4+ #97 114 ROLLOVER RUMBLER INSTRUCTIONS 2.4GHz CONTENTS: - MULTI-FUNCTION RC VEHICLE - REMOTE CONTROL REMOTE CONTROL: X2 1.5V AA (LR6) ALKALINE BATTERIES REQUIRED NOT INCLUDED © MARVEL TM & ©2016 Manufactured by JAKKS Pacific, Inc., 2951 28th Street, Santa Monica, CA 90405 U.S.A. All other symbols, marks, logos, and designs (collectively “Trademarks”) are Trademarks of and proprietary to their respective owners and used under license. Contents may vary in style, color, shape and decoration from images shown on package or in advertising. PATENT PENDING Questions or comments? www.jakks.com, [email protected], or 1-877-875-2557 in North America. Retain packaging and instructions since they contain important information. ATTENTION! Remove and discard Packaging ties and fasteners before giving toy to child. MADE IN CHINA. BATTERY INSTALLATION 1 1 2 2 CONTROLS LEFT JOYSTICK: FORWARD / REVERSE RIGHT JOYSTICK: RIGHT / LEFT INDICATOR LIGHT OFF / ON SWITCH REMOTE CONTROL VEHICLE FRONT WHEELS BACK WHEELS 1 ® 2 CAUTION: ADULT SUPERVISION REQUIRED ALWAYS PLAY IN SAFE SURROUNDINGS, AWAY FROM STREETS OR MOVING VEHICLES. 234 VEHICLE: X8 1.5V AA (LR6) ALKALINE BATTERIES REQUIRED NOT INCLUDED ADULT INSTALLATION REQUIRED Requires 10 “AA” (LR6) alkaline batteries total: 4 in each side of the Vehicle and 2 in the Remote Control. Batteries not included. When performance diminishes, replace with fresh batteries. BOTTOM VIEW TOP VIEW TOP VIEW CAPTAIN AMERICA TOP VIEW IRON MAN BOTTOM VIEW REMOTE CONTROL 1. Locate and open BATTERY COVER as shown. Use a Phillips/cross head screwdriver (not included) to loosen screw. Screw remains attached to cover. 2. Install 2 - 1.5V AA (LR6) ALKALINE BATTERIES in the orientation shown. 3. Replace BATTERY COVER and tighten screw. VEHICLE 1. Locate and open BATTERY COVER(S) as shown. Use a Phillips/cross head screwdriver (not included) to loosen screw(s). Screw remains attached to cover. 2. Install 4 - 1.5V AA (LR6) ALKALINE BATTERIES in each battery compartment in the orientation shown. 3. Replace BATTERY COVER(S) and tighten screw(s). Note: Always replace all 8 batteries at the same time. OFF / ON SWITCH FORWARDBACKWARD RIGHT TURN MOVING FORWARD LEFT TURN MOVING FORWARD OPERATION OPERATION 1. VEHICLE: Move the OFF / ON SWITCH to the ON position. TOP VIEW 2. REMOTE CONTROL: Move the OFF / ON SWITCH to the ON position. The INDICATOR LIGHT will blink. When the unit is paired with the VEHICLE, the LIGHT will be solid. Note: If INDICATOR LIGHT keeps flashing for a long time, switch off both VEHICLE and REMOTE CONTROL and repeat the pairing process. Note: Pairing is required every time the VEHICLE/REMOTE CONTROL is turned on. 97114 Rollover Rumbler IS size: 16.5”W x 8.5”H x 2 Color: Grayscale BATTERY SAFETY INFORMATION WARNING! Battery acid leakage can cause personal injury and cause damage to the product and surrounding property. If battery leakage occurs, thoroughly wash any affected skin, making sure to keep battery acid away from eyes, ears, nose and mouth. Immediately wash any clothing or other surface that comes in contact with leaked battery acid. Leaking batteries may make "popping" sounds. Dispose according to Local, State or Federal Battery Laws. TO AVOID BATTERY PROBLEMS: NEVER mix old and new batteries or different brands of batteries. NEVER mix alkaline, standard (carbon-zinc), rechargeable (nickel-cadmium) batteries with this product. NEVER dispose of batteries in fire, as they may leak and explode. NEVER use rechargeable batteries. ALWAYS remove exhausted batteries from toy. ALWAYS have an adult install batteries consistent with installation instructions. ONLY use batteries specified by manufacturer. Batteries are to be inserted with the correct polarity. The supply terminals are not to be short-circuited. Non-rechargeable batteries are not to be recharged. OPERATION 3. Place the VEHICLE on ground and point the REMOTE CONTROL directly at the VEHICLE. The LEFT STICK operates the FORWARD/BACKWARD movement The RIGHT STICK operates the RIGHT and LEFT TURNS OPERATION ADVANCED MOVEMENT TROUBLESHOOTING PROBLEMPOSSIBLE CAUSESOLUTION Vehicle won’t move. Vehicle won’t flip. Remote Control is not close enough to Vehicle. Surface is too smooth. Make sure the Remote Control is placed within the signal receiving range. Vehicle and Remote Control does not paired (Remote Control indicator light blink). Power off Vehicle and Remote Control, then perform pairing process again. Move the Vehicle to a surface with more roughness and try again. Speed too slow. Make sure the Vehicle gains full speed before pressing left/right. Weak Vehicle batteries.Replace all 8 batteries in Vehicle. Weak vehicle batteries. Replace batteries. Vehicle / Remote Control switch is switched OFF. Weak Remote Control batteries. Move switch to ON position. Press any direction button. If indicator light does not activate, replace batteries in the Remote Control. Vehicle is stuck. Move vehicle to a smoother surface, clean tires, make sure surface or floor is clean as well. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur …
