©1999 Navia Aviation AS NORMARC 7000 INSTRUMENT LANDING SYSTEM Installation & Commissioning Handbook Vol. 1 and Vol. 2 ©1999 Navia Aviation AS Following relevant system alternatives are covered by this manual: * The actual system chosen for a given location is site dependant. LLZ model DescriptionAntenna model DescriptionIntended category * NM 7011 single frequencyNM 35226 elementCat I NM 7011single frequencyNM 3523B 12 elementCat I, Cat II NM 7013dual frequencyNM 352412 elementCat I, Cat II NM 7013dual frequencyNM 352524 elementCat II NM 7013dual frequencyNM 352616 elementCat I, Cat II GP model DescriptionAntenna model DescriptionIntended category * NM 7031single frequencyNM 3543Null referenceCat I, Cat II NM 7031single frequencyNM 3544SB referenceCat I, Cat II NM 7033dual frequencyNM 3545M-arrayCat I, Cat II MKR model DescriptionAntenna model DescriptionIntended category * NM 7050 Marker BeaconNM 3561Single Antenna N.A. NM 7050 Marker BeaconNM 3562Dual AntennaN.A

© 1999 Navia Aviation AS 21465-3.0 NORMARC 7000 INSTRUMENT LANDING SYSTEM Installation & Commissioning Handbook Vol. 1 1250$5& ã1DYLD$YLDWLRQ$6 ,167580(17/$1',1*6<67(0 ,167$//$7,21 &200,66,21,1*+$1'%22. RECORD OF CHANGES NM 7000 series Part no.: 21465 Change No.:Section:Entered by:Rev.: Section 13.0. Section 23.0. Section 33.0. Section 43.0. Section 53.0. Section 63.0. Change No.:Description: 1250$5& ã1DYLD$YLDWLRQ$6 ,167580(17/$1',1*6<67(0 ,167$//$7,21 &200,66,21,1*+$1'%22. TABLE OF CONTENTS Installation and Commissioning Handbook Vol. 1 NM 7000 Series For further information, please look up Installation & Commissioning Handbook Volume 2, containing drawings and parts lists. SECTION 1ANTENNA INSTALLATION PROCEDURES SECTION 2SHELTER INSTALLATION SECTION 3ANTENNA SYSTEMS ADJUSTMENTS PROCEDURES Chapter 1NM 35226-element Array Chapter 2NM 3523B12-element Single Frequency Array Chapter 3NM 352412-element Dual Frequency Array Chapter 4NM 352524-element Array Chapter 5NM 352616-element Array Chapter 6NM 3543Null-Reference Glide Path Chapter 7NM 3544Sideband-Reference Glide Path Chapter 8NM 3545M-array Glide Path Chapter 9NM 3561Marker Beacon System Chapter 10NM 3562Dual Antenna Marker Beacon SECTION 4EQUIPMENT TEST AND ADJUSTMENTS SECTION 5APPENDIX Chapter 1Ground commissioning document Localizer Chapter 2Ground commissioning document Glide Path Chapter 3Ground commissioning document Marker Beacon Chapter 4Ground commissioning document Far Field Monitor SECTION 6APPENDIX Diagrams Instructions for coax connectors 1250$5& ã1DYLD$YLDWLRQ$6 ,167580(17/$1',1*6<67(0 ,167$//$7,21 &200,66,21,1*+$1'%22. SECTION 1 ANTENNA INSTALLATION PROCEDURE Table of contents 1 Civil Work Checks .................................................................................................... 3 1.1 Unpacking .......................................................................................................... 3 2 Localizer Antenna System Assembly ..................................................................... 5 2.1 Positioning of antenna frame work ..................................................................... 5 2.2 Framework assembly ......................................................................................... 5 2.3 Cable duct assembly .......................................................................................... 6 2.4 Antenna assembly.............................................................................................. 6 2.5 Anntenna cables................................................................................................. 6 2.6 Near Field monitor antenna installation.............................................................. 9 2.7 Cable installation NF .......................................................................................... 9 3 Glidepath antenna system assembly/towers 10m and 15m ................................. 11 3.1 General............................................................................................................... 11 3.2 Bottom Section ................................................................................................... 12 3.2.1 Vertical Beams............................................................................................. 12 3.2.2 Bottom Flange ............................................................................................. 12 3.2.3 Diagonal struts ............................................................................................. 13 3.2.4 Third vertical leg .......................................................................................... 13 3.2.5 Ladder.......................................................................................................... 13 3.2.6 Locking of nuts............................................................................................. 13 3.3 Middle section .................................................................................................... 13 3.3.1 Vertical legs ................................................................................................. 13 3.4 Top section......................................................................................................... 13 3.4.1 General ........................................................................................................ 13 3.4.2 Horizontal struts ........................................................................................... 13 3.5 Obstruction light ................................................................................................. 13 3.5.1 Obstruction light bracket .............................................................................. 13 3.5.2 Obstruction light ........................................................................................... 14 3.6 Antenna suport ................................................................................................... 14 3.6.1 Adjustment rails ........................................................................................... 14 3.6.2 Mounting of supports ................................................................................... 14 3.6.3 Antenna assembly ....................................................................................... 14 3.7 Cable trunks ....................................................................................................... 14 3.7.1 Cable trunk brackets .................................................................................... 14 3.7.2 Antenna cables ............................................................................................ 15 3.8 Antenna mast erection ....................................................................................... 15 3.8.1 Erection of the mast ..................................................................................... 15 3.…

