ON9S-2260RPro-Modern C-Car 49MHz - Receiver

Date: 1999-07-30TEST REPORTPage 1 of 4 No.: HM101234 ____Law Man Kit ___ ____Kitty Choy____ ____Patrick Wong__ Patrick Wong Testing EngineerVerify byfor Managing Director Conditions in issuance of Test Report 1. This Report is issued in confidence to the client and it will be strictly treated as such by the Hong Kong Standards and Testing Centre Ltd. It may not be reproduced either in its entirety or in part and it may not be used for advertising. The client to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Hong Kong Standards and Testing Centre Ltd. to his customer, supplier or other persons directly concerned. The Hong Kong Standards and Testing Centre Ltd. will not, without the consent of the client, enter into any discussion or correspondence with any third party concerning the contents of the Report. 2. The report refers only to the sample tested and does not apply to the bulk, unless the sampling has been carried out by the Hong Kong Standards and Testing Centre Ltd. and is stated as such in the Report. 3. In the event of the improper use of the report, the Hong Kong Standards and Testing Centre Ltd. reserves the rights to withdraw it, and to adopt any other remedies which may be appropriate. 4. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Hong Kong Standards and Testing Centre Ltd. 5. The Hong Kong Standards and Testing Centre Ltd. will not be liable for or accept responsibility for any loss or damage howsoever arising from the use of information contained in any of its Reports or in any communication whatsoever about its said tests or investigations. 6. Applicants wishing to use the Report in court proceedings or arbitration shall inform the Hong Kong Standards and testing Centre Ltd. to that effect prior to submitting the sample for testing. APPLICANT: (CODE : SAI007) SANDER IND. CO. LTD. 10/F, HONG KONG MFG. BLDG., 128 WAI YIP ST., KWUN TONG, KOWLOON, HONG KONG. DATE OF SAMPLES RECEIVED: 1999.07.20 DATE OF TESTING: 1999.07.27. DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:PRO-MODERN C-CAR 49MHz - Receiver Manufacturer:SANDER TOYS MANUFACTURER (HUIZHOU) LTD. Model Number: S-2260RCB/RC Brand Name:SANDER Rating:3Vd.c. (“AA” size battery × 2) Origin:China Additional Model Number/Brand Name : S-2270RCB/RC, S-2280RCB/RC, S-2290RCB/RC, S-2320RCB/RC, S-2330RCB/RC, S-2340RCB/RC, S-2350RCB/RC, S-2380RCB/RC, S-2390RCB/RC INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the clause 15.109(a) & ANSI C63.4:1992 section 12.1.1.1-2 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 1999-07-30TEST REPORTPage 2 of 4 No.: HM101234 T E S T S U M M A R Y ***UNINTENTIONAL RADIATOR*** (A)Measurement of Radiated Emissions ....................................................... Satisfactory (B) Line Conducted Voltage Test. ................................................................. Not applicable T E S T D A T A Please refer to the attached result sheets. Date: 1999-07-30TEST REPORTPage 3 of 4 No.: HM101234 ***UNINTENTIONAL RADIATOR*** ** RECEIVER SECTION ** (A) Measurement of Radiated Interference ================================= TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109(a) TEST CONDITION : Normal TEST DATE : 1999.07.27. ============================================== Freq. to which Freq of thePolarizationMeter Antenna Field Strength FCC limit tuned emission H-V reading (at 3m) factor (at 3m) @ MHz MHz dB(μV) dB dB(μV/m) μV/m μV/m 49.86049.9H19.2+15.034.251.3100 99.7<1.0+12.2< 13.2<4.6150 149.6<1.0+9.8< 10.8<3.5150 199.4<1.0+11.5< 12.5<4.2150 249.3<1.0+15.9< 16.9<7.0200 299.1<1.0+17.0< 18.0<7.9200 349.0<1.0+17.2< 18.2<8.1200 398.8<1.0+18.8< 19.8<9.8200 448.7<1.0+19.7< 20.7<10.8200 498.6<1.0+20.6< 21.6<12.0200 548.4<1.0+22.2< 23.2<14.5200 598.3<1.0+23.4< 24.4<16.6200 648.1<1.0+23.5< 24.5<16.8200 698.0<1.0+25.0< 26.0<20.0200 747.8<1.0+26.2< 27.2<22.9200 797.7<1.0+27.2< 28.2<25.7200 847.5<1.0+27.2< 28.2<25.7200 897.5<1.0+27.2< 28.2<25.7200 947.2<1.0+27.8< 28.8<27.5200 997.1<1.0+28.5< 29.5<29.9500 ============================================================================== ==========SUMMARY========== All data is within limits ============================= Broad-band Antennas were used and both polarizations of emissions were measured Polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================ Date: 1999-07-30TEST REPORTPage 4 of 4 No.: HM101234 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC Rules. (2) Distance between the ET and measuring antenna: 3 meters. (3) Measuring instrumentation’s: CISPR Quasi-peak type field strength meter (25 MHz - 1000 MHz.). 6 dB bandwidth set at 120 KHz. Also, peak level of the fundamental emissions was measured in order to determine compliance with the 20dB peak to average limit specified in Section 15.35(b) of the FCC new Rules. (4) Measuring antenna: Broad band antenna for the frequency range 25-1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for measurement data. The antenna are capable of measuring both horizontal and vertical polarizations. (5) Frequency range scanned: The frequency range from 25 MHz to 1000 MHz had been searched. Readings of the highest emissions relating to the limit were reported as above. (6) Arrangement of EUT: During the test, the sample was operated at rated supply voltage and a…

