OV4RT910Wireless Temperature Monitor

Instruction Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example - use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID label location Side : 2mm x 6mm 2mm x 9mm Note: The device of Wireless Temperature Monitor is too small to put FCC Part 15 description so we put it in the user’s manual.

1111 Report NO. : RF89052212Page. 1/21 Issue Date : June 8, 2000 FCC ID: OV4RT910 REPORT NO:RF89052212 PRODUCT:Wireless Temperature Monitor Transmitter MODEL NO:RT-910 SERIAL NO:N/A CLIENT:FUNAI Radio & Communications Corp. ADDRESS:3F, No. 24, Chien Kou RD. T.E.P.Z., Tantzu, Taichung Taiwan, R.O.C. ISSUED BY:ADVANCE DATA TECHNOLOGY CORPORATION (ADT CORP.) OFFICE ADDRESS:11F, NO. 1, SEC. 4, NAN-KING EAST RD., TAIPEI, TAIWAN, R.O.C. LABORATORY ADDRESS:NO. 47, 14 LING, CHIA PAU TSUEN, LIN KOU HSIANG, TAIPEI HSIEN, TAIWAN, R.O.C. TEST STANDARD:47CFR Part 15, Subpart C (15.231) TEST DATE:June 3, 2000 TEST RESULT:Pass This test report consists of 21 pages in total. This test report is the property of ADT Corp. and shall not be reproduced, except in full without the written consent of ADT. ADT hereby returns all rights in data to the client for legal use by the client. The test results contained in this report apply only to the samples tested. Accredited Laboratory 2222 Report NO. : RF89052212Page. 2/21 Issue Date : June 8, 2000 FCC ID: OV4RT910 CONTENTS 1. CERTIFICATION.................................................................................................3 2. SUMMARY OF TEST RESULTS & GENERAL STATEMENT OF CERTIFICATION..4 3. GENERAL INFORMATION...................................................................................5 3.1General Description of EUT..................................................................................5 3.2Specification:.........................................................................................................5 3.2 Description of Test mode.........................................................................................6 3.3 Test Methodology....................................................................................................6 3.4 Support Units List....................................................................................................6 3.5 Configuration of System Under Test.......................................................................6 4. GENERAL INFORMATION OF TEST FACILITY................................................................7 4.1 Test Lab.:.................................................................................................................7 4.2 Calibration Interval :................................................................................................7 5. TEST PROCEDURES AND TEST RESULTS........................................................8 5.1 Conducted Emission Measurement..........................................................................8 5.2 Radiated Emission Measurement.............................................................................9 5.2.1 Test instruments....................................................................................................9 5.2.2 Test Procedure.....................................................................................................10 5.2.3 Test Setup............................................................................................................10 5.2.4 Photograph of Test Setup....................................................................................11 5.2.5 EUT Operating condition....................................................................................12 5.2.6 Climate Condition...............................................................................................12 5.2.7 Test Results.........................................................................................................13 6.20 dB Bandwidth Measurement.................................................................15 6.1 Test Instruments..............................................................................................15 6.2 Test Procedure..................................................................................................15 6.3Test Setup.........................................................................................................15 6.4EUT Operating condition.................................................................................16 6.5Climate Condition............................................................................................16 6.6Test Results......................................................................................................16 7.EUT Photos.............................................................................................18 3333 Report NO. : RF89052212Page. 3/21 Issue Date : June 8, 2000 FCC ID: OV4RT910 1. CERTIFICATION Issue Date: June 8, 2000 PRODUCT:Wireless Temperature Monitor Transmitter MODEL NO: RT-910 FCC ID: OV4RT910 CLIENT:FUNAI Radio & Communications Corp. TEST STANDARD:FCC 47CFR Part 15, Subpart C (Section 15.231) ANSI C63.4-1992 We, ADVANCE DATA TECHNOLOGY CORPORATION, hereby certify that one sample of the designated sample has been tested in our facility. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate representation of the measurements of the sample's EMC characteristics and the energy emitted under the conditions herein specified. 4444 Report NO. : RF89052212Page. 4/21 Issue Date : June 8, 2000 FCC ID: OV4RT910 2. SUMMARY OF TEST RESULTS & GENERAL STATEMENT OF CERTIFICATION The EUT has been tested according to the following specifications: 47 CFR Part 15, Subpart C PARAGRAPH . TEST REQUIREMENTS COMPLIANC E (YES/NO) TEST RESULT 15.107, 15.109 AC Power Conducted Emissions Spec.: 48 dBuV N/AN/A 15.231( c)20dB BandwidthYes311.11kHz < 1084.80kHz 15.231(e)Transmitter Radiated EmissionsYes Minimum passing margin is –5.0 dBuV at 867.81 MHz Note 1 : The digital circuits and receiver portion of the EUT has been tested and verified to comply with FCC Part 15, Subpart B, Class B – Computing Devices (FCC DoC). The engineering test report can be provided upon FCC requests. 5555 Report NO. : RF89052212Page. 5/21 Issue Dat…
