OQ8-1302-1R/C For Model Trains

Date: 2000-01-13TEST REPORTPage 1 of 7 No.: HM102051 Law Man KitKitty ChoyPatrick Wong Testing EngineerVerify byPatrick Wong for Managing Director APPLICANT: (CODE : SAK001) LIFE-LIKE PRODUCTS INC. 1600 UNION AVENUE, BALTIMORE, MD 21211, U.S.A. DATE OF SAMPLES RECEIVED: 1999.12.11 DATE OF TESTING: 1999.12.23. DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:R/C FOR TRAINS Manufacturer:SANDA KAN INDUSTRIAL LTD. Model Number: 1302 Brand Name:LIFE-LIKE Rating:120.0Va.c. Origin:CHINA INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED with the clause 15.109(a) & ANSI C63.4:1992 section 12.1.1.1-2 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 2000-01-13TEST REPORTPage 2 of 7 No.: HM102051 T E S T S U M M A R Y ***UNINTENTIONAL RADIATOR*** (A) Measurement of Radiated Emissions .......................................................Satisfactory (B) Line Conducted Voltage Test. .................................................................Satisfactory T E S T D A T A Please refer to the attached result sheets. Date: 2000-01-13TEST REPORTPage 3 of 7 No.: HM102051 ***UNINTENTIONAL RADIATOR*** ** RECEIVER SECTION ** (A) Measurement of Radiated Interference TEST REFERENCE:FCC Rules Part 15 Subpart B section 15.107(a) TEST CONDITION:Normal TEST DATE:1999.12.23 Freq. to which tuned Freq. of the emission PolarizationMeter reading (at 3m) Antenna factor Field Strength (at 3m)FCC Limit MHz MHz H-VdB dB(μV)μV/mμV/m 49.849.8V19.1+15.034.150.7100 99.7<1.0+12.2<13.2<4.6150 149.5<1.0+9.8<10.8<3.5150 199.3<1.0+11.5<12.5<4.2150 249.2<1.0+15.9<16.9<7.0200 299.0<1.0+17.0<18.0<7.9200 348.8<1.0+17.2<18.2<8.1200 398.6<1.0+18.8<19.8<9.8200 448.5<1.0+19.7<20.7<10.8200 498.3<1.0+20.6<21.6<12.0200 543.1<1.0+22.2<23.2<14.5200 598.0<1.0+23.4<24.4<16.6200 647.8<1.0+23.5<24.5<16.8200 697.4<1.0+25.0<26.0<20.0200 747.5<1.0+26.3<27.2<22.9200 797.3<1.0+27.2<28.2<25.7200 847.1<1.0+26.6<28.2<25.7200 896.9<1.0+27.1<28.2<25.7200 946.8<1.0+28.0<28.8<27.5200 996.6<1.0+28.5<29.5<29.9500 ==========SUMMARY========== All data is within limits ============================= Broad-band Antennas were used and both polarizations of emissions were measured Polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================ Date: 2000-01-13TEST REPORTPage 4 of 7 No.: HM102051 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC Rules. (2) Distance between the EUT and measuring antenna: 3 meters. (3) Measuring instrumentation’s: CISPR Quasi-peak type field strength meter (25 MHz - 1000 MHz.). 6 dB bandwidth set at 120 KHz. Also, peak level of the fundamental emissions was measured in order to determine compliance with the 20dB peak to average limit specified in Section 15.35(b) of the FCC new Rules. (4) Measuring antenna: Broad band antenna for the frequency range 25-1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable included in the Antenna Factor for measurement data. The antenna are capable of measuring both horizontal and vertical polarizations. (5) Frequency range scanned: The frequency range from 25 MHz to 1000 MHz had been searched. Readings of the highest emissions relating to the limit were reported as above. (6) Arrangement of EUT: During the test, the sample was operated at rated supply voltage and arranged for maximum emissions. (7) Measuring Procedure: In accordance with the relevant clauses of the FCC Rules Part 15 section 15.109(a) and ANSI C63.4:1992 section 12.1.1.1-2. For superregenerative receivers, an independent signal generator had been used to radiated an unmodulated were (cw) signal to the receiver at its operating frequency in order to “cohere” or resolve the individual components of the characteristic broadband emission from such a receiver. The level of such signal may need to be adjusted in order to accomplish this. (8) Measuring Uncertainty: The calculated uncertainty for measurement performed at 3M test distance are:- 30MHz to 300MHz = ± 3.7dB, 300MHz to 1000MHz = + 3.0dB/-2.7dB. Remark: Purpose of this test is to provide the Applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under FCC’s Equipment Authorization Program. This test itself is not an Approval Test. Date: 2000-01-13TEST REPORTPage 5 of 7 No.: HM102051 *** RECEIVER *** (2) Measurement of Line-Conducted Voltage onto AC Power Line TEST REFERENCE:FCC Rules Part 15 Subpart B Section 15.107(a) (Class B) TEST CONDITION:Normal TEST DATE:1999.12.23 (1) Between "Live" and "Ground” Frequency Range of Emission Maximum Measured Radio NoiseFCC Limit (Class B) MHz dB(μV)μVμV 0.45 - 0.824.5416.87250.00 0.8 - 1.622.0612.68250.00 1.6 - 3.019.599.54250.00 3.0 - 5.019.449.38250.00 5.0 - 7.018.828.73250.00 7.0 - 9.019.779.74250.00 9.0 - 11.022.4813.30250.00 11.0 - 13.023.9615.78250.00 13.0 - 15.026.7021.63250.00 15.0 - 17.031.8739.22250.00 17.0 - 19.00.001.00250.00 19.0 - 21.0<36.5467.14250.00 21.0 - 23.00.001.00250.00 23.0 - 25.039.9699.54250.00 25.0 - 27.0<29.8631.12250.00 27.0 - 30.00.001.00250.00 - End - ================= SUMMARY =================== All data is within limits ========================================== Date: 2000-01-13TEST REPORTPage 6 of 7 No.: HM102051 (2) Measurement of Line-Conducted Voltage onto AC Power Line TEST REFERENCE:FCC Rules Part 15 Subpart B Section 15.107(a) (Class B) TEST CONDITION:Normal TEST DATE:1999.12.23 (1) Between "Neutral” and "Ground” Frequency Range of Emission Maximum Measured Radio NoiseFCC Limit (Class B) MHz dB(μV)μVμV 0.45 - 0.835.…

