B60-5188-00 00 MA (K, P, M, X) 0109 AUDIO VIDEO SURROUND RECEIVER VR - 6060 KRF - V8060D INSTRUCTION MANUAL KENWOOD CORPORATION This instruction manual is used to describe multiple models listed above. Model availability and features (functions) may differ depending on the country and sales area. About the supplied remote control Compared to standard remote controls, the remote control supplied with this receiver has several operation modes. These modes enable the remote control to control other audio/video components. In order to effectively use the remote control it is important to read the operating instructions and obtain a proper understanding of the remote control and how to switch its operation modes (etc.). Using the remote control without completely understanding its design and how to switch the operation modes may result in incorrect operations. •VR609/01-09/EN new10/24/01, 10:32 PM1 2 EN Units are designed for operation as follows. U.S.A. and Canada ........................................... AC 120 V only Australia ........................................................... AC 240 V only China and Russia ............................................. AC 220 V only Other countries .......... AC 110-120 / 220-240 V switchable* * AC voltage selection The AC voltage selector switch on the rear panel is set to the voltage that prevails in the area to which the unit is shipped. Before connecting the power cord to your AC outlet, make sure that the setting position of this switch matches your line voltage. If not, it must be set to your voltage in accordance with the following direction. VOLTAGE SELECTOR AC 110- 120V~ AC 220- 240V~ Note: Our warranty does not cover damage caused by excessive line voltage due to improper setting of the AC voltage selector switch. Before applying the power Caution : Read this page carefully to ensure safe operation. Unpacking Unpack the unit carefully and make sure that all accessories are present. FM indoor antenna (1)AM loop antenna (1) RF remote antenna (1) (For VR-6060 only) For VR-6060 Remote control unit (1)Batteries (R6/AA) (2) RC-R0816 For KRF-V8060D Remote control unit (1)Batteries (R6/AA) (2) RC-R0725 *AC plug adaptor (1) *Use to adapt the plug on the power cord to the shape of the wall outlet. (Accessory only for regions where use is necessary.) If any acccessories are missing, or if the unit is damaged or fails to operate, notify your dealer immediately. If the unit was shipped to you directly, notify your shipper immediately. Kenwood recommends that you retain the original carton and packing materials in case you need to move or ship the unit in the future. Keep this manual handy for future reference. AC voltage selector switch Move switch lever to match your line voltage with a small screwdriver or other pointed tool. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Safety precautions WARNING : TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS IN- SIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT’S EN- CLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRI- ANGLE IS INTENDED TO ALERT THE USER TO THE PRES- ENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOM- PANYING THE APPLIANCE. •VR609/01-09/EN new10/24/01, 10:32 PM2 3 EN Contents Caution : Read the pages marked carefully to ensure safe operation. Before applying the power Before applying the power .............................. 2 Safety precautions ............................................. 2 Unpacking.......................................................... 2 How to use this manual ..................................... 4 Special features ................................................. 5 Names and functions of parts ......................... 6 Main Unit ........................................................... 6 Remote control unit RC-R0816 (VR-6060) ............7 Remote control unit RC-R0725 (KRF-V8060D) .....8 Setting up the system ........................................ 9 Connecting audio components ........................ 10 Connecting video components ........................ 11 Connecting a DVD player (6-channel input) ..... 12 Digital connections .......................................... 13 Connecting video components (COMPONENT VIDEO) .................................... 14 Connecting the speakers ................................. 15 Connecting the terminals ................................ 16 Connecting the RF antenna and external IR Repeater (For VR-6060 only) ....................... 17 Connecting to the AV AUX jacks ..................... 18 Connecting the antennas ................................. 18 Connecting the system control ....................... 19 Preparing the remote control .......................... 20 RF remote control function (For VR-6060 only)20 Preparing for surround sound ....................... 21 Speaker settings .............................................. 21 Normal playback .............................................. 24 Preparing for playback ..................................... 24 Listening to a source component .................... 24 Adjusting the sound ......................................... 25 Recording .......................................................... 26 Recording audio (analog sources) ................... 26 Recording video ............................................... 26 Recording audio (digital sources) .................... 26 Listening to radio broadcasts ....................... 27 Tuning radio stations ....................................... 27 Presetting radio stations manually ..…

Text truncated - open the document above for the full version.

