OU3IBM39202.4 GHz DSS Digital Cordless Telephone

TABLE OF CONTENTS LIST APPLICANT: SONUS TELECOM, INC. FCC ID: OU3IBM3920 TEST REPORT: PAGE 1..........SECURITY CODING INFORMATION PAGE 2-3........TEST PROCEDURE AND TEST EQUIPMENT LIST PAGE 4-6........POWER LINE CONDUCTED INTERFERENCE PAGE 7-13.......OCCUPIED BANDWIDTH AND PEAK POWER OUTPUT PAGE 14.........RADIATED SPURIOUS EMISSIONS HANDSET PAGE 15.........RADIATED SPURIOUS EMISSIONS BASE PAGE 16-18......RADIATED SPURIOUS EMMISSIONS INTO ADJACENT RESTRICTED BAND PAGE 19-25.......SPECTRAL POWER DENSITY AND PROCESSING GAIN EXHIBITS: EXHIBIT 1........FCC ID LABEL SAMPLES EXHIBIT 2A.......SKETCH OF LABEL LOCATION - HANDSET EXHIBIT 2B.......SKETCH OF LABEL LOCATION BASE EXHIBIT 3A-C.....BLOCK DIAGRAMS EXHIBIT 4A-E.....SCHEMATICS EXHIBIT 5A.......EXTERNAL PHOTO – FRONT VIEW – BASE EXHIBIT 5B.......EXTERNAL PHOTO – BOTTOM VIEW – BASE EXHIBIT 5C.......EXTERNAL PHOTO – FRONT VIEW – HANDSET EXHIBIT 5D.......EXTERNAL PHOTO – REAR VIEW – HANDSET EXHIBIT 6A.......INTERNAL COMPONENT SIDE PHOTO - BASE EXHIBIT 6B.......INTERNAL SOLDER SIDE PHOTO - BASE EXHIBIT 6C.......INTERNAL COMPONENT SIDE PHOTO – HANDSET EXHIBIT 6D.......INTERNAL SOLDER SIDE PHOTO - HANDSET EXHIBIT 7A-B.....INSTRUCTION MANUAL EXHIBIT 8........CIRCUIT DESCRIPTION EXHIBIT 9........RADIATED TEST SET UP PHOTO - HANDSET EXHIBIT 10.......RADIATED TEST SET UP PHOTO - BASE EXHIBIT 11.......POWERLINE CONDUCTED TEST SET UP PHOTO – BASE EXHIBIT 12A-C....PROCESSING GAIN TEST DATA EXHIBIT 13A-B....SPECIFICATION SHEET APPLICANT: SONUS TELECOM, INC. FCCID: OU3IBM3920 DATE: APRIL 18, 2001 REPORT #: S\SONUS\244AK1\244AK1RPT.DOC APPLICANT: SONUS TELECOM, INC. FCC ID: OU3IBM3920 15.214(d) THIS DEVICE COMPLIES WITH THE SECURITY CODE REQUIREMENTS OF 15.214(d)(1)(2) AND (3) BY MEANS OF THE FOLLOWING: THIS DEVICE HAS 65536 POSSIBLE SECURITY CODES. ONE SECURITY CODE OUT OF 65536 IS PRE-PROGRAMMED WHEN MANUFACTURED AT THE FACTORY. THE CPU CONTROLS THE RF FREQUENCY CHANNEL. AND THE ASIC CONTROLS ADPCM CODEC AND AUDIO SIGNAL SWITCHING ALSO SET UP THE SPREADING CODE. BEFORE THE COMMUNICATION LINK IS ESTABLISHED, THE DEVICE SEARCHES FOR A VACANT RF CHANNEL AND THEN TRANSMITS RF SIGNAL ON THE VACANT CHANNEL. APPLICANT: SONUS TELECOM, INC. FCCID: OU3IBM3920 DATE: APRIL 18, 2001 REPORT #: S\SONUS\244AK1\244AK1RPT.DOC PAGE #: 1 APPLICANT: SONUS TELECOM, INC. FCCID : OU3IBM3920 TEST EQUIPMENT LIST 1._X_Spectrum Analyzer: HP 8566B-Opt 462, S/N 3138A07786, w/ preselector HP 85685A, S/N 3221A01400, Quasi-Peak Adapter HP 8565OA, S/N 3303A01690 & Preamplifier HP 8449B-OPT H02, S/N 3008A00372 2._X_Biconnical Antenna: Eaton Model 94455-1, S/N 1057 3.___Biconnical Antenna: Electro-Metrics Model BIA-25, S/N 1171 4._X_Log-Periodic Antenna: Electro-Metrics Model EM-6950, S/N 632 5.___Log-Periodic Antenna: Electro-Metrics Model LPA-30, S/N 409 6._X_Double-Ridged Horn Antenna: Electro-Metrics Model RGA-180, 1-18 GHz, S/N 2319 7.