OH8-SS200RSolar Environmental Measurement

Read these operating instructions before using this instrument. This equipment should only be used by suitably trained personnel. The Solar Survey is intended for use in a dry environment only. Check the Solar Survey PV100 and all associated cables and leads before operating the equipment. Do not use if there are signs of damage. Only use the connecting leads & temperature probes supplied with the Solar Survey. Use 2x 1.5V AA Cells - these may be Alkaline or rechargeable NiCd or NiMH. FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications to the Solar Survey 200R not expressly approved by Seaward could void your authority to operate it. 396A558 rev C June 2012 SOLAR SURVEY200 HOLD S E A W A R D ON/OFF OK LOG 823 W m 2 43 272 + Overview Multi-mode LCD Function Keys Meter always powers up in ANGLE Mode 'HOLD' Indicator PV Sensor Press to turn power on/off ON/OFF Power will turn off automatically if no key is pressed for 120s Probe Socket Temperature USB Socket Link Socket to Other Solar Products 2 x AA, 1.5V Alkaline Cells Battery Holder on Back of Case Press 'HOLD' to freeze values on display Press again to un-freeze display Optical Sighting Marks (Survey 200 only) (Survey 200 only) SOLAR SURVEY200 HOLD S E A W A R D ON/OFF OK LOG 823 W m 2 43 272 + Irradiance with Compass and Tilt Measurement Tilt Angle Press to select Compass/Tilt Mode User Tilt Zero Calibration Press >5s - display will flash 'Z' Place meter on a flat surface Press to store '+ SET' value Turn meter through 180 Press to store '- SET' value Meter will display 'Z' to show user zero is enabled To clear this, press for >5s - 'Z' will clear Place meter against surface to be measured or use optical Magnetic Bearing Point meter in direction required Compass Keep meter away from metallic Keep the meter horizontal - tilting more than +/-20 objects - these can influence reading will blank the bearing display (- - -) sights to align with roof slope SOLAR SURVEY200 HOLD S E A W A R D ON/OFF OK LOG 823 W m 2 36 27 C C + TPV + TA Irradiance and Temperature Measurement Panel Temperature Ambient Temperature Pressto select Temperature Mode Panel SensorAmbient Sensor Irradiance To Change Display Units Press >5s Use to select temperature or irradiance units (flashing) Press OK to save 22 Use or to toggle units ( C or F), (W/m or BTU/hr/ft ) SOLAR SURVEY200 HOLD S E A W A R D ON/OFF OK LOG 14:28 24/10 2011 Time & Date (Survey 200 only) Year Press to select Time/Date Mode Date (dd/mm) 24 Hour Clock (hh:mm) To set Time & Date Press>5s - display will flash hours value Useto select date/time fields (flashing) Useto increase/decrease value& Press OK to save Log 500 4500 Datalogging (Survey 200 only) Start Data Logging Press LOG, then OK to confirm RUN Meter will enter SLEEP mode between Press HOLD >5s to display Log Status measurements to conserve battery power Stop Data Logging Press any key to display Log Status Press LOG, then OK to confirm STOP Check Logging Progress Press any key to display Log Status Display automatically blanks after a few seconds Log Setup Use & to increase/decrease value Press HOLD >5s to display Log Status Press HOLD >5s to display Log Interval in minutes Use & to select STOP (when memory full) or, Press to display Data Store Mode Use & to select YES or NO Press to display Delete option Press OK at any time to save & exit Log Setup Log 3.1 30' V Battery Voltage Log Interval Memory Used Memory Left Alternating Log Status Display ROLL for data to overwrite memory from start

6304 Benjamin Rd  Suite 506  Tampa FL 33634 Phone: (813) 886-2775  Fax: (813) 886-2754  www.seaward-groupusa.com Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date 23 July 2012 SUBJECT: FCC Application for OH8-SS200R To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, Frank Belluccia – Sales Manager