Text truncated - open the document above for the full version.

© 1999 Navia Aviation AS21466-3.0 NORMARC 7000 INSTRUMENT LANDING SYSTEM Installation & Commissioning Handbook Vol. 2 NORMARC 7000INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS21466-3.01-1 TABLE OF CONTENTS Installation and Commissioning Handbook Vol. 2 NM 7000 Series SECTION 1SITE IMPLEMENTATIONS SECTION 2LOCALIZER SECTION 3GLIDE PATH SECTION 4MARKER BEACON For further information, please look up Installation & Commissioning Handbook Volume 1. NORMARC 7000INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS21466-3.0TABLE OF CONTENTS SECTION 1 SITE IMPLEMENTATIONS Site Implementation 115991A3 Site Implementation 216588A3 NORMARC 7000INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS21466-3.0TABLE OF CONTENTS SECTION 2 LOCALIZER Chapter 1.CONFIGURATIONS Typical configuration 1 LLZ on course line15989A3 Typical configuration 2 LLZ off set16584A3 Chapter 2.SHELTER INSTALLATION MECHANICAL System rack16138A3 Shelter installation16266A4 Chapter 3.SHELTER INSTALLATION ELECTRICAL Diagram el. installation14220A3 Battery and tele installation15975A3 El. installation15976A3 Grounding15977A3 Chapter 4.EQUIPMENT INST. DIAGRAMS NM 3522 1-frekv 6-element16585A3 NM 3523B 1-frekv 12-element16939A3 NM 3524 2-frekv 12-element15986A3 NM 3525 2-frekv 24-element16346A3 NM 3526 2-frekv 16-element16577A3 Chapter 5.ANTENNA FOUNDATION NM 3522 1-frekv 6-element16385A3 NM 3523B 1-frekv 12-element16875A3 NM 3524 2-frekv 12-element16390A3 NM 3525 2-frekv 24-element16392A3 NM 3526 2-frekv 16-element16358A3 Chapter 6.ANTENNA ASSEMBLY NM 3522Antenna assembly16386A3 NM 3522Parts List2134 NM 3522Mechanical details16373A3 NM 3522Cable duct16384A3 NM 3522ADU/MCU assembly16361A3 NM 3522ADU/MCU cables in duct10288A4 NORMARC 7000 INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS 21466-3.0 TABLE OF CONTENTS Chapter 6. ANTENNA ASSEMBLY (Continued) NM 3523B Antenna assembly 16874A3 NM 3523B Parts List 2748 NM 3523B Mechanical details 16876A3 NM 3523B Cable duct 16857A3 NM 3523B ADU/MCU assembly 16361A3 NM 3523B ADU/MCU cables in duct 10288A4 NM 3524 Antenna assembly 16389A3 NM 3524 Parts List 2136 NM 3524 Mechanical details 16413A3 NM 3524 Cable duct 16416A3 NM 3424 ADU/MCU assembly 16361A3 NM 3524 ADU/MCU cables in duct 10288A4 NM 3525 Antenna assembly 16391A3 NM 3525 Parts List 2137 NM 3525 Mechanical details 16414A3 NM 3525 Cable duct 16417A3 NM 3525 ADU/MCU assembly 