OG7CR16Portable Bluetooth Speaker

FCC Information The device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The distance between user and products should be no less than 20cm

IXT SYSTEMS INTERNATIONAL LTD. 24A, Lan Se Hai Yun Ju, 1st Street, Shi Xia North, Fu Tian District, Shenzhen China. DATE :2014-6-18 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong (Name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with IXT SYSTEMS INTERNATIONAL LTD. and 24A, Lan Se Hai Yun Ju, 1st Street, Shi Xia North, Fu Tian District, Shenzhen China. (Applicant name and address). Dated this / Day of 06/18/2014 / Agency agreement expiration date: 06/18/2015 By: Jorlen Huang Signature Printed Title: Manager On behalf of : IXT SYSTEMS INTERNATIONAL LTD. Telephone: (86) 755-82020030

IXT SYSTEMS INTERNATIONAL LTD. 24A, Lan Se Hai Yun Ju, 1st Street, Shi Xia North, Fu Tian District, Shenzhen China. DATE 2014-6-18 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: OG7CR16 Product Name: Portable Bluetooth Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this / Day of 06/18/2014 / By: Jorlen Huang Signature Printed Title: Manager On behalf of : IXT SYSTEMS INTERNATIONAL LTD. Telephone: (86) 755-82020030

CR16 Rating Label Size : W 34 x H 27.5mm Color : Black background with white text Date : 17-6-2014 OG7CR16

Label location

FCC ID: OG7R16 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is r ounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30gt where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---0.2m So pt = (EXd) 2 /30 x gt Field strength = 96.45 dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1 So pt={ [10 (96.45/20) /10 6 x 3] 2 /30x1 }x1000 mW = 1.325mW So (1.325 mW /5mm)x √2.402 = 0.411<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE14050086701 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: IXT SYSTEMS INTERNATIONAL LTD. Address of Applicant: 24A, Lan Se Hai Yun Ju, 1st Street, Shi Xia North, Fu Tian District, Shenzhen China Equipment Under Test (EUT) Product Name: Portable Bluetooth Speaker Model No.: CR16 FCC ID: OG7R16 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2013 Date of sample receipt: May 29, 2014 Date of Test: May 29-June 17, 2014 Date of report issued: June 17, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. OG7CR16 Report No.: GTSE14050086701 Global United Technology Services Co., Ltd. Project No.: GTSE140500867RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 31 2 Version Version No. Date Description 00 June 17, 2014 Original Prepared By: Date: June 17, 2014 Project Engineer Check By: Date: June 17, 2014 Reviewer Report No.: GTSE14050086701 Global United Technology Services Co., Ltd. Project No.: GTSE140500867RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 31 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3CONTENTS .............................................................................................................................................. 3 4TEST SUMMARY ..................................................................................................................................... 4 5GENERAL INFORMATION ...................................................................................................................... 5 5.1CLIENT INFORMATION ......................................................................................................................... 5 5.2GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3TEST MODE ........................................................................................................................................ 7 5.4DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.5TEST FACILITY .................................................................................................................................... 7 5.6TEST LOCATION ................................................................................................................................. 7 5.7OTHER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 7 6TEST INSTRUMENTS LIST ..................................................................................................................... 8 7TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1ANTENNA REQUIREMENT: .................................................................................................................... 9 7.2CONDUCTED EMISSIONS ................................................................................................................... 10 7.3RADIATED EMISSION METHOD ........................................................................................................... 13 7.3.1Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2Spurious emissions .................................................................................................................... 16 7.3.3Bandedge emissions.................................................................................................................. 20 7.420DB OCCUPY BANDWIDTH .............................................................................................................. 21 8TEST SETUP PHOTO ............................................................................................................................ 23 9EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 25 Report No.: GTSE14050086701 Global United Technology Services Co., Ltd. Project…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
