OIS-SSI8638Digital Camera for Inspection

8638 User manual Prepared by Eric Lee (D3) Key [Power] [Snap] [Up] [Down] [Menu] Menu Tree Basic function 1. Operation Power on units by Power button, press again to Power off unit by Power button. 2. Snap & record image Short-Press [Snap] for capture a still shot Long-Press [Snap] for recording , Long press [Snap] again for stop recording 3. Adjust LED brightness [Menu] -> [UP]/[Down] to adjust LED brightness of the sensor 4. Zoom for capture [UP]/[Down] to adjust the Zoom level, press [Snap] to capture 5. Review Images Review Images [Menu] -> [Menu] -> select {Playback} by [Snap] -> select {photo} by snap Review Videos [Menu] -> [Menu] -> select {Playback} by [Snap] -> select {video} by snap 6. Change USB mode You can select 2 kinds of USB (MSDC/PC camera). [Menu] -> [Menu] -> select {Setup} by [Snap] -> select {USB mode} by snap -> choose {MSDC/ PC camera} 7. Image color mode You can select 3 kinds different color mode in the unit; they are (Normal/Black and White/Vivid). [Menu] -> [Menu] -> select {Display} by [Snap] -> select {Color} by snap -> choose {Vivid/BW/Normal} (Vivid/BW/Normal) 8. Unit ID Unit ID is the mark for unique ID mark on the image. Enter a 8-digits Character, when you record a video or snap a image, the ID name will be encoded on the video or image. [Menu] -> [Menu] -> select {Setup} by [Snap] -> select {Unit ID} by snap Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment。 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC ID: OIS-SSI8638 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Securesight International Limited PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 29.06.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Digital Camera for Inspection Model Name SSI8638 Easyview ‘Retail Record’, SSI8822 Easyview ‘Tradesman’, SSI8829 Easyview ‘Pro Basic’ Brand Name Eazyview We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Simon P Holmes Position Mansging Director Company Name Securesight International Limited Address Unit 6, CSD Business Park, Gannaway Lane, Tewkesbury, UK, GL20 8FD Tel +44-8706099944 Fax +44-8706099944 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Securesight International Limited Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Securesight International Limited FCC ID : OIS-SSI8638 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Simon P Holmes Position Mansging Director Company Name Securesight International Limited Address Unit 6, CSD Business Park, Gannaway Lane, Tewkesbury, UK, GL20 8FD Tel +44-8706099944 Fax +44-8706099944 Email [email protected]

Top View Bottom View Rear View Left View Right View Front View

Label FCC ID: OIS-SSI8638

Shenzhen Certification Technologh Service Co., Ltd 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China FCC ID: OIS-SSI8638 Page 1 of 26 TEST REPORT FCC ID: OIS-SSI8638 Applicant Securesight International Limited Address Unit 6, CSD Business Park, Gannaway Lane, Tewkesbury, UK, GL20 8FD Equipment under Test (EUT): Name : Digital Camera for Inspection Model : SSI8638 Easyview ‘Retail Record’, SSI8822 Easyview ‘Tradesman’, SSI8829 Easyview ‘Pro Basic’ Standards : FCC PART 15, Subpart B Class B 2011 Report No. : STE120327326 Date of Test : June 12-19, 2012 Date of Issue : June 20, 2012 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.: STE120327326 FCC ID: OIS-SSI8638 Page 2 of 26 TABLE OF CONTENTS Description Page Test Report Declaration ...............................................................3 1. Summary of standards and results...................................................................................4 1.1. Description of Standards and Results.........................................................................4 2. GENERAL INFORMATION............................................................................................5 2.1. Description of Device (EUT).....................................................................................5 2.2. Tested Supporting System Details.............................................................................6 2.3. Block Diagram of connection between EUT and simulators.....................................6 2.4. Test Facility................................................................................................................7 2.5. Measurement Uncertainty..........................................................................................7 3. POWER LINE CONDUCTED Emission test..................................................................8 3.1. Test Equipment..........................................................................................................8 3.2. Block Diagram of Test Setup.....................................................................................8 3.3. Power Line Conducted Emission Test Limits............................................................8 3.4. Configuration of EUT on Test...................................................................................9 3.5. Operating Condition of EUT......................................................................................9 3.6. Test Procedure............................................................................................................9 3.7. Conducted Disturbance at Mains Terminals Test Results.........................................9 4. Radiated emission Test.....................................................................................................12 4.1. Test Equipment........................................................................................................12 4.2. Block Diagram of Test Setup...................................................................................12 4.3. Radiated Emission Limit..........................................................................................13 4.4. EUT Configuration on Test......................................................................................13 4.5. Operating Condition of EUT....................................................................................14 4.6. Test Procedure..........................................................................................................14 4.7. Radiated Disturbance Test Results...........................................................................14 5. Photograph........................................................................................................................19 5.1. Photos of Power Line Conducted Emission Test.....................................................19 5.2. Photos of Radiated Emission Test (In Anechoic Chamber).....................................20 6. Photos of the EUT.............................................................................................................21 Report No.: STE120327326 FCC ID: OIS-SSI8638 Page 3 of 26 TEST REPORT VERIFICATION Applicant : Securesight International Limited Manufacturer : Securesight International Limited EUT Description : Digital Camera for Inspection (A) Model No. : SSI8638 Easyview ‘Retail Record’, SSI8822 Easyview ‘Tradesman’, SSI8829 Easyview ‘Pro Basic’ (B)Trademark : Easyview (C) Serial No. : N/A (D) Power Supply : DC 4.5V from battery or DC 5V From PC with AC 120V/60Hz (E) Test Voltage : DC 4.5V from battery or DC 5V From PC with AC 120V/60Hz Measurement Standard Used: FCC Rules and Regulations Part 15 Subpart B Class B 2011 The device described above is tested by Shenzhen Certification Technology Service Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B Class B limits both conducted and radiated emissions. The test results are contained in this test report and Shenzhen Certification Technology Service Co., Ltd. is assumed of full responsibility for the accuracy…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber Photos of Power Line Conducted Emission Test