16361A3 NM 3525 ADU/MCU cables in duct 10288A4 NM 3526 Antenna assembly 16362A3 NM 3526 Parts List 2670 NM 3526 Mechanical details 16430A3 NM 3526 Cable duct 16429A3 NM 3526 ADU/MCU assembly 16361A3 NM 3526 ADU/MCU cables in duct 10288A4 Chapter 7. OBSTRUCTION LIGHT OL 522 Installation 11463A3 OL 522 Wiring 6348A4 Chapter 8. NEAR FIELD MONITOR LLZ NF-Antenna foundation 6245A3 NF-Assembly 14256A3 NF-Assembly w/Obstruction Light 16806A3 Chapter 9. GROUNDING LLZ-NF Grounding 8467A4 LLZ-NF Aperture grounding 6346A4 NORMARC 7000INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS21466-3.0TABLE OF CONTENTS SECTION 3 GLIDE PATH Chapter 1.CONFIGURATIONS Typical configuration15990A3 Chapter 2.SHELTER INSTALLATION MECHANICAL System rack16138A3 Shelter installation I RWY to the right16212A4 Shelter installation II RWY to the left16265A4 Chapter 3.SHELTER INSTALLATION ELECTRICAL Diagram el. Installation14220A3 Battery and tele installation15975A3 El. Installation15976A3 Grounding15977A3 Chapter 4.EQUIPMENT INST. DIAGRAM NM 3543 Null reference16587A3 NM 3544 Sideband reference15988A3 NM 3545 M-array16375A3 NM 3546 Modified M-array16586A3 Chapter 5.ANTENNA FOUNDATION NM 3543 - 46 Antenna Foundation7084A3 Template Foundation bolts16644A4 Chapter 6.ANTENNA MAST ASSEMBLY NM 3543 - 44 10 m16641A3 NM 3545 - 46 15 m16642A3 Mast Section Assembly16612A3 Vertical Adjustment Frame16643A3 Assembly Adapter Kathrein antenna16792A3 Suppliers drawings supplied with mast. Chapter 7.OBSTRUCTION LIGHTS Obstruction Light wiring6344A4 NORMARC 7000INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS21466-3.0TABLE OF CONTENTS Chapter 8.NEAR FIELD MOITOR GP NF-Antenna Foundation6798A3 NF-Antenna Assembly7058A3 Chapter 9.GROUNDING NM 3543 - 44 Grounding6345A4 NM 3545 - 46 Grounding16475A4 NORMARC 7000INSTALLATION & COMMISSIONING HANDBOOK INSTRUMENT LANDING SYSTEM 1999 NAVIA AVIATION AS21466-3.0TABLE OF CONTENTS SECTION 4 MARKER BEACON Chapter 1.CONFIGURATIONS NM 3561 1- Element Marker Beacon7059A3 NM 3562 2- Element Marker Beacon (Distr. Netw. inside)7109A3 NM 3562 2- Element Marker Beacon (Distr. Netw. outside)16583A3 Marker Beacon Mast w/Kathrein Antenna Adapter14460A4 Chapter 2.SHELTER INSTALLATION MECHANICAL MB Equipment Shelter13258A3 Chapter 3.EQUIPMENT INST. DIAGRAM Marker Beacon Single Antenna17174A3 Marker Beacon Dual Antenna17173A3 Chapter 4.MARKER BEACON FOUNDATION Antenna Foundation6798A3 Chapter 5.GROUNDING MB Grounding8468A4