Text truncated - open the document above for the full version.

Date:1999-07-30APPENDIX APage A1 of A1 No.: HM101234 TEST EQUIPMENT AUDIT Radiated Emission EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM007SPECTRUM ANALYZERH PHP85660B3144A2119211/06/99 EM008SPECTRUM ANALYZER DISPLAYH PHP85662A3144A2051411/06/99 EM009QUASI PEAK ADAPTORH PHP85650A3303A0170211/06/99 EM010RF PRESELECTORH PHP85685A3221A0141011/06/99 EM011ATTENNUATOR/SWITCHH PHP11713A2508A1059511/06/99 EM012PRE-AMPLIFIERH PHP8449B3008A0026211/06/99 EM013CONTROLLER (COMPUTER), COLOR MONITOR, KEYBOARD & MOUSE FLOPPY DRIVE H P H P H P HP9000 HP A1097C HP9133L 6226A60314 3151J39517 2623A02468 CM EM016ANTENNAARA INC.LPB-2513/A106930/12/97 EM072SIGNAL GENERATORHP8640B1948A1189230/03/98 EM083HKSTC OPEN AREA TEST SITEHKSTCN/AN/A25/02/99 ABBREVIATIONS: CM = Corrective Maintenance N/A = Not Applicable

Date: 1999-07-30TEST REPORTPage 1 of 4 No.: HM101234 __Law Man Kit________ ___Kitty Choy_____ ______Patrick Wong______ Patrick Wong Testing EngineerVerify byfor Managing Director Conditions in issuance of Test Report 1. This Report is issued in confidence to the client and it will be strictly treated as such by the Hong Kong Standards and Testing Centre Ltd. It may not be reproduced either in its entirety or in part and it may not be used for advertising. The client to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Hong Kong Standards and Testing Centre Ltd. to his customer, supplier or other persons directly concerned. The Hong Kong Standards and Testing Centre Ltd. will not, without the consent of the client, enter into any discussion or correspondence with any third party concerning the contents of the Report. 2. The report refers only to the sample tested and does not apply to the bulk, unless the sampling has been carried out by the Hong Kong Standards and Testing Centre Ltd. and is stated as such in the Report. 3. In the event of the improper use of the report, the Hong Kong Standards and Testing Centre Ltd. reserves the rights to withdraw it, and to adopt any other remedies which may be appropriate. 4. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Hong Kong Standards and Testing Centre Ltd. 5. The Hong Kong Standards and Testing Centre Ltd. will not be liable for or accept responsibility for any loss or damage howsoever arising from the use of information contained in any of its Reports or in any communication whatsoever about its said tests or investigations. 6. Applicants wishing to use the Report in court proceedings or arbitration shall inform the Hong Kong Standards and testing Centre Ltd. to that effect prior to submitting the sample for testing. APPLICANT: (CODE : SAI007) SANDER IND. CO. LTD. 10/F, HONG KONG MFG. BLDG., 128 WAI YIP ST., KWUN TONG, KOWLOON, HONG KONG. DATE OF SAMPLES RECEIVED: 1999.07.20 DATE OF TESTING: 1999.07.27. DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:PRO-MODERN C-CAR 49MHz - Receiver Manufacturer:SANDER TOYS MANUFACTURER (HUIZHOU) LTD. Model Number: S-2260RCB/RC Brand Name:SANDER Rating:3Vd.c. (“AA” size battery × 2) Origin:China Additional Model Number/Brand Name : S-2270RCB/RC, S-2280RCB/RC, S-2290RCB/RC, S-2320RCB/RC, S-2330RCB/RC, S-2340RCB/RC, S-2350RCB/RC, S-2380RCB/RC, S-2390RCB/RC INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the clause 15.109(a) & ANSI C63.4:1992 section 12.1.1.1-2 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 1999-07-30TEST REPORTPage 2 of 4 No.: HM101234 T E S T S U M M A R Y ***UNINTENTIONAL