WARNING Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Notice: (1)A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent interference to the nearby radio and television reception. It is essential that only the supplied power cord by used. (2)Use only shielded cables to connect I/O devices to this equipment. (3)Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Photo # 1 Front View Photo # 2 Rear View Photo # 3 Unit Partially Disassembled Photo # 4 Unit Partially Disassembled Photo # 5 Unit Partially Disassembled Photo # 6 Unit Partially Disassembled Photo # 7 Unit Partially Disassembled Photo # 8 Unit Partially Disassembled Photo # 9 Unit Partially Disassembled Photo # 10 Unit Partially Disassembled Photo # 11 Unit Partially Disassembled Photo # 12 Unit Partially Disassembled

1. Product Labeling 1-1. FCC ID label SOMAPA Model:SN-3600 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation. 1-2 Location of Label on EUT FCC ID:OSJSONIXPC 2.3 cm 0.3cm

NEUTRON EMC LAB. FCC ID:OSJSONIXPC 1/22 MEASUREMENT/TECHNICAL REPORT APPLICANT: SOMAPA Information Technology Co., Ltd. MODEL NO.: SN-3450,SN-3500,SN-3550,SN-3600 FCC ID: OSJSONIXPC This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type: PC Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce ment of the product so that the grant can be issued on that date. Transiyion Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House : Neutron Engineering Inc. for Company Name : SOMAPA Information Technology Co., Ltd. Address: 51/6-7 Navamintara Rd., Klongkum, Buengkum, Bangkok 10240 Thailand. Applicant Signature : Namchoke Somapa / Managing Director NEUTRON EMC LAB. FCC ID:OSJSONIXPC 2/22 CERTIFICATION We hereby certify that: The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992)/CISPR 22(1996) and the energy emitted by the sample EUT tested as described in this report is in compliance with CLASS B conducted and radiated emission limits of FCC Rules Part 15, Subpart B/CISPR 22(1996). Prepared by : Carol Chen Reviewed by : Andy Chiu Approved by : George Yao Issued Date : Oct. 02, 1999 Report No. : NEI-FCCB-99142 Company Stamp : NEUTRON ENGINEERING INC. 20, Alley 50, Lane 119, Dong Hwu Rd., P.O. Box 6-158, Nei Hwu, Taipei, Taiwan TEL : (02) 2646-5426 FAX : (02) 2646-6815 NEUTRON EMC LAB. FCC ID:OSJSONIXPC 3/22 Table of Contents 1. General Information........................................................................................................................ 1-1 Product Description................................................................................................................... 4 1-2 Related Submittal(s)/Grant(s).................................................................................................... 5 1-3 CPU Information....................................................................................................................... 5 1-4 Tested System Details............................................................................................................... 6 1-5 Test Methodology..................................................................................................................... 7 1-6 Test Facility............................................................................................................................... 7 3. System Test Configuration.............................................................................................................. 3-1 Justification............................................................................................................................... 8 3-2 EUT Exercise Software............................................................................................................. 8 3-3 Special Accessories................................................................................................................... 9 3-4 Equipment Modifications........................................................................................................... 9 3-5 Configuration of Tested System................................................................................................. 10 Figure 3-1 Configuration of Tested System...................................................................................... 12 4. Block Diagram(s).............................................................................................................................. 13 5. Conducted and Radiated Measurement Photos.............................................................................. Figure 5-1.Conducted Measurement Photos..................................................................................... 14 Figure 5-2 Radiated Emission Data.................................................................................................. 15 6. Conducted Emission Datas.............................................................................................................. 16 7. Radiated Emission Datas ................................................................................................................ 17 7-1 Radiated Emission Data............................................................................................................. 17 7-2 Field Strength Calculation......................................................................................................... 19 7-3 Correction Factor Table VS Frequency...................................................................................... 20 8.Attachment Photos of Tested EUT........................................................................................................................ 21 User‘s Manual.................................................................................................................................... 22 NEUTRON EMC LAB. FCC ID:OSJSONIXPC 4/22 1. GENERAL INFORMATION 1-1. Product Description The SOMAPA Information Technology Co., Ltd. Model : SN-3450,SN-3500,SN-3550,SN- 3600(referred to as the EUT in this report) is a person computer. It is designed base on the Intel Pentium III series of processors. A.The summarized features of the EUT are described as follows: l ATX form factor of 12x7.75 inches with seven mounting screw holes l Support for Intel Pentium III processor l Three DIMM sockets —Supports up to 384 MB of synchronous DRAM(SDRAM)memory l Intel 82440BX AGP set —PCI/AGP controller(PAC) —PCI ISA IDE Xcelerator(PIIX4E) l I/O controller l Two USB ports l Intel/Phoenix Basic Input/Output System(BIOS) l Single-jumper configuration l Accelerated Graphics Port(AGP)conn…