©1999 Navia Aviation AS NORMARC 7011 INSTRUMENT LANDING SYSTEM GENERAL DESCRIPTION ©1999 Navia Aviation AS ©1999 Navia Aviation ASTable of contents GENERAL DESCRIPTIONNORMARC 7011 INSTRUMENT LANDING SYSTEM iii TABLE OF CONTENTS DESCRIPTION OF NORMARC 7011 1-FREQUENCY LOCALIZER SYSTEM.1 1 GENERAL DESCRIPTION ..............................................................................1 1.1 Technical Specification....................................................................................... 1 1.1.1 Signal Minimum Performance LLZ .............................................................. 1 1.1.2 Environmental Characteristics ..................................................................... 2 1.1.3 EMC Characteristics .................................................................................... 2 1.1.4 Mechanical Characteristics .......................................................................... 2 1.1.5 Power Supply............................................................................................... 3 1.2 General Information............................................................................................ 3 1.2.1 Introduction ................................................................................................. 3 1.2.2 Product Type Numbers ................................................................................ 6 1.2.3 Abbreviations ............................................................................................... 7 2 PHYSICAL ORGANIZATION ...........................................................................8 2.1 Module and Assembly Location ......................................................................... 8 2.2 Power Supply ..................................................................................................... 8 3 SYSTEM DESCRIPTION.................................................................................12 3.1 Overview ............................................................................................................ 12 3.2 Physical Description ........................................................................................... 12 3.3 Monitors.............................................................................................................. 13 3.4 Transmitters / Modulators................................................................................... 13 3.5 TX Control .......................................................................................................... 13 3.6 Remote Monitoring (RMS) Unit .......................................................................... 14 3.7 Remote Control Unit........................................................................................... 14 3.8 Remote Slave Panel........................................................................................... 14 3.9 Remote Maintenance Monitoring (RMM) ........................................................... 14 3.9.1 RMM Access................................................................................................ 16 3.9.2 Local Keyboard/Display Functions .............................................................. 16 3.9.3 Diagnostic functions..................................................................................... 17 4 ELECTRICAL INSTALLATION ........................................................................18 4.1 Connection Overview ......................................................................................... 18 4.2 Power and Battery.............................................................................................. 18 4.3 RF Inputs............................................................................................................ 19 4.4 RF Outputs ......................................................................................................... 20 4.5 DC Loop ............................................................................................................. 21 4.6 Remote Control .................................................................................................. 22 4.7 PC and Modem .................................................................................................. 23 4.8 DME ................................................................................................................... 24 4.9 Analog Inputs ..................................................................................................... 25 4.10 Digital Inputs and Outputs .................................................................................. 26 4.11 Battery Warning.................................................................................................. 27 4.12 Remote control connections............................................................................... 28 4.13 Remote slave connection ................................................................................... 30 4.14 Interlock switch connection ................................................................................ 31 GENERAL DESCRIPTION iv NORMARC 7011 INSTRUMENT LANDING SYSTEM Table of contents©1999 Navia Aviation AS ©1999 Navia Aviation ASList of Figures GENERAL DESCRIPTIONNORMARC 7011 INSTRUMENT LANDING SYSTEM v LIST OF FIGURES Figure1-1 Typical ILS installation .......................................................................... 3 Figure1-2 Localizer block diagram ........................................................................ 4 Figure1-3 Localizer Antenna ................................................................................. 5 Figure1-4 Localizer Cabinet Installation ............................................................... 5 Figure1-5 Localizer Cabinet External Label .......................................................... 6 Figure2-1 NM 7011 Module Location - Front view. ............................................... 9 …

Text truncated - open the document above for the full version.

