OTA78425HERO GATEWAY - DC

Holylite Microelectronics Corp. Sino Matrix Technology Inc. HL5233 HF RFID Reader IC Aug.2012 1/9 Features ̇ Low standby current. ̇ Low power consumption. ̇ Simple application circuit. ̇ Stable performance. ̇ The system and oscillator can be enable separately. ̇ 3 kinds of decoder outputs. ̇ Level hold mode and one-shot trigger mode. ̇ High active and low active output selectable. Applications <Patent： ：： ：US6731177B2> ̇ Toy RFID. ̇ Asset control. ̇ Contactless entry control. ̇ Education. General Description HL5233 is a CMOS IC used to perform the function of a RFID Reader. A RFID contains two parts: RFID TAG (HL5230) and RFID Reader (HL5233). HL5233 contains of a 13.56MHz crystal oscillator, a 13.56MHz output buffer, a preamplifier and data decoder. The output buffer drives an antenna which can transmits RF signal to the RFID TAG. If TAG is close enough to the Reader, the encoder of TAG will send out a data train. The data train is used to modulate the RF signal in the TAG, and the amplitude of RF signal in the Reader will be modulated also. Preamplifier is used to amplify the modulating signal. The decoder is used to decoder the encoded data transmitted from TAG. There are three kinds of output data: Synchronous, Asynchronous and Direct drive outputs. In order to interface to most of power Speech IC, the data rate of the outputs is slower than the data rate of the RFID TAG. Block Diagram IN COM VDD2 VSS2 OENB SL READY PLAYMODE LHOLD ENB VDD VSS OUT0 OUT1 OUT2 OUT3 OUT4 OUT5 AO1IN2AO2AO3 OSC1 OSC2 VDD1 VSS1 DRVI1 DATAI CLOCKI SDATAI Decoder BUF OSCAmp. Stage

Dec 2013 Letter of Agency "I, an officer of JAKKS Pacific(HK) Ltd do hereby authorize Intertek Testing Services (Mr. Terry Chan / Koo Wai Ip / Kenneth Wong) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice." I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,862. Dated this 16 day June of 2014__ By Signature Dick Au Printed Name Senior Manager, Product Integrity Title Remark: The person who signs this authorization letter must be the grantee contact of record in the Grantee Code data base.

INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Equipment Photographs Model : 78425 (External)

62mm

INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Equipment Photographs Model : 78425 (Internal) INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Equipment Photographs Model : 78425 (Internal) INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Equipment Photographs Model : 78425 (Internal) INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Equipment Photographs Model : 78425 (Internal) INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Equipment Photographs Model : 78425 (Internal)

