FCC CERTIFICATION REPORT ELECTROMAGNETIC INTERFERENCE TEST RESULTS For CFR 47 Part 15B Intentional Radiators FOR CONTER MFR. AND SUPPLY/USA 4200 W. 83rd St., Suite 203 Shawnee Mission, KS 66208 Phone: (913) 649-3589 Edmund Chow, President MODEL: WAVE 2000 FCC ID: OG8 PROFMWAVE Test Date:March 2, 1999 Certification Date: March 2, 1999 Certifying Engineer: ________________________ Scot D. Rogers ROGERS LABS, INC. 4405 West 259th Terrace Louisburg, KS 66053 Phone: (913) 837-3214 FAX: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. CONTER MFR.& SUPPLY/USA 4405 W. 259th Terrace MODEL:Wave 2000 Louisburg, KS 66053 Test #: 990302 FCCID#: Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c Page 2 of 29 CERT.\CONTERPROFM.doc 7/2/01 TABLE OF CONTENTS APPLICABLE STANDARDS & TEST PROCEDURES3 2.1033(B) APPLICATION FOR CERTIFICATION4 EQUIPMENT TESTED4 EQUIPMENT FUNCTION AND TESTING PROCEDURES5 EQUIPMENT AND CABLE CONFIGURATIONS5 Conducted Emission Test Procedure:5 Radiated Emission Test Procedure:5 LIST OF TEST EQUIPMENT6 UNITS OF MEASUREMENTS7 TEST SITE LOCATIONS7 SUBPART C - INTENTIONAL RADIATORS7 15.203 ANTENNA REQUIREMENTS:8 RESTRICTED BANDS OF OPERATION PER 15.205:8 Data 15.205:8 15.207 CONDUCTED LIMITS9 Conducted EMI:9 Data 15.207:10 Summary of results for Conducted Emissions:10 15.209 RADIATED EMISSIONS LIMITS; GENERAL REQUIREMENTS10 Radiated EMI:10 Data 15.209:12 Summary of Results for Radiated Emissions:12 15.239 OPERATION IN THE BAND 88-108 MHZ12 Data 15.239:14 SUMMARY OF RESULTS17 Radiated Emissions:17 Statement of Modifications:17 APPENDIX18 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. CONTER MFR.& SUPPLY/USA 4405 W. 259th Terrace MODEL:Wave 2000 Louisburg, KS 66053 Test #: 990302 FCCID#: Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c Page 3 of 29 CERT.\CONTERPROFM.doc 7/2/01 FORWARD: The following is submitted for consideration in obtaining a Grant of Certification for low power intentional radiators. Name of Applicant: CONTER MFR. AND SUPPLY/USA 4200 W. 83rd St., Suite 203 Shawnee Mission, KS 66208 Model: WAVE 2000 FCC I.D.: OG8 PROFMWAVE Frequency Range: 88.1-107.9 MHz Operating Power: 250μV/m @ 3 Meters Applicable Standards & Test Procedures a) In accordance with Part 1, Subpart G, Paragraphs 1.1103; Part 2, Subpart J, Paragraphs 2.907, 2.925, 2.926, 2.1031 through 2.1043; and Part 15, Subpart B, Paragraphs 15.19(A)(3), 15.21, 15.31, 15.33, 15.35, 15.201 (B), 15.203, 15.204(C), 15.205, 15.207(A), 15.209(A), and 15.239 of the Code of Federal Regulations, dated October 1, 1997 and FCC 98-58. The transition provisions in Paragraph 15.37 are not being requested. b) Test procedures used are the established Methods of Measurement of Radio-Noise Emissions as described in the ANSI 63.4-1992 Document. NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. CONTER MFR.& SUPPLY/USA 4405 W. 259th Terrace MODEL:Wave 2000 Louisburg, KS 66053 Test #: 990302 FCCID#: Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c Page 4 of 29 CERT.\CONTERPROFM.doc 7/2/01 2.1033(b) Application for Certification (1) Manufacturer: CONTER MFG. & SUPPLY/USA 4200 W. 83 RD Street, Suite 203 Shawnee Mission, KS 66208 (2) Identification: Model: WAVE 2000 FCC I.D.: OG8 PROFMWAVE (3) Instruction Book: Draft Instruction Manual attached. (4) Description of Circuit Functions: Device Operation: The VTX434LPC is a low power FM transmitter. Antenna and Ground plane: (5) Block Diagram with Frequencies: (6) Report of Measurements: Follows in this Report. (7) Photos: Construction, Component Placement, etc.: Refer to Appendix. (8) No Peripheral Equipment Was Necessary. (9) Transition Provisions of 15.37 are not being requested. (10) Direct Sequence Spread Spectrum: Not Applicable. (11) Not Applicable. The EUT is not a Scanning Receiver. Equipment Tested EUT FCC I.D.# WAVE 2000 OG8 PROFMWAVE NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. CONTER MFR.& SUPPLY/USA 4405 W. 259th Terrace MODEL:Wave 2000 Louisburg, KS 66053 Test #: 990302 FCCID#: Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c Page 5 of 29 CERT.\CONTERPROFM.doc 7/2/01 Equipment Function and Testing Procedures The EUT is a multi-channel transmitter operating in the FM radio band. The units allow a message, recorded or live, to be broadcast to a FM receiver in close proximity. The unit is targeted to broadcast into a parking lot local information or business announcement. Other applications are possible. The design of the system allows for the use of FM channels not currently in use in the target area. Equipment and Cable Configurations Conducted Emission Test Procedure: The test setup, including the EUT, was arranged in a typical equipment configuration and placed ona1x1.5-meter wooden bench, 0.8 meters high located in a screen room. The power lines of the system were isolated from the power source using a standard LISN with a 50 μHy choke. EMI was coupled to the spectrum analyzer through a 0.1 μF capacitor internal to the LISN. The LISN was positioned on the floor beneath the wooden bench supporting the EUT. The power lines and cables were draped over the back edge of the table. Radiated Emission Test Procedure: The EUT was placed on a rotatable 1 x 1.5-meter wooden platform 0.8 meters above the ground plane at a distance of 3 meters from the FSM antenna. EMI energy was maximized by equipment NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. CONTER MFR.& SUPPLY/USA 4405 W. 259th Terrace MODEL:Wave 2000 Louisburg, KS 66053 Test #: 990302 FCCID#: Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c Page 6 of 29 CERT.\CONTERPROFM.doc 7/2/01 placement, raising and lowering the FSM antenna, changing the antenna polarizat…