NORMARC 7011 INSTRUMENT LANDING SYSTEM Technical Handbook 21823-3.6 ©1999 Navia Aviation AS TECHNICAL HANDBOOK ©1999 Navia Aviation AS21823-3.6 i TECHNICAL HANDBOOK NORMARC 7011 TABLE OF CONTENTS NORMARC 7011 INSTRUMENT LANDING SYSTEM Table of contents PART I INTRODUCTION .....................................................................................1-1 1 GENERAL INFORMATION.............................................................................1-1 1.1 Introduction........................................................................................................ 1-1 1.1.1 ILS Overview ............................................................................................... 1-1 1.1.2 Localizer Overview ...................................................................................... 1-1 1.1.3 Localizer Description ................................................................................... 1-2 1.2 Product Type Numbers ...................................................................................... 1-2 1.3 Abbreviations...................................................................................................... 1-3 2 PHYSICAL ORGANIZATION ..........................................................................2-1 2.1 Module and Assembly Location ......................................................................... 2-1 2.2 Service Kit Assembly.......................................................................................... 2-1 2.3 Power Supply ..................................................................................................... 2-1 3 SYSTEM DESCRIPTION................................................................................3-1 3.1 Overview ............................................................................................................ 3-1 3.2 Physical Description ........................................................................................... 3-1 3.3 Monitors.............................................................................................................. 3-2 3.4 Transmitters / Modulators................................................................................... 3-2 3.5 TX Control .......................................................................................................... 3-2 3.6 Remote Monitoring (RMS) Unit .......................................................................... 3-3 3.7 Remote Control Unit........................................................................................... 3-3 3.8 Remote Slave Panel........................................................................................... 3-3 3.9 Remote Maintenance Monitoring (RMM) ........................................................... 3-3 3.9.1 RMM Access................................................................................................ 3-5 3.9.2 Storage Functions........................................................................................ 3-5 3.9.3 Local Keyboard/Display Functions .............................................................. 3-5 3.9.4 Diagnostic functions..................................................................................... 3-6 4 TECHNICAL SPECIFICATIONS.....................................................................4-1 4.1 Signal Minimum Performance LLZ ..................................................................... 4-1 4.2 Environmental Characteristics............................................................................ 4-2 4.3 EMC Characteristics........................................................................................... 4-2 4.4 Mechanical Characteristics ................................................................................ 4-2 4.5 Power Supply ..................................................................................................... 4-2 NORMARC 7011 INSTRUMENT LANDING SYSTEM TECHNICAL HANDBOOK Table of contents21823-3.6©1999 Navia Aviation AS ii PART II INSTALLATION .....................................................................................5-1 5 MECHANICAL INSTALLATION ......................................................................5-1 5.1 Mounting Kit MK1343A....................................................................................... 5-1 5.2 Moving RF Connectors....................................................................................... 5-2 6 ELECTRICAL INSTALLATION .......................................................................6-1 6.1 Connection Overview ......................................................................................... 6-1 6.2 Power and Battery.............................................................................................. 6-1 6.3 RF Inputs............................................................................................................ 6-2 6.4 RF Outputs ......................................................................................................... 6-3 6.5 DC Loop (Localizer only).................................................................................... 6-4 6.6 Remote Control .................................................................................................. 6-5 6.7 PC and Modem .................................................................................................. 6-6 6.8 DME (localizer only) ........................................................................................... 6-7 6.9 For the Fernau 2020 DME the following connection is recommended............... 6-9 6.10 Analog Inputs ..................................................................................................... 6-9 6.11 Digital Inputs and Outputs .................................................................................. 6-11 6.12 Battery Warning.................................................................................…

Text truncated - open the document above for the full version.

May 1, 2000 Federal Communication Commission Application Processing Branch 445 12th St. S.W. Washington DC 20554 Attn.: Mr. Frank Coperich Subject:: FCC ID ORTNORMARC7011; EA95842 Dear Mr. Coperich: This letter is in response to your request for further information regarding Confidentiality details on our pending application. It has been determined that none of the items submitted as attachments to the FCC under this Form 731 require Confidentiality. Therefore, Lockheed Martin requests that Confidentiality be w ithdraw n on this application. Sincerely, Jennifer M. Rogers Adecco TAD for Lockheed Martin ATM 9221 Corporate Blvd., Rockville, MD 20850

June 6, 2000 Federal Communications Commission Application Processing Branch 445 12 th St., SW Washington, DC 20554 Attn.: Mr. Frank Coperich Subject: FCC ID ORT7011; EA95842; Corresp # 12628 Dear Mr. Coperich: This letter is in reference to your fax of March 9, 2000 to Joseph Allan and specifically addresses Item #2 of that fax. The label submitted to you reflects the correct ID. It is hereby requested that our Form 731 be amended to read: ORTNORMARC7011. This was the way we resolved the label issue on two other applications. If you require further information please contact me immediately on 301-640-3224; E-mail “[email protected]”. Sincerely, Jennifer M. Rogers Adecco TAD for Lockheed Martin ATM

