Subj: FW: 2.4 GHz WLAN FCC Report Date:11/3/99 9:28:11 AM Pacific Standard Time From:[email protected] (Anthony Le) Reply-to:[email protected] To:[email protected] Kyle, Here is the letter from Celestica confirming their permission on our using there data on the processing gain. If you need a more official letter, please let me know. Thanks. -----Original Message----- From: Eddie Saavedra Sent: Monday, October 18, 1999 3:42 PM To: Anthony Le Cc: Tony lopez; Tony Wong Subject: FW: 2.4 GHz WLAN FCC Report -----Original Message----- From: [email protected] [mailto:[email protected]] Sent:Monday, October 18, 1999 3:16 PM To:[email protected] Cc:[email protected] Subject:2.4 GHz WLAN FCC Report Hi Ed, As per our phone conversation today, Entertainment Systems Technology has permission to use the FCC results in the engineering test report. The FCC ID information is given below: Product: OEM WLAN PC CARD 13316C FCC ID: MRF13316C FCC Part 15, Subpart C, Para. 15.247 Direct Sequence Spread Spectrum (DSSS) Transmitters Operating in the Frequency Band 2412-2462 MHz Please let me know if you have any questions. Thanks. Regards, Roni Rahman Wireless Designer Celestica Incorporated e-mail: [email protected] Phone: 416-448-5969 Cellular: 416-436-4172 Fax: 416-448-5335 Wednesday, November 03, 1999 America Online: CEkyle Page: 1 ----------------------- Headers -------------------------------- Return-Path: <[email protected]> Received: from rly-yc02.mx.aol.com (rly-yc02.mail.aol.com [172.18.149.34]) by air-yc05.mail.aol.com (v62.15) with ESMTP; Wed, 03 Nov 1999 12:28:11 -0500 Received: from sheffield.cnchost.com (sheffield.concentric.net [207.155.252.12]) by rly-yc02.mx.aol.com (v62.10) with ESMTP; Wed, 03 Nov 1999 12:27:55 -0400 Received: from ale (w086.z206111086.lax-ca.dsl.cnc.net [206.111.86.86]) by sheffield.cnchost.com id MAA21685; Wed, 3 Nov 1999 12:27:54 -0500 (EST) [ConcentricHost SMTP Relay 1.8] Errors-To: <[email protected]> Reply-To: <[email protected]> From: "Anthony Le" <[email protected]> To: <[email protected]> Subject: FW: 2.4 GHz WLAN FCC Report Date: Wed, 3 Nov 1999 09:23:48 -0800 Message-ID: <[email protected]> MIME-Version: 1.0 Content-Type: text/plain; charset="iso-8859-1" Content-Transfer-Encoding: 7bit X-Priority: 3 (Normal) X-MSMail-Priority: Normal X-Mailer: Microsoft Outlook 8.5, Build 4.71.2173.0 Importance: Normal X-MimeOLE: Produced By Microsoft MimeOLE V4.72.3110.3 Wednesday, November 03, 1999 America Online: CEkyle Page: 2 Subj: Statement of fact on FunPad Transmitter Date:11/4/99 11:24:46 AM Pacific Standard Time From:[email protected] (Anthony Le) Reply-to:[email protected] To:[email protected] Dear Kyle: This letter is to confirm the fact that we are using the exact design that was implemented in Celestica Spread Spectrum Transmitter. As a result, we can properly use any applicable data on Celestica card for our own FCC report. We will be faxing to you the revised letter of confidentiality soon. Anthony Tuan Le Entertainment Systems Technology (714)841-9116 ----------------------- Headers -------------------------------- Return-Path: <[email protected]> Received: from rly-yc05.mx.aol.com (rly-yc05.mail.aol.com [172.18.149.37]) by air-yc02.mail.aol.com (v62.15) with ESMTP; Thu, 04 Nov 1999 14:24:46 -0500 Received: from marlborough.cnchost.com ([207.155.248.14]) by rly-yc05.mx.aol.com (v62.10) with ESMTP; Thu, 04 Nov 1999 14:22:44 -0500 Received: from ale (w086.z206111086.lax-ca.dsl.cnc.net [206.111.86.86]) by marlborough.cnchost.com id OAA02118; Thu, 4 Nov 1999 14:22:42 -0500 (EST) [ConcentricHost SMTP Relay 1.8] Errors-To: <[email protected]> Reply-To: <[email protected]> From: "Anthony Le" <[email protected]> To: <[email protected]> Subject: Statement of fact on FunPad Transmitter Date: Thu, 4 Nov 1999 11:22:11 -0800 Message-ID: <[email protected]> MIME-Version: 1.0 Content-Type: text/plain; charset="iso-8859-1" Content-Transfer-Encoding: 7bit X-Priority: 3 (Normal) X-MSMail-Priority: Normal X-Mailer: Microsoft Outlook 8.5, Build 4.71.2173.0 Importance: Normal X-MimeOLE: Produced By Microsoft MimeOLE V4.72.3110.3 Thursday, November 04, 1999 America Online: CEkyle Page: 1

