O8LDSP24VALUESound Card

About this manual: The product described in this manual has been developed and produced by Hoontech Co., Ltd. SoundTrack Audio DSP24 Value is a trademark of Hoontech Co., Ltd. SoundTrack Audio DSP24 Value Bracket is a trademark of Hoontech Co., Ltd. Microsoft, Windows, Windows 95, Windows 98 and Windows NT are registered trademarks or trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of their respective holders. Dezember 2000 It is the policy of Hoontech to improve products as new technology, newer components, improved software and drivers become available. Hoontech, therefore reserves the right to change specifications without prior notice. A/S Center Hoontech Co., Ltd. 4th Flr., Minkyung Bldg., #332 Songne-1Dong, Sosa-Ku, Bucheon City, Kyungki-Do, Korea Tel.: +82-32-611-1994 Fax: +82-32-612-0079 Internet: http://www.hoontech.com Copyright 1998, 1999, 2000 Hoontech Co., Ltd. This documentation was created by Hoontech Co., Ltd. (Korea) and RIDI multimedia (Germany). Note: To avoid damage of your speakers, always turn down the volume or turn off the power of your amplifier connected to the SoundTrack Audio DSP24 Value when you are rebooting or shutting down your PC. - 2 - Contents I. Introduction............................................................ 3 II. Specifications ........................................................ 5 III. In- and output connectors .................................... 6 SoundTrack Audio DSP24 Value PCI-card 6 SoundTrack Audio DSP24 Value Bracket 7 IV. Block diagram........................................................ 8 V. Hardware installation ............................................ 9 VI. Driver and software installation ......................... 10 Driver installation 10 Software installation 13 VII. Mixer controls ...................................................... 17 Internal Mixer 17 Output Mixer 20 VIII. Hardware settings ............................................... 23 IX. Usage with software applications...................... 25 Available in- and output devices 25 Setting up Emagic Logic SoundTrack24 26 Setting up Steinberg Cubase VST/24 3.72 27 Setting up Emagic Logic Audio Platinum 4.5 29 Setting up Cakewalk 9.x 31 Setting up Nemesys GigaSampler 1.6 32. - 3 – FCC NOTICE FCC NOTICEFCC NOTICE FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC FULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. - Consult the dealer of an experienced radio/TV technician for help. NOTE : The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. I. Introduction Congratulations on your purchase of the SoundTrack Audio DSP24 Value. The Audio DSP24 Value is a PCI digital soundcard for high quality recording applications. You should have received the following with your Audio DSP24 Value: Hoontech SoundTrack Audio DSP24 Value PCI soundcard 4pin-3pin cable for analog CD-ROM audio connection Sound Track Audio DSP24 Value Bracket (optional) MIDI in/out cable (optional) 10 pin flat for Value Bracket (optional) 2pin cable for CD-ROM digital output (optional) driver and installation CD this manual - 4 - Superb multi-track quality: The Audio DSP24 Value supports up to 24-bit resolution and 96kHz sample rates for two in- and output channels. Optionally, you can connect the DSP24 Value Bracket to supply optical and coaxial S/PDIF and MIDI in/out connectors. In addition, all internal signal paths are processed at 36-bit resolution ensuring the highest amount of headroom and fidelity. Intuitive Software Interface: The Audio DSP24 Value comes with a selection of software interfaces. The Output Mixer software Iis used to route the output signals. Also it displays level meters for in- and output monitoring of all signals. The Internal Mixer allows to control the function for Windows multimedia system sounds. It controls the levels of the CD and Wave signals. The output signal of Internal Mixer is always played through the Line Output on the card. This makes it possible to use the card as an ordinary standard soundcard. - 5 - II. Specifications PCI 2.1 compliant interface 2 inputs and 2outputs channels (RCA connectors) supported sample rates in kHz: 22.05, 32, 44.1, 48, 88.2, and 96 24-bit converter rsolution Internal CD in, Aux In, and Line Out via AC-97 Codec (Internal Mixer) Optical and coaxial S/PDIF standards (optional) MPU-401 compatible MIDI interface (optional) Drivers for Windows 95/98/ME, NT4 and Windows 2000 available. - 6 - III. In- and output connectors SoundTrack Audio DSP24 Value PCI-card 1. Analog Input 1 (RCA) 2. Analog Input 2 (RCA) 3. Analog Output 1 (RCA) 4. Analog Output 2 (RCA) 5. Line Ou…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫ ∫∫∫∫∫∫∫∫ ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID : O8LDSP24VALUE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE Internal Photographs of EUT