Technical Description The brief circuit description is listed as follows: - U1 GPL32612B acts as MCU. - U2 H27U518S2CTR-BC acts as NAND ROM. - U3 HL5233 acts as RFID Reader IC. - U4 AMS1117-3.3V acts as Voltage Regulator. - U7 FT24C16A acts as EEPROM. - Y1 acts as 12 MHz Oscillator. - Y2 acts as 32.768 KHz Oscillator. - Y4 and associated circuit act as 13.560 MHz Oscillator. - POWER acts as ON/OFF Switch Circuit. - BOTTON KEY acts as all control switches. Antenna Used: An internal, integral antenna has been used. Antenna Gain: 0dBi Nominal rated field strength: 67.3dBμV/m at 3m Production tolerance: -3dBm (Minimum) to +3dBm (Maximum) Holylite Microelectronics Corp. Sino Matrix Technology Inc. HL5233 HF RFID Reader IC Aug.2012 1/9 Features ̇ Low standby current. ̇ Low power consumption. ̇ Simple application circuit. ̇ Stable performance. ̇ The system and oscillator can be enable separately. ̇ 3 kinds of decoder outputs. ̇ Level hold mode and one-shot trigger mode. ̇ High active and low active output selectable. Applications <Patent： ：： ：US6731177B2> ̇ Toy RFID. ̇ Asset control. ̇ Contactless entry control. ̇ Education. General Description HL5233 is a CMOS IC used to perform the function of a RFID Reader. A RFID contains two parts: RFID TAG (HL5230) and RFID Reader (HL5233). HL5233 contains of a 13.56MHz crystal oscillator, a 13.56MHz output buffer, a preamplifier and data decoder. The output buffer drives an antenna which can transmits RF signal to the RFID TAG. If TAG is close enough to the Reader, the encoder of TAG will send out a data train. The data train is used to modulate the RF signal in the TAG, and the amplitude of RF signal in the Reader will be modulated also. Preamplifier is used to amplify the modulating signal. The decoder is used to decoder the encoded data transmitted from TAG. There are three kinds of output data: Synchronous, Asynchronous and Direct drive outputs. In order to interface to most of power Speech IC, the data rate of the outputs is slower than the data rate of the RFID TAG. Block Diagram IN COM VDD2 VSS2 OENB SL READY PLAYMODE LHOLD ENB VDD VSS OUT0 OUT1 OUT2 OUT3 OUT4 OUT5 AO1IN2AO2AO3 OSC1 OSC2 VDD1 VSS1 DRVI1 DATAI CLOCKI SDATAI Decoder BUF OSCAmp. Stage Holylite Microelectronics Corp. Sino Matrix Technology Inc. HL5233 2/9 Pin Connection HL5233 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 VSS VSS2 COM IN1 A01 IN2 AO2 AO3 OSC1 OSC2 ENB OENB VDD2 VDD VSS1 DRIV1 SL READY PLAYMODE LHOLDN SDATAI/OUT7 CLOCKI/OUT6 DATAI/OUT5 OUT4 OUT3 OUT2 OUT1 OUT0 VDD VDD1 Holylite Microelectronics Corp. Sino Matrix Technology Inc. HL5233 3/9 Pin Description PIN NO. PIN NAME DESCRIPTION 1 SL Data Bit Rate Select Pin. It is used to determine the bit rate received from TAG. SL = 1, Bit rate = 8KHz; SL = 0, Bit rate = 4KHz 2 READY Play Mode Select Pin. When PLAYMODE pin is high, this pin is used as Output Polarity Control Pin. When PLAYMODE pin is low this pin is used as Ready input pin. When READY = 0, output signal is not available. 3 PLAYMODE Output DATA Mode Control Pin. When PLAYMODE = 1, Out0 ~ Out4, DATAI, CLOCKI, and SDATAI is used as direct output pin. When PLAYMODE = 0, Out0 ~ Out4 is also used as direct output, but DATAI, CLOCKI and SDATAI is used as serial data output pin. 4 LHOLDN Level-Hold Control Pin. When LHOLDN = 0, DATA will be sent out continuously or output will active as long as TAG is closed to Reader. When LHOLDN = 1, only one set of DATA will be sent out or output will active for a short time. 5 SDATAI Serial Data Output. When PLAYMODE = 0, this pin is used as serial data output, i.e., DATA and CLOCK exist at same output. When PLAYMODE = 1, this pin is used as one of the direct output. 6 CLOCKI CLOCK Output. When PLAYMODE = 0, this pin (combined with DATAI,) is used as synchronous DATA output pin. When PLAYMODE = 1, this pin is used as one of the direct output pins. 7 DATAI DATA Output. ( As illustrated in CLOCKI ) 8~12 Out0~Out4 Direct Output Pin. 13 VDD Positive Power Supply Terminal. 14 VDD1 Positive Power Supply Terminal. 15 DRIV1 Coil Driver Output of 13.56MHz oscillator. 16 VSS1 Negative Power Supply Terminal. 17 VDD Positive Power Supply Terminal. 18 VDD2 Positive Power Supply Terminal of Preamplifier. 19 OENB Coil Driver Enable Pin. When OENB = 0, coil driver will disable, others circuit still work. When OENB = 1, coil driver enable. 20 ENB Enable Input Pin of the whole system. 21 OSC2 Oscillator Output Pin. 22 OSC1 Oscillator Input Pin. 23 AO3 Output Pin of 3 rd stage of Preamplifier. 24 AO2 Output Pin of 2 nd stage of Preamplifier. 25 IN2 Inverting Input Pin of 2 nd stage of Preamplifier. 26 AO1 Output Pin of 1 st stage of Preamplifier. 27 IN1 Inverting Input Pin of 1 st stage of Preamplifier. 28 COM Common Input Pin of Preamplifier. 29 VSS2 Negative Power Supply Terminal of Preamplifier. 30 VSS Negative Power Supply Terminal. Holylite Microelectronics Corp. Sino Matrix Technology Inc. HL5233 4/9 Absolute Maximum Ratings Power Supply .......................................5V Input Voltage ........................................ VSS-0.3V to VDD+0.3V Operating Temperature..................................0 O C to 60 O C Storage Temperature .....................................-65 O C to 125 O C Electrical Characteristics 1. LIMIT SYSTEM DESCRIPTION TEST CONDITION MIN. TYP. MAX. UNIT VDD Supply Voltage 3 4.5 5 V VIL Input Voltage Low VDD=4.5V 0.3*VDD V VIH Input Voltage High VDD=4.5V 0.7*VDD V VOSC Oscillator Starting Voltage 2.2 V IOP1 Operating Current 1 VDD=4.5V 19* mA IOP2 Operating Current 2 (Driver Off) VDD=4.5V 1 mA IST Stand-by Current VDD=4.5V 0.5 uA * IOP depends on external coil. 2. LIMIT SYSTEM DESCRIPTION TEST CONDITION MIN. TYP. MAX. UNIT VDD Supply Voltage 2.4 3 3.6 V VIL Input Voltage Low VDD=3V 0.3*VDD V VIH Input Voltage High VDD=3V 0.7*VDD V VOSC Oscillator Starting Voltage 2.2 V IOP1 Operating Current 1 VDD=3V 10* mA IOP2 Operating Curr…