FCC ID: ORUEST-9-1998 Report Number: B91028D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 24 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 5 1. PURPOSE 7 2. ADMINISTRATIVE DATA 8 2.1 Location of Testing 8 2.2 Traceability Statement 8 2.3 Cognizant Personnel 8 2.4 Date Test Sample was Received 8 2.5 Disposition of the Test Sample 8 2.6 Abbreviations and Acronyms 8 3. APPLICABLE DOCUMENTS 9 4. Description of Test Configuration 10 4.1 Description of Test Configuration - EMI 10 4.1.1 Cable Construction and Termination 11 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 12 5.1 EUT and Accessory List 12 5.2 EMI Test Equipment (For the transmitter radiated emissions) 13 5.3 Processing Gain Test Equipment 14 6. TEST SITE DESCRIPTION 15 6.1 Test Facility Description 15 6.2 EUT Mounting, Bonding and Grounding 15 7. CHARACTERISTICS OF THE TRANSMITTER 16 7.1 Transmitter Power 16 7.2 Channel Number and Frequencies 16 7.3 Chipping Rate 16 7.4 Spreading Gain 16 7.5 Antenna Gain 16 7.6 Description of Transmitter 17 7.7 Processing Gain 18 8. Test Procedures 20 8.1 RF Emissions 20 8.1.1 Radiated Emissions (Spurious and Harmonics) Test 20 8.2 6 dB Bandwidth for Direct Sequence Systems 22 8.3 Peak Output Power 22 8.4 Spectral Density Output 22 8.5 RF Antenna Conducted Test 23 8.6 RF Band Edges 23 8.7 Processing Gain 24 9. CONCLUSIONS 25 FCC ID: ORUEST-9-1998 Report Number: B91028D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 24 LIST OF APPENDICES APPENDIX TITLE A Modifications to the EUT B Additional Models Covered Under This Report C Diagrams, Charts and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors D Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site FCC ID: ORUEST-9-1998 Report Number: B91028D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 24 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form unless done so in full with the written permission of Compatible Electronics. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: Funpad Model: FP1-99 S/N: N/A Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Entertainment Systems Technology 17011 Beach Blvd., Suite 530 Huntington Beach, California 92647-5989 Test Dates: October 13 (spurious emissions for the digital circuits and receiver portion) October 26 and 28, 1999 File # For Canada IC2154-D Test Specifications: EMI requirements FCC Title 47, Part 15 Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedure: ANSI C63.4: 1992 Test Deviations: The test procedure was not deviated from during the testing. FCC ID: ORUEST-9-1998 Report Number: B91028D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 24 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 450 kHz – 30 MHz The EUT runs off a 10.8Vdc, 4800 mAh battery only. Thusly, this test was not performed. 2 Spurious Radiated RF Emissions, 10 kHz – 1000 MHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart B, section 15.109(b) (See Note 1 and Note 2) 3 Fundamental and Emissions produced by the intentional radiator in non-restricted bands, 10 kHz – 25 GHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247(c) 4 Emissions produced by the intentional radiator in restricted bands, 10 kHz – 25 GHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.205 and 15.209(a) 5 6 dB Bandwidth Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (a)(2) 6 Maximum Peak Output Power Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (b)(1) 7 RF Antenna Conducted Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (c) 8 Peak Power Spectral Density Conducted from the Intentional Radiator to the Antenna Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (d) 9 Processing Gain Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (e) Note 1: The digital circuits of the EUT have been tested and verified to comply with FCC Part 15, Subpart B, Verification – Class A Digital Devices. This test report can be provided upon FCC request. This device will be used for commercial and/or business environments only (i.e. restaurants) Note 2: The receiver portion is exempt because according to FCC 15.101 (b), “Receivers operating above 960 MHz or below 30 MHz, except for CB receivers, are exempt from complying with the technical provisions of this part but are subject to 15.5” FCC ID: ORUEST-9-1998 Report Number: B91028D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 24 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Funpad Model: FP1-99. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the Funpad, referred to as EUT hereafter, are within the spec…
