O7URECSPEED-8000PADSL Modem Card

DW-8000P Installation Guide i Copyright     2000, DAEWOO Corporation All rights reserved. This manual and software described in it are copyrighted with all rights reserved. This manual may not be copied, in whole or in part, without the written consent of DAEWOO Corporation. DW-8000P is a trademark of DAEWOO Corporation. All other product names are trademarks and or registered trademarks of their respective companies. Part Number UG8000P-xx FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measure:
Reorient or relocated the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded cables must be used to comply with FCC regulations. WARNING(Part15,Section 15.21) Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. DW-8000P Installation Guide ii BEFORE YOU START! .............................................................................................................. ..........1 G STEP 1 – GATHER SYSTEM AND SERVICE CONNECTION INFORMATION......................... 2 G S YSTEM R EQUIREMENTS ......................................................................................................................2 G D ETERMINING Y OUR O PERATING S YSTEM ...........................................................................................2 G D ETERMINING Y OUR C ONNECTION A DDRESS AND C ONFIGURATION ...................................................3 G STEP 2 – INSTALL THE ADSL MODEM CARD..............................................................................4 G H ARDWARE I NSTALLATION ..................................................................................................................4 G STEP3 – INSTALL THE DRIVERS.................................................................................................... .5 G D RIVER I NSTALLATION AND I NTERNET S ERVICE C ONNECTION ...........................................................5 G NDIS D RIVER I NSTALL FOR W INDOWS 95/98 ......................................................................................6 G NDIS D RIVER I NSTALL FOR W INDOWS 2000 .......................................................................................9 G NDIS D RIVER I NSTALL FOR W INDOWS NT4......................................................................................10 G APPENDIX A - CONNECTOR PINOUT...........................................................................................12 G APPENDIX B - TROUBLE SHOOTING ...........................................................................................13 G APPENDIX C - REMOVING DW-8000P DRIVERS ........................................................................14 G W INDOWS 95/98.......................................................................................................................... .......14 G W INDOWS 2000........................................................................................................................... .......14 G W INDOWS NT4.0 .......................................................................................................................... .....14 G DW-8000P Installation Guide 1 Before you Start! The DW-8000P Installation Guide tells you everything you need to know to install and use the DW-8000P card. This guide is designed to walk you through the installation of the DW-8000P card and drivers, and then through the establishment of an Internet service connection. This is a (3) step process. Step 1 – Gather system and service connection information Step 2 – Install the ADSL modem card Step 3 – Install the drivers and establish an Internet service connection
If you’re a beginner to the Internet – or if you’re experienced but have never installed an ADSL PCI card before – Start at the beginning and work your way carefully through the instructions. It is important to gather all the information required before you actually install the PCI card and ADSL drivers.
If you’re familiar with installing PCI cards and drivers - you may be able to browse the chapters to get the basics - However, it is still important to gather all the information required before you actually install the PCI card and ADSL drivers.
Your ADSL board only has one RJ-11 connector for ADSL connection. POTS splitters or microfilters can be plugged outside from the board using multiple port phone jacks. hkzs hj{ jyj spurkh{h DW-8000P Installation Guide 2 Step 1 – Gather system and service connection information System Requirements Make sure your PC system meets ALL of the following minimum hardware and software requirements: Hardware:  IBM PC/AT or compatible  Pentium 66Mhz or faster  2Mbytes available hard disk space or more  2x CD-ROM drive or better  32Mbyte available system memory or more Software: Your Operating System must be one of the following:  Microsoft Windows 95 – Win 95A, Win 95B  Microsoft Windows 98 – Win 98, Win 98A  Microsoft Windows Millennium Edition – Win ME  Microsoft Windows NT 4.0 with Servic…

Text truncated - open the document above for the full version.

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

ΦΧΧ Ι∆. : Ο7ΥΡΕΧΣΠΕΕ∆−8000Π Φιλε Νο. : Ε00∆Ρ−053 ONETECH Testing & Evaluation Lab . ΦΧΧ Ι∆. : Ο7ΥΡΕΧΣΠΕΕ∆−8000Π Φιλε Νο. : Ε00∆Ρ−053 ONETECH Testing & Evaluation Lab .

FCC ID. : O7URECSPEED-8000P File No. : E00DR-053 ONETECH Testing & Evaluation Lab . IDENTIFICATION LABEL: PROPOSED FCC ID LABEL The label included following statement will be attached on the rear side of product. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. Made in Korea FCC ID : O7URECSPEED-8000P ΦΧΧ Ι∆ ΑΡΕΑ

ΦΧΧ Ι∆. : Ο7ΥΡΕΧΣΠΕΕ∆−8000Π Φιλε Νο. : Ε00∆Ρ−053 ONETECH Testing & Evaluation Lab . ΦΧΧ Ι∆. : Ο7ΥΡΕΧΣΠΕΕ∆−8000Π Φιλε Νο. : Ε00∆Ρ−053 ONETECH Testing & Evaluation Lab .