Text truncated - open the document above for the full version.

Analysis Report Report No.: 14041841HKG-001 Model: 78425 The equipment under test (EUT) is a 13MHz RFID for control panel (RFID toy reader) operating at 13.560MHz which is controlled by a crystal. The EUT is powered by 4 x AA size batteries. This product consists of a control panel (RFID tag reader) and six Hero Figures (passive type powered tags). The EUT has an ON/OFF switch and a RFID tag sensor on the control panel. It can also connect to the TV monitor for game playing. After switched on the EUT, the monitor can show the game mode while the Hero Figure (passive tags) was placed on it. Antenna Type: Internal integral antenna Antenna Gain: 0dBi Nominal rated field strength: 67.3dBμV/m at 3m Maximum allowed field strength of production tolerance: +/- 3dB According to the KDB 447498: Based on the Maximum allowed field strength of production tolerance was 70.3 dBμV/m at 3m in frequency 2.4GHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 0.003mW Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power = 0.003mW. The SAR Exclusion Threshold Level for 13.56MHz when the minimum test separation distance is < 50mm: = [474 * (1 + log100/f(MHz))]/2 = 442.7mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

9.Mar.2013 JAKKS 10KO 1KO 10KO 10KO 10KO 33KO 33KO 33KO 4.7KO 330O 47O 75O 2.2KO 1KO 1O 0O NC 1O 100KO 100KO 102OHM 10KO 1KO 1KO NC NC 1MO 10KO 10KO 1KO 1KO 1KO 1KO 1KO 1KO 1KO 1KO 47O 102OHM 330O 102ohm 100KO 1MO 10KO

