OTA87374RXXPV/MARVEL - RC HULK SMASH

4+ #87374 HULK SMASH RC INSTRUCTIONS CONTENTS: - RC VEHICLE - REMOTE CONTROL - HULK’S LEFT ARM * Please remove try-me cable from VEHICLE and REMOTE CONTROL before use. REMOTE CONTROL: X2 1.5V AA (LR6) ALKALINE BATTERIES REQUIRED REMOTE CONTROL VEHICLE: X6 1.5V AA (LR6) ALKALINE BATTERIES INCLUDED ® CAUTION: ADULT SUPERVISION REQUIRED ALWAYS PLAY IN SAFE SURROUNDINGS, AWAY FROM STREETS OR MOVING VEHICLES. VEHICLE ARM ASSEMBLY INSTRUCTION BATTERY REPLACEMENT / INSTALLATION ADULT INSTALLATION REQUIRED ADULT ASSEMBLY REQUIRED Align the rib on arm to the slot of hexagonal junction. 2. Plug Hulk’s left arm in and push until the arm is completely attached with the body. - + - + - + - + 1 1 2 2 TRY ME - + - + 1 3 2 - + - + 1 2 BATTERY SAFETY INFORMATION WARNING! Battery acid leakage can cause personal injury and cause damage to the product and battery acid away from eyes, ears, nose and mouth. Immediately wash any clothing or other surface that comes in contact with leaked battery acid. Leaking batteries may make "popping" sounds. Dispose according to Local, State or Federal Battery Laws. BOTTOM BACK 2. Locate and open BATTERY COVERS 1. Unplug the Try-me cable at the back of vehicle and remote control. 1. Locate and open BATTERY COVER as shown. Use a Philips/cross head screwdriver (not included) to loosen screws. Screws remain attached to the cover. 2. Install 2 – 1.5V AA (LR6) ALKALINE BATTERIES in the orientation shown. 3. Replace BATTERY COVER and tighten screws. Requires 6 “AA” (LR6) ALKALINE BATTERIES for vehicle and 2 “AA” (LR6) ALKALINE BATTERIES for remote control. Batteries for the vehicle are included. When performance diminishes, replace with fresh batteries. on BACK and BOTTOM of the vehicle as shown. Use a Phillips/cross head screwdriver (not included) to loosen screws. Screws remain attached to cover. 3. Replace / install 4 - 1.5V AA (LR6) ALKALINE BATTERIES in the back and 2 - 1.5V AA (LR6) ALKALINE BATTERIES in the BOTTOM in the orientation shown. 4. Replace BATTERY COVERS and tighten screws. Note: Always replace all 6 batteries at the same time. TRY ME TRY ME CONTROLS OPERATIONSPIN MODE CUSTOM SMASH MODE 1 FORWARD OFF / ON SWITCH REM O TE CONTROL ON/OFF/TRY-ME SWITCH SLOT FOR TRY-ME CABLE VEHICLE 1. VEHICLE: Move the ON/OFF/TRY-ME SWITCH to the ON position. 1. Push joystick FORWARD to drive VEHICLE forward with powered SMASHING ARMS. The more the joystick push FORWARD, the higher the VEHICLE speed. The more the joystick push BACKWARD, the higher the VEHICLE speed. Tips: Keep hand position over the floor to have the best performance. 2. Pull joystick BACKWARDS to spin VEHICLE without powering SMASHING ARMS. This will TURN and change direction of the VEHICLE. 3. Press SPIN BUTTON to move SMASHING ARMS into WHEELIE position. Vehicle will SPIN for five seconds. Keep pressing the SPIN BUTTON for longer spinning time. 4. Press SPIN BUTTON to have the vehicle spin for 10 seconds. Hold down the SPIN BUTTON to keep the vehicle spinning. NOTE: Hulk’s arms need to be in the same position on each side.Rotate left arm FORWARD/ BACKWARD if necessary to match right arm position. NOTE: Wheelie SPIN is un-achieveable if fist’s starting position is at front of toe. NOTE: Wheelie SPIN does not success all of the time due to a combination of fist position/floor friction/battery power factors. If wheelie SPIN does not success, repeat SPIN mode one or more times. 2. REMOTE CONTROL: Move the OFF / ON SWITCH to the ON position. There are EIGHT different positions for the SMASHING ARMS. Each position gives different forward driving actions based on when the FISTS hit the ground. 1. TTo change arm position, rotate LEFT ARM forward or backwards the desired number of clicks. 2. Drive VEHICLE forward, SMASHING ARMS will nudge the VEHICLE left or right in different combinations to find new results. Note: This vehicle is for indoor use only. Works best on tile, hardwood floor and other smooth hard surfaces. Not recommended for use on carpets, grass, loose dirt, wet surface or concrete. Never use in water or mud. Never use near glass and other fragile objects. 2 3 ROTATE SPIN BUTTON High Speed Low Speed Low Speed High Speed 3. Place the VEHICLE on ground and point the REMOTE CONTROL directly at the VEHICLE. The LED light on REMOTE CONTROL will flash when pairing with the VEHICLE. Pairing process is completed when the LED light is solid on and the VEHICLE is ready to go. Use the FORWARD/ROTATE to maneuver the VEHICLE. Pairing is required every time the VEHICLE/ REMOTE CONTROL is turn ON. Note: When LED light on REMOTE CONTROL is keep flashing, switch off both VEHICLE and REMOTE CONTROL and repeat pairing process. CORRECTION IMPORTANT SAFETY INFORMATION If the VEHICLE flips over, first try to continue pushing the joystick FORWARD. When Hulk’s arms are not in the same position on each side, the vehicle may not always self-right. Tips: Try to lower down the forward speed if the vehicle keep flipping over continously. - NEVER drive near traffic, buildings, trees, people or other obstructions. - NEVER operate during storms or other adverse weather conditions. - ALWAYS point away from face, eyes, people, animals and property when driving. - ALWAYS use alkaline batteries only. - Never use in water or mud. - Never use near glass and other fragile objects. TROUBLESHOOTING PROBLEMPOSSIBLE CAUSESOLUTION Vehicle won ’t move. Vehicle won ’t do high speed wheelie spins after pressed spin button. Remote Con tr ol is not close enough to vehicle. Large friction between tires and floor. Hulk’s arms are not in the same position on each side. Use on tile, hardwood floor and other smooth hard surfaces. Rotate left arm forward or backwards the desired number of clicks. weak vehicle batteries. Replace batteries. Make sure the Remote Con tr ol is placed within the signal receiving range. Weak vehicle batt er ies. Replace batt er ies. Vehicle / Remote Con tr ol switch is switched OFF. Weak Remote Con tr ol batt er ies. Move switch to O…

