OPGX800GSM mobile phone

GSM mobile phone User Manual FCC ID: OPGX800 Brand Name: XPHONEX Model Name: X800 -1- Content 1 General Information ................................................................................................................................................. 3 1.1 Profile .............................................................................................................................................................. 3 1.2 Safety Information .......................................................................................................................................... 3 1.3 Safety warning and Attentions ........................................................................................................................ 3 2 Your phone ................................................................................................................................................................. 6 2.1 Phone overview ............................................................................................................................................... 6 2.2 Functions of Keys ........................................................................................................................................... 6 2.3 Technical specifications .................................................................................................................................. 8 3 Getting started ........................................................................................................................................................... 8 3.1 Installing the SIM Cards and the Battery ........................................................................................................ 8 3.2 Installing T-Flash Card .................................................................................................................................. 10 3.3 Charging the Battery ...................................................................................................................................... 11 3.4 Powering On/Off the Mobile Phone ............................................................................................................. 13 3.5 Linking to the Network ................................................................................................................................. 14 3.6 Dialing Calls ................................................................................................................................................. 14 3.7 Using the Headset ......................................................................................................................................... 15 -2- 4 Input method ........................................................................................................................................................... 15 4.1 Icons for Input Methods ................................................................................................................................ 15 4.2 To Shift Entry Methods ................................................................................................................................. 16 4.3 Numeric Input ............................................................................................................................................... 16 4.4 English input and numeric input: .................................................................................................................. 16 4.5 Inserting a Symbol ........................................................................................................................................ 17 5 Using the menu ........................................................................................................................................................ 17 5.1 Phonebook..................................................................................................................................................... 17 5.2 Call logs ........................................................................................................................................................ 18 5.3 Calendar ........................................................................................................................................................ 20 5.4 Multimedia .................................................................................................................................................... 20 5.5 Messages ....................................................................................................................................................... 22 5.6 Tools .............................................................................................................................................................. 23 5.7 File ................................................................................................................................................................ 24 5.8 Manage Connections ..................................................................................................................................... 25 5.9 Settings .......................................................................................................................................................... 26 5.10 Profile ............................................................................................................................................................ 29 5.11 Pastime .......................................................................................................................................................... 30 -3- 6 Appendix .................................................................................................................................................................. 31 1 General Information 1.1 Profile Please read this pamphlet carefully in order to make…

Text truncated - open the document above for the full version.

July 11, 2012 Federal Communication Commission Authorization and Evaluation Division FCC ID: OPGX800 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List 5: Tune Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, HONG KONG ESKY INDUSTRIAL LIMITED Contact person: Alice Yan Title: CEO

HONG KONG ESKY INDUSTRIAL LIMITED FLAT/RM B27 BLK B 1/F EAST SUN INDUSTRIAL CENTRE 16 SHING YIP STREET KWUN TONG KL, HONG KONG, CHINA FAX: 0755‐83326511 Date: July 11, 2012 Statement We, HONG KONG ESKY INDUSTRIAL LIMITED states that our device, FCC ID: OPGX800, has no space to put the label except the battery compartment of this device. It is visible to the users as they purchase the products and install the battery. Sincerely yours,

TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FRONT VIEW OF SAMPLE BACK VEIW OF SAMPLE ALL VIEW OF SAMPLE

Mod FCC Mad e FCC ID GSM el:X800 ID:OPGX8 0 e In China Label Lo M mobile ph 00 ocation hone XPHONEX X

OPEN VIEW OF SAMPLE-1 OPEN VIEW OF SAMPLE-2 OPEN VIEW OF SAMPLE-3 INTERNAL VIEW OF SAMPLE-1 GSM Antenna INTERNAL VIEW OF SAMPLE-2 INTERNAL VIEW OF SAMPLE-3 Bluetooth Antenna

