O5XHP-420BPDP MONITOR

OWNER'S MANUAL 1 Contents 45PICTURE (PC) 30Displayable Monitor Specification Volume Control TV channel Selection Turning the PDP on / off 31Basic Operation 31 31 31 68Warranty Card 67Trouble Shooting 63Specification 62Viewing the Picture-In-Picture 61TELETEXT 58TIME 51SET UP 47SOUND 38PICTURE (TV) 33CHANNEL (TV) 32OSD Menu Structure 29Connecting the PC 28Watching Set Top Box 27Watching DVD 26Watching VCR 25Watching TV 21Speaker Installation (optional) 19Table Stand Installation (optional) 15Wall Mount Installation (optional) 15Monitor Installation 14Reception Rage of Remote Control 14Loading the Batteries 12Key Description 12Remote Control 11Optional Extras 10Accessories 9Ports descriptions and RS-232C 8Back Panel and Ports 7OSD key function 7OSD key Position 7Overview of Your New PDP 2Important Safety Information OWNER'S MANUAL 2 Important Safety Information Always be careful when using your Monitor. To reduce the risk of fire, electrical shock, and other injuries, keep these safety precautions in mind when installing, using, and maintaining your machine. The violation of this instruction may cause serious injuries and even death. HIGH VOLTAGE RISK OF ELECTRIC SHOCK DO NOT OPEN. WARNING - TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR SHOCK HAZARD. - DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. - SHOCK HAZARD DO NOT OPEN. CAUTION WARNING This is Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. WARNING To reduce the risk of fire and electric shock, do not expose this product to rain or moisture. FCC NOTICE This device has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in home environment as well as in a commercial, industrial or business environment. This equipment can generate, use and radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Connecting of peripherals requires the use of grounded shielded signal cables. Read all safety and operating instructions before operating your Monitor. Keep the safety and operating instructions for future reference. Heed all warnings on the Monitor and in the operating instructions. OWNER'S MANUAL 3 Follow all operating and use instructions. Unplug the Monitor from the wall outlet before cleaning. Use a damp cloth; do not use liquid or aerosol cleaners. Never add any attachments and/or equipment without approval of the manufacturer. Such additions can increase the risk of fire, electric shock, or other personal injury. Do not use the Monitor where contact with or immersion in water is a possibility, such as near bath tubs, sinks, washing machines, swimming pools, etc. Do not place the Monitor on an unstable cart, stand, tripod, bracket, table, or floor where it can fall. A falling Monitor can cause serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the Monitor. Move the Monitor and cart with care. Quick stops, excessive force,and uneven surfaces can make the unit and cart unsteady and likely to overturn. Important Safety Information This plasma display is designed to be mounted horizontally (wide viewing). Any inquiry regarding its vertical position should be forwarded to the manufacture directly When installing the Monitor on a table, be careful not to place the edge of its stand. - This may cause the Monitor to fall, causing serious injury to a child or adult, and serious damage to the Monitor. OWNER'S MANUAL 4 Important Safety Information Provide ventilation for the Monitor. The unit is designed with slots in the cabinet for ventilation to protect it from overheating. Do not block these openings with any object, and do not place the Monitor on a bed, sofa, rug or other similar surface. Do not place it near a radiator or heat register. If you place the Monitor on a rack or bookcase, ensure that there is adequate ventilation and that you've followed the manufacturer's instructions for mounting. Use only the accessory cord designed for this product to prevent shock. The power supply voltage rating of this product is AC100-240V, the power cord attached conforms to the following power supply voltage. Use only the power cord designated by our dealer to ensure Safety and EMC. When it is used by other power supply voltage, power cable must be changed. Consult your product dealer. Use only a grounded or polarized outlet. For your safety, this Monitor is equipped with a polarized alternating current line plug having one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still does not fit, contact your electrician to replace your outlet. Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead power lines or other electric light or power circuits or where it can f…