Text truncated - open the document above for the full version.

Revision: 080408A Power of Attorney 03/23/2015 To whom it may concern: We, the undersigned, JAKKS Pacific(HK) Ltd, hereby authorize Bureau Veritas (Hong Kong) Limited, Mr, Keith Yeung to act on our behalf in all matters relating to all processes required in the FCC part 15 approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas (Hong Kong) Limited on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please do not hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------- Name Dick Au Title Senior Manager, Product Integrity Tel.: 22697631 Fax: 23668247 Mail:[email protected]

HULK Body Batterybox TRY ME OFF ON TRY ME OFF ON R6P,SUM-3, “AA”(DC 1.5V) R6P,SUM-3, “AA”(DC 1.5V) R6P,SUM-3, “AA”(DC 1.5V) R6P,SUM-3, “AA”(DC 1.5V) R6P,SUM-3, “AA”(DC 1.5V) R6P,SUM-3, “AA”(DC 1.5V) MADE IN CHINA © 2015 JAKKS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IC: 7783A-87374RX This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IC: 7783A-87374RX FCC ID: OTA87374RX 87374RX FCC ID: OTA87374RX 87374RX JAKKS, Santa Monica, CA 90405 U.S.A. MADE IN CHINA © 2015 JAKKS JAKKS, Santa Monica, CA 90405 U.S.A.

TEST REPORT No: (5215)078-0471(A) BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 1 of 22 TEST REPORT To: JAKKS PACIFIC (H.K) LIMITED To: - Attn: Horace Chau / Kin Yiu / Jessica Ho Attn: - Address: 12/F, Wharf T&T Centre, 7 Canton Road, Tsim Sha Tsui, Kowloon, Hong Kong. Address: - Fax: -- Fax: - E-mail: [email protected] / [email protected] / [email protected] E-mail: - Folder No.: -- Factory name: ROOTLAND PLASTIC FACTORY Location: -- Product: XPV/ MARVEL – RC HULK SMASH Model No.: 87374RX Sample No: (5215)078-0471 Test date: March 19, 2015 Test Requested: FCC Part 15 - 2012 Test Method: ANSI C63.4 - 2009 FCC ID: OTA87374RX The results given in this report are related to the tested specimen of the described electrical apparatus. CONCLUSION: The submitted sample was found to COMPLY with requirement of FCC Part 15 Subpart C. Authorized Signature: Reviewed by: Keith Yeung Approved by: Steven Tsang Date: March 31, 2015 Date: March 31, 2015 TEST REPORT No: (5215)078-0471(A) BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 2 of 22 Test Result Summary EMISSION TEST Test requirement: FCC Part 15 - 2012 Test Condition Test Method Test Result Pass Failed Radiated Emission Test, 9kHz to 24GHz ANSI C63.4 Frequency range of Fundamental Emission ANSI C63.4 26dB Bandwidth of Fundamental Emission ANSI C63.4 Duty Cycle Correction During 100msec ANSI C63.4 Report Revision & Sample Re-submit History: -- TEST REPORT No: (5215)078-0471(A) BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 3 of 22 Location of the test laboratory Radiated and Conducted emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. An Open Area Test Site and Full Anechoic Chamber (FCC Listed Site, Registration No. 642151) are set up for investigation and located at : BUREAU VERITAS HONG KONG LIMITED, EMC CENTRE No. 2106-2107, 21/F., Westin Centre, 26 Hung To Road, Kwun Tong, Kowloon, Hong Kong List of measuring equipment Radiated Emission EQUIPMENT MANUFACTURER MODEL NO. SERIAL NO. LAST CALIBRATION CALIBRATION DUE EMI TEST RECEIVER R&S ESCI 100379 21-JAN-2015 20-JAN-2016 SPECTRUM ANALYZER R&S R3127 111000909 27-MAR-2014 26-MAR-2015 LOOP ANTENNA ETS LINDGREN 6502 00102266 28-SEP-2014 27-SEP-2015 BILOG ANTENNA SCHAFFNER CBL6112D 2522…
