OWJ9312503Radio Control Car

INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. F C C - TEST REPORT REPORT NO.: 21190/9/400F Units 602-605, 6/F., 31 Lok Yip Road, On Lok Tsuen, Fanling, N.T., Hong Kong Tel: [852] 2305-2570 Fax: [852] 2756-4480 INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 2 of 2 FCC listed testlab acc. to Section 2.948 of the FCC - Rules in compliance with the requirements of ANSI C63.4 - 1992 Product: Radio Control Car -- 49 MHz Transmitter Model: R/C 9719 Applicant: HIP CHONG TOYS MANUFACTURERS LIMITED Manufacturer : HIP CHONG TOYS MANUFACTURERS LIMITED INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 3 of 3 TABLE OF CONTENTS 1. Cover sheet 2. Introduction 3. Table of Contents 4. Laboratory Report 5. Summary of Testresults 6. Test Equipment List 7. Radiated Emission Testprocedure 8. Interference Radiation (Datasheet) 9. Notes for Radiation Measurement (acc. to ANSI C63.4 - 1992) 10. Measurement of Emissions within Band Edges (Datasheet) 11. Notes for Measurement of Emissions within Band Edges INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 4 of 4 LABORATORY - REPORT APPLICANT: ADDRESS: HIP CHONG TOYS MANUFACTURERS LIMITED Room 801, 8/F., Lippo Sun Plaza No.28 Canton Road Tsimshatsui, Kowloon HONG KONG DATE OF SAMPLE RECEIVED:1999-11-26 DATE OF TESTING:2000-01-03 DESCRIPTION OF SAMPLE: Product:Radio Control Car -- 49 MHz Transmitter Manufacturer:HIP CHONG TOYS MANUFACTURERS LIMITED Model number:R/C 9719 Rating:DC 9V ('6F22' Size Battery x 1) Country of Origin:P.R. CHINA INVESTIGATIONS REQUESTED: Measurements to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart C - Intentional Radiators RESULTS:See the attached test sheets CONCLUSIONSFrom the measurement data obtained, the tested sample was considered to have COMPLIED with the requirements for the relevant clauses of Federal Communications Commission Rules as specified above. _____________________________ Authorized Signature Remark: Purpose of those tests in this report is to provide the applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under the FCC Equipment Authorization Program. The tests themselves are not Approval Tests INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 5 of 5 Summary of Test Results Interference Radiation: Test result:O.K. Test data:See attached data sheet Interference Voltage: Test result:N.A. Test data:N.A. Measurement of Emissions within Band Edges Test result:O.K. Test data:See attached data sheet INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 6 of 6 TEST EQUIPMENT LIST EquipmentManufacturerModelSerial No.Remark Test ReceiverRohde & Schwarz ESH 3863497/01510KHz – 30MHz Test ReceiverRohde & Schwarz ESVP860688/02225MHz – 1,300 MHz Artificial Mains Network (LISN) SchwarzbeckNSLK 8127--2 x 10A, 50Ω, 50μH 10KHz-30MHz Antenna SystemSchwarzbeckBBA 9106 / UHALP 9107 --30MHz – 1000MHz Antenna Mast System SchwarzbeckAM9104--Max. 4 meters height Spectrum Analyzer with Q. Peak Tektronix2712B0230069KHz – 1.8GHz Interface for Spectrum 2712 TektronixTD3F14A-- Test ReceiverRohde & Schwarz ESH 3892580/00610KHz – 30MHz Test ReceiverRohde & Schwarz ESVP863512/01225MHz – 1,300 MHz Impulse LimiterRohde & Schwarz ESH-3-Z2-- Artificial Mains Network (LISN) SchwarzbeckNSLK 8127--2 x 10A, 50Ω, 50μH 10KHz-30MHz Antenna SystemSchwarzbeckBBA 9106 / UHALP 9107 --30MHz – 1000MHz Signal GeneratorRohde & Schwarz SWS 2879113/42100KHz – 1040 MHz Digital MultimeterTektronixDM2510GDM- 2510GTW10555 10KHz – 30MHz Turntable with Controller DrehtischDT312-- φ120 cm INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 7 of 7 Radiated Emission Test Procedure Equipment under test (on turntable) Test receiver ESVP R & S Required test distance: 3m Antenna system Schwarzbeck BBA 9106/ UHALP 9107 91Interference Radiation Measurement of Radiated Emissions (30MHz-1000MHz) International Electrical Certification Centre Ltd. Acc:FCC Part 15 Subpart C IECC Ref:21190/9/400FTest Equipment Model:R/C 9719Receiver: ESVP Rohde & Schwarz Applicant:HIP CHONG TOYS MANUFACTURERS Antenna: Schwarzbeck BBA 9106 LIMITED and UHALP 9107 Ser.Nr.:1 Set under test:Radio Control Car Connected sets: - Operating mode:Motor test with forward mode Frequency (MHz) Horz. Reading dB(μV) Vert. Reading dB(μV) Antenna Factor (dB) Horiz. Test Result (μV/m) Vert. Test Result (μV/m) Limit (μV/m) Peak49.8661677.0 25255037 100,000 Av.49.8659.565.57.02124423810000 Harm.299.722530.58.54890150 Harm.3149.58191813.04035150 Harm.4199.44171615.14036150 Harm.5249.321.51816.78154200 Harm.6299.16<16<1618.0<50<50200 Harm.7349.02<16<1617.4<47<47200 Harm.8398.88<16<1618.3<52<52200 Harm.9448.74<16<1619.0<56<56200 Harm.10498.6<16<1619.7<61<61200 Harm.11548.46<16<1620.2<64<64200 Harm.12598.32<16<1620.9<70<70200 Harm.13648.18<16<1621.6<76<76200 Harm.14698.04<16<1622.4<83<83200 Harm.15747.9<16<1623.0<90<90200 Harm.16797.76<16<1623.7<96<96200 Harm.17847.62<16<1624.3<104<104200 Harm.18897.48<16<1625.0<112<112200 Harm.19947.34<16<1625.7<122<122200 0 20 40 60 80 100 120 101001000 MHz dBμV/m Data (Horz.)Data (Vert.)Limit Test result: ̋ O.K. Ž Not O.K. Date: _______________ Operator: _______________ INTERNATIONAL ELECTRICAL CERTIFICATION CENTRE LTD. FCC – Test Report No. 21190/9/400F Date: 2000-01-03 Page 9 of 9 Notes for Radiation Measurement 1. Measurement facility: Measurement facility located at Fanling (Hong Kong), placed on file with the FCC Pursuant to Section 2.948 of the FCC Rules. 2. Distance between the EUT and measuring antenna: 3 meters. 3. Measuring instrumentations: Rohde & Schwarz ESVP Test Receiver ( 20 - 1300 MHz ) with a CISPR weighting QP detector, 6 dB bandwidth set at …
