OM601401R4949.82-49.90 MHz WIRELESS REMOTE CONTROL TOY - RX

FCC ID Label Sample for FCC ID: OM601401R49 49MHz FCC ID: OM601401R49 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Ronin Syndicate LLC Model Number: 01401 REPORT NO.: GKK201207040B PAGE 1 OF 10 PART 15.109 & RSS-310 ISSUE 3 Test Report Applicant Ronin Syndicate LLC Address 8100E. Indian School Road, Suite 103, Scottsdale, Arizona 85251, United States FCC ID Number FCC ID: OM601401R49 Brand Name None Model Number 01401 Product Description 49.82-49.90 MHz Wireless Remote Control Toy - RX Operating Frequency 49.860 MHz Rules/Standards Part 15.109 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 4th July, 2012 Tested Date 5th July, 2012 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of SEM.Test) Signed by Jandy So (Manager of SEM.Test) Report Number GKK201207040B Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Ronin Syndicate LLC Model Number: 01401 REPORT NO.: GKK201207040B PAGE 2 OF 10 PART 15.109 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the SEM.Test Compliance Service Co., Ltd., 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 994117. The Industry Canada IC OATS Filing Number/Assigned Code is 7673A. Ronin Syndicate LLC Model Number: 01401 REPORT NO.: GKK201207040B PAGE 3 OF 10 PART 15.109 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..................................................................... 4 1.2 TEST STANDARDS....................................................................................................................................... 4 1.3 TEST METHODOLOGY................................................................................................................................. 4 1.4 EUT EXERCISE SOFTWARE..........................................................................................................................5 1.5 ACCESSORIES EQUIPMENT LIST AND DETAILS..............................................................................................5 1.6 EUT CABLE LIST AND DETAILS....................................................................................................................5 2. SUMMARY OF TEST RESULTS......................................................................................... 6 3. PART 15.109(A) & RSS-310 ISSUE 3 §3.1 - RADIATED EMISSION ..................................... 7 3.1 MEASUREMENT UNCERTAINTY....................................................................................................................7 3.2 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................7 3.3 TEST PROCEDURE.......................................................................................................................................7 3.4 TEST RECEIVER SETUP...............................................................................................................................8 3.5 CORRECTED AMPLITUDE & MARGIN CALCULATION.................................................................................... 8 3.6 ENVIRONMENTAL CONDITIONS.................................................................................................................. 8 3.7 SUMMARY OF TEST RESULTS/PLOTS........................................................................................................... 8 Ronin Syndicate LLC Model Number: 01401 REPORT NO.: GKK201207040B PAGE 4 OF 10 PART 15.109 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Ronin Syndicate LLC Address of applicant: 8100E. Indian School Road, Suite 103, Scottsdale, Arizona 85251, United States Manufacturer: Ronin Syndicate LLC Address of manufacturer: 8100E. Indian School Road, Suite 103, Scottsdale, Arizona 85251, United States General Description of E.U.T Items Description Product Description: 49.82-49.90 MHz Wireless Remote Control Toy - RX Brand Name: None Model Number: 01401 Rated Voltage: 6 X DC 1.5V AA-Size Batteries Rated Current: / For more information refer to the circuit diagram form and the user’s manual. The test data is gathered from a production sample, provided by the manufacturer. 1.2 Test Standards The following report is prepared on behalf of the Ronin Syndicate LLC in accordance with Part 2 Subpart J and Part 15 Subparts B of the FCC Rules. The objective is to determine compliance with Part 15.109 of the FCC Rules and RSS-310 Issue 3 & RSS-Gen Issue 3 of the Industry Canada. Maintenance of compliance is the responsibility of the manufacturer. Any modification of the product, which results in lowering the emission/immunity, should be checked to ensure compliance has been maintained. 1.3 Test Methodology All measurements contained in this report were conducted with ANSI Standard C63.4-2009, American National Standard Institute for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. The equipment under test (EUT) was configured to measure its highest possible susceptibility against the tested phenomena. The test modes were adapted accordingly in reference to the Operating Instructions. Ronin Syndicate LLC Model Number: 01401 REPORT NO.: GKK201207040B PAGE 5 OF 10 PART 15.109 & RSS-310 ISSUE 3 1.4 EUT Exercise Software The EUT exercise program used during the testing was desig…
