1 Freedom Expression Slim Quick Start Guide Table of Contents Page Keyboard Hardware 2-3 Connecting the keyboard to an Apple iOS Device 4-6 General Troubleshooting and FAQ 7 2 Your Freedom Expression Slim Keyboard Before we proceed with installing the keyboard on your Apple iOS device, let’s take a brief look at the hardware. 1) Power Switch: Switches the keyboard on and off. 2) Micro USB Charging Port: The Freedom Expression Slim is powered by an internal rechargeable battery. This will give the average person around 100 hours of use before it needs to be recharged. The keyboard will automatically go into power saving mode (switch itself off) if it is left turned on for 15 minutes without any input. To take the keyboard out of power saving mode, simply switch the keyboard off and then switch it back on again. To recharge the Freedom Expression Slim: Use either the Micro USB cable supplied or a standard Micro USB charger (such as a mobile phone charger). While charging the power warning light will show up as solid red. Once fully charged the power warning light will switch off. Charging can take between 3-4 hours to fully recharge from flat. 3) Pairing Button/Indicator Lights (Blue): Used for putting keyboard in pairing button. 3.1) Bluetooth Indicator Light (Blue): Flashes rapidly when in pairing/waiting to connect mode (once per second). Flashes slowly when connected (once every 8 seconds). 3.2) Power Warning Light (Red): Flashes when batteries need to be replaced. 4). Show/Hide Virtual Keyboard. 5) “Menu” Key. 3 5 Shortcut Keys 1. Screen Lock – Locks your iOS device’s screen 2. Search – Opens the “Search Bar” 3. Screen Brightness – Decreases the Screen brightness 4. Screen Brightness – Increases the Screen brightness 5. Cut – Cuts the selected text 6. Copy – Copies the selected text to the clipboard 7. Paste – Pastes text from the clipboard. 8. Undo – Undo the last action 9. Skip Back –Skip back to previous media track 10. Play/Pause – Play or Pause current media track 11. Skip Forward – Skip forward to next media track 12. Mute 13. Decrease Volume 14. Increase Volume 15. Apple “Home Key” 1 2 3 4 4 Connecting the keyboard to an Apple iOS Device Pairing the Keyboard 1) Turn the keyboard on and press pairing button, which is situated on the top right hand corner of the keyboard, for 5 seconds. 2) On your Apple iOS Device, go to “Settings". Then from the settings screen select “General”. 3) Now under the “General” settings select “Bluetooth”. Once your device finds the keyboard select “Freedom Expression Slim” from the list. 5 4) Your device will now give you a 4 digit passkey. Enter this key onto the Freedom Expression Slim and press enter to complete the pairing (also on the Freedom Expression Slim). 5) Now go back to the “Settings” page and select “Keyboard”. 6 6) Select “International Keyboards”. Now select “QWERTY” and “US International – PC”. Optional: You can also add additional keyboard layouts for other language inputs. Select the “International Keyboards” button again and then select the “Add New Keyboard” option. 7) Now your Freedom Expression Slim will be connected. From this point forward you just need to switch the keyboard on and off when you need it. It will automatically reconnect when switched on. 7 General Trouble shooting and FAQ. Q) My device is not seeing the keyboard when I’m trying to pair it. A) Please ensure the keyboard is turned on and that you have held down the pairing button for at least 5 seconds. Also make sure that the Bluetooth LED on the keyboard is flashing. If the LED is not flashing check the keyboard has sufficient battery life. Q) Some of the keys are not matching what is showing on screen. A) The Freedom Expression Slim is based on the US International keyboard layout. Some devices will require you to change your input layout settings to US International. Q) The keyboard drops connection or I get key repeats A) This can happen if either the battery power on the keyboard is low or if there is another Bluetooth device connected at the same time, which is taking a priority connection. Make sure that the Freedom Expression Slim is the first Bluetooth device and is charged sufficiently. For technical support on this product please visit: http://freedom.helpserve.com For the latest announcements and updates for this product please visit: www.freedominput.com 8 FCC STATEMENT Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to omply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without RF striction. FCC Radiat…

Text truncated - open the document above for the full version.