FCC Test Report Report No.: AGCX0J120601F1 FCC ID : OPGX800 PRODUCT DESIGNATION : GSM mobile phone BRAND NAME : XPHONEX MODEL NAME : X800 CLIENT : HONG KONG ESKY INDUSTRIAL LIMITED DATE OF ISSUE : July 10, 2012 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd. CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGCX0J120601F1 Page 1 of 22 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ............................................................................................................... 2 2. PRODUCT INFORMATION ........................................................................................................................... 3 3. TEST FACILITY ............................................................................................................................................. 4 4. SUPPORT EQUIPMENT LIST ....................................................................................................................... 5 5. SYSTEM DESCRIPTION ............................................................................................................................... 5 6. TEST MODE .................................................................................................................................................. 5 7. SUMMARY OF TEST RESULTS ................................................................................................................... 6 8. MEASUREMENT UNCERTAINTY ................................................................................................................. 6 9. FCC LINE CONDUCTED EMISSION TEST .................................................................................................. 7 9.1 TEST EQUIPMENT OF LINE CONDUCTED EMISSION TEST ................................................................ 7 9.2 LIMITS OF LINE CONDUCTED EMISSION TEST .................................................................................... 7 9.3 BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST .................................................................. 7 9.4 PROCEDURE OF LINE CONDUCTED EMISSION TEST......................................................................... 8 9.5 TEST RESULT OF LINE CONDUCTED EMISSION TEST ....................................................................... 9 10. FCC RADIATED EMISSION TEST ............................................................................................................ 11 10.1 TEST EQUIPMENT OF RADIATED EMISSION .................................................................................... 11 10.2 LIMITS OF RADIATED EMISSION TEST .............................................................................................. 11 10.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ........................................................................... 11 10.4 PROCEDURE OF RADIATED EMISSION TEST .................................................................................. 12 10.5 TEST RESULT OF RADIATED EMISSION TEST ................................................................................. 13 APPENDIX 1 .................................................................................................................................................... 15 PHOTOGRAPHS OF TEST SETUP ................................................................................................................ 15 APPENDIX 2 .................................................................................................................................................... 16 PHOTOGRAPHS OF EUT ............................................................................................................................... 16 Report No.: AGCX0J120601F1 Page 2 of 22 1. VERIFICATION OF COMPLIANCE Applicant: HONG KONG ESKY INDUSTRIAL LIMITED FLAT/RM B27 BLK B 1/F EAST SUN INDUSTRIAL CENTRE 16 SHING YIP STREET KWUN TONG KL Manufacturer: HONG KONG ESKY INDUSTRIAL LIMITED FLAT/RM B27 BLK B 1/F EAST SUN INDUSTRIAL CENTRE 16 SHING YIP STREET KWUN TONG KL Product Designation: GSM mobile phone Brand name: XPHONEX Test Model: X800 FCC ID: OPGX800 Measurement Procedure: ANSI C63.4: 2003 File Number: AGCX0J120601F1 Date of test: June 30, 2012 to July 09, 2012 Deviation: None Condition of Test Sample: Normal The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2003. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Tested By : Leo Lee July 10, 2012 Reviewed By : Forrest Lei July 10, 2012 Approved By: Solger Zhang July 10, 2012 Report No.: AGCX0J120601F1 Page 3 of 22 2. PRODUCT INFORMATION I/O Port Information ( Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with USB port 1 1.0 m, unshielded 1 Housing Type: Plastic and Metal EUT Rating Voltage: DC 3.7V by battery Adapter Input AC100~240V,50/60Hz,0.15A Adapter Output DC5.0V,500mA ±50mA Report No.: AGCX0J120601F1 Page 4 of 22 3. TEST FACILITY Facility Attestation of Global Compliance (Shenzhen) Co., Ltd. Location: 2/F., Building 2, No.1-No.4, Chaxi Sanwei Technical Industrial Park, Gushu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Description: The test site is constructed and calibrated to meet the FCC requirements in documents ANSI C63.4:2003. Site Filing: The FCC Registration Number is 259865 Instrument Tolerance: All measuring equipment is in accord with ANSI C63.4 requirements that meet industry regulatory agency and accreditation agency requirement.…

Text truncated - open the document above for the full version.

FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