RADIATOR*** (A)Measurement of Radiated Emissions ....................................................... Satisfactory (B) Line Conducted Voltage Test. ................................................................. Not applicable T E S T D A T A Please refer to the attached result sheets. Date: 1999-07-30TEST REPORTPage 3 of 4 No.: HM101234 ***UNINTENTIONAL RADIATOR*** ** RECEIVER SECTION ** (A) Measurement of Radiated Interference ================================= TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109(a) TEST CONDITION : Normal TEST DATE : 1999.07.27. ============================================== Freq. to which Freq of thePolarizationMeter Antenna Field Strength FCC limit tuned emission H-V reading (at 3m) factor (at 3m) @ MHz MHz dB(μV) dB dB(μV/m) μV/m μV/m 49.86049.9H19.2+15.034.251.3100 99.7<1.0+12.2< 13.2<4.6150 149.6<1.0+9.8< 10.8<3.5150 199.4<1.0+11.5< 12.5<4.2150 249.3<1.0+15.9< 16.9<7.0200 299.1<1.0+17.0< 18.0<7.9200 349.0<1.0+17.2< 18.2<8.1200 398.8<1.0+18.8< 19.8<9.8200 448.7<1.0+19.7< 20.7<10.8200 498.6<1.0+20.6< 21.6<12.0200 548.4<1.0+22.2< 23.2<14.5200 598.3<1.0+23.4< 24.4<16.6200 648.1<1.0+23.5< 24.5<16.8200 698.0<1.0+25.0< 26.0<20.0200 747.8<1.0+26.2< 27.2<22.9200 797.7<1.0+27.2< 28.2<25.7200 847.5<1.0+27.2< 28.2<25.7200 897.5<1.0+27.2< 28.2<25.7200 947.2<1.0+27.8< 28.8<27.5200 997.1<1.0+28.5< 29.5<29.9500 ============================================================================== ==========SUMMARY========== All data is within limits ============================= Broad-band Antennas were used and both polarizations of emissions were measured Polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================ Date: 1999-07-30TEST REPORTPage 4 of 4 No.: HM101234 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC Rules. (2) Distance between the ET and measuring antenna: 3 meters. (3) Measuring instrumentation’s: CISPR Quasi-peak type field strength meter (25 MHz - 1000 MHz.). 6 dB bandwidth set at 120 KHz. Also, peak level of the fundamental emissions was measured in order to determine compliance with the 20dB peak to average limit specified in Section 15.35(b) of the FCC new Rules. (4) Measuring antenna: Broad band antenna for the frequency range 25-1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for measurement data. The antenna are capable of measuring both horizontal and vertical polarizations. (5) Frequency range scanned: The frequency range from 25 MHz to 1000 MHz had been searched. Readings of the highest emissions relating to the limit were reported as above. (6) Arrangement of EUT: During the test, the sample was operated at rated supply volta…

Text truncated - open the document above for the full version.

Date: 1999-07-30TEST REPORTPage A1 of A1 No.: HM101234APPENDIX A TEST EQUIPMENT AUDIT Radiated Emission EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM007SPECTRUM ANALYZERH PHP85660B3144A2119211/06/99 EM008SPECTRUM ANALYZER DISPLAYH PHP85662A3144A2051411/06/99 EM009QUASI PEAK ADAPTORH PHP85650A3303A0170211/06/99 EM010RF PRESELECTORH PHP85685A3221A0141011/06/99 EM011ATTENNUATOR/SWITCH-H PHP11713A2508A1059511/06/99 EM012PRE-AMPLIFIERH PHP8449B3008A0026211/06/99 EM013 CONTROLLER (COMPUTER), COLOR MONITOR, KEYBOARD & MOUSE FLOPPY DRIVE H P H P H P HP9000 HPA1097C HP9133L 6226A60314 3151J39517 2623A02468 CM EM017ANTENNAARA INC.LPB-2513/A106930/12/97 EM072SIGNAL GENERATORHP8640B1948A1189230/03/98 EM083HKSTC OPEN AREA TEST SITEHKSTCN/AN/A25/02/99 ABBREVIATIONS: CM = Corrective Maintenance N/A= Not Applicable