Text truncated - open the document above for the full version.

Date: 2000-01-13 TEST REPORT Page A1 of A1 No.: HM102051 APPENDIX A TEST EQUIPMENT AUDIT Radiated Emission EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL. EM007SPECTRUM ANALYZERHEWLETT PACKARDHP85660B3144A2119211/06/99 EM008SPECTRUM ANALYZER DISPLAYHEWLETT PACKARDHP85662A3144A2051411/06/99 EM009QUASI PEAK ADAPTORHEWLETT PACKARDHP85650A3303A0170211/06/99 EM010RF PRESELECTORHEWLETT PACKARDHP85685A3221A0141011/06/99 EM011ATTENNUATOR/SWITCHHEWLETT PACKARDHP11713A2508A1059511/06/99 EM012PRE-AMPLIFIERHEWLETT PACKARDHP8449B3008A0026211/06/99 EM013CONTROLLER (COMPUTER), COLOR MONITOR, KEYBOARD & MOUSE FLOPPY DRIVE HEWLETT PACKARD HEWLETT PACKARD HEWLETT PACKARD HP9000 HP A1097C HP9133L 6226A60314 3151J39517 2623A02468 CM EM017ANTENNAARA INC.LPB-2513/A1069TBD EM072SIGNAL GENERATORHEWLETT PACKARD8640B1948A1189230/03/98 EM083HKSTC OPEN AREA TEST SITEHKSTCN/AN/A25/02/99 EM145EMI TEST RECEIVERR & SESCS 30830245/02110/05/99 EM080LARGE SCREENED ROOMMIKO INST HKN/AN/A09/09/99 Remarks:- CMCorrective Maintenance N/ANot Applicable or Not Available TBDTo Be Determined