SK TECH CO., LTD. Page 1 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE Certificate of Compliance Test Report No.: SKTOS-01026 NVLAP CODE : 200220-0 Applicant: HOONTECH CO., LTD Applicant Address: 4 th Flr., Minkyung Bldg., #332, Songnae-Dong, Sosa-Gu, Buchon-City, Kyungki-Do, Korea Product: SOUND CARD FCC ID: O8LDSP24VALUE Model No.: DSP24VALUE Receipt No.: SKE20010221-128 Date of receipt: Feb. 21, 2001 Date of Issue: Mar. 05, 2001 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 1992 Rule Parts: FCC part 15 Subpart B Equipment Class : Class B Digital Device Peripheral Test Result: The above mentioned product has been tested and passed. Prepared by:Y.H. Kang Tested by:K.T.Lee/Engineer Approved by: J.Y.Hyun /Lab.Manager Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ ☞☞ ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE 》》 》》》》 》》 Contents 《《 《《《《 《《 Contents 2 List of Tables 2 List of Figures 2 List of Photographs 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Data 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical characteristics 5 3.2 Submitted documents 5 4. Measurement conditions 6 4.1 Modes of operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 7 4.5 Uncertainty 7 5. Emission Test 8 5.1 Conducted Emissions 8 5.2 Radiated Emissions 12 》 》》 》List of Tables Table 1 List of test and measurement equipment 4 Table 2 Test Data, Conducted Emissions 11 Table 3 Test Data, Radiated Emissions 13 》 》》 》List of Figures Figure 1 Spectral Diagram, LINE-PE 9 Figure 2 Spectral Diagram, Neutral-PE 10 SK TECH CO., LTD. Page 3 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK Tech Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ANSI C63.4/1992 for measurement of radio interference. SK TECH CO., LTD. Page 4 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment z Conducted Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESHS 10 862970/019 04.2001 LISN KNW-407 M63284 07.2001 LISN ESH2-Z5 862060/029 06.2001 Conducted Cable N/A N/A 07.2001 z Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESVS 10 825120/013 04.2001 Spectrum Analyzer R3361A 11730187 07.2001 Amplifier 8447F 3113A05153 05.2001 Log Periodic Antenna UHALP9107 91071238 04.2001 Biconical Antenna BBA9106 N/A 04.2001 Open Site Cable N/A N/A 07.2001 Antenna Mast 5907 N/A N/A Antenna & Turntable controller 5906 91X519 N/A Amp & Receiver connection cable N/A N/A 07.2001 Amp & Spectrum connection cable N/A N/A 07.2001 50Ω Switcher MP59B M93083 07.2001 2.3 Test Date Date of Application : Feb. 21, 2001 Date of Test : Feb . 23, 2001~ Mar. 02, 2001 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE 3. Description of the tested samples The EUT is Sound Card. 3.1 Rating and Physical Characteristics •PCI 2.1 Interface with busmastering board and rack-mountable boxes for external use •24-bit resolution audio format support •Sampling rates up to 96KHz •10 input and 10 output-channels in total •Up to 10CH 96KHz 24-bit Digital or Analog Ins. •Up to 10CH 96KHz 24-bit Digital or Analog Outs •20 channel mixer with 36 bit internal resolution •Up to 4 Audio DSP24 MK II •Simultaneous recording and playback of 16 channels up to 24-bit/96KHz •2 channels digital in/out (Optical, Coaxial. AES/EBU I/O using the digital I/O board and CE digital In) •Additional analog monitor out 16-bit / 48KHz •Sampling Rates : 33KHz, 44.1KHz, 48KHz, 88.2KHz, 96KHz •Converter Resolution : 16-bit, 20-bit, 24-bit Output •Output DATA : 24-bit •MPU-401 compatible MIDI interface up to 32CH (optional) •Windows TM 95/98. Windows TM NT4 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE 4. Measurement Conditions Testing Input Voltage : AC 120V, 60Hz 4.1 Modes of Operation The EUT was in the following operation mode during all testing; A Music file is continuously played and checked it.. 4.2 List of Peripherals Description Manufacturer Model Name Serial No. FCC ID Monitor Samsung SyncMaster750P PG17HS9U/ADC Doc PC H.P Brio BA 600/650 SG03603357 Doc Printer H.P 2225C 3245S12493 DSI6XU2225 Keyboard I-GANG IGK-2000i 100060126134 HQKBITS9001 Mouse 1 Logitech M-S48 LZA91457567 DZL211153 Mouse 2 Logitech M-BE55 LZE02551778 Doc Joystick Logitech J-ZA10 LZS01651409 Doc Speaker CAMAC CMK660 N/A Doc Mic N/A N/A N/A N/A INNO dispenser Biopia BD-2000 N/A Doc SK TECH CO., LTD. Page 7 of 13 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE 4.3 Type of Used Cables Description Length Type of shield Manufa…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE Test set up photos Photograph 1: Setup for Conducted Emissions SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-01026 FCC ID : O8LDSP24VALUE Photograph 2: Setup for Radiated Emissions