June 30, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: OD8DOK-K7132B To Whom It May Concern: This letter is to ascertain that Freedom Input UK Limited （Product：Expression Slim Model name: DOK-K7132B, DOK-K7157B, DOK-K7158B, DOK-K7159B, DOK-K7160B, DOK-K7161B, DOK-K7162B, DOK-K7163B） has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title: Paul Bowles / Technical Manager Contact information / address: 65 Salisbury Road, Dover, CT161EY, United Kingdom

June 30, 2012 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ Freedom Input UK Limited ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: Expression Slim Model name: DOK-K7132B, DOK-K7157B, DOK-K7158B, DOK-K7159B, DOK-K7160B, DOK-K7161B, DOK-K7162B, DOK-K7163B We affirm that between SIEMIC and _ Freedom Input UK Limited __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Paul Bowles / Technical Manager Contact information / address: 65 Salisbury Road, Dover, CT161EY, United Kingdom

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 June 30, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: OD8DOK-K7132B We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Paul Bowles / Technical Manager Contact information / address: 65 Salisbury Road, Dover, CT161EY, United Kingdom

FCC Certification label Sample FCC ID: OD8DOK-K7132B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired o peration.

FCC Certification label location Sample Label location

Antenna

FCC ID : OD8DOK-K7132B Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Maximum measured transmitter power frequency (MHz) 60/f SAR Limitation (mw) 2402 2480 2402 25.0 Maximum measured transmitter power Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 0.60 0 0.60 Remark: The best case gain of the antenna is 0dBi. 0dBi logarithmic terms convert to numeric result is nearly 1 According to the formula. calculate the EIRP test result: EIRP= P x G = 0.60mW x 1.= 0.60mW Threshold at which no SAR required is 25.0mw. Maximum Tx power is 0.60mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

Page 1 of 82 FCC ID: OD8DOK-K7132B ACCURATE TECHNOLOGY CO. LTD Report No.: ATE20121387 APPLICATION CERTIFICATION On Behalf of Freedom Input UK Limited Expression Slim Model No.: DOK-K7132B, DOK-K7157B, DOK-K7158B, DOK-K7159B, DOK-K7160B, DOK-K7161B, DOK-K7162B, DOK-K7163B FCC ID: OD8DOK-K7132B Prepared for : Freedom Input UK Limited Address : 65 Salisbury Road, Dover, CT161EY, United Kingdom Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20121387 Date of Test : June 23-July 13, 2012 Date of Report : July 14, 2012 Page 2 of 82 FCC ID: OD8DOK-K7132B ACCURATE TECHNOLOGY CO. LTD Report No.: ATE20121387 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT)....................................................................................................................5 1.2. Special Accessory and Auxiliary Equipment ...........................................................................................5 1.3. Description of Test Facility ......................................................................................................................6 1.4. Measurement Uncertainty.........................................................................................................................6 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 7 3. OPERATION OF EUT DURING TESTING ................................................................................. 8 3.1. Operating Mode ........................................................................................................................................8 3.2. Configuration and peripherals ..................................................................................................................8 4. TEST PROCEDURES AND RESULTS ......................................................................................... 9 5. 20DB BANDWIDTH TEST............................................................................................................10 5.1. Block Diagram of Test Setup..................................................................................................................10 5.2. The Requirement For Section 15.247(a)(1) ............................................................................................10 5.3. EUT Configuration on Measurement .....................................................................................................10 5.4. Operating Condition of EUT ..................................................................................................................10 5.5. Test Procedure ........................................................................................................................................11 5.6. Test Result ..............................................................................................................................................11 6. CARRIER FREQUENCY SEPARATION TEST........................................................................ 15 6.1. Block Diagram of Test Setup..................................................................................................................15 6.2. The Requirement For Section 15.247(a)(1) ............................................................................................15 6.3. EUT Configuration on Measurement .....................................................................................................15 6.4. Operating Condition of EUT ..................................................................................................................15 6.5. Test Procedure ........................................................................................................................................16 6.6. Test Result ..............................................................................................................................................16 7. NUMBER OF HOPPING FREQUENCY TEST ......................................................................... 20 7.1. Block Diagram of Test Setup..................................................................................................................20 7.2. The Requirement For Section 15.247(a)(1)(iii) ......................................................................................20 7.3. EUT Configuration on Measurement .....................................................................................................20 7.4. Operating Condition of EUT ..................................................................................................................20 7.5. Test Procedure ........................................................................................................................................21 7.6. Test Result ..............................................................................................................................................21 8. DWELL TIME TEST ..................................................................................................................... 25 8.1. Block Diagram of Test Setup..................................................................................................................25 8.2. The Requirement For Section 15.247(a)(1)(iii) ......................................................................................25 8.3. EUT Configuration on Measurement .....................................................................................................25 8.4. Operating Condition of EUT ..............................................................................................…