Page 1 of 13 FCCID.:O7URECSPEED-8000P File No.: Error! Unknown docume nt prope rty name . This report shall not be reproduced except in full without our written approval.FCC-004 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon- Gu, Seongnam- C ity, K yunggi- Do, 462-121, Korea (TEL: 82- 31-746-8500 FAX: 82-31-746-8700 ) EM C Te s ting De pt : 426-1 Daessangryung- Ri, C howol- Myun, K wangju- K un, K yunggi- Do 464-860 Korea. (TEL: 82- 31-765-8289 FAX: 82-31-766-2904) ONETECH Testing & Evaluation Lab . ELECTROMAGNETIC EMISSION COMPLIANCE REPORT Test report file number : E00DR-053 Applicant : RECSOL I&C CO., LTD. Addre ss: Fl. 5th, Yeo-Sam B/D 648-23, Yeoksam-Dong, Kangnam-Gu, Seoul, 135-080, Korea Manufacture r : RECSOL I&C CO., LTD. Addre ss: Fl. 5th, Yeo-Sam B/D 648-23, Yeoksam-Dong, Kangnam-Gu, Seoul, 135-080, Korea Type of Equipme nt : ADSL MODEM CARD FCC ID: O7URECSPEED-8000P Model / Type No. : RECSPEED-8000P Se rial numbe r: N/ A Total page of Report: 13 pages (including this page) Date of Incoming: November 13, 2000 Date of issuing : December 29, 2000 SUMMARY The equipment complies with the regulation; FCC CFR47 PART 15 SUBPART B SECTION 15.101. This test report contains only the result of a single test of the sample supplied for the examination. It is not a general valid assessment of the features of the respective products of the mass-production. Prepared by: Approved by: Y. K. Nam / Asst. Chief EngineerS. S. Hong / Managing Director EMC Dept.EMC Dept. ONETECH Corp.ONETECH Corp. Page 2 of 13 FCCID.:O7URECSPEED-8000P File No.: Error! Unknown docume nt prope rty name . This report shall not be reproduced except in full without our written approval.FCC-004 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon- Gu, Seongnam- C ity, K yunggi- Do, 462-121, Korea (TEL: 82- 31-746-8500 FAX: 82-31-746-8700 ) EM C Te s ting De pt : 426-1 Daessangryung- Ri, C howol- Myun, K wangju- K un, K yunggi- Do 464-860 Korea. (TEL: 82- 31-765-8289 FAX: 82-31-766-2904) ONETECH Testing & Evaluation Lab . CONTENTS Page 1. VERIFICATION OF COMPLIANCE...............................................................................................................................3 2. GENERAL INFORMATION ............................................................................................................................................. 4 2.1 P RODUCT D ESCRIPTIO N .................................................................................................................................................... 4 2.2 R ELATED S UBMITTAL ( S ) / G RANT ( S ) ................................................................................................................................ 4 2.3 T EST S YSTEM D ETAILS ..................................................................................................................................................... 5 2.4 T EST M ETHODOLOGY ....................................................................................................................................................... 5 2.5 T EST F ACILITY ................................................................................................................................................................. 5 3. SYSTEM TEST CONFIGURATION................................................................................................................................. 6 3.1 J USTIFICATIO N ................................................................................................................................................................. 6 3.2 EUT EXERCISE S OFTWARE ............................................................................................................................................... 6 3.3 C ABLE D ESCRIPTIO N ........................................................................................................................................................ 6 3.4 N OISE S UPPRESSION P ARTS ON C ABLE ............................................................................................................................. 7 3.5 E QUIPMENT M ODIFICATIONS ........................................................................................................................................... 7 3.6 C ONFIGURATION OF T EST S YSTEM ................................................................................................................................... 7 4. PRELIMINARY TEST........................................................................................................................................................ 8 4.1 AC P O WER LIN E C ONDUCTED E MISSION T EST ................................................................................................................. 8 4.2 R ADIATED E MISSION T EST ............................................................................................................................................... 8 5. FINAL RESULT OF MEASURMENT .............................................................................................................................. 9 5.1 C ONDUCTED E MISSION T EST ............................................................................................................................................ 9 5.2 R ADIATED E MISSION T EST ............................................................................................................................................. 11 6. FIELD STRENGTH CALCULATION............................................................................................................................ 13 7. LIST OF TEST EQUIPMENT ......................................................................................................................................... 14 Page 3 of 13 FCCID.:O7URECSPEED-8000P File No.: Error! Unknown docume nt prope rty name . This report shall not be reproduced except in …