___18-26.3GHz Systron Donner Standard Gain Horn #DBE-520-20 8.___Horn 40-60GHz: ATM Part #19-443-6R 9._X_Line Impedance Stabilization Network: Electro-Metrics Model ANS-25/2, S/N 2604 10.___Temperature Chamber: Tenney Engineering Model TTRC, S/N 11717-7 11.___Frequency Counter: HP Model 5385A, S/N 3242A07460 12.___Peak Power Meter: HP Model 8900C, S/N 2131A00545 13._X_Open Area Test Site #1-3meters 14.___Signal Generator: HP 8640B, S/N 2308A21464 15.___Signal Generator: HP 8614A, S/N 2015A07428 16.___Passive Loop Antenna: EMCO Model 6512, 9KHz to 30MHz, S/N 9706-1211 17.___Dipole Antenna Kit: Electro-Metrics Model TDA-30/1-4, S/N 152 and 153 18.___AC Voltmeter: HP Model 400FL, S/N 2213A14499 19.___Digital Multimeter: Fluke Model 8012A, S/N 4810047 20.___Digital Multimeter: Fluke Model 77, S/N 43850817 21.___Oscilloscope: Tektronix Model 2230, S/N 300572 FCC ID : OU3IBM3920 DATE: APRIL 18, 2001 REPORT #: S\SONUS\244AK1\244AK1RPT.DOC PAGE # : 2 TEST PROCEDURES GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. Shielded interface cables were used in all cases except for cables connecting to the telephone line and the power cords. A test program was run which simulated a normal data transmission on a network. POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STAN- DARD C63.4-1992 using a 50uH LISN. Both lines were observed. The bandwidth of the spectrum analyzer was 10kHz with an appropriate sweep speed. The ambient temperature of the UUT was 83°F with a humidity of 19%. BANDWIDTH 6.0dB: The measurements were made with the spectrum analyz- er's resolution bandwidth(RBW)=100kHz and the video bandwidth(VBW) =300KHz and the span set as shown on plot. See pages 8-13. POWER OUTPUT: The RF power output was measured at the antenna feed point by removing the permanent antenna and connecting the UUT to a peak power meter, HP Model No. 8900C. ANTENNA CONDUCTED EMISSIONS: The RBW=100kHz, VBW > or = RBW and the spectrum was scanned from 30MHz to the 10th Harmonic of the fundamental. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth(RBW) of the spectrum analyzer was 100kHz up to 1GHz and 1.0MHz above 1GHz with an appropriate sweep speed. The VBW above 1.0GHz was = 1.0MHz. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The ambient temperature of the UUT was 83°F with a humidity of 19%. 15.247(d) POWER SPECTRAL DENSITY. The peak within the pass band was located with a RBW set to 30Khz and a span of 5MHz, slightly greater than the 6dB bandwidth, then the emission was centered on the display and the span and RBW reduced. A 1.5MHz span, 3Khz RBW, and a sweep time to sweep time set to 500 seconds. Since spectral line spacing could not be resolved, the noise power density method was used. The reponse was then plotted, a correction factor of measured using the noise power density and adding the correction of 35dB and any attenuation used was added. See pages 20-25. 1…