Date: 1999-07-30TEST REPORTPage 1 of 4 No.: HM101234 ____________________ ____________________ ____________________ Patrick Wong Testing EngineerVerify byfor Managing Director Conditions in issuance of Test Report 1. This Report is issued in confidence to the client and it will be strictly treated as such by the Hong Kong Standards and Testing Centre Ltd. It may not be reproduced either in its entirety or in part and it may not be used for advertising. The client to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Hong Kong Standards and Testing Centre Ltd. to his customer, supplier or other persons directly concerned. The Hong Kong Standards and Testing Centre Ltd. will not, without the consent of the client, enter into any discussion or correspondence with any third party concerning the contents of the Report. 2. The report refers only to the sample tested and does not apply to the bulk, unless the sampling has been carried out by the Hong Kong Standards and Testing Centre Ltd. and is stated as such in the Report. 3. In the event of the improper use of the report, the Hong Kong Standards and Testing Centre Ltd. reserves the rights to withdraw it, and to adopt any other remedies which may be appropriate. 4. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Hong Kong Standards and Testing Centre Ltd. 5. The Hong Kong Standards and Testing Centre Ltd. will not be liable for or accept responsibility for any loss or damage howsoever arising from the use of information contained in any of its Reports or in any communication whatsoever about its said tests or investigations. 6. Applicants wishing to use the Report in court proceedings or arbitration shall inform the Hong Kong Standards and testing Centre Ltd. to that effect prior to submitting the sample for testing. APPLICANT: (CODE : SAI007) SANDER IND. CO. LTD. 10/F, HONG KONG MFG. BLDG., 128 WAI YIP ST., KWUN TONG, KOWLOON, HONG KONG. DATE OF SAMPLES RECEIVED: 1999.07.20 DATE OF TESTING: 1999.07.27. DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:PRO-MODERN C-CAR 49MHz - Receiver Manufacturer:SANDER TOYS MANUFACTURER (HUIZHOU) LTD. Model Number: S-2260RCB/RC Brand Name:SANDER Rating:3Vd.c. (“AA” size battery × 2) Origin:China Additional Model Number/Brand Name : S-2270RCB/RC, S-2280RCB/RC, S-2290RCB/RC, S-2320RCB/RC, S-2330RCB/RC, S-2340RCB/RC, S-2350RCB/RC, S-2380RCB/RC, S-2390RCB/RC INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the clause 15.109(a) & ANSI C63.4:1992 section 12.1.1.1-2 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 1999-07-30TEST REPORTPage 2 of 4 No.: HM101234 T E S T S U M M A R Y ***UNINTENTIONAL RADIATOR*** (A)Measurement of Radiated Emissions ....................................................... Satisfactory (B) Line Conducted Voltage Test. ................................................................. Not applicable T E S T D A T A Please refer to the attached result sheets. Date: 1999-07-30TEST REPORTPage 3 of 4 No.: HM101234 ***UNINTENTIONAL RADIATOR*** ** RECEIVER SECTION ** (A) Measurement of Radiated Interference ================================= TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109(a) TEST CONDITION : Normal TEST DATE : 1999.07.27. ============================================== Freq. to which Freq of thePolarizationMeter Antenna Field Strength FCC limit tuned emission H-V reading (at 3m) factor (at 3m) @ MHz MHz dB(μV) dB dB(μV/m) μV/m μV/m 49.86049.9H19.2+15.034.251.3100 99.7<1.0+12.2< 13.2<4.6150 149.6<1.0+9.8< 10.8<3.5150 199.4<1.0+11.5< 12.5<4.2150 249.3<1.0+15.9< 16.9<7.0200 299.1<1.0+17.0< 18.0<7.9200 349.0<1.0+17.2< 18.2<8.1200 398.8<1.0+18.8< 19.8<9.8200 448.7<1.0+19.7< 20.7<10.8200 498.6<1.0+20.6< 21.6<12.0200 548.4<1.0+22.2< 23.2<14.5200 598.3<1.0+23.4< 24.4<16.6200 648.1<1.0+23.5< 24.5<16.8200 698.0<1.0+25.0< 26.0<20.0200 747.8<1.0+26.2< 27.2<22.9200 797.7<1.0+27.2< 28.2<25.7200 847.5<1.0+27.2< 28.2<25.7200 897.5<1.0+27.2< 28.2<25.7200 947.2<1.0+27.8< 28.8<27.5200 997.1<1.0+28.5< 29.5<29.9500 ============================================================================== ==========SUMMARY========== All data is within limits ============================= Broad-band Antennas were used and both polarizations of emissions were measured Polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================ Date: 1999-07-30TEST REPORTPage 4 of 4 No.: HM101234 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC Rules. (2) Distance between the ET and measuring antenna: 3 meters. (3) Measuring instrumentation’s: CISPR Quasi-peak type field strength meter (25 MHz - 1000 MHz.). 6 dB bandwidth set at 120 KHz. Also, peak level of the fundamental emissions was measured in order to determine compliance with the 20dB peak to average limit specified in Section 15.35(b) of the FCC new Rules. (4) Measuring antenna: Broad band antenna for the frequency range 25-1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for measurement data. The antenna are capable of measuring both horizontal and vertical polarizations. (5) Frequency range scanned: The frequency range from 25 MHz to 1000 MHz had been searched. Readings of the highest emissions relating to the limit were reported as above. (6) Arrangement of EUT: During the test, the sample was operated at rated supply voltage …