June 6, 2000 Federal Communication Commission Application Processing Branch 445 12th St. S.W. Washington DC 20554 Attn.: Mr. Frank Coperich Subject:: FCC ID ORTNORMARC7011; EA95842 Dear Mr. Coperich: This letter is in response to your request for further information regarding Confidentiality details on our pending application. It has been determined that none of the items submitted as attachments to the FCC under this Form 731 require Confidentiality. Therefore, Lockheed Martin requests that Confidentiality be w ithdraw n on this application. Sincerely, Jennifer M. Rogers Adecco TAD for Lockheed Martin ATM 9221 Corporate Blvd., Rockville, MD 20850

FCC ID ORT NORMARC 7011

©1999 Navia Aviation AS NORMARC 7011 INSTRUMENT LANDING SYSTEM TRANSMITTER FIGURES ©1999 Navia Aviation AS ©1999 Navia Aviation ASTable of contents TRANSMITTER FIGURESNORMARC 7011 INSTRUMENT LANDING SYSTEM iii TABLE OF CONTENTS 1 LF1223A LOW FREQUENCY GENERATOR ..................................................7 1.1 Schematic Diagrams .......................................................................................... 7 1.2 Photos ................................................................................................................ 8 2 OS1221A RF OSCILLATOR............................................................................9 2.1 Circuit Diagrams................................................................................................. 9 2.2 Component Location .......................................................................................... 10 2.3 Photos ................................................................................................................ 11 3 LPA1230A POWER AMPLIFIER .....................................................................13 3.1 Photos ................................................................................................................ 13 4 PA1233A LOW FREQUENCY GENERATOR .................................................15 4.1 Schematic Diagrams .......................................................................................... 15 4.2 Parts List ............................................................................................................ 16 4.3 Photos ................................................................................................................ 17 5 AC1226A AMPLITUDE CONTROL .................................................................19 5.1 Schematic Diagrams .......................................................................................... 19 5.2 Photos ................................................................................................................ 20 6 PC1225A PHASE CONTROL..........................................................................21 6.1 Schematic Diagrams .......................................................................................... 21 6.2 Photos ................................................................................................................ 22 7 FD1235A FEEDBACK DETECTOR.................................................................23 7.1 Schematic Diagrams .......................................................................................... 23 7.2 Photos ................................................................................................................ 24 8 CD 1237A COMBINER DETECTOR ...............................................................25 8.1 Schematic Diagrams .......................................................................................... 25 8.2 Photos ................................................................................................................ 26 TRANSMITTER FIGURES iv NORMARC 7011 INSTRUMENT LANDING SYSTEM Table of contents©1999 Navia Aviation AS ©1999 Navia Aviation ASList of Figures TRANSMITTER FIGURESNORMARC 7011 INSTRUMENT LANDING SYSTEM v LIST OF FIGURES TRANSMITTER FIGURES vi NORMARC 7011 INSTRUMENT LANDING SYSTEM List of Figures©1999 Navia Aviation AS LF1223A LOW FREQUENCY GEN- NORMARC 7011 1-7 INSTRUMENT LANDING SYSTEM TRANSMITTER FIGURES ©1999 Navia Aviation AS 1LF1223A Low Frequency Generator 1.1Schematic Diagrams NORMARC 7011 INSTRUMENT LANDING SYSTEM TRANSMITTER FIGURES LF1223A LOW FREQUENCY GEN-©1999 Navia Aviation AS 1-8 1.2Photos OS1221A RF OSCILLATOR NORMARC 7011 2-9 INSTRUMENT LANDING SYSTEM TRANSMITTER FIGURES ©1999 Navia Aviation AS 2OS1221A RF Oscillator 2.1Circuit Diagrams NORMARC 7011 INSTRUMENT LANDING SYSTEM TRANSMITTER FIGURES OS1221A RF OSCILLATOR©1999 Navia Aviation AS 2-10 2.2C…
