OLV-A830ABiTalkBB Chinese TV

User's installation manual of the STB Package contains STB RCU Power Cable HDMI Cable Power Adapter Power Interface Ethernet Interface Micro USB Interface HDMI Interface AV Interface Installation Steps To connect the TV Recommend that you choose the HDMI cable to connect the iTalkBB STB and TV, so you can experience high-definition content. If you are using a traditional TV, you can also choose the AV composite video cable to connect with the iTalkBB STB (It's OK to choose AV cable or HDMI cable as you like). To connect the Internet The iTalkBB STB supports wired and wireless Internet access. Please connect the network cable before booting the STB when you choose the Wired Network. Select an available wireless network and enter your password to complete the connection when you choose the Wireless Network. Boot up The iTalkBB STB will automatically boot up after you connect the power supply. Done! Then you can enjoy the hot Chinese live channels and look back, and you can also enjoy the variety shows through the wireless VOD. Installation HDMI Cable Connect the TV's HDMI Input AV Cable (Optional) Connect the TV's AV Input (for no HDMI) Power Cable 100-240V/50-60Hz Alternate Current Connect mobile devices USB Cable (Optional) Net Cable (Optional) No need for wired network Router/Modem The accessories marked with dashed sold separately in this picture. RCU function Home Standby/boot Arrow keys OK/start or stop Menu Back Volume To use the first time, please remove the insulation sheet below the battery Network Settings Network Settings Wireless net settings Wired net auto settings Previous Enter the network settings after the language settings when you choose the wireless network. If you choose the wired network, have connected network cable and the network is unimpeded, the network settings will be skipped. A.Wired network connection Connect the STB with the network cable. Click on the Wired net auto settings，the STB will automatically enter the next step if the network is unimpeded. Previous Refresh Network quick settings Select net Select net at home Choose name Refresh if no wlan Hint: We recommend you using English or digital to set network name, or some special characters will not be recognized. B.Wireless network connection Choose wireless net settings. Select a wireless network by the list of network names in your home ( If you encounter any questions ,just do like the Tips by the right ). Input the password and then click OK, the STB will go to the next step if the network is unimpeded. 24h customer service US/CA: AU: Global official website FCC STATEMENT 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation.

Beijing Capital Online Network Technology Co., Ltd. 2014-04-29 To: SIEMIC, INC. 775 Montague Expressway Milpitas , CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We , Beijing Capital Online Network Technology Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: iTalkBB Chinese TV Model name: A830-AB FCC ID: OLV-A830AB We affirm that between SIEMIC and Beijing Capital Online Network Technology Co., Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature ：Yu a n Yi n Contact information / address ：+ 86-10-64425263 （16th Floor, Jian Da Building, 14 East Tucheng Road, Beijing, China）

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 Beijing Capital Online Network Technology Co., Ltd. 2014-04-29 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: OLV-A830AB We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Client’s signature ：Yuan Yin Contact information / address ：+ 86-10-64425263 （16th Floor, Jian Da Building, 14 East Tucheng Road, Beijing, China）

Antenna

FCC ID : OLV-A830AB 1. RF EXPOSURE 1.1. The Requirement System operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See Section 15.247(b)(4) and Section 1.1307(b)(1) 1.2. Limit For Maximum Permissible Exposure (MPE) Limits for General Population/ Uncontrolled Exposure F = frequency in MHz, * Plane-wave equivalent power density 1.3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) ( 2 mW/cm) Averaging Time 2 E, 2 H or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the antenna is 4.09 dBi, the RF power density can be obtained. 1.4. TEST RESULTS Maximum measured transmitter power 802.11b Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 15.17 32.89 2.56 1.000 0.017 Pass 2437 20.00 15.09 32.28 2.56 1.000 0.016 Pass 2462 20.00 15.21 33.19 2.56 1.000 0.017 Pass 802.11g Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 14.62 28.97 2.56 1.000 0.015 Pass 2437 20.00 14.63 29.04 2.56 1.000 0.015 Pass 2462 20.00 14.63 29.04 2.56 1.000 0.015 Pass 802.11n(20MHz) Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 13.43 22.03 2.56 1.000 0.011 Pass 2437 20.00 13.60 22.91 2.56 1.000 0.012 Pass 2462 20.00 13.62 23.01 2.56 1.000 0.012 Pass 802.11n (40MHz) Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Output Power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2422 20.00 12.56 18.03 2.56 1.000 0.009 Pass 2437 20.00 12.76 18.88 2.56 1.000 0.010 Pass 2452 20.00 12.68 18.54 2.56 1.000 0.009 Pass The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure. 1.5. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less than 20cm(8 inches) during normal operation. Proposed RF exposure safety information to include in User’s Manual.

Page 1 of 98 FCC ID:OLV-A830AB ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20140514 APPLICATION CERTIFICATION FCC Part 15C On Behalf of Beijing Capital Online Network Technology Co.,Ltd. iTalkBB Chinese TV Model No.: A830-AB FCC ID: OLV-A830AB Prepared for : Beijing Capital Online Network Technology Co.,Ltd. Address : 16th Floor, Jian Da Building, 14 East Tucheng Road, Beijing, China Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20140514 Date of Test : Apr 10-22,2014 Date of Report : Apr 22,2014 Page 2 of 98 FCC ID:OLV-A830AB ACCURATE TECHNOLOGY CO., LTD Report No.: ATE20140514 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT)....................................................................................................................5 1.2. Carrier Frequency of Channels .................................................................................................................6 1.3. Special Accessory and Auxiliary Equipment ...........................................................................................6 1.4. Description of Test Facility ......................................................................................................................6 1.5. Measurement Uncertainty.........................................................................................................................7 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 8 3. OPERATION OF EUT DURING TESTING ................................................................................. 9 3.1. Operating Mode ........................................................................................................................................9 3.2. Configuration and peripherals ..................................................................................................................9 4. TEST PROCEDURES AND RESULTS ....................................................................................... 10 5. 6DB BANDWIDTH MEASUREMENT ........................................................................................ 11 5.1. Block Diagram of Test Setup..................................................................................................................11 5.2. The Requirement For Section 15.247(a)(2) ............................................................................................11 5.3. EUT Configuration on Measurement .....................................................................................................11 5.4. Operating Condition of EUT ..................................................................................................................11 5.5. Test Procedure ........................................................................................................................................11 5.6. Test Result ..............................................................................................................................................12 6. MAXIMUM PEAK OUTPUT POWER ....................................................................................... 19 6.1. Block Diagram of Test Setup..................................................................................................................19 6.2. The Requirement For Section 15.247(b)(3)............................................................................................19 6.3. EUT Configuration on Measurement .....................................................................................................19 6.4. Operating Condition of EUT ..................................................................................................................19 6.5. Test Procedure ........................................................................................................................................19 6.6. Test Result ..............................................................................................................................................20 7. POWER SPECTRAL DENSITY MEASUREMENT.................................................................. 27 7.1. Block Diagram of Test Setup..................................................................................................................27 7.2. The Requirement For Section 15.247(e).................................................................................................27 7.3. EUT Configuration on Measurement .....................................................................................................27 7.4. Operating Condition of EUT ..................................................................................................................27 7.5. Test Procedure ........................................................................................................................................27 7.6. Test Result ..............................................................................................................................................28 8. BAND EDGE COMPLIANCE TEST ........................................................................................... 35 8.1. Block Diagram of Test Setup..................................................................................................................35 8.2. The Requirement For Section 15.247(d) ................................................................................................35 8.3. EUT Configuration on Measurement .....................................................................................................35 8.4. Operating Cond…