Infared Emitting RF transmitcircuit Pack Receiving circuit MainMicrocontroller Key Matrices SubMicrocontroller EEPROM Ceramic Resonator 8MHzQuartz crystal 32.768KHz Ceramic Resonator 4MHz 309.5MHz or315MHz Dry battery V(3V) V V V V V 37.9KHz infared rays 940nm

1. Code Table(RECEIVER mode) 1. Code Table(RECEIVER mode) 1. Code Table(RECEIVER mode) 1. Code Table(RECEIVER mode) 送信コード表（ RECEIVER モード） 送信コード表（ RECEIVER モード） 送信コード表（ RECEIVER モード） 送信コード表（ RECEIVER モード） Key No. Key name Custom Sub Data Custom Sub Data Code transmission classification Learning possible key ｷｰ番号 キｰの名前 Custom Custom コード送信区分 学習可能キー (BIN) (BIN) (BIN) DVD CBL DSS/ VCR TV DVD CBL DSS/ VCR TV OTHERS (HEX) (HEX) (HEX) C0 C7 C0' C7' D0 D7 SAT SAT 1 LEARN -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- 2 -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- 3 SOURCE POWER -- -- -- -- -- -- A B C D -- ○○○○○ ○ 4 RECEIVER POWER B8 00 9D 0001 1101 0000 0000 1011 1001 F F F F F -- -- -- -- -- -- 5 REMOTE MODE DVD -- -- -- -- -- -- G G G G G -- -- -- -- -- -- 6 REMOTE MODE CBL -- -- -- -- -- -- G G G G G -- -- -- -- -- -- 7 REMOTE MODE DSS/SAT -- -- -- -- -- -- G G G G G -- -- -- -- -- -- 8 RECEIVER -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- 9 REMOTE MODE VCR -- -- -- -- -- -- G G G G G -- -- -- -- -- -- 10 REMOTE MODE TV -- -- -- -- -- -- G G G G G -- -- -- -- -- -- 11 REMOTE MODE OTHERS -- -- -- -- -- -- G G G G G -- -- -- -- -- -- 12 THX B8 01 C2 0001 1101 1000 0000 0100 0011 F F F F F -- -- -- -- -- -- 13 1 B8 00 81 0001 1101 0000 0000 1000 0001 A B C D E ○○○○○ ○ 14 2 B8 00 82 0001 1101 0000 0000 0100 0001 A B C D E ○○○○○ ○ 15 3 B8 00 83 0001 1101 0000 0000 1100 0001 A B C D E ○○○○○ ○ 16 LISTEN MODE △ B8 00 DF 0001 1101 0000 0000 1111 1011 F F F F F -- -- -- -- -- -- 17 4 B8 00 84 0001 1101 0000 0000 0010 0001 A B C D E ○○○○○ ○ 18 5 B8 00 85 0001 1101 0000 0000 1010 0001 A B C D E ○○○○○ ○ 19 6 B8 00 86 0001 1101 0000 0000 0110 0001 A B C D E ○○○○○ ○ 20 LISTEN MODE ▽ B8 07 1F 0001 1101 1110 0000 1111 1000 F F F F F -- -- -- -- -- -- 21 7 B8 00 87 0001 1101 0000 0000 1110 0001 A B C D E ○○○○○ ○ 22 8 B8 00 88 0001 1101 0000 0000 0001 0001 A B C D E ○○○○○ ○ 23 9 B8 00 89 0001 1101 0000 0000 1001 0001 A B C D E ○○○○○ ○ 24 CINEMA EQ B8 06 47 0001 1101 0110 0000 1110 0010 F F F F F -- -- -- -- -- -- 25 +10 B8 00 0D 0001 1101 0000 0000 1011 0000 A -- -- D E ○○○○○ ○ 26 0 B8 00 80 0001 1101 0000 0000 0000 0001 A B C D E ○○○○○ ○ 27 +100 B8 02 4F 0001 1101 0100 0000 1111 0010 A -- -- -- -- ○○○○○ ○ 28 ACTIVE EQ. B8 06 49 0001 1101 0110 0000 1001 0010 F F F F F -- -- -- -- -- -- 29 INPUT MODE B8 04 9F 0001 1101 0010 0000 1111 1001 F F F F F -- -- -- -- -- -- 30 STEREO B8 00 D7 0001 1101 0000 0000 1110 1011 F F F F F -- -- -- -- -- -- 31 DSP MODE B8 01 0C 0001 1101 1000 0000 0011 0000 F F F F F -- -- -- -- -- -- 32 MUTE B8 00 9C 0001 1101 0000 0000 0011 1001 -- -- -- -- E -- -- -- -- ○ (*1) ○ 33 CH + / DVD -- -- -- -- -- -- A B C D E ○○○○○ ○ 34 TV CONTROL INPUT SEL. -- -- -- -- -- -- E E E E E -- -- -- -- ○ (*1) ○ 35 TV CONTROL POWER -- -- -- -- -- -- E E E E E -- -- -- -- ○ (*1) ○ 36 VOLUME + B8 00 9B 0001 1101 0000 0000 1101 1001 F F F F F -- -- -- -- -- -- 37 CH - / DVD -- -- -- -- -- -- A B C D E ○○○○○ ○ 38 TV CONTROL VOL. - -- -- -- -- -- -- E E E E E -- -- -- -- ○ (*1) ○ 39 TV CONTROL VOL. + -- -- -- -- -- -- E E E E E -- -- -- -- ○ (*1) ○ 40 VOLUME - B8 00 9A 0001 1101 0000 0000 0101 1001 F F F F F -- -- -- -- -- -- 41 SET UP / TOP MENU B8 03 19 0001 1101 1100 0000 1001 1000 A -- -- -- -- ○○○○○ ○ 42 MENU / SOUND B8 01 57 0001 1101 1000 0000 1110 1010 A -- C -- -- ○○○○○ ○ 43 ENTER -- -- -- -- -- -- A B C -- E ○○○○○ ○ 44 ▲ B8 01 55 0001 1101 1000 0000 1010 1010 A -- C -- -- ○○○○○ ○ 45 P.CALL/DOWN/ B8 02 00 0001 1101 0100 0000 0000 0000 A -- C -- -- ○○○○○ ○ 46 P.CALL/DOWN/ B8 02 01 0001 1101 0100 0000 1000 0000 A -- C -- -- ○○○○○ ○ 47 ▼ B8 01 54 0001 1101 1000 0000 0010 1010 A -- C -- -- ○○○○○ ○ 48 OSD -- -- -- -- -- -- A -- -- -- -- ○○○○○ ○ 49 PAGE ▽ -- -- -- -- -- -- A -- -- -- -- ○○○○○ ○ 50 PAGE △ -- -- -- -- -- -- A -- -- -- -- ○○○○○ ○ ２． Format (RECEIVER Mode) ２． Format (RECEIVER Mode) ２． Format (RECEIVER Mode) ２． Format (RECEIVER Mode) ： ： ： ： NEC Format NEC Format NEC Format NEC Format ３． Setting procedure for relation between Device key and Input Sel key Setting procedure for relation between Device key and Input Sel key Setting procedure for relation between Device key and Input Sel key Setting procedure for relation between Device key and Input Sel key 送信フォーマット（レシーバモード） 送信フォーマット（レシーバモード） 送信フォーマット（レシーバモード） 送信フォーマット（レシーバモード） デバイスキーと INPUT SEL キーの関連付け デバイスキーと INPUT SEL キーの関連付け デバイスキーと INPUT SEL キーの関連付け デバイスキーと INPUT SEL キーの関連付け Repeat Code 3. 1 Setting procedure Setting procedure Setting procedure Setting procedure ﾘﾋﾟｰﾄｺｰﾄﾞ 関連付け設定方法 関連付け設定方法 関連付け設定方法 関連付け設定方法 1 ) Press source power key (K3) continuously unit setting is completed. 設定を完了するまで SOURCE POWER キー (K3) を押し続ける。 . 2) Press and release Device key (K5,K6,K7,K9,K 1 0,K 11 ). 1 08ms 1 08ms デバイスキー（Ｋ５，Ｋ６，Ｋ７，Ｋ９，Ｋ１０，Ｋ１１）を押して離す。 1 st Frame( 第１フレーム ) 2nd Frame( 第２フレーム ) 3) Press and release Input Sel key (from K60 to K68). INPUT SEL キー（Ｋ６０～Ｋ６８）を押して離す。 4) Release source power key. SOURCE POWER キーを離す。 C0 C7 C0' C7' D0 D7 D0 D7 * The remote does not transmit any signals while in the setting mode. Sub 設定中は、リモコンコードを送信しない。 Leader Custom Code Custom Code Data Code Data Code End Bit Code 8bit 8bit 8bit 8bit 3.2 Transmitting of Device key Transmitting of Device key Transmitting of Device key Transmitting of Device key ﾍｯﾀﾞｰ ｶｽﾀﾑｺｰﾄﾞ ｻﾌﾞｶｽﾀﾑｺｰﾄﾞ ﾃﾞｰﾀｺｰﾄﾞ ﾃﾞｰﾀｺｰﾄﾞ ｴﾝﾄﾞﾋﾞｯﾄ デバイスキーの動作 デバイスキーの動作 デバイスキーの動作 デバイスキーの動作 Repeat Code In case, the Device key which is set with Input Sel key is pressed, Device Mode ﾘﾋﾟｰﾄｺｰﾄﾞ is changed to pressed Device, and code of the Input Sel key is transmitted.Device key does not have any transmission code, if setting with Input Sel key is not completed.関連付けされているデバイスキーを押した場合、押されたデバイスのモードに変更し関連付けされたINPUT SEL キーを送信する。 関連付け未設定時、デバイスキーは送信コードを持たない。 9ms 4.5ms 9ms 2.25ms 3.3 Transmitting of Input Sel key Transmitting of Input Sel key Transmitting of Input Sel key Transmitting of Input Sel key 0.56ms 0.56ms INPUT SEL キーの動作 INPUT SEL キーの動作 INPUT SEL キーの動作 INPUT SEL キーの動作 1 . 1 25ms 2.25ms 0 1 In case, the Input Sel key whi…

Text truncated - open the document above for the full version.

JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 400-10521 Issue Date : January 10, 2002 Page 1 of 31 EMI TEST REPORT JQA APPLICATION NO. : 400-10521 Model No. : SBLM04001 Type of Equipment : Remote Control Unit Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : OHELM04001 Applicant : ALPS MECHATRONIC DEVICES DIVISION WAKUYA PLANT Address : 230, Shibue, Wakuya-cho, Tohda-gun, Miyagi-pref 987-0195 Japan Manufacture : ALPS MECHATRONIC DEVICES DIVISION WAKUYA PLANT Address : 230, Shibue, Wakuya-cho, Tohda-gun, Miyagi-pref 987-0195 Japan Received date of EUT : December 19, 2001 Final Judgment : Passed TEST RESULTS IN THIS REPORT are obtained in use of equipment that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and Communication Research Laboratory (CRL) of Japan. The test results only respond to the tested sample. This report should not be reproduced except in full, without the written approval of JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-10521 FCC ID :OHELM04001 Model No. :SBLM04001 Issue Date :January 10, 2002 Standard :CFR 47 FCC Rules Part 15 Page 2 of 31 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 8 1.4 EUT Modifications / Deviation from Standard 9 1.5 Test results 10 1.6 Summary 11 1.7 Test Configuration / Operation of EUT 12 1.8 EUT Arrangement(Drawing) 13 1.9 Preliminary Test and Test-setup (Drawings) 14 – 19 1.10 EUT Arrangement (Photographs) 20 - 21 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N/A 2.2 Radiated Emission (Electric Field) 22 – 28 2.3 Frequency Stability N/A 2.4 Occupied Bandwidth 29 – 31 C O P Y JQA Application No. :400-10521 FCC ID :OHELM04001 Model No. :SBLM04001 Issue Date :January 10, 2002 Standard :CFR 47 FCC Rules Part 15 Page 3 of 31 JAPAN QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and C (June 23, 1989) Intentional Radiators Test procedure : AC power line conducted emission, radiated emission, frequency stability and occupied bandwidth tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers( 3 meters Site ). - Shielded Enclosure. Expiration date of FCC test facility filing : June 04, 2002 2) EMC Engineering Dept. Testing Div. is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2002) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : Remote Control Unit 2) Product Type : Production 3) Category : Security/Remote Control Transmitter 4) EUT Authorization : Certification 5) FCC ID : OHELM04001 6) Trade Name : KENWOOD 7) Model No. : SBLM04001 8) Operating Frequency Range : 309.5 MHz, 315 MHz 9) Highest Frequency Used in the EUT : 315 MHz 10) Serial No. : None 11) Date of Manufacture : November 2001 12) Power Rating : DC 3.0V(Battery) 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-10521 FCC ID :OHELM04001 Model No. :SBLM04001 Issue Date :January 10, 2002 Standard :CFR 47 FCC Rules Part 15 Page 4 of 31 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan - Shielded Enclosure - Anechoic Chamber No. 2 (portable Type) Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 June 2001 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/030 May 2001 1 Year - Test Receiver ESHS10 Rohde & Schwarz 835871/004 Aug. 2001 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-6 Apr. 2001 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-855-2 Apr. 2001 1 Year - LISN KNW-407 Kyoritsu Electrical 8-757-1 Apr. 2001 1 Year - RF Cable 3D-2W Fujikura 155-21-006E0 Apr. 2001 1 Year - RF Cable 3D-2W Fujikura 155-21-007E0 Apr. 2001 1 Year - 50ohm Termination - SUHNER 154-06-501E0 Jan. 2001 1 Year - 50ohm Termination - SUHNER 154-06-502E0 Jan. 2001 1 Year C O P Y JQA Application No. :400-10521 FCC ID :OHELM04001 Model No. :SBLM04001 Issue Date :January 10, 2002 Standard :CFR 47 FCC Rules Part 15 Page 5 of 31 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(9 kHz – 30 MHz) - was performed in the following test site. x - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan - Anechoic Chamber No. 2 (3 meters) - Anechoic Chamber No. 3 (3 meters) Validation of Site Attenuation : 1) Last Confirmed Date : N/A 2) Interval : N/A Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 June 2001 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/030 May 2001 1 Year - Test Receiver ESHS10 Rohde & Schwarz 835871/004 Aug 2001 1 Year - Antenna HFH2-Z2 Rohde & Schwarz 881058/62 Nov 2001 1 Year - RF Cable RG-213/U F & G 155-21-010E0 Apr. 2001 1 Year C O P Y JQA Application No. :400-10521 FCC ID :OHELM04001 Model No. :SBLM04001 Issue Date :January …
