OLM-JR14Wireless Microphone Reciever

FCC ID OLM-JR14 FCC ID: OLM-JR14 External Photographs

FCC ID OLM-JR14 FCC ID: OLM-JR14 Label Information

FCC ID OLM-JR14 FCC ID: OLM-JR14 Label Location

FCC ID OLM-JR14 FCC ID: OLM-JR14 Internal Photographs FCC ID OLM-JR14 FCC ID OLM-JR14 FCC ID OLM-JR14 FCC ID OLM-JR14 FCC ID OLM-JR14

FCC-ID: Test Report No. 56404-00358-3 Page 1 of 58 Pages Straubing, June 29, 2000 T E S T - R E P O R T No. 56404-00358-3 for JR 14 Two channel wireless receiver Variants covered by this test report: JR 13 and One Channel wireless Receiver JR 11 / JR 12 Applicant:AV-Leader Corporation Purpose of testing:To show compliance with FCC Code of Federal Regulations, Part 15 Subpart C, Sections §15.207 and §15.209 Industry Canada Radio Standards Specification RSS-210 Issue 2, Sections 7.3 and 7.4 (Category I Equipment) Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. FCC-ID: Test Report No. 56404-00358-3 Page 2 of 58 Pages Table of Contents 1. Administrative Data ............................................................................................. 3 2. Identification of Test Laboratory.......................................................................... 4 3. Summary of Test Results .................................................................................... 5 4. Operation Mode of EUT ...................................................................................... 6 5. Configuration of EUT and Peripheral Devices..................................................... 7 6. Measuring Methods............................................................................................. 8 6.1. Conducted Emission 0.45 MHz - 30 MHz (FCC §15.207 / RSS-210 Section 7.4)................................................................................... 8 6.2. Radiated Emission 30 MHz - 1 GHz (FCC §15.209 / RSS-210 Section 7.3) ................................................................................................ 10 6.3. Radiated Emission 1 GHz - 2 GHz (FCC §15.205.a,b, §15.209, §15.231.b / RSS-210 Sections 6.1.1.b, 6.3)................................ 12 7. Equipment List .................................................................................................. 14 8. Photographs Taken During Testing................................................................... 16 9. List of Measurements ........................................................................................ 20 9.1. List of Measurements According To FCC Part 15 Subpart C ..................... 21 9.2. List of Measurements According To Industry Canada RSS- 210 22 10. Referenced Regulations.................................................................................... 23 11. Test Results ...................................................................................................... 24 11.1. Test results of Sample 1............................................................................. 25 11.2. Test results of Sample 2............................................................................. 42 FCC-ID: Test Report No. 56404-00358-3 Page 3 of 58 Pages 1.Administrative Data Equipment Under Test (EUT):JR 14 Variants covered by this test report: JR 13 and One Channel wireless Receiver JR 11 / JR 12 Serial number(s):2 Samples Type of equipment:Two channel wireless receiver Parts/accessories:Sample 1: 179.2 / 198.3 MHz Sample 2: 184.9 / 209.2 MHz FCC-ID:--- Applicant:AV-Leader Corporation (full address)24, Lane 90, Kuei-Yang St., Tai-San Hsiang Taipei Hsien 243, Taiwan, R.O.C. Contract identification:9908/June 01, 2000 Contact person:Mr. Yung-Te Chen Manufacturer:AV-Leader Corporation Receipt of EUT:June 8, 2000 Date of test:June 2000 Note:--- Responsible for testing:Rupert Kohlhäufl Responsible for test report:Rupert Kohlhäufl EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 4 of 58 Pages 2.Identification of Test Laboratory Test Laboratory:Senton GmbH EMI/EMC Test Center (full address):Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Contact person:Mr. Johann Roidt Communication:Telephone(+49) 0 94 21 / 55 22-0 Fax (+49) 0 94 21 / 55 22-99 eMail:[email protected] FCC file number:31040/SIT 1300F2 Industry Canada file number:IC 3050 EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 5 of 58 Pages 3.Summary of Test Results The tested sample complies with the requirements set forth in the Code of Regulations Part 15 Subpart C, Sections §15.207 and §15.209 (intentional radiators) of the Federal Communication Commission (FCC) and the Radio Standards Specification RSS-210 Issue 2, Sections 7.3 and 7.4 for Low Power Licence-Exempt Radiocommuniction Devices of Industry Canada. Johann RoidtRupert Kohlhäufl Technical ManagerTest Engineer EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 6 of 58 Pages 4.Operation Mode of EUT • Receiver operating continuously • With supply voltage 12 V DC EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 7 of 58 Pages 5.Configuration of EUT and Peripheral Devices Configuration of EUT Not applicable Configuration of cables of EUT • Non shielded DC supply input line • Shielded audio output line Configuration of peripheral devices connected to EUT • AC/DC adaptor 115/12 V connected to DC supply input EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 8 of 58 Pages 6.Measuring Methods 6.1.Conducted Emission 0.45 MHz - 30 MHz (FCC §15.207 / RSS-210 Section 7.4) Conducted emissions were measured in the frequency range 0.45 MHz to 30 MHz. The bandwidth of the EMI-Receiver was set to 9 kHz and the detector-function was set to CISPR quasi-peak. The test setup was made in accordance with ANSI C63.4-1992. Measurements were performed on phase and neutral lines of the power-cords of the tested system. Preliminary scans were taken with the detector-function of the EMI- receiver set to peak to determine the conducted EMI-profile of the EUT. At the final test the cables and equipment were placed and moved within the range of positions likely to find their maximum emissions. See figure 1 f…

Text truncated - open the document above for the full version.

EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 1 of 3 Pages Photos No. 8.1 - 8.2 Test setup for conducted emission test 450 kHz - 30 MHz EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 2 of 3 Pages Photos No. 8.3 - 8.4 Test setup for radiated emission 30 MHz - 2 GHz (semi anechoic room) EMV-PrüfzentrumEMI/EMC-Testcenter FCC-ID: Test Report No. 56404-00358-3 Page 3 of 3 Pages Photos No. 8.5 - 8.6 Test setup for radiated emission final test 30 MHz - 1 GHz (open area test site)