lntertek Valued Qualit}'. Deliveæd, lssuing Laboratory: lntertek Testing Services Hong Kong Limited Hong Kong Accred¡tation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditat¡on Scheme (HOKLqS) for specific laboratory activities as l¡sted in the HOKLAS d¡rectory of accredited laboratories. The results shown in this report were detsrmined by this laboretory in accordance with its torms of accreditation Report No.: 1 4041841HKG-001 TEST REPORT JAKKS Pacific (HK) Limited Application Gertification (Original Grant) Prepared and Checked by: TEST (FCC lD: OTA78425\ For (tC= 77834-784251 Transmitter Wong Kwok Yeung, Kenneth Lead Engineer Thê tost report only allows to be rovisgd within lhs retenl¡on p€riod unless furthsr standârd or thB requ¡rsmsnt was noticed Th¡s report ls for the exclusive uss of lntelek's Cli6nt and is provid€d pursuant to the agreemont botw€en lnlert€k and ¡ts Cl¡ont lntertek's respons¡b¡l¡ty end l¡abil¡ty ars llm¡ted to the terms snd cond¡tjons of the agreem€nt lnt€rtek assumes no liab¡l¡ly to any parly, other than to th€ Cli€nt in accordance with th8 agreem€nt, for any loss, expense or damage o@sionêd by ths use ol th¡s report Only the Cli€nt is authorized to permit copying or distribut¡on of th¡s reporl and lh€n only in its ent¡rety Any uss of ths lntertek nams or ono of ¡ts marks for ths ssls or adv€rlisement ol the test€d matsrial, product or s6Mæ musl first be approvsd in writ¡ng by lnt€rtêk Tho observations and t€st rosults ¡n lhis report aro rolevÊnt only to the sample tôsted This ßport by ¡tsolf do8s not imply that ths material, product, or seru¡æ is or has €vsr bsen undor an lntertêk ærlif¡€tion program. lntertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong Tel: (852) 2173 8888 Fax: (852) 2785 5487 Websit6: www.hk.intertek-etlsemko.com Approved by: Supervisor Date: June 26,2014 iHung, Terry Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Report No.: 14041841HKG-001 i FCC ID: OTA78425 IC: 7783A-78425 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION Grantee: JAKKS Pacific (HK) Limited Grantee Address: 12/F., Wharf T&T Centre, 7 Canton Road, Tsim Sha Tsui, Kowloon, Hong Kong. Contact Person: Dick Au Tel: 2269 7631 Fax: 2366 8247 e-mail: [email protected] Manufacturer: Root Land Plastic Factory Manufacturer Address: Bai Yun Keng Industrial, Danshui Town, Huiyang Zone, Huizhou City, Guangdong, Province China. Vendor: Rootland Plastic Factory Brand Name: N/A FCC & IC Model: Refer to report P.ii Additional Model No.: Refer to report P.ii Asst. No.: Refer to report P.ii GL Class No.: 3500.8020.105 Type of EUT: Transceiver Description of EUT: Refer to report P.ii Serial Number: N/A FCC ID / IC: OTA78425 / 7783A-78425 Date of Sample Submitted: April 30, 2014 Date of Test: April 30, 2014 to May 19, 2014 Report No.: 14041841HKG-001 Report Date: June 26, 2014 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Report No.: 14041841HKG-001 ii FCC ID: OTA78425 IC: 7783A-78425 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION (Cont’d) FCC Model: 78425 FCC Additional Model No.: 78425, 78426, 80947, 82307, 82639, 78426, 80947, 84899, 78426, 80947 IC Model: 78425 Asst. No.: 78425-QVC, 78425-UK, 80948, 80948-CAN, 80948-EU, 82307, 82307-CAN, 82307-EU, 82639, 82639-CAN, 82639-EU, 84899, 84899-CAN, 84899-EU, 80947, 80947-CAN, 80947-EU, 84907, 84907-CAN, 84907-EU, 82712, 82712-CAN, 82712-EU Description of EUT: HERO PORTAL ASST., HERO PORTAL ASST. - 4 characters: HERO GATEWAY – DC (78425) HERO GATEWAY WITH BONUS FIGURE – DC: HERO GATEWAY WITH BONUS FIGURE – DC (78425) HERO GATEWAY - DC Booster Pack Assortment: HERO GATEWAY - DC Booster Pack (Green Lantern & Cyborg) (78426) HERO GATEWAY - DC Booster Pack (Wonder Woman & Flash) (80947) HERO GATEWAY – Kmart DC GATEWAY + 4 Figures: HERO GATEWAY – Kmart DC GATEWAY + 4 Figures (82307) HERO GATEWAY WITH TWO FIGURES – DC: HERO GATEWAY WITH TWO FIGURES – DC (82639) DC HERO GATEWAY BOOSTER PACK ASST.: HERO GATEWAY - DC Booster Pack (Green Lantern & Cyborg) (78426) HERO GATEWAY - DC Booster Pack (Wonder Woman & Flash): HERO GATEWAY - DC Booster Pack (Wonder Woman & Flash) (80947) HERO PORTAL BOOSTER PACK ASST.: DC HERO GATEWAY PDQ (84899) HERO GATEWAY - DC Booster Pack (Green Lantern & Cyborg) (78426) HERO GATEWAY - DC Booster Pack (Wonder Woman & Flash) (80947) Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Report No.: 14041841HKG-001 iii FCC ID: OTA78425 IC: 7783A-78425 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 57…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Configuration Photographs Worst-Case Radiated Emissions (Front View) Model: 78425 Radiated Emission 78425 HK14041841HKG-001 A5 B… INTERTEK TESTING SERVICE FCC ID: OTA78425 IC: 7783A-78425 Configuration Photographs Worst-Case Radiated Emissions (Back View) Model: 78425 Radiated Emission 78425 HK14041841HKG-001 A…B5