Test Report Number 12F190B FCC ID:OH8-SS200R Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 1 of 12 Testing Certification # 1367-01 TEST REPORT Laboratory IDSubmitter ID PRODUCT SAFETY ENGINEERING, INC.Seaward Group USA 12955 Bellamy Brothers Boulevard6304 Benjamin Road Dade City, Florida 33525 USASuite 506 PH (352) 588-2209 FX (352) 588-2544Tampa, FL 33634 Report Issue Date: 07/13/2012 Test Report Number: 12F190B Sample S/N: A2-915 Model Designation: SS200R Sample Receipt Date: 06/01/2012 Product Description: Solar Environmental Measurement Sample Test Date: see data sheets Description of non-standard test method or test practice: None Estimated Measurement Uncertainty: Not Applicable Special limitations of use: None Traceability: reference standards of measurement have been calibrated by a competent body using standards traceable to the NIST. According to testing performed at Product Safety Engineering, Inc., the above-mentioned unit is in compliance with the electromagnetic compatibility requirements defined in regulations indicated on page (3) of the test report. The test results contained herein relate only to the model(s) identified above. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Project Engineer, I hereby declare that the equipment tested as specified above conforms to the requirements indicated on page (3) of the test report. Signature Name David Foerstner Title Test Engineer Date 07/13/2012 Reviewed by: Approved Signatory 07/13/2012 This report may only be reproduced in full without written permission from Product Safety Engineering, Inc. Test Report Number 12F190B FCC ID:OH8-SS200R Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 2 of 12 D I R E C T O R Y - EMISSIONS Page(s) A)Documentation Test report1 - 10 Directory2 Test Regulations3 General Remarks10 Test-setups (Photos)11 - 12 B)Test data Conducted emissions150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Conducted Emissions - Telecom port150 kHz - 30 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 Antenna Terminal30 MHz - 1000 MHz7,9 C)Appendix A Test Equipment Calibration Information Test Data Sheets A2 A3 - A5 D)Appendix B System Under Test DescriptionB2 - B2 E) Appendix C Measurement Protocol C1 - C2 Test Report Number 12F190B FCC ID:OH8-SS200R Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 3 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: 9 - EN 61000-6-3:2001 9 - EN 61000-6-4:2001 9 - EN 55011 : 2006 /A2:20079 - Group 19 - Group 2 9 - Class A9 - Class B 9 - EN 55013 : 1990 / A12:1994 / A13:1996 / A14:1999 9 - EN 55014 -1: 2001/A1:2001 A2:20029 - Household appliances and similar 9 - Portable tools 9 - Semiconductor devices 9 - EN 55022:20069 - Class A9 - Class B 9 -AS/NZS CISPR 22:20069 - Class A9 - Class B # - RSS-210 (A2.9) # - Technical Acceptance Certificate 9 - CNS 134389 - Class A9 - Class B 9 - VCCI V-3/2007.49 - Class A9 - Class B # - FCC Part 15.109 9 - Class A# - Class B FCC Part 15.249 (per ANSI C63.4:2003) # - Certification 9 - Verification # - Declaration of Conformity 9 - FCC Part 18 (per FCC MP-5) Test Report Number 12F190B FCC ID:OH8-SS200R Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 4 of 12 Environmental conditions during testing: LAB OATS Temperature: * _________: ________ Relative Humidity: ** _________: ________ * The ambient temperature during the testing was within the range of (50 o - 104 o F) unless indicted above. ** The humidity levels during the testing was within the range of (10% - 90%) relative humidity unless indicated above. Power supply system: * Volts Hz SINGLE phase Internal battery Sign Explanations: 9 - not applicable # - applicable Test Report Number 12F190B FCC ID:OH8-SS200R Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 5 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: # - Test not applicable 9 - Darby Test Site (Open Area Test Site) 9 - Darby Laboratory Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - 8028-50Solar50 S LISN829012, 829022 9 - 3825/2Solar50 S LISN924840 9 - EMC-30Electro-MetricsEMI Receiver191 9 - 8566BHewlett-PackardSpectrum Analyzer2421A00526 9 - 85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 - 85662AHewlett Packard Analyzer Display2403A07352 9 - 8028-50Solar50 S LISN903725, 903726 9 - FCC-TLISN-T4-02Fisher Custom Com.Telecom ISN20454 9 - FCC-TLISN-T8-02Fisher Custom Com.Telecom ISN20452 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The RADIATED EMISSIONS (MAGNETIC FIELD) measurements, in the frequency range of 9 kHz - 30 MHz were performed at the following test location: # - Darby Test Site (Open Area Test Site) 9 - 9 - at a test distance of : # - 3 meters 9 - 30 meters # - Test not applicable Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - 3148EMCOLog Periodic Antenna00044783 9 - BIA-25Electro-MetricsBiconical Antenna4283 #-8566BHewlett-PackardSpectrum Analyzer2421A00526 # - 85662AHewlett-PackardAnalyzer Display2403A07352 # - 85650AHewlett-PackardQuasi-Peak Adapter2043A00209 # - ALR-30MElectro-MetricsLoop Antenna824 # - 8447DHewlett PackardPreamplifier2944A06832 9 - 9 - EMC-30 ALA-130/A Electro-Metrics Antenna Research EMI Receiver Loop Antenna 191 106 Test Report Number 12F190B FCC ID:OH8-SS200R Product Safety…

Text truncated - open the document above for the full version.

Test Report Number 12F190B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 11 of 12 Test-setup photo(s): Conducted emission 150 kHz - 30 MHz NA Test Report Number 12F190B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz
