / 30.0 56.9 V / 1.0 / 101.0 N/ A N/A 3471.19 30.3Pk 4.1 / 33.3 / 30.0 37.7 V / 1.0 / 141.0 N/A N/A 3905.07 38.1Pk 4.4 / 33.3 / 30.0 45.8 V / 1.0 / 130.0 N/A N/A 1301.68 55.3Pk 2.4 / 25.6 / 30.0 53.3 H / 1.8 / 180.0 N/A N/A 1735.58 42.0Pk 2.7 / 27.7 / 30.0 42.3 H / 1.4 / 10.0 N/A N/A File No. BC1G944301, Page A2 of A12 T ÜV PRODUCT SERVICE INC 5541 Central Avenue Boulder, Colorado 80301 Tel: 303 786 7999 Fax: 303 449 3004 Rev.No 1.0 Radiated Electromagnetic Emissions Test Report #: B9443 Run 01 Test Area: Pinewood Site 1 (3m) Test Method: Test Date: 08-Nov-1999 EUT Model #: Thomas EUT Power: EUT Serial #: EMC1 Tem…

Text truncated - open the document above for the full version.

FreqPolarityOrignal report Final resultDuty cycleActual Final MHzdbuV/mdbuV/mdbuV/m 433.88.v81.10-24.7056.40 433.88.h76.60-24.7051.90 867.78.h 60.40 -24.7035.70 867.78.v66.70-24.7042.00 1301.68.v50.40-24.7025.70 1735.58v50.00-24.7025.30 2169.48v55.60-24.7030.90 2603.38v63.40-24.7038.70 3037.27v56.90-24.7032.20 3471.19v37.70-24.7013.00 3905.07v45.80-24.7021.10 1301.68h53.30-24.7028.60 1735.58h42.30-24.7017.60 2169.47h62.50-24.7037.80 2603.37h62.10-24.7037.40 3037.27h59.70-24.7035.00 3471.17h41.20-24.7016.50 3905.06h45.20-24.7020.50 4338.96h41.40-24.7016.70 4338.97v44.30-24.7019.60

TUV test setup back view
